give an error as stated above). If the subfunction code is
not one of those described in this manual, an illegal
subfunction error will be returned.
HP 27130B
For each of the subfunctions defined in the following paragraphs, a brief description of the type of
validation performed on the parameter passed in the data block will be given. If the parameter is not
valid, an illegal configuration parameter value error will be returned.
Subfunction O. This subfunction sets all of the configuration data defined in subfunctions 1 through
32. The data are position -dependent according to each subfunction code. This subfunction allows one
call to configure everything, instead of calling each individual item. After the initial configuration, a
particular item can be changed as needed.
Note that if you use this subfunction, every item must be specified with new values. The default
values or the previous values that were specified will be set to the new values given.
The data block is defined as follows:
byte
0: configure frontplane control
1: high byte end-an-count length
2: low byte
end~on-count
length
3: alert 1 read mode option
4: reserved
5: transmission mode
6: backspace character
7: line delete character
8: other options
9: device handshake option
10: baud rate
11: character length
12: number of stop bits
13: parity
14: reserved
15: reserved
16: reserved
4-23
