Summary of Contents for Salus OPTIMA ZigBee
Page 1
OPTIMA
Z igBee
T hermostat
Quick
S tart
G uide For other language versions, please visit: www.salusinc.com...
Page 2
’ .
S
G ET
S TARTED Make sure you have the following items: Thermostat with Trim plate Screws and Anchors Mounting Plate Wire Labels 2 x AA alkaline User’s Manual Quick Start Guide batteries...
Page 3
Turn
o ff
t he
h eating
a nd/or
c ooling
Turn OFF the breakers or remove the fuses to the heating and/or cooling systems at the electrical panel. In some regions, there may be a switch located near the furnace. ...
Page 4
Determine
w iring
c onfiguration
Remove the old thermostat to expose • the wiring terminals. Take a picture of the wiring for future • reference. Note the terminals attached to each • wire and attach the matching label to the ends of the wires.
Page 5
Remove
o ld
t hermostat
t erminals
TIP:
Wrap
the
wire
ends
Remove the old thermostat wiring terminals around
a
l ong
s tick,
s uch
a s
from the wall, taking care not to allow the a
...
Page 6
Install
B atteries
Insert the alkaline batteries into the back of the thermostat. Make sure the polarity of the batteries is correct. After inserting the batteries, the display will flash all the segments, followed by the version number of the firmware, then display US / CA with a blinking US.
Page 7
Attach
T hermostat
T o
M ounting
P late
Attach the thermostat to the Mounting Plate by aligning the connector pins and the plastic retention posts and pushing the thermostat onto the Mounting Plate. Make sure the connector pins are not bent and that the thermostat is fully seated on the Mounting Plate.
ALUS
ARRANTY Salus Controls Inc. (“Salus”) warrants that for a period of two (2) years (“Warranty Period”) from the date of purchase by the consumer (“Customer”), this device, excluding batteries (“Product”), shall be free of defects in materials and workmanship under normal use and service in accordance with all supplied instructions.
Page 9
fitness, so these exclusions or limitations may not apply to you. No oral or written information or advice given by Salus or a Salus-authorized representative shall modify or extend this warranty. If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be affected or impaired.
Page 10
FCC
S tatements
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 11
FCC
a nd
I ndustry
C anada
RF Radiation Exposure statement: This equipment complies with FCC and Industry Canada RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the antenna and all persons.
Page 12
Salus Controls Inc. 123 Townsend St. Level LL2 San Francisco, CA 94107 Version
