Thermal Arc Fabricator 181i Operating Manual page 95

ITEM PART NUMBER
1 W7004962
2 W7004963
3 W7003033
4 W7004970
5 W7004969
6 W7004905
7 W7004906
8 7977036
9 W7004947
10 W7003010
11 W7003215
12 W7004909
13 W7004955
14 W7004942
15 W7003053
16 W7004911
17 W7004912
18 W7004975
19 W7004976
20 W7004922
21 W7004977
22 W7004966
23 W7004925
24 W7004967
25 W7004978
26 W7004928
27 870734
28 W7004972
29 W7004957
30 W7004953
31 OTWAK/1S
32 W7004961
33 W7004940
34 W7004968
35 W7004979
36 W7004982
37 9-0025
38 W7004973
39 W7004974
40 W7004960
41 W7004951
42 W7004943
43 W7004983
Manual 0-5191
FABRICATOR 181i POWER SOURCE SPARE PARTS
PCB,Power,181i
PCB,Control,181i
Solenoid,Valve,24VDC
PCB,Display,181i
PCB,Remote Interface,181i
Wiredrive Assy,w/ Motor,181i
Feedroll retaining thumb screw
Feed Roll .024(0.6mm)-.030"(0.8mm) V groove Installed
Fan,24VDC,4.75"x4.75"x1",181i
Rectifier Bridge,1000V,50A
Connector,Gas Inlet,5/8"-18UNF
Dinse,Socket,181i
Connector,Dinse,181i
Socket,8 Pin,w/ Harness
Switch,On/Off,250V
CT Sensor,Output,181i
Wire Hub Assy,181i
Panel, Front
Panel, Rear
Handle,181i
Side and Top Panels (not shown)
Adapter,Tweco 4,181i
Guide,Inlet,.023-.045,181i
Guide,Inlet,.023-.045,181i
Panel,Door (not shown)
Panel,Base,181i
Knob,1/4" IDx.72" ODx.9" H
Knob,1/4" IDx1" ODx0.9" H
Panel,Front Control,181i
Push Button Actuator
Screw,Locking,MIG Gun
Thermistor,NTC,K45 47K,181i
PCB Burnback Potentiometer
PCB,Spool Gun,181i
Fuse Holder,181i
Fuse,10 Amp
Power Cord,12AWG,NEMA 6-50P (not shown)
Label,Setup Chart,181i,English (not shown)
Label,Setup Chart,181i,French (not shown)
Inductor,181i (not shown)
Spool Hub,181i
Switch,250V/2A,181i
Shoulder strap, 181i (not shown)
Table 6-2
6-3
Fabricator 181i
DESCRIPTION
KEY SPARE PARTS
