USER MANUAL
Glass Bridge Display
Canadian
Nauticomp Inc.
Headquarters:
8 Callaghan Road
Lindsay, Ontario
Canada
K9V 4R4
p: +1 705 328 2992
f: +1 705 328 2990
21-1210
12.1" Daylight Display
21-1510
15.0" Daylight Display
21-1910
19.0" Daylight Display
21-2110
21.3" Daylight Display
22-1210
12.1" Sunlight Display
22-1510
15.0" Sunlight Display
22-1910
19.0" Sunlight Display
22-2110
21.3" Sunlight Display
UK: Nauticomp European Distribution
2 Mornington Place, Waterberry Drive
Waterlooville, Hants, PO7 7XX
P:+44 2392 247920
f: +44 2392 261959
URL: www.nauticomp.com E-Mail: sales@nauticomp.com
Page 1 of 30
Models
®
United States: Nauticomp International
th
1200 NE 7
Fort Lauderdale
Florida, United States
33304
p: +1 954 235 4875
f: +1-705-328-2990
Avenue
Advertisement
Table of Contents
Related Manuals for Nauticomp 21-1210
Summary of Contents for Nauticomp 21-1210
-
Page 1: User Manual
22-1510 15.0” Sunlight Display 22-1910 19.0” Sunlight Display 22-2110 21.3” Sunlight Display Canadian Nauticomp Inc. UK: Nauticomp European Distribution United States: Nauticomp International Headquarters: 8 Callaghan Road 2 Mornington Place, Waterberry Drive 1200 NE 7 Avenue Lindsay, Ontario Waterlooville, Hants, PO7 7XX... -
Page 2: Table Of Contents
TABLE OF CONTENTS 1 GENERAL Forward Display Description…………………………………………………………………………………………..4 Contents of the Package………………………………………………………………………………….. 5 Warnings…………………………………………………………………………………………………………6 Important Information…………………………………………………………………………………….. 6 INSTALLATION Handling Precautions Planning Power Requirements Grounding DC Power Connections Extending the Power Cable Cable Runs Display Location EMC Guidelines……………………………………………………………………………………………… 10 2.10 Mechanical Installation – Display 2.11 Electrical Installation –... -
Page 3: General
GENERAL Forward Founded in 1997, Nauticomp Inc. based in Canada designs and manufactures the widest range of watertight sunlight readable displays for worldwide markets. Nauticomp Inc. is a fully accredited ISO 9001:2000 Company with regional offices located in the United States of America and Europe. -
Page 4: Contents Of The Package
Each Display is shipped with:- Description Part Number Qty Remarks Display - Power Cable 23-LTWPOW Feed from Nauticomp Power Supply: Display input 2pin (RED) connector – Length approx. 10’ (3m). Display - Mounting Kit 23-GBHARDWARE 1 Kit X11 Fixing Bolts, Bolt Clips & Centering Plates. -
Page 5: Warnings
This User manual contains important information on the installation and operation of your new display. In order to obtain the best results in operation and performance, please read this User Manual thoroughly. Nauticomp’s Technical Service representatives or your local dealer will be available to answer any questions you may have. -
Page 6: Installation
The display requires an external, regulated, 12.1V DC power supply. To meet onboard requirements, Nauticomp offers a wide range of external power supplies to match the power consumption requirements of individual displays being – 12V DC, 24V DC, & 115/230V AC. -
Page 7: Grounding
RF ground source. DC Power Connections The power connection to the Nauticomp Power Supply should be made at either the output of the battery isolator switch, or at a DC power distribution panel. Nauticomp recommends that power be fed directly to the Nauticomp Power Supply via its own dedicated cable system. -
Page 8: Cable Runs
INSTALLATION continued Cable Runs Consider the following before installing the Display:- 2.7.1 All cables should be adequately secured, protected from physical damage and protected from exposure to heat. Avoid running cables through bilges or doorways, or close to moving or hot objects. 2.7.2 Acute bends must be avoided. -
Page 9: Emc Guidelines
Provide additional shading. EMC Guidelines All Nauticomp Displays and accessories are designed to the best industry standards for use in the rugged electronic environment. The design and manufacture conforms to the appropriate Electromagnetic Compatibility (EMC) standards (Section 1.4.5 refers), but correct installation is required to ensure that performance is not compromised. -
Page 10: Mechanical Installation - Display
Step 2 Refer to the cut-out dimensions supplied in the package, make a cut-out in the mounting location. Step 3 Add a “Non Adhesive” Silicon sealant to interior cut-out perimeter. Step 4 Place your Nauticomp Glass Bridge Display into the cut-out. ®... -
Page 11: Electrical Installation - Display
Power Supply – Nauticomp recommends using a thin-bladed screwdriver through the side hole to change selection. **This should not be done with ANY power connected to the unit. CAUTION: Nauticomp Power Supply DO NOT ADJUST the potentiometer labelled ‘V ADJ’ - Factory Set 12.1V DC. Page 11 of 30... - Page 12 INSTALLATION continued 2.11.2 Cabling – Connections 2.11.2.1 Power output from the provided Nauticomp Power Supply is to be 12.1V DC. Please check voltage before connecting to the Display for the first time. 2.11.2.2 To aid installation ALL circular connectors on the display are colour coded and labelled to match corresponding interface cables.
