OWNER'S OPERATION AND INSTALLATION MANUAL
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance
CONSUMER: Retain this manual for future reference.
For more information, visit www.fmiproducts.com
DIRECT-VENT FIREPLACE
NATURAL GAS
CHDV32NR
PFS
®
US
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comfort Glow CHDV32NR
Summary of Contents for Comfort Glow CHDV32NR
- Page 1 DIRECT-VENT FIREPLACE OWNER’S OPERATION AND INSTALLATION MANUAL ® NATURAL GAS CHDV32NR WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
TAbLE OF CONTENTS Safety ..............2 Cleaning and Maintenance ........ 30 Local Codes............4 Troubleshooting ..........32 Product Identification ........... 4 Replacement Parts ..........36 Product Features ..........4 Service Hints ............. 36 Pre-Installation Preparation ......... 5 Technical Service..........36 Location of Termination Cap ........ -
Page 3: Safety
SAFETy Continued a coaxial pipe (pipe within a pipe and having WARNING: Do not allow fans the same center) venting system. It brings in to blow directly into the fireplace. fresh air for combustion through the outer pipe and combustion gases are exhausted through Avoid any drafts that alter burner the inner pipe. -
Page 4: Local Codes
SAFETy LOCAL CODES Continued Install and use fireplace with care. Follow all local codes. In the absence to local codes, 2. If you smell gas use the current National Fuel Gas Code ANSI • shut off gas supply Z223.1/NFPA 54* (USA). •... -
Page 5: Pre-Installation Preparation
PRODUCT FEATURES • Your fireplace is designed to be used in zero clearance installations. Wall or framing Continued material can be placed directly against any • This fireplace does not require electricity exterior surface on the back, sides or top of to operate. - Page 6 PRE-INSTALLATION PREPARATION Continued CLEARANCES Minimum clearances to combustibles for the fireplace are as follows: *Back and sides 0" " Perpendicular walls 6" Floor 0" Ceiling to louver opening 42" " 19" Front 36" Top of Standoffs 0" Figure 4 - Framing Clearances for Vent (See venting instructions for Installation Against an Exterior Wall...
-
Page 7: Location Of Termination Cap
LOCATION OF TERMINATION CAP Fixed Openable Fixed Closed Closed Openable TERMINATION CAP GAS METER RESTRICTED AREA AIR SUPPLY INLET (TERMINATION PROHIBITED) A = clearance above grade, veranda, porch, deck, or I = clearance to service regulator vent outlet [*72" (182.9 cm) minimum] balcony [*12"... -
Page 8: Venting Installation
VENTING INSTALLATION NOTICE: Failure to follow these in- NOTICE: Read these instruc- structions will void the warranty. tions completely before attempt- ing installation. NOTICE: Do not seal termination These models are tested and approved for cap to vent pipe. Cap must be use with FMI PRODUCTS, LLC (direct-vent) removable for vent inspection pipe components and terminations. -
Page 9: Venting Installation
VENTING INSTALLATION 5. Carefully determine the location where vent pipe assembly will penetrate outside Continued wall. The center of hole should line up with INSTALLATION pLANNING center line of horizontal vent pipe. Mark wall for a 10" x 10" square hole. Cut and There are two basic types of direct-vent frame square hole in exterior wall where installation:... - Page 10 VENTING INSTALLATION Continued Apply Mastic to All Four Sides WARNING: Do not recess vent termination into any wall. Vent Cap This will cause a fire hazard. 6. Noncombustible Exterior Wall: Posi- tion horizontal vent cap in the center of 7 "...
- Page 11 VENTING INSTALLATION GROUND FLOOR INSTALLATION Recommended Applications: Continued • Installation using cabinet surrounds Minimum Pipe • Through the wall using round or square Siding Standoff Overlap 1 " termination (up to 12" horizontal pipe) • NOT FOR CORNER INSTALLATION Direct-Vent Pipe Screws Adjustable...
- Page 12 VENTING INSTALLATION Continued CORNER AND ALTERNATE INSTALLATION Not to Exceed (H) Limits Recommended Applications: Square Termination • Corner ground floor installation 90° Elbow • Ground floor installation where pipe vents hori- zontally through wall (over 12" horizontal pipe) • Basement installation where one foot clear- ance from ground to termination is possible Wall 90°...
- Page 13 VENTING INSTALLATION Continued HORIZONTAL SYSTEM INSTALLATION USING TWO 90° ELBOWS The following configurations show the minimum vertical rise requirements for a horizontal sys- tem using two 90° elbows. 45° Elbow Venting with Two 90° Elbows Horizontal (H Vertical (V) Horizontal (H Horizontal (H 5' min.
