S e t t i n g t h e a n g l e w i t h i n t h e y o k e
Step 1:
Loosen the yoke locking knobs (see
Step 2:
Tilt the fixture to the desired position.
Step 3:
Tighten the yoke locking knobs to secure in position.
8
Yoke locking knob
Figure
11). Do not remove them.
Source Four jr / jr Zoom User Manual
Figure 11
