Installation Guide

For Models:

WOD52ABZ5X

WOD52BK5X

WOD52BR5X

WOD52CS5X

WOD52EV5X

WOD52GV5X

WOD52MBK5X

WOD52WW5X

FOR WET LOCATIONS

E192641

net weight of fan: 15 lbs. (6.8 KG)

READ THESE INSTRUCTIONS

AND SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the WOD52ABZ5X and is the answer not in the manual?

Questions and answers

Summary of Contents for Ellington WOD52ABZ5X

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Models: WOD52ABZ5X Table of Contents: WOD52BK5X Safety Tips. pg. 1 WOD52BR5X Unpacking Your Fan. pg. 2 WOD52CS5X Parts Inventory. pg. 2 Installation Preparation. pg. 3 WOD52EV5X Hanging Bracket Installation. pg. 3 WOD52GV5X Fan Assembly.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. Read all instructions and safety information carefully before installing your fan and save these instructions.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) clearance of 7ft. (2.13m) from the floor and 30in. (2.13m) (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 12ft.
Page 5: Fan Assembly (With Downrod)
5. Fan Assembly (with downrod). If you wish to extend the hanging length of set screw hole your fan, you must remove the hanging ball set screw from the 4-inch downrod provided to use with stop pin an extended downrod (sold separately). [If you wish to use the 4-inch downrod, please proceed to instructions following the dotted line below.] To remove hanging ball, loosen set screw on...
Page 6: Fan Assembly. Pgs
5. Fan Assembly (with downrod). (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging hanging bracket tab bracket and let hanging ball rest on the hanging hanging ball slot...
Page 7: Wiring
7. Wiring. white supply wire ground (green or bare) Important: Be sure outlet box is properly grounded or that a black supply wire ground wire (GREEN or Bare) is present. Make sure all electrical connections comply with Local from ceiling Codes or Ordinances and the National Electrical Code.
Page 8: Blade Assembly
9. Blade Assembly. motor housing Time Saver: Washers for blade screws can be set on each blade screw prior to installing blades. Locate 15 blade attachment screws and washers in one of the hardware packs. Hold blade arm up blade to blade and align holes.
Page 9: Light Kit Assembly (Optional)
11. Light Kit Assembly (Optional). motor housing WARNING: Failure to disconnect power supply at main panel prior to light kit assembly may result in serious injury. switch housing If you wish to use your fan WITH a light kit (sold blue wire white wire separately), it MUST be UL-APPROVED for WET...
Page 10: Troubleshooting
Warranty. WARNING: Failure to disconnect power Ellington 30-Year Limited Warranty: supply prior to troubleshooting any wiring issues may ELLINGTON/LITEX INDUSTRIES, LTD. warrants this fan to the result in serious injury. original household purchaser for indoor use under the following provisions: Problem: Fan fails to operate.
