Firmware upgradable items
Current firmware version
(1) DO NOT power off until the upgrade is finished.
(2) If the firmware upgrade failed, the main controller will enter a waiting for firmware upgrade
status automatically. If this happens, repeat the above procedures.
Firmware upgradable items:
(1) Main Controller
(2) GPS
(3) 5.8G Receiver
(4) P330CB (Main Board)
(5) Battery

13.4 PHANTOM RC Assistant Description

Please follow the procedures to finish the configuration of the remote controller.
1. Turn off the remote controller and find the Micro-USB port on the back of it. (If there is no one, users
should open the rear cover to find the Micro-USB port on the board inner the remote controller.)
2. Start up the PC, power on the remote controller, and then Connect the remote controller to the PC with a
Micro-USB cable. DO NOT disconnect until the configuration is finished.
3. Run the PHANTOM RC Assistant and wait for the remote controller to connect to the Assistant. Observe
the indicators
indicator is and communication indicator is blinking
4. Finish configuration in the [Main] page.
5. Finish upgrade in the [Info] page if necessary.
©2015 DJI. All Rights Reserved.
on the bottom left of the screen. When connected successfully, the connection
64 |
.
Upgrade link
*This image is for reference
only. Please refer to the
actual user interface.
