- Page 1 MIO AV-AViewer User Manual V1.0 www.gefei-tech.com [Gefei Tech.Co.,Ltd]...
- Page 2 Copyright Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 3: Table Of Contents
Table of Contents Product Description ......................... 1 Features ............................1 Panel Description ..........................2 Left Panel ........................... 2 Right Panel ..........................3 Buttons Definition ........................3 Special Notice ..........................4 How to Use the Remote Control Software ................... 6 Attention before use ........................6 Introduction of Web Control ...................... - Page 4 Waveform Display ....................14 Disable OSD (Full screen) ..................15 Layout management ....................15 Alarm Settings ......................... 17 Audio Detection ...................... 18 Video Detection....................... 19 Status of Video and Audio ....................20 User Configuration ......................21 Network Configuration ....................22 Change IP address ....................
-
Page 5: Product Description
Provide on-screen display: input formats, safe marker Mini box structure easily installed inside frame racks, video walls and so on Widely used in broadcasting system, studios and other professional fields Gefei Tech. Co., Ltd 1 / 29... -
Page 6: Panel Description
1024x768x60p, 1280x720x50p/60p 1280x768x60p, 1280x800x60p 1280x1024x60p, 1360x768x60p 1400x1050x60p, 1600x900x60p 1680x1050x60p, 1920x1080x50i/60i 1920x1080x50p/60p, AUTO HDMI Network: RJ45 interface with 10/100/1000M auto-detection. And the default IP address is 192.168.1.76. The web server is remote control interface. Gefei Tech. Co., Ltd 2 / 29... -
Page 7: Right Panel
Support input formats as below NTSC,PAL L-IN & R-IN：RCA interface, 1 analog audio stereo signal input Buttons Definition Resolution/ Default: Using a push pin to short press the button, the output resolut ion Gefei Tech. Co., Ltd 3 / 29... -
Page 8: Special Notice
IP address of Mini box is in the same network segment as your computer. And the IP and Mac address of Mini box are unique value in Ethernet. User can also upgrade system under the label “Network”. Before the upgrade, the Gefei Tech. Co., Ltd 4 / 29... - Page 9 MIO AV- AViewer system without reject ion. Power and network cannot be cut off during upgrading. Gefei Tech. Co., Ltd 5 / 29...
-
Page 10: How To Use The Remote Control Software
OSD: Configuration of UMD display, Audio meters, AFD information display, Safe Marker, Waveform, and Layout management. Alarm: The system supplies detection of audio, mute, frame frozen, black, signal loss. Each alarm threshold can set to meet your needs. Gefei Tech. Co., Ltd 6 / 29... -
Page 11: Audio & Video
Help: Show the versions of each firmware here. Audio & Video Input Source You can choose input source between Cable and Fiber. So far, only the type of BNC cable is available. Gefei Tech. Co., Ltd 7 / 29... -
Page 12: Output Resolution
Video Display Mode There are two types of video display: Full channel and Original Ratio. Full channel means the video image will cover the entire window and ignore the aspect ratio of video signal. Gefei Tech. Co., Ltd 8 / 29... -
Page 13: Color Parameters
Select audio channels from analog audio to embed into HDMI signal. It supports eight audio channels for HDMI signal. The drop-down list is shown as following. Off/ CH1&2 “Off” option means no audio signal is embedded into the selected channels of HDMI signal. Gefei Tech. Co., Ltd 9 / 29... -
Page 14: Osd Parameters
(AM4) on the right side. Left Side: AM1, AM2, AM3, and AM4 are all located on the left side of screen. Right Side: AM1、AM2、AM3、AM4 are all located on the right side of screen. Gefei Tech. Co., Ltd 10 / 29... -
Page 15: Editable Program Umd
The picture that you need to upload must be 32bits TGA format with Alpha channel. The size of picture is 720x60 pixels Check/ uncheck UMD Check the box “UMD”. It will be shown within the channel, otherwise, not. Gefei Tech. Co., Ltd 11 / 29... -
Page 16: Attach Umd And Audio Meters To Edge
