VENT-FREE FREESTANDING PEDESTAL STOVE SYSTEM
OWNER'S OPERATION AND INSTALLATION MANUAL
THERMOSTATICALLY - CONTROLLED MODELS
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's in-
structions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency, or the gas supplier.
For more information, visit www.desatech.com
CS26PT AND CS26NT
20,000 TO 26,000 BTU/HR
Save this manual for future reference.
Advertisement
Table of Contents
Related Manuals for Comfort Glow CS26NT
Summary of Contents for Comfort Glow CS26NT
- Page 1 VENT-FREE FREESTANDING PEDESTAL STOVE SYSTEM OWNER’S OPERATION AND INSTALLATION MANUAL THERMOSTATICALLY - CONTROLLED MODELS CS26PT AND CS26NT 20,000 TO 26,000 BTU/HR WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
-
Page 2: Table Of Contents
WARNING: Improper installation, adjustment, altera- tion, service, or maintenance can cause injury or prop- erty damage. Refer to this manual for correct installation and operational procedures. For assistance or addi- tional information consult a qualified installer, service agency, or the gas supplier. WARNING: This is an unvented gas-fired heater. -
Page 3: Safety Information
SAFETY INFORMATION WARNING: Do not use a blower insert, heat exchanger WARNING: This product con- insert, or other accessory not tains and/or generates chemicals approved for use with this known to the state of California heater. to cause cancer or birth defects, or other reproductive harm. -
Page 4: Product Identification
12. Keep all air openings in front and bottom of SAFETY INFORMATION heater clear and free of debris. This will in- Continued sure enough air for proper combustion. 1. This appliance is only for use with the type of 13. Do not run heater gas indicated on the rating plate. -
Page 5: Local Codes
LOCAL CODES AIR FOR COMBUSTION AND VENTILATION Install and use heater with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code, ANSI WARNING: This heater shall Z223.1/NFPA 54*. not be installed in a confined space *Available from: or unusually tight construction... - Page 6 Determine the volume of the space (length x AIR FOR COMBUSTION width x height). AND VENTILATION Length x Width x Height =__________cu. ft. Continued (volume of space) Unusually tight construction is defined as Example: Space size 20 ft. (length) x 16 ft. construction where: (width) x 8 ft.
-
Page 7: Installation
Ventilation Air From Outdoors AIR FOR COMBUSTION Provide extra fresh air by using ventilation grills AND VENTILATION or ducts. You must provide two permanent open- Continued ings: one within 12" of the ceiling and one within 12" of the floor. Connect these items directly to If the actual Btu/Hr used is less than the maximum the outdoors or spaces open to the outdoors. - Page 8 Carefully follow the instructions below. This stove INSTALLATION is a freestanding unit designed to set directly on Continued the floor. IMPORTANT: You must maintain mini- mum wall and ceiling clearances during installa- WARNING: Never install the tion. The minimum clearances are shown in Fig- heater ure 4.
- Page 9 INSTALLATION CAUTION: Use only new, black Continued iron or steel pipe. Internally-tinned CONNECTING TO GAS SUPPLY copper tubing may be used in certain areas. Check your local WARNING: A qualified ser- codes. Use pipe of 1/2" diameter vice person must connect heater or greater to allow proper gas to gas supply.
- Page 10 CHECKING GAS CONNECTIONS INSTALLATION Continued WARNING: Test all gas pip- ing and connections, internal WARNING: Use pipe joint and external to unit, for leaks sealant that is resistant to liquid after installing or servicing. Cor- petroleum (LP) gas. rect all leaks at once. We recommend that you install a sediment trap in supply line as shown in Figure 7.
- Page 11 INSTALLATION Equipment Shutoff Valve Continued 2. Pressurize supply piping system by either opening propane/LP supply tank valve for Gas Meter propane/LP gas, opening main gas valve lo- cated on or near gas meter for natural gas, or using compressed air. 3.
- Page 12 INSTALLATION Continued IMPORTANT: Make sure log does not cover any burner ports (see Figure 12). One Piece Burner Ports Log Set Figure 13 - Removing Stove Top Panel Figure 12 - Installing One-Piece Log set (Top View) Black Powercord Wire White INSTALLING BLOWER ACCESSORY Powercord...