-
Page 14: Installation For Vertical Termination
VENTING INSTALLATION Continued INSTALLATION FOR VERTICAL Flat Ceiling Installation 1. Cut a 10" square hole in the ceiling using TERMINATION the locating hole as a center point. The Note: Vertical restrictor must be installed in opening should be framed to 10" x 10" all vertical installations. -
Page 15: Venting Installation Instructions
VENTING INSTALLATION INSTRUCTIONS Continued Note: If an offset is needed to avoid Note: You must increase vent height for obstructions, you must support the vent steep roof pitches. Nearby trees, adjoining pipe every 3 feet. Use wall straps for this rooflines, steep pitched roofs and other purpose (see Figure 19, page 14). - Page 16 VENTING INSTALLATION Continued Note: Install restrictor into inner collar of Vertical Venting fireplace as V = 40' max. shown. Note: Install restrictor into inner collar of fireplace as 45° Elbow shown. 45° Elbow Venting with Two 90° Elbows Vertical (V Horizontal (H) 5' min.
- Page 17 VENTING INSTALLATION Continued PARTS LIST FOR VENTING KITS AND COMpONENTS Number Description FMI PRODUCTS, LLC Pipe & Vent Kits Horizontal Round Termination Kit Number Description (Includes: Round Termination, P47-6 6" Section Coaxial Pipe, Wall Firestop and 45° Elbow) Galvanized HTKS-47 Horizontal Square Termination Kit P47-12 12"...
-
Page 18: Fireplace Installation
(see Accessories, page 36). A conversion tel, determine whether power cord will kit is supplied with the CHDV32NR. exit left side or right side of firebox. INSTALLING OPTIONAL BLOWER Route power cord through exit hole... - Page 19 FIREPLACE 4. Be certain that all wire terminals are securely attached to terminals on blower INSTALLATION motor and thermal switch, and that screw Continued for thermodisc bracket and green ground wire is tight. 9. Check to make sure power cord is com- 5.
- Page 20 FIREPLACE Installation Items Needed Before installing fireplace, make sure you have INSTALLATION the items listed below. Continued • external regulator (supplied by installer) • piping (check local codes) 11. Peel off backing paper and stick supplied • sealant (resistant to propane/LP gas) wiring diagram decal on firebox bottom •...
- Page 21 FIREPLACE CONNECTING FIREpLACE TO GAS SUppLY INSTALLATION Continued Installation Items Needed • 5/16" hex socket wrench or nut-driver Installation must include an equipment shutoff • sealant (resistant to propane/LP gas, not valve, union, and plugged 1/8" NPT tap. Lo- provided) cate NPT tap within reach for test gauge hook 1.
- Page 22 FIREPLACE INSTALLATION Continued pRESSURE TESTING GAS SUppLY Equipment Shutoff Valve pIpING SYSTEM Propane/LP Supply Tank Test Pressures In Excess Of 1/2 PSIG (3.5 kPa) 1. Disconnect fireplace and its individual equipment shutoff valve from gas supply piping system. Pressures in excess of 1/2 psig (3.5 kPa) will damage fireplace gas regulator.
- Page 23 FIREPLACE INSTALLATION Continued INSTALLING OpTIONAL WALL MOUNT SWITCH - GWMS2 1. Connect one terminal of 25 ft. wire for wall switch to TPTH terminal on the valve. Connect remaining wire terminal to the TH terminal on the valve. Make sure wire ter- minals are in positions on unit as pictured in Figure 36.
- Page 24 FIREPLACE Removing Glass Door If replacement of glass is necessary, the entire INSTALLATION assembly, glass and frame, must be replaced. Continued If glass is broken, wear gloves and tape the remaining fragments onto the frame. REMOVING/REPLACING GLASS 1. Remove screen assembly by pushing the DOOR rod either left or right and then down and forward to remove screen/rod assembly...
-
Page 25: Brick Panels
FIREPLACE 7. Install the right brick panel using the same method described INSTALLATION 8. Replace deflector shield using screws Continued removed in step 4. INSTALLING OPTIONAL BRICK 9. Install logs, lava rock, and ember material see Installing Logs, Lava Rock and Glow- LINER MODEL BL32D ing Embers. - Page 26 FIREPLACE 9. Close glass door, lock door latches, replace screen and close louvers (see Removing/ INSTALLATION Replacing Glass Door, steps 5 through 7, Continued page 24). 6. Place log #6 (left log) onto two pins on left WARNING: The glass door must side of back and front log.
