- Page 1 MMIO HDMI-HDSDI HDMI to HD Converter User Manual V1.4 www.gefei-tech.com [Gefei Tech. Co., Ltd]...
- Page 2 Copyright Copyright © 2009 Gefei Tech. Co., Ltd all rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 3: Table Of Contents
Contents Product Description ..........................1 Features ................................1 Interfaces on the Panel ...........................2 Top View ..............................2 Installation Guide ............................5 Technical specifications .........................7 Contact Us ..............................10... -
Page 4: Product Description
HDM to HD/SD SDI with embedded audio. It provides automatic input detection and supports a wide variety of input formats (720p, 1080i, 1080p). The max resolution is up to 1080p 60.MMIO HDMI-HDSDI is a cost-effective device used in the professional and non-professional fields. -
Page 5: Interfaces On The Panel
DC IN: 12V 1A. Power socket with fixing lock PWR：Power indicator, the indicator shows green when the power works normal. IN：Signal input indicator, the indicator shows green when the input signal is in normal © Gefei Tech. Co., Ltd 2 /10... - Page 6 R-IN MODE SET HDMI IN: HDMI interface. Support HDMI signal with embedded audio, and various input resolutions as below: Video Format: 480i 60, 576i 50 720p 50/59.94/60 1080i 50/59.94/60 1080P 25/24/23.98 1080P 50/59.94/60 © Gefei Tech. Co., Ltd 3 /10...
- Page 7 1 analog audio stereo signal input MODE SET: DIP switch, users can set DIP position to achieve more functions, the DIP specific meaning as following: DIP Switch Function Add external audio Auto HDMI audio © Gefei Tech. Co., Ltd 4 /10...
-
Page 8: Installation Guide
Use screw hole to fix unit to rack or back of monitor. Mini Converter HDMI to HDSDI Use these two screw holes to fix bracket to case. Fix the bracket horizontally like thiSs: © Gefei Tech. Co., Ltd 5 /10... - Page 9 MMIO HDMI-HDSDI Use these two screw holes to fix bracket to case. Use screw hole to fix unit to rack or back of monitor. © Gefei Tech. Co., Ltd 6 /10...
-
Page 10: Technical Specifications
Power Video Input Interface: HDMI In, Format: Video Format: SD：625i 50, 525i 60; HD：720P 50/59.94/60, 1080I 50/59.94/60, 1080P 25/24/23.98 1080P 50/59.94/60 Graphic resolution: 1280x720x50p, 1280x720x60p, 1920x1080x24p 1920x1080x25p, 1920x1080x50p ,1920x1080x60p Audio Input Interface: 2*RCA © Gefei Tech. Co., Ltd 7 /10... - Page 11 MMIO HDMI-HDSDI Video Output Connector：2*BNC 75 ohm Impedance: 75Ω Format: SMPTE-259M-C；270Mb/s SMPTE-292M；1.485Gps SMPTE-425；2.970Gps Level: 800mV±10% Rise time/Fall time: ≤270PS（20%-80%）(HD) ≤1500PS（20%-80%）(SD) Jitter: <0.2UI (100 kHz) © Gefei Tech. Co., Ltd 8 /10...
- Page 12 HDMI TO HDSDI AC-DC Power 12VDC 1A Total Accessories List Name Specification Quantity Remark Video Cable ----------- ----------- Audio Cable ----------- ----------- Power Cable ----------- ----------- User’s Manual (or Disk) Others otic placode Screw Total © Gefei Tech. Co., Ltd 9 /10...
-
Page 13: Contact Us
Contact Us Technical support: Tel: 010-58858188 Fax: 010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address: Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd.Haidian District Beijing 100085 To find more information, please visit www.gefei-tech.com © Gefei Tech. Co., Ltd 10 /10...