0 to 100, and then press “Enter” on keyboard. “0” stands for full transparency and “100” stands for opacity. Tally Display This function is reserved so far. Safe Marker Line: Marker showed with lines Mask: block the image with Mark Gefei Tech. Co., Ltd 12 / 29... -
Page 17: Input Format
0 to 100, and then press “Enter” on keyboard. “0” stands for full transparency and “100” stands for opacity. Input Format Check the box, and input resolution/format will be overlaid on the top of the screen, otherwise, not. 1080i 60 Input Resolution Gefei Tech. Co., Ltd 13 / 29... -
Page 18: Waveform Display
They are “None”, “Y+PbPr+Vector”, and “Y+Audio Waveform/Phase”. Y+PbPr+Vector Y Waveform PbPr Waveform Vector Y+Audio Waveform/Phase Y Waveform Audio Waveform of two channels Audio Phase of two channels None: No waveform on the screen Gefei Tech. Co., Ltd 14 / 29... -
Page 19: Disable Osd (Full Screen)
Uncheck the box, the checked elements appear on the screen. Meanwhile, the status of each on-screen-display element can be set individually. Layout management All configured parameters can be saved as a template. System provides up to four templates for quick application of different occasions. Gefei Tech. Co., Ltd 15 / 29... - Page 20 Click the template which is saved already, and a message box appears to show the status of its each parameter. You can apply the template, or delete the template. After you change its parameters, even its name, press “Save” button to submit the new data. Gefei Tech. Co., Ltd 16 / 29...
-
Page 21: Alarm Settings
: Restore Factory Setting The video and audio signal can report signal status and validity, with detection of: (1) Video lose (2) Video black (3) Video frozen (4) Audio overload (5) Audio in silence Gefei Tech. Co., Ltd 17 / 29... -
Page 22: Audio Detection
It will prompt an alarm picture as soon as the audio level lowers the threshold you settled. It provides 8 audio channels detect ion. And there is a box in front of each audio Gefei Tech. Co., Ltd 18 / 29... -
Page 23: Video Detection
It will prompt an alarm picture as soon as video level is lower the threshold. This detection will take effect only if the box is checked. The duration of detection can be configured. Gefei Tech. Co., Ltd 19 / 29... -
Page 24: Status Of Video And Audio
“Yes”. If audio value of one channel is below -70dBfs, the status of the audio channel is mute marked as “None” So far, audio G1 and G2 of input source can be detected, and G3 and G4 are not. Gefei Tech. Co., Ltd 20 / 29... -
Page 25: User Configuration
000000 (Six zeros). Users can modify the password; maximum password length is 12 bits. When you modify the password successfully, information will prompt as "The password is altered successfully. It will take effect when you login next time." Gefei Tech. Co., Ltd 21 / 29... -
Page 26: Network Configuration
Configure the “Manager IP” to be the local IP address of SNMP Server. The Server and MIO mini box should be in the same network segment. And Trap common and Trap port are for SNMP. Do not change them. Gefei Tech. Co., Ltd 22 / 29... -
Page 27: Upgrade Firmware Of System
Power and network cannot be cut off during upgrading. When system is upgraded successfully, please turn off the power and restart the device again. It takes about 5 minutes to upgrade main DSP or font. Gefei Tech. Co., Ltd 23 / 29... -
Page 28: Specifications
1400x1050x60p, 1600x900x60p, 1680x1050x60p 1920x1080x50i/60i, 1920x1080x50p/60p, AUTO HDMI (EDID) Ethernet Control 1 x RJ45, 10/100/1000M adaptive Status Indicator Input signal status indicator Power indicator (Indicate by shining or extinguishing of the green LED) Dimension Gefei Tech. Co., Ltd 24 / 29... - Page 29 MIO AV- AViewer User Manual V1.0 Gefei-tech 120x98x27mm Power 12V 1A Gefei Tech. Co., Ltd 25 / 29...
-
Page 30: Contact Us
MIO AV- AViewer User Manual V1.0 Gefei-tech Contact Us Technical support: Tel:010-58858188 Fax:010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address: Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd.Haidian District Beijing 100085 To Find More information, please visit www.gefei-tech.com Gefei Tech. Co., Ltd 26 / 29...
