Pro-face AGP3200-A1-D24 Installation Manual

Gp3000 series
Hide thumbs

Advertisement

Table of Contents

GP-3200 Series
Installation Guide
Caution
Be sure to read the "Warning/Caution
Information" on the attached sheet before
using the product.

Package Contents

(1) GP Unit (1)
(2) English and Japanese Installation Guides
(one of each) <This Guide>
(3) Warning/Caution Information (1)
(4) Installation Gasket (1)
(Attached to the GP unit)
(5) Installation Fasteners (Set of 4)
(6) Power Connector (1)
(Attached to the GP unit)
(7) USB Cable Clamp (1 set)
(Holder: 1, Cover: 1)
This unit has been carefully packed, with
special attention to quality. However, should
you find anything damaged or missing,
please contact your local GP distributor
immediately.
About the Manual
For the detailed information on GP3000
series, refer to the following manual.
• GP3000 Series Hardware Manual
• Maintenance/Troubleshooting
GP3000 Series Hardware Manual can be
selected from the help menu of GP-Pro EX or
downloaded from Pro-face Home Page.
URL
http://www.pro-face.com/otasuke/
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGP3200-A1-D24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-face AGP3200-A1-D24

Summary of Contents for Pro-face AGP3200-A1-D24

  • Page 1: Package Contents

    GP3000 Series Hardware Manual can be Information” on the attached sheet before selected from the help menu of GP-Pro EX or using the product. downloaded from Pro-face Home Page. Package Contents http://www.pro-face.com/otasuke/ (1) GP Unit (1) (2) English and Japanese Installation Guides (one of each) <This Guide>...

  • Page 2: Part Names And Functions

    Part Names and Functions Rear Front Bottom Name Description GP Status Normal operation (power is ON.) or Green (lit) OFFLINE operation. A Status LED Orange During software startup. (blinking) Red (lit) When power is turned ON. Not lit Power is OFF. B Power Connector (Socket) USB1.1 Host I/F Connector: USB TYPE-A x 1...

  • Page 3: General Specifications

    Pollution Degree For use in Pollution Degree 2 environment. *1 When using AGP3200-A1-D24 in an environment where the temperature becomes or exceeds 40°C for an extended period of time, the screen contrast level may decrease from its original level of...

  • Page 4: External Interfaces

    External Interfaces • The GP series’ serial interface is not isolated. When the host (PLC) unit is also not isolated, and to reduce the risk of damaging the RS232C/RS422/RS485 circuit, be sure to connect pin #5 SG (Signal Ground) terminal. •...

  • Page 5: Installations

    GP Installation Installations (1) Create a Panel Cut following the dimen- sions in the table below. Installation Requirements Unit: mm [in.] Under Panel • For easier maintenance, operation, and 4-R3[0.12] thickness improved ventilation, be sure to install the GP at least 100 mm [3.94 in.] away from adjacent structures and other equipment.

  • Page 6: Power Cord Specifications

    Power Connector (Plug) Specifications Insertion Direction Grounding Terminal connected to the GP chassis • The power connector (plug) is CA5- DCCNM-01 made by Pro-face or MSTB2,5/3-ST-5,08 made by Phoenix Contact.

  • Page 7: Power Supply Cautions

    When connecting the Power Cord, use the Power Supply Cautions following items when performing wiring. (Items are made by Phoenix Contact.) • Input and Output signal lines must be sepa- rated from the power control cables for Recommended SZF 1-0.6x3.5 operational circuits.

  • Page 8: Grounding Cautions

    Use the associated USB Cable Clamp: CA5-USBATL-01 (made by Pro-face) Exclusive Grounding (BEST) b) Use the USB cable with the housing Other...
  • Page 9 (2) Attach the USB holder to the USB Host Removing the USB Holder Interface part of the main unit. Hook the (1) Lift up the tab of the USB holder and upper pick of the USB holder to the then remove the USB cover as shown attachment hole of the main unit and below.

  • Page 10: Ul/C-Ul/Csa Approval

    UL/c-UL/CSA Product Model No. National Electrical Code, NFPA 70 Registration Model No. within the United States, and in accor- AGP3200-A1-D24 3580205-03 dance with Section 18-152 of the Cana- dian Electrical Code for units installed AGP3200-T1-D24 3580205-04 within Canada. (2) Suitable for use in Class I, Division 2, Groups...
  • Page 11 CE Marking Inquiry • The AGP3200-A1-D24 and AGP3200-T1- Do you have any questions about D24 units are CE marked, EMC compliant difficulties with this product? products. These units also conform to Please access our site anytime that EN55011 Class A, EN61131-2 directives.

This manual is also suitable for:

Agp3200-t1-d24
