- Page 1 MIO DEC Analog video to SDI converter User Manual V1.0 www.gefei-tech.com [Gefei Tech.Co.,Ltd]...
-
Page 2: Table Of Contents
Table of Content Ⅰ Description ..........................1 Ⅱ Interfaces on the panel ......................2 2.1 Overview ......................2 2.2 Right panel ......................2 2.3 Left panel ......................3 2.4 Front panel ......................3 Ⅲ Technical Specifications: ......................6 Ⅳ Contact Us ..........................7... - Page 3 Copyright Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech， Magi， MIO， VIO， XIO， MVS， MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 4: Ⅰ Description
MIO DEC Ⅰ Description Based on Mini BOX platform, MIO DEC is a small converter which can convert analog video to serial digital video signal. The SDI output can be converted from analog composite video signal, analog component video signal, or S-video signal by simple mode switch. And it supports the input format of 576i 50 and 480i 60. -
Page 5: Ⅱ Interfaces On The Panel
MIO DEC analog video to SDI converter User manual Ⅱ Interfaces on the panel 2.1 Overview Load Default: Insert a thin thing though the hole and press the button to restore the default settings. The default parameters: auto gain, CVBS input, PAL standard. -
Page 6: Left Panel
MIO DEC analog video to SDI converter User manual left), others are invalid; ii. When analog component signal is selected, the input interfaces from left are Y signal, R-Y signal, and B-Y signal; iii. When analog S video signal is selected, the input interfaces from left are Y, C, and the third interface is invalid. - Page 7 MIO DEC analog video to SDI converter User manual DIP switch： Auto gain Adjustment CVBS Adjustment input Analog video Adjustment input input Adjustment input Remarks: Power switch DOWN =ON UP=OFF DIP indicates by 10 figures: The NO. 1 indicates manual or automatic configuration. Place it at ON, the device is under manual status, it can configure the function by setting the DIP switch;...
- Page 8 MIO DEC analog video to SDI converter User manual Note: 1. When user sets the DIP switch, only if the NO. 1 and NO.10 are at ON, can the DIP switch takes effect. Others (No.2-4) are reserved without any use in this product.
-
Page 9: Ⅲ Technical Specifications
MIO DEC analog video to SDI converter User manual Ⅲ Technical Specifications: Analog video input: Input interface: 3*BNC connection (Selectable CVBS/YUV/YC input model) Impedance: 75Ω System: PAL/NTSC Max cable length: ≤200 (Belden 8281) Digital video output: Output interface: 2*SDI, BNC connection Impedance: 75Ω... -
Page 10: Ⅳ Contact Us
MIO DEC analog video to SDI converter User manual Ⅳ Contact Us Technical support Tel:010-58858188 Fax:010-58858189 Website www.gefei-tech.com E-mail：support@gefei-tech.com Address Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd. Haidian District Beijing 100085 To Find More information , please visit www.gefei-tech.com...
