Inserting a Battery

Lift the notch at the edge of the battery compartment and swivel
1
open the door of the battery compartment.
Remove the yellow-colored tab on a new battery (size 10A).
2
Insert the battery with the positive "+" side facing up.
(FIgURe 4)
FIGURE 3
8 Inserting a Battery
(FIgURe 3)
FIGURE 4
gently close the battery door. It should close easily; do not force
3
the door closed.
(FIgURe 5)
If resistance is experienced while closing the battery door, make sure the
battery is inserted properly. When the battery door is completely closed,
your Tweak Mini is ready for operation.
ON –When the battery door is
completely closed, your
Tweak Mini is on.
OFF –To turn off your Tweak Mini,
open the battery door part way.
FIGURE 5
Inserting a Battery 9