-
Page 13: Recommendations For Vga/Dvi Source
INSTALLATION continued 2.12 Recommendations for VGA/DVI Source All Nauticomp Displays comply with VESA DDC1/2B Windows Plug and Play. No driver disks are required. A computer running Windows 2000, XP and later versions may interrogate the display for its technical characteristics. For best results Nauticomp recommends that you set the PC or device to match the “native”... -
Page 14: Operation
The Display is designed to minimize overall physical dimensions to enable multiple Displays to be mounted in close proximity maximizing available space. No user controls or indicators are on the actual Display. Nauticomp developed the GB Commander which is an external four button display controller, used to control the Glass Bridge Display functionality. -
Page 15: Overview - Menu Mode
OPERATION continued Overview - Menu Mode There are Four (4) Menu Tabs: Picture Source Utility Exit Buttons 1, 2, 3 and 4 (section 3.1 refers) are used to navigate and select OSD (On Screen Display) settings: 3.2.1 Momentarily pressing button 1 (Menu button) activates the Display’s OSD. When this is done the monitor displays the Glass Bridge Menu - In Menu Mode other functions for button 1 are: Select / Scroll down. -
Page 16: Picture Menu
OPERATION continued Picture Menu PICTURE - Functionality… OPTION FUNCTION ILLUSTRATION BRIGHTNESS Adjusts the LCD panel Brightness not the Backlight Brightness CONTRAST Adjusts the LCD Panel Contrast Adjusts the LCD Panel Saturation SATURATION Adjusts the LCD Panel Hue SHARPNESS Adjusts the video image sharpness level Adjusts the image horizontally and POSITION vertically... -
Page 17: Source Menu
OPERATION continued Source Menu SOURCE - Functionality… OPTION FUNCTION ILLUSTRATION Main Port Select the input Change video source VGA 1, VGA 2, DVI 1, DVI 2, Composite 1, Composite 2, Composite 3, Composite 4 PIP Port Select the PIP No PIP, VGA 1, VGA 2, DVI 1, DVI 2 Composite 1, Composite 2, Composite 3, Change source Composite 4... -
Page 18: Utilities Menu
OPERATION continued Utilities Menu Utilities - Functionality… OPTION DESCRIPTION / ILLUSTRATION Setup Auto Picture Setup: Auto adjust the image position, phase and size Auto Color Gain: Auto Color Calibration (See appendix IV) Wide Screen Mode detection: Recognize the wide screen mode coming from ARGB port. - Off - 1280x768 - 1360x768... - Page 19 OPERATION continued 3.6 Utilities Menu OSD position : H POS : Move the OSD menu image horizontally V POS : Move the OSD menu image vertically OSD Timeout (sec): ON – 60: Adjust the OSD menu timeout period in a step of 5 seconds (max 60 seconds) ON = Continuous to display OSD menu.
- Page 20 OPERATION continued 3.6 Utilities Menu 5000K Red Gain: Green Gain: Blue Gain: Red Offset: Green Offset : Blue Offset : Reset to Defaults : Resume to the default values 6500K Red Gain: Green Gain: Blue Gain: Red Offset: Green Offset: Blue Offset: Reset to Defaults : Resume to the default values 8000K...
-
Page 21: Maintenance
4.1.1 Check all cable connectors on the rear of the display to ensure they are secured. 4.1.2 Check the cable connectors on the external Nauticomp Power Supply. Inspect for corrosion on all connections – Terminal contacts must be tightly fastened. -
Page 22: Emc Servicing And Safety Guidelines
Kindly note the following: 4.2.1 There are no user serviceable parts in any Nauticomp Display or power supply. 4.2.2 Some products generate high voltages. Never handle the cables/connectors when power is being supplied to the equipment. -
Page 23: Troubleshooting
However, if this unit should develop a fault, please refer to the following table to identify the most likely cause and the corrective action required to restore normal operation. If you still have a problem after referring to the table below, contact Nauticomp Technical Services Department for further advice. - Page 24 TROUBLESHOOTING continued Symptom Cause Possible Solution Screen Blacking Out? Excessive UV Rays If LCD does black out the Display needs to be shaded until picture returns to normal. …Once the affected area’s temperature decreases normal operation will resume. Display seems dim? Backlight Brightness to a) Press and hold brightness up (+) button on GB Commander...
-
Page 25: Appendix
APPENDIX Declaration of Conformity Page 25 of 30... -
Page 26: Warranty Certificate
3 years/36 months from date of shipment from Nauticomp. Nauticomp Limited Warranty covers the parts and labour associated with any warranty repair as described above, provided that the unit is returned to Nauticomp or one of its appointed agents. -
Page 27: Return Of Goods Information (Rma)
Return of Goods Information (RMA) Obtaining Warranty Service In the event of Warranty service being required, contact Nauticomp directly. A suitable proof of purchase, showing date, place of purchase, and serial number must be made available to Nauticomp or authorized service agent at the time of request for Warranty service. -
Page 28: Contact Details
Fax: +44 2392 261959 United States: Nauticomp International. 1200 NE 7 Avenue. Ft Lauderdale, Florida, 33304. Tel: +1 954 235 4875 Fax: +1 705 328 2990 Nauticomp Inc. is fully accredited ISO 9001:2000 Company INTERTEK Certification Nº 4546 Page 28 of 30... -
Page 29: Product Notes
APPENDIX continued 6.7 Product Notes: Page 29 of 30... - Page 30 All other product names or trademarks are properties of their respective owners All rights are reserved by Nauticomp Inc. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form without the prior written consent of Nauticomp Inc.
