Battery Information

Tweak Mini uses a 10A zinc air battery.
With normal full-time use, the battery will last
approximately fi ve days.
When the battery is depleted, remove and
replace it immediately. Replacements may be
purchased at www.TweakHearing.com
When not in use, be sure to turn off your
Tweak Mini by opening the battery door part
way.
(FIgURe 3, Pg. 8)
Low Battery Warning
For your convenience, Tweak Mini warns you
when the battery is almost depleted. You will
hear three sets of double beeps every 10 minutes,
indicating it's time to change the battery. Once the
voltage drops below 0.95V, Tweak Mini emits six
sets of double beeps, then shuts down.
6 Battery Information

Preparing for Use

Important —
Always discard
used batteries.
Small batteries
can be harmful
if swallowed.
Keep batteries
out of reach of
pets and small
children. In case
of ingestion, seek
medical attention
immediately and
call (collect, if
necessary) the
National Battery
Ingestion Hotline
at 202-625-3333.
For more info visit
poison.org/battery
www.
Tweak Mini comes with two thin tubes, one for your right ear and one for
your left ear. "Sleeve" tips are already installed on these tubes, so all you
have to do is pick either a right or a left tube, and connect it to the amplifi er
case.
Tubes are marked with red lettering for the right and blue lettering for the
left.
(FIgURe 1)
Align the tube connector end with the end of the case, then push the tube
straight onto the sound post until it snaps into place.
TIPS
SLEEVE VENTED DOME
CLOSED DOME
Text represents size of tube.
Color of text indicates right
FIGURE 1
or left. Red=right, Blue=left
(FIgURe 2)
FIGURE 2
Preparing for Use 7
