Compass Model 7HV Instruction Manual page 5

This model is packed according to assembling steps. Do not open all the bags at one time.
Frame Set
Step 3
Motor Set
Linkages
Mishandling due to failure to follow these instructions may result in damage, personal injury or danger.
Use Blue Threadlock
Use Grease
Use AB Glue
Use Bearing Retainer
* Always apply blue Threadlock when fixing Bolts on Metal parts.
* Always apply green retainer where bearings has to be fit into metal parts.
* Do not over-tighten self tapping screws into plastic parts or you will strip the threads!
In The Box
Open only one bag for each step of assemply when building.
Step 1
Tail Set
Rotor Set
Blades
Symbols & Assembling
Step 2
Step 4
Swash Set
Canopy
