Page 1: User Manual
MIO HDSDI-HDMI HDSDI to DVI (HDMI) Converter User Manual www.gefei-tech.com [Gefei Tech. Co., Ltd]... - Page 2 Copyright Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 3: Table Of Contents
Contents Product Description ..........................1 Features ................................1 MIO HDSDI-HDMI panel Introduction....................2 Application ..............................4 How to Connect the MIO HDSDI-HDMI Converter System ............4 Technical specifications .........................5 Contact Us ..............................8... -
Page 4: Product Description
MIO HDSDI-HDMI User Manual Product Description MIO HDSDI-HDMI is a miniature high quality converter, from HD/SD signal to DVI (HDMI) which can be easily connected to LCD or PDP. It supports HD/SDSDI with embedded audio. provides automatic input detection, and supports a wide variety of input formats (720p, 1080i, 1080p) and the output resolution is up to 1080p 60. -
Page 5: Mio Hdsdi-Hdmi Panel Introduction
Gefei-tech MIO HDSDI-HDMI User Manual MIO HDSDI-HDMI panel Introduction MIO HDSDI-HDMI right panel interface HDSDI-IN: Cable with BNC interface. Support various resolutions. SD: 480i 60, 576i 50 HD：720P 50/59.94/60, 1080I 50/59.94/60, 1080P 30/29.97/25/24/23.98 1080P 50/60 © Gefei Tech. Co., Ltd... - Page 6 Gefei-tech MIO HDSDI-HDMI User Manual LOOP: Loop out the data from HDSDI-IN. MIO HDSDI-HDMI left panel interface HDMI/DVI-OUT: Support digital DVI or HDMI signal output with a female DVI-I interface. Power jack: standard power, 12V, 1A © Gefei Tech. Co., Ltd...
-
Page 7: Application
MIO HDSDI-HDMI User Manual Application How to Connect the MIO HDSDI-HDMI Converter System 1. Connect the MIO HDSDI-HDMI converter (interface marked as HDSDI-IN) to the HD-SDI source device. 2. Connect MIO HDSDI-HDMI converter (interface marked as HDMI/DVI-OUT) to the DVI/HDMI display device, and you need a HDMI-to-DVI adapter if display device uses HDMI interface. -
Page 8: Technical Specifications
Gefei-tech MIO HDSDI-HDMI User Manual Technical specifications Dimension 120x98x27mm Power 12 V 1A Video Input Connector： 1* BNC Impedance： 75 ohms Input：SD: 576i/50, 480i/59.94 HD: 720p 50/59.94/60 1080i 50/59.94/60; 1080p30/29.97/25/24/23.98; 1080p50/59.94/60; Format: SMPTE 259M-C；270Mb/s SMPTE-292M；1.485Gps SMPTE-425；2.970Gps Length: up to 100m (Belden 1694A) ©... - Page 9 Gefei-tech MIO HDSDI-HDMI User Manual Video Output Connector： 1*SD/HD-SDI Loop output 1*DVI-I (digital signal), female Format: SMPTE-259M-C；270Mb/s SMPTE-292M；1.485Gps SMPTE-425；2.970Gps Level: 800mV±10% Rise time/Fall time: ≤270PS（20%-80%）(HD) ≤1500PS（20%-80%）(SD) Jitter: <0.2UI (100 kHz) © Gefei Tech. Co., Ltd 6 / 7...
-
Page 10: Device List
Gefei-tech MIO HDSDI-HDMI User Manual Device List Name Specification Quantity Remark MIO HDSDI-HDMI HD-SDI TO DVI (HDMI) AC-DC Power 12VDC 1A Total Accessories List Name Specification Quantity Remark Video Cable ----------- ----------- Audio Cable ----------- ----------- Power Cable ----------- ----------- User’s Manual (or Disk) -
Page 11: Contact Us
Gefei-tech MIO HDSDI-HDMI User Manual Contact Us Technical support: Tel: 010-58858188 Fax: 010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address: Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd.Haidian District Beijing 100085 To find more information, please visit www.gefei-tech.com © Gefei Tech. Co., Ltd...
