Federal regulations require ceiling fans
with light kits manufactured or imported
after January 1, 2009, to limit total
wattage consumed by the light kit to
190W.
Therefore, this fan is equipped
with a wattage limiting device.
Installation Guide
For Models:
CEN54BCH5
CEN54BNK5
E192641
net weight of fan: 22.93 lb (10.4 kg)
READ THESE INSTRUCTIONS AND
AND SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 7
Blade Assembly. pg. 7
Wall Control Operation. pg. 9
Remote Control Operation. pg. 10
Testing Your Fan. pg. 10
Troubleshooting. pg. 11
Warranty. pg. 11
Parts Replacement. pg. 11
PRINTED IN CHINA
Advertisement
Table of Contents
Related Manuals for Ellington CEN54BCH5
Summary of Contents for Ellington CEN54BCH5
-
Page 1: Table Of Contents
190W. Therefore, this fan is equipped with a wattage limiting device. Installation Guide For Models: Table of Contents: CEN54BCH5 Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 CEN54BNK5 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure 7 feet inches that the hanging location allows the blades a (2.13 m) (76 cm) clearance of 7 feet (2.13 m) from the floor and 30 in (76 cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12 ft. -
Page 5: Fan Assembly. Pgs
5. Fan Assembly If you wish to extend the hanging length of your fan, you must remove the hanging ball from the set screw set screw hole 6in. downrod provided to use with an extended stop pin downrod (sold separately). [If you wish to use the 6in. downrod, please proceed to instructions following the dotted line below.] hanging ball... - Page 6 5. Fan Assembly. (cont.) safety cable loop With the hanging bracket secured to the wood outlet box and able to support the fan, you are ceiling joist now ready to hang your fan. Grab the fan wood screw firmly with two hands. Slide downrod through and washer opening in hanging bracket and let hanging ball rest on the hanging bracket.
-
Page 7: Wiring
6. Wiring ground (green or bare) white supply wire CAUTION: Be sure outlet box is properly grounded black supply wire and that a ground wire (GREEN or Bare) is present. Make sure all electrical connections comply with ground (green Local Codes or Ordinances and the National or bare) blue Electrical Code. -
Page 8: Canopy Assembly
7. Canopy Assembly. antenna hanging bracket Temporarily raise canopy to hanging bracket to determine which 2 screws in hanging bracket align with slotted holes in canopy, and then lower canopy and partially loosen these 2 screws. Remove the other 2 screws and set aside. Now, lift canopy to hanging bracket again, canopy aligning slotted holes in canopy with loosened... -
Page 9: Assembly Of Lights, Upper And Lower
9. Assembly of Lights, Upper and Lower. Remove 1 screw on fitter plate (on underside of motor assembly motor assembly) and loosen the other 2 screws. Turn motor housing so that the posts are facing down. Align slotted holes in center of motor housing with loosened screws on fitter plate, allowing the male plug from motor assembly to come through hole in middle of motor housing. -
Page 10: Automated Learning Process./ Activating Code
10. Automated Learning Process./ Activating Code. TRANSMITTER (back) switches CAUTION: The remote control transmitter can be programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. Remove battery cover on back side of remote control transmitter. -
Page 11: Remote Control Operation
12. Remote Control Operation. HI button - turns fan to HIGH speed MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed REV button - used to REVERSE blade direction (fan must be set on low before reversing blade direction) OFF button - turns fan OFF button - pushing TOP of button turns upper light ON/OFF and pushing BOTTOM of button turns lower... -
Page 12: Troubleshooting
Return fan, shipping prepaid, to 4. Verify that receiver is wired properly. Craftmade/Ellington. We will repair or ship you a 5. Verify that fan is wired properly. replacement fan, and we will pay the return shipping cost.
