Changing the monitor settings

When putting the monitor into operation for the first time, the screen display should
be optimally adapted to the display adapter used.
Changing the monitor settings with the buttons
of the control panel
The buttons of the control panel have two functions. With the OSD menu not
activated, you can make the following settings directly:
1 = Buttons for the OSD menu (On
Screen Display)
2 = Power indicator
Performing auto-adjustment of the monitor
► Press the
EXIT / AUTO
The Auto Processing message appears
Picture quality and position are set to optimum values for your system.

Brightness adjustment

► Press the BACK /
This setting changes the backlight brightness.
Activating/deactivating muting
► Press the FORWARD /
A message will be displayed confirming that the action has been performed.
A26361-K1338-Z220-1-7619, edition 1
Downloaded from ManualMonitor.com Manuals
button for about 1 second.
button to adjust the brightness.
button to toggle sound off or on.
3 = ON/OFF switch
Operation
15
