NATURAL GAS LOG
VENTED DECORATIVE APPLIANCES
OWNER'S OPERATION AND INSTALLATION MANUAL
TESTED AND
LISTED BY
Std RADCO Listing No. 1292
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury, or
loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the
gas supplier.
WARNING: This is a gas-fired appliance. It uses air (oxygen) from the room in which
it is installed. Provisions for adequate combustion and ventilation air must be
provided. Refer to Air for Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited by
state or local codes.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Save this manual for future reference.
Models:
CVTR18/24
HVTR18/24
LVTR18/24
RGA 2-72
APPROVED
WARNING: Improper installa-
tion, adjustment, alteration, ser-
vice, or maintenance can cause
injury or property damage. Re-
fer to this manual for correct
installation and operational
procedures. For assistance or
additional information consult
a qualified installer, service
agency, or the gas supplier.
WARNING: This appliance is
for installation only in a solid-
fuel burning masonry or UL127
factory-built fireplace, con-
structed of noncombustible
material, and connected to a
working flue. (See page 7 for
minimum flue opening.)
Advertisement
Table of Contents
Related Manuals for Comfort Glow 901910-01A.pdf
Summary of Contents for Comfort Glow 901910-01A.pdf
- Page 1 NATURAL GAS LOG VENTED DECORATIVE APPLIANCES OWNER’S OPERATION AND INSTALLATION MANUAL TESTED AND LISTED BY Std RADCO Listing No. 1292 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
-
Page 2: Safety Information
VENTED NATURAL GAS LOGS SAFETY INFORMATION WARNINGS WARNING ICON G 001 WARNING: Keep flue open when operating unit. IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, oper- ate, or service this log set. Im- proper use of this log set can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. -
Page 3: Product Identification
PRODUCT IDENTIFICATION Grate Burner Front Burner Figure 1 - Product Identification Serial Number ________________________________________ LOCAL CODES Install and use log set with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code ANS Z223.1, also known as NFPA 54*. -
Page 4: Air For Combustion And Ventilation
VENTED NATURAL GAS LOGS AIR FOR COMBUSTION AND VENTILATION WARNING: This appliance shall not be installed in a con- fined space or unusually tight construction unless provisions are provided for adequate com- bustion and ventilation air. Read the following instructions to in- sure proper fresh air for this and other fuel-burning appliances in your home. - Page 5 INSTALLATION Continued MODELS DESCRIPTION CVTR18 18" Triple Burner HVTR18 LVTR18 CVTR24 24" Triple Burner HVTR24 LVTR24 MINIMUM FIREBOX SIZES LOG FRONT BACK SIZE WIDTH* WIDTH** DEPTH HEIGHT 18" 28" 16" 14" 24" " 17" *Add 2" if safety valve/pilot is used **At depth indicated FUEL INLET PRESSURE SPECIFICATIONS ("W.C.)
-
Page 6: Checking Gas Connections
VENTED NATURAL GAS LOGS INSTALLATION Continued INSTALLING DAMPER CLAMP Secure the damper stop clamp provided to the leading edge of the damper as shown in Figure 3. If for any reason this clamp doesn't work on your fireplace, another suitable clamp or permanent stop must be installed, or the damper blade must be cut or removed. - Page 7 INSTALLATION Continued Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa) 1. Close equipment shutoff valve (see Fig- ure 5). Pressurize supply piping system by either using compressed air or opening main gas valve located on or near gas meter. Check all joints from gas meter to equip- ment shutoff valve (see Figure 5).
-
Page 8: Operating Appliance
VENTED NATURAL GAS LOGS TESTING BURNER FOR LEAKS 1. Generously apply soapy solution to all connections. WARNING: Never check for gas leaks with open flame. 2. Light the burner with the shutoff valve no more than half open and holding a match slightly in front of the pan (see Lighting Instructions, column 2). -
Page 9: Troubleshooting
TROUBLESHOOTING Note: For additional help, visit DESA International’s technical service web site at www.desatech.com. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM Log set is smoking/sooting excessively ( Note: It is natural and unavoidable for vented gas log sets to produce moderate levels of carbon (soot) where flames contact the logs. - Page 10 VENTED NATURAL GAS LOGS TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
-
Page 11: Cleaning And Maintenance
PARTS UNDER WARRANTY Contact authorized dealers of this product or Parts Central (see page 14). If they can’t supply original replacement part(s), call DESA International’s Technical Service Department at 1-800-DESA LOG (1-800-337-2564). When calling DESA International, have ready •... -
Page 12: Illustrated Parts Breakdown
VENTED NATURAL GAS LOGS ILLUSTRATED PARTS BREAKDOWN Triple Burner Models For more information, visit www.desatech.com 901910... -
Page 13: Parts List
PARTS LIST This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 11 of this manual. Triple Burner Models KEY PART NUMBER FOR 18" Triple 098249-01 901752-02 102843-01 901246-01 098304-01 901762-01... -
Page 14: Parts Centrals
VENTED NATURAL GAS LOGS PARTS CENTRALS Baltimore Electric 1348 Dixwell Avenue Hamden, CT 06514-0322 1-800-397-7553 203-248-7553 Parts Department Portable Heater Parts 342 N. County Rd. 400 E. Valparaiso, IN 46383-9704 All States 219-462-7441 1-800-362-6951 Parts Department 1349 Adams St. Bowling Green, KY 42103-3414 270-846-1199 1-800-654-8534 Fax: 1-800-846-0090... - Page 15 OWNER’S MANUAL NOTES _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ For more information, visit www.desatech.com 901910...
-
Page 16: Warranty Information
COMFORT GLOW VENTED GAS LOGS DESA International warrants this product to be free from defects on burner system for two (2) years and logs for a lifetime from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions.
