- Page 1 Operating Guide EPIA NL-Series Nano-ITX Mainboard January 30, 2012 Version 1.11...
-
Page 2: Table Of Contents
VIA EPIA NL PROCESSOR SKUS ..............................4 VIA LUKE COREFUSION™ OVERVIEW ............................5 VIA EPIA NL-SERIES LAYOUT DIAGRAM & HEIGHT DISTRIBUTION (TOP) ..............6 VIA EPIA NL-SERIES LAYOUT DIAGRAM & HEIGHT DISTRIBUTION (BOTTOM)............7 VIA EPIA NL-SERIES HEAT SINK LAYOUT & HEIGHT DISTRIBUTION ................8 VIA EPIA NL-SERIES BOARD COOLING METHOD &... -
Page 3: Via Epia Nl-Series Overview
COM / LPC / SIR pin header and one 10/100 Fast Ethernet pin header for extended broadband connectivity. The VIA EPIA NL-Series also offers support for a number of LVDS embedded LCD panels, TV-out, S-Video, Video interface port, CRT VGA / SMBus / CAP0 and has one Mini-PCI slot for expandability options. -
Page 4: Via Epia Nl-Series Layout
EPIA NL-Series Operating Guide VIA EPIA NL-Series Layout January 30, 2012 - 2 - Version 1.11... -
Page 5: Via Epia Nl-Series Specifications
EPIA NL-Series Operating Guide VIA EPIA NL-Series Specifications Core Logic - VIA Luke CoreFusion™ processor - VIA VT8237R-series South Bridge System Memory - 1 DDR400/333/266 SODIMM socket - Up to 1GB memory size - Integrated VIA UniChrome™ Pro AGP Graphics with MPEG-2... -
Page 6: Via Epia Nl Processor Skus
EPIA NL-Series Operating Guide VIA EPIA NL Processor SKUs The VIA EPIA NL-Series is available in 533MHz, 800MHz and 1.0GHz speed grades. The VIA EPIA NL utilizes VIA’s ultra low power VIA Luke Core Fusion™ processor. PadLock ACE US government... -
Page 7: Via Luke Corefusion™ Overview
EPIA NL-Series Operating Guide VIA Luke CoreFusion™ Overview The Luke CoreFusion™ Processor is a high performance, cost-effective and energy efficient processor with integrated UniChrome Pro graphics / video controller. The Luke CoreFusion™ Processor integrates VIA’s most advanced system controller with high-performance UniChrome Pro 3D / 2D graphics and video controller, DVI monitor and TV-Out interfaces. -
Page 8: Via Epia Nl-Series Layout Diagram & Height Distribution (Top)
EPIA NL-Series Operating Guide VIA EPIA NL-Series Layout Diagram & Height Distribution (Top) January 30, 2012 - 6 - Version 1.11... -
Page 9: Via Epia Nl-Series Layout Diagram & Height Distribution (Bottom)
EPIA NL-Series Operating Guide VIA EPIA NL-Series Layout Diagram & Height Distribution (Bottom) January 30, 2012 - 7 - Version 1.11... -
Page 10: Via Epia Nl-Series Heat Sink Layout & Height Distribution
EPIA NL-Series Operating Guide VIA EPIA NL-Series Heat Sink Layout & Height Distribution January 30, 2012 - 8 - Version 1.11... -
Page 11: Via Epia Nl-Series Board Cooling Method & Height Distribution
EPIA NL-Series Operating Guide VIA EPIA NL-Series Board Cooling Method & Height Distribution January 30, 2012 - 9 - Version 1.11... -
Page 12: Noise Level Data
EPIA NL-Series Operating Guide Noise Level Data VIA and the EPIA series have been at the forefront of the quiet computing initiative. The VIA EPIA NL- Series has been designed to be totally non-obtrusive with noise levels equivalent to a person whispering. -
Page 13: Power Consumption
EPIA NL-Series Operating Guide Power Consumption Power consumption tests were carried out comparing the VIA EPIA NL5000E (running the 533MHz VIA CoreFusion™ processor), VIA EPIA NL8000E (running the 800MHz VIA CoreFusion™ processor) and VIA EPIA NL10000 (running the 1.0GHz VIA CoreFusion™ processor). -
Page 14: Via Epia Nl 8000E
EPIA NL-Series Operating Guide D. Idle Measured Voltage Measured Amp. Watts Main Board +3.3V 3.252 2.571 8.361 Main Board +5V 5.059 0.441 2.231 Main Board 5VSB 4.921 0.053 0.261 Main Board +12V 11.983 0.101 1.210 Main Board Power Consumption 12.063 E. - Page 15 EPIA NL-Series Operating Guide B. Playing MP3 – Media Player Measured Voltage Measured Amp. Watts Main Board +3.3V 3.239 2.839 9.196 Main Board +5V 5.046 1.053 5.313 Main Board 5VSB 4.918 0.055 0.270 Main Board +12V 12.005 0.105 1.261 Main Board Power Consumption 16.040...
-
Page 16: Via Epia Nl 10000
EPIA NL-Series Operating Guide VIA EPIA NL 10000 A. Playing DVD – Power DVD 5.0 Measured Voltage Measured Amp. Watts Main Board +3.3V 3.236 2.965 9.595 Main Board +5V 5.036 1.277 6.431 Main Board 5VSB 4.911 0.064 0.314 Main Board +12V 11.987... - Page 17 EPIA NL-Series Operating Guide E. Run C.C. Winstone 2001 Measured Voltage Measured Amp. Watts Main Board +3.3V 3.235 2.777 8.984 Main Board +5V 5.035 1.445 7.276 Main Board 5VSB 4.914 0.062 0.305 Main Board +12V 11.999 0.157 0.000 Main Board Power Consumption 16.564...
-
Page 18: Power Specifications
EPIA NL-Series Operating Guide Power Specifications The EPIA NL utilizes an industry standard 12-pin ATX main connector to the power supply. Due to the EPIA NL platform’s ultra low power requirements, a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications. -
Page 19: Via Epia Nl-Series Microsoft And Linux Driver Support
VIA EPIA NL-Series Microsoft and Linux Driver Support Microsoft Driver Support VIA EPIA NL-Series offer full support for the complete range of Microsoft operating systems. For standard operating systems, Windows 98/Me/2000/XP latest drivers downloads can be found in the VEPD website at www.viaembedded.com. -
Page 20: Contact
EPIA NL-Series Operating Guide Contact For more information on the VIA EPIA NL-Series Nano-ITX Mainboard contact your sales representative or visit our website at www.viaembedded.com Taiwan Headquarters Europe 1F, 531 Zhong-Zheng Road 940 Mission Court In den Dauen 6 Xindian District, New Taipei City...
