- Page 1 Operating Guide EPIA N-Series Nano-ITX Mainboard May 23, 2006 Version 1.1...
-
Page 2: Table Of Contents
VIA LUKE COREFUSION™ OVERVIEW ..........................5 VIA EPIA N-SERIES I/O BACK PANEL LAYOUT........................6 VIA EPIA N-SERIES LAYOUT DIAGRAM & HEIGHT DISTRIBUTION ................7 VIA EPIA NL-SERIES LAYOUT DIAGRAM & HEIGHT DISTRIBUTION (BOTTOM) ........... 8 VIA EPIA NL-SERIES THERMAL LAYOUT & HEIGHT DISTRIBUTION................ 9 NOISE LEVEL DATA ................................. -
Page 3: Via Epia N-Series Overview
LVDS embedded LCD panels, TV-out, S-Video, Video interface port and has one Mini-PCI slot for expandability options. The VIA EPIA N-Series is compatible with a full range of Nano- ITX chassis as well as FlexATX and MicroATX enclosures and power supplies. -
Page 4: Via Epia N-Series Layout
EPIA N-Series Operating Guide VIA EPIA N-Series Layout May 23, 2006 - 2 - Version 1.1... -
Page 5: Via Epia N-Series Specifications
EPIA N-Series Operating Guide VIA EPIA N-Series Specifications - VIA Luke CoreFusion™ processor Core Logic - VIA VT8237R-series South Bridge System Memory - 1 DDR400/333/266 SODIMM socket - Up to 1GB memory size - Integrated VIA UniChrome™ Pro AGP Graphics with MPEG-2... -
Page 6: Via Epia N Processor Skus
EPIA N-Series Operating Guide VIA EPIA N Processor SKUs The VIA EPIA N-Series is available in 533MHz, 800MHz and 1.0GHz speed grades. The VIA EPIA N utilizes VIA’s ultra low power VIA Luke Core Fusion™ processor. PadLock ACE US government... -
Page 7: Via Luke Corefusion™ Overview
EPIA N-Series Operating Guide VIA Luke CoreFusion™ Overview The Luke CoreFusion™ Processor is a high performance, cost-effective and energy efficient processor with integrated UniChrome Pro graphics / video controller. The Luke CoreFusion™ Processor integrates VIA’s most advanced system controller with high-performance UniChrome Pro 3D / 2D graphics and video controller, DVI monitor and TV-Out interfaces. -
Page 8: Via Epia N-Series I/O Back Panel Layout
EPIA N-Series Operating Guide VIA EPIA N-Series I/O Back Panel Layout The EPIA N’s ultra compact 12cm x 12cm, integrated design supports all the standard legacy x86 connectivity options as well as USB 2.0, VGA port, RJ45 LAN port and VIA 6 channel AC’97 audio. -
Page 9: Via Epia N-Series Layout Diagram & Height Distribution
EPIA N-Series Operating Guide VIA EPIA N-Series Layout Diagram & Height Distribution May 23, 2006 - 7 - Version 1.1... -
Page 10: Via Epia Nl-Series Layout Diagram & Height Distribution (Bottom)
EPIA N-Series Operating Guide VIA EPIA NL-Series Layout Diagram & Height Distribution (Bottom) May 23, 2006 - 8 - Version 1.1... -
Page 11: Via Epia Nl-Series Thermal Layout & Height Distribution
EPIA N-Series Operating Guide VIA EPIA NL-Series Thermal Layout & Height Distribution May 23, 2006 - 9 - Version 1.1... -
Page 12: Noise Level Data
EPIA N-Series Operating Guide Noise Level Data VIA and the EPIA series have been at the forefront of the quiet computing initiative. The VIA EPIA N- Series has been designed to be totally non-obtrusive with noise levels equivalent to a person whispering. -
Page 13: Power Consumption
EPIA N-Series Operating Guide Power Consumption Power consumption tests were carried out comparing the VIA EPIA N5000E (running the 533MHz VIA CoreFusion™ processor), VIA EPIA N8000E (running the 800MHz VIA CoreFusion™ processor) and VIA EPIA N10000 (running the 1.0GHz VIA CoreFusion™ processor). The following tables are a comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values while running... -
Page 14: Via Epia N 8000E
EPIA N-Series Operating Guide E. Run C.C. Winstone 2001 Measured Voltage Measured Amp. Watts Main Board +3.3V 3.234 2.750 8.894 Main Board +5V 5.051 0.897 4.531 Main Board 5VSB 4.922 0.059 0.290 Main Board +12V 12.004 0.097 0.000 13.715 Main Board Power Consumption F. -
Page 15: Via Epia N 10000
EPIA N-Series Operating Guide D. Idle Measured Voltage Measured Amp. Watts Main Board +3.3V 3.244 2.575 8.353 Main Board +5V 5.062 0.491 2.485 Main Board 5VSB 4.927 0.059 0.291 Main Board +12V 11.996 0.093 1.116 12.245 Main Board Power Consumption E. - Page 16 EPIA N-Series Operating Guide B. Playing MP3 – Media Player Measured Voltage Measured Amp. Watts 3.232 2.877 9.298 Main Board +3.3V 5.049 1.045 5.276 Main Board +5V 4.918 0.063 0.310 Main Board 5VSB 11.994 0.170 2.039 Main Board +12V 16.923 Main Board Power Consumption C.
-
Page 17: Power Specifications
EPIA N-Series Operating Guide Power Specifications The EPIA N utilizes an industry standard 12-pin ATX main connector to the power supply. Due to the EPIA N platform’s ultra low power requirements, a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications. -
Page 18: Via Epia N-Series Microsoft And Linux Driver Support
VIA EPIA N-Series Microsoft and Linux Driver Support Microsoft Driver Support VIA EPIA N-Series offer full support for the complete range of Microsoft operating systems. For standard operating systems, Windows 98/Me/2000/XP latest drivers downloads can be found in the VEPD website at www.viaembedded.com. -
Page 19: Contact
EPIA N-Series Operating Guide Contact For more information on the VIA EPIA N-Series Nano-ITX Mainboard contact your sales representative or visit our website at www.viaembedded.com Taiwan 440 Mission Court, Suite 220 1F, 531, Chung Cheng Road Fremont, CA 94539 Hsin Tien, Taipei...
