- Page 1 MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual V1.0...
-
Page 2: Table Of Contents
Table of Content Ⅰ Description ..............................1 Ⅱ Features ................................1 Ⅲ MMIO DEMUX-HDSDI-4AES interface display ..................2 3.1 Overview ..............................2 3.2 Left panel ..............................2 3.3 Right panel..............................3 3.4 Front panel .............................4 Ⅳ Technical specification..........................7 Ⅴ Contact ................................9... - Page 3 Copyright Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 4: Ⅰ Description
MMIO DEMUX-HDSDI-4AES Ⅰ Description MMIO DEMUX-HDSDI-4AES is a kind of de-embedder based on Mini-Box chassis. It can extract four AES digital audio signal from a single serial digital signal. It supports SD-SDI, 1.5 Gbps HD-SDI and 3.0 Gbps HD-SDI for inputs and outputs. -
Page 5: Ⅲ Mmio Demux-Hdsdi-4Aes Interface Display
MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual Ⅲ MMIO DEMUX-HDSDI-4AES interface display 3.1 Overview 3.2 Right panel LOOP SDI IN ： 12V 1A DC IN ： Power indicator, when the power works normally, the indicator shows green. -
Page 6: Left Panel
MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual ： BNC interface, digital signal input with embedded audio, support 3G/HD/SD IN the SD-SDI, HD-SDI, and 3G-SDI. SD: 525i 60, 625i 50 HD: 720p 50Hz/59.94Hz/60Hz 1080i 50Hz/59.94Hz/60Hz 1080p 23.97Hz/24Hz/25Hz/29.97Hz/30Hz 1080p 50 Hz/59.94Hz/60 Hz ：BNC interface, support bypass SDI input with power on. -
Page 7: Front Panel
MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual 3.4 Front panel MODE SET: DIP Switch, users can set DIP position to achieve more functions, the DIP specific meaning as following: DIP Switch Silence G1 &G2 G3 &G4 Select de-embedded G2 &G3... -
Page 8: Installation Guide
MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual Ⅳ Installation Guide The unit is equipped with mini mounting bracket. And there are several screw holes on the bottom of unit for installing the mini bracket. Please see the pictures below. - Page 9 MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual Use these two screw holes to fix bracket to case. Use screw hole to fix unit to rack or back of monitor. 6 / 9...
-
Page 10: Ⅳ Technical Specification
MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual Ⅴ Technical specification Digital video input: Input interface: 1*HD/SD-SDI, BNC connection Impedance: 75Ω Format: SMPTE-259M-C；270Mb/s SMPTE-292M；1.485Gps SMPTE-425；2.970Gps Analog audio Output: Output interface: 2*3pin Impedance: 600Ω Digital video output: Output interface:... - Page 11 MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual Status indicator: Input signal status indicator Power indicator (Indicate by shining or extinguishing of the green LED) Power consumption: Power: 12VDC 1.5A Dimension: 123mm*92mm*29mm 8 / 9...
-
Page 12: Ⅴ Contact
MMIO DEMUX-HDSDI-4AES 3G/HD/SD Signal & AES Audio De-embedder User manual Ⅴ Contact Technical support Tel: 010-58858188 Fax: 010-58858189 Website: www.gefei-tech.com E-mail：swang@gefei-tech.com Address Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd. Haidian District Beijing 100085 To find more information, please visit www.gefei-tech.com...