- Page 13 INSTALLATION Power Cord Continued 10. Using four screws from hardware bag, mount blower assembly to stove by attaching blower brackets to stove top panel (see Fig- ure 16, page 12). Tighten screws securely. 11. Working from the inside of the stove, insert shaft of speed control housing into hole on right side of stove next to the control knob/ piezo ignitor (see Figure 17).
-
Page 14: Operating Heater
OPERATING HEATER 3. Turn control knob clockwise to the OFF position. FOR YOUR SAFETY 4. Wait five (5) minutes to clear out any gas. READ BEFORE LIGHTING Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the WARNING: If you do not fol- safety information, column 1. -
Page 15: Inspecting Burners
OPERATING HEATER rect pilot flame is not touching the thermocouple. Continued This will cause the thermocouple to cool. When the thermocouple cools, the heater will shut down. Ignitor Electrode If pilot flame pattern is incorrect, as shown in Fig- Thermocouple Pilot Burner ure 21 •... -
Page 16: Cleaning And Maintenance
3. Blow air through the ports/slots and holes in CLEANING AND the burner. MAINTENANCE 4. Check the injector holder located at the end of the burner tube again. Remove any large WARNING: Turn off heater particles of dust, dirt, lint, or pet hair with a and let cool before cleaning. -
Page 17: Service Hints
Some burner flame holes may become blocked by debris or rust, with no flame present. If so, turn off heater and let cool. Remove blockage. Blocked burner flame holes will create soot. SPECIFICATIONS CS26PT CS26NT Btu (Variable) 20,000/26,000 20,000/26,000 Type Gas Propane/LP Natural... -
Page 18: Troubleshooting
TROUBLESHOOTING Note: All troubleshooting items are listed in order of operation. WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle, or similar object to clean ODS/pilot. - Page 19 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot lights but flame goes 1. Control knob not fully pressed in 1. Press in control knob fully out when control knob is re- 2. Control knob not pressed in 2. After ODS/pilot lights, keep con- leased long enough trol knob pressed in 30 seconds...
- Page 20 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Heater produces a whistling 1. Turning control knob to HI po- 1. Turn control knob to LO po- noise when burner is lit sition when burner is cold sition and let warm up for a minute 2.
-
Page 21: Shut Off Gas Supply
TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. -
Page 22: Illustrated Parts Breakdown And Parts List
ILLUSTRATED PARTS BREAKDOWN MODELS CS26PT AND CS26NT (Shown) 113066-01A www.desatech.com... -
Page 23: Parts List
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 26 of this manual. PART NUMBER CS26PT CS26NT DESCRIPTION QTY. 113067-01 113067-01 Log Set 104286-01 104285-01 ODS Pilot... - Page 24 ILLUSTRATED PARTS BREAKDOWN MODELS CS26PT AND CS26NT See Page 22 113066-01A www.desatech.com...
- Page 25 PARTS LIST MODELS CS26PT AND CS26NT This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 26 of this manual. PART NO. DESCRIPTION QTY. 112983-01CX Stove Pedestal 112984-01CX Left and Right Stove Sides...
-
Page 26: Replacement Parts
REPLACEMENT PARTS ACCESSORIES Note: Use only original replacement parts. This Purchase these heater accessories from your local will protect your warranty coverage for parts re- dealer or Parts Central (see page 27). If they can- placed under warranty. not supply these accessories call DESA Heating Products’... -
Page 27: Parts Central
PARTS CENTRAL These Parts Centrals are privately owned businesses. They have agreed to support our customer’s needs by providing original replacement parts and accessories. Tool & Equipment Company Washer Equipment Co. 1348 Dixwell Avenue 1715 Main Street Hamden, CT 06514-0322 Kansas City, MO 64108-2195 1-800-397-7553 KS, MO, AR... -
Page 28: Warranty Information
WARRANTY INFORMATION KEEP THIS WARRANTY Model Serial No. Date Purchased Always specify model and serial numbers when communicating with the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty.