- Page 27 FIREPLACE INSTALLATION Continued PERIMETER TRIM KIT (PROVIDED) 1. Remove packaging from three pieces of 6. While firmly holding edges of trim together, trim. tighten both screws on the adjusting plate using a slotted screwdriver. 2. Locate the two adjusting plates with set screws and two shims in the hardware 7.
-
Page 28: Operation
OPERATION 4. Push in gas control knob slightly and turn clockwise to OFF. FOR YOUR SAFETY 5. Wait five (5) minutes to clear out any gas. READ BEFORE LIGHTING Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” WARNING: If you do not fol- in the safety information in column 1. - Page 29 OPERATION IMPORTANT: Do not leave the selector switch in the REMOTE or ON position when the pilot Continued is not lit. This will drain the battery. MANUAL LIGHTING ON/OFF SERIES pROCEDURE (MODELS HRC100 AND HRC101) 1. Remove glass door (see Removing/Re- Hold the control button on the hand-held placing Glass Door, page 24).
- Page 30 OPERATION OpERATING OpTIONAL GWMT1 WALL MOUNTED Continued THERMOSTAT Note: Do not leave the hand-held remote in the AUTO mode close to the fireplace. The radiant WARNING: Do not con- heat from the fireplace will turn off the fireplace. nect the thermostat to a power Ideally, place the hand-held remote in the center source.
-
Page 31: Inspecting Burners
INSPECTING bURNERS CLEANING AND MAINTENANCE Check pilot flame pattern and burner flame patterns often. WARNING: Turn off fireplace PILOT ASSEMBLY and let cool before cleaning. The pilot assembly is factory preset for the proper flame height. Alterations may have occurred dur- ing shipping and handling. - Page 32 CLEANING AND LOGS • If you remove logs for cleaning, refer to MAINTENANCE Installing Logs, Lava Rock, and Glowing Continued Embers, page 25, to properly replace logs. WARNING: Only parts sup- • Use a vacuum cleaner to remove any plied by the manufacturer should carbon buildup on logs.
-
Page 33: Troubleshooting
TROUbLESHOOTING WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle, or similar object to clean pilot. This can damage pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY... - Page 34 TROUbLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Pilot lights but flame goes 1. Gas control knob not fully 1. Press in gas control knob out when control knob is pressed in fully released 2. G a s c o n t r o l k n o b n o t 2.
- Page 35 TROUbLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Heater produces a whistling 1. Turning gas control knob to 1. Turn gas control knob to LO noise when burner is lit HI position when burner is position and let warm up for cold a minute 2.
- Page 36 TROUbLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 37: Replacement Parts
REPLACEMENT PARTS SPECIFICATIONS Note: Use only original replacement parts. CHDV32NR This will protect your warranty coverage for • Rating: 12,000/18,000 Btu/Hr parts replaced under warranty. • Gas Type: Natural pARTS UNDER WARRANTY • Ignition: Piezo Contact authorized dealers of this product. - Page 38 ACCESSORIES Continued FACE/LOUVER PANEL KIT WALL MOUNTED THERMOSTAT RLD32 - Rolled Louver, Black CONTROL KIT - GWMT1 Allows easy wall access for thermostatic ROLLED LOUVER TRIM KIT operation of your fireplace. LT32B - Brushed Brass WALL MOUNTED ON/OFF SWITCH LT32P - Platinum GWMS2 DEFLECTION HOOD Allows burner system to be turned on and off...
-
Page 39: Parts
PARTS MODEL CHDV32NR 22-3 22-5 22-4 22-6 22-2 22-1 111986-01G www.fmiproducts.com... - Page 40 PARTS MODEL CHDV32NR This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 37 of this manual. NO. PART NO. DESCRIpTION QTY. Firebox Assembly Face Weldment 108892-01 Door Assembly...
- Page 41 PARTS BURNER ASSEMBLY MODEL CHDV32NR 111986-01G www.fmiproducts.com...
- Page 42 PARTS BURNER ASSEMBLY MODEL CHDV32NR This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 37 of this manual. NO. PART NO. DESCRIpTION QTY. 11102 Screw #8-32 x 3/8 PPH Zinc...
- Page 43 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 111986-01G www.fmiproducts.com...
-
Page 44: Warranty
WARRANTy KEEP THIS WARRANTy Model (located on product or identification tag) _____________________________ Serial No. (located on product or identification tag) __________________________ Date Purchased __________________________ Keep receipt for warranty verification. FMI PRODUCTS, LLC LIMITED WARRANTIES New products Standard Warranty: FMI PRODUCTS, LLC warrants this new product and any parts thereof to be free from defects in material and workmanship for a period of four (4) year from the date of first purchase from an authorized dealer provided the product has been installed, maintained and operated in accordance with FMI PRODUCTS, LLC’s warnings and instructions.
