APOLLO
Do not confuse the receiver code switches with the red program switches on the gate control board.
Never set all code switches to the same position. Transmitters must match code switches for proper operation.
If power is taken directly from battery or connected as shown below, receiver should be configured for 12VDC
Gate Operators
Multi-Code/Digi-Code
Allstar
Lift-Master
Jumpers must be
set for 12V &
constant relay
option
Heddolf
black
RECEIVER OPTIONS
black
gray
white
black
red
1
2
3
4
white
yellow
red
gray
red
22
