Page 1: Assembly Instructions
841101 WEIGHT STACK OPTION ASSEMBLY INSTRUCTIONS CLASS H Version: 841101 Revision: 06/19/01 PART # 6754401 REV. A... -
Page 2: Tools Required For Assembly
WELCOME TO THE WORLD OF Please note: * Thank you for purchasing the Parabody 841101 WEIGHT STACK OPTION. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. -
Page 3: Table Of Contents
PART # DESCRIPTION 6750803 UPRIGHT 6753703 TOP BOOM 6274402 LOW ROW BAR 6275302 LAT BAR 6609002 LOW ROW ATTACHMENT 6610402 KNEE SUPPORT 6750503 WEIGHT STACK BASE 6176201 ROLLER PAD 6754501 79-1/2” GUIDE ROD 6189501 WEIGHT STACK LABEL 3116101 4-1/2” PULLEY 3116201 3-1/2”... - Page 4 POWER RACK 3/8 X 3-1/4” 27 FIGURE 2 STEP 2: • Insert two 2” SQ ENDCAPS (36) into the ends of the UPRIGHT (1) as shown in FIGURE 2. • SECURELY assemble the LOW ROW ATTACHMENT (5) and the UPRIGHT (1) to the POWER RACK using two 3/8 X 3-1/4” BOLTS (27), four 3/8”...
- Page 5 1/2 X 3” 28 FIGURE 3 STEP 3 • Slide one 2” SQ. COVER CAP (22) over the end of the WEIGHT STACK BASE (7) as shown in FIGURE 3. • SECURELY assemble the WEIGHT STACK BASE (7) to the UPRIGHT (1) using two 1/2 X 3” BOLTS (28), two 1/2” WASH- ERS (29), and two 1/2”...
-
Page 6: X 1-1/4" Bolt
FIGURE 5 STEP 5: • Insert four CAP PLUGS (21) into the bottom end & top end of the two GUIDE RODS (9) as shown in FIGURE 5. • Securely assemble the WEIGHT STACK SHAFT (13) to the HEAD PLATE (14) using one 3/8 X 1-1/4” BOLT (23) and one 3/8” WASHER (31). -
Page 7: X 2-3/4" Bolt
25 3/8 X 2-3/4” FIGURE 6 STEP 6: • Insert two 2 X 3” END CAPS (34) into the TOP BOOM (2) as shown in FIGURE 6. • Route threaded end of the LAT CABLE (15) through the TOP BOOM (2) as shown in FIGURE 6. •... - Page 8 25 3/8 X 2-3/4” FIGURE 8 STEP 8: • Route threaded end of the LAT CABLE (15) around the one of the PULLEYS in PLATE & PULLEY ASSEMBLY (17) and through the holes in the TOP BOOM (2) as shown in FIGURE 8. •...
-
Page 9: Lock Nut
FIGURE 9 POWER RACK 3/8 X 3” 26 STEP 9: • Swing the GUIDE RODS (9) under the TOP BOOM (2) as shown on FIGURE 9. • Assemble the TOP BOOM (2) over the GUIDE RODS (9) and SECURELY assemble the TOP BOOM (2) to the UPRIGHT (1) using two 1/2 X 3”... -
Page 10: Flange Spacer
3/8 X 2-3/4” 25 FIGURE 10 STEP 10: • Loop the ball end of the LOW ROW CABLE (16) around one 4-1/2” PULLEY (11) and SECURELY assemble the 4-1/2” PUL- LEY (11) to the UPRIGHT (1) using two 3/8 X 2-3/4” BOLTS (25), two 3/8” FLANGE SPACERS (33), two 3/8” WASHERS (31), and two 3/8”... - Page 11 FIGURE 11 STEP 11: • Route the threaded end of the LOW ROW CABLE (16) around the bottom PULLEY of the PULLEY & PLATE ASSEMBLY (17) as shown in FIGURE 11. STEP 12: • Screw the threaded end of the LOW ROW CABLE (16) approximately 3/4”...
- Page 12 FIGURE 13 STEP 13: • Attach the LAT BAR (4) to the ball end of the LAT CABLE (15) using one 5/16” SNAP LINK (40) as shown in FIGURE 13.. • Slide two 1 X 8” GRIPS (18) over the ends of the LAT BAR (4) as shown in FIGURE 13. STEP 14: •...
-
Page 13: Sq. End Cap
FIGURE 15 STEP 15: • Slide two ROLLER PADS (8) onto the KNEE SUPPORT (6), then insert one 1-3/4” SQ. END CAP (37) into the end of the KNEE SUPPORT (6) as shown in FIGURE 15. FIGURE 16 STEP 16: •... -
Page 14: Figure
LAT CABLE (15) and the LOW ROW CABLE (16) accordingly and retighten the jam nut. See FIGURE 17. • Make sure all connections are tight and secure. THIS CONCLUDES THE ASSEMBLY OF THE 841101 WEIGHT STACK OPTION...
