- Page 1 MMIO VDA Analog video Distribution User Manual V1.0 www. gefei-tech.com [Gefei Tech. Co., Ltd]...
-
Page 2: Table Of Contents
Table of Content Description ...............................1 Features ..............................1 Interfaces on the panel ........................2 Top View ............................2 Right panel ............................2 Left panel............................3 Installation Guide............................4 Technical Specifications:........................6 Contact Us ................................7... - Page 3 Copyright Copyright © 2013 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 4: Description
MMIO VDA analog video distribution 1. Description Based on Mini MIO BOX platform, MMIO VDA is a high-quality distribution which can distribute one analog video to four analog video outputs, the mini-size unit of 96.7x65x28 mm. And the device supports CVBS input signal and automatic input detection of PAL and NTSC format. -
Page 5: Interfaces On The Panel
MMIO VDA analog video distribution User manual 3. Interfaces on the panel 3.1 Top View 3.2 Right panel CVBS IN CVBS OUT4 DC IN： 12V 1A. Power socket with fixing lock Indicators PWR：Power indicator, the indicator shows green when the power works normal. -
Page 6: Left Panel
MMIO VDA analog video distribution User manual IN：Signal input indicator, the indicator shows green when the input signal is in normal status. Signals CVBS IN: BNC interface. It supports PAL/NTSC input source and auto-detection of input signal. CVBS OUT4: BNC interface. It’s one of four distribution outputs. -
Page 7: Installation Guide
MMIO VDA analog video distribution User manual 4. Installation Guide The unit is equipped with mini mounting bracket. And there are several screw holes on the bottom of unit for installing the mini bracket. Please see the pictures below. 24mm 61.5mm... - Page 8 MMIO VDA analog video distribution User manual Fix the bracket horizontally like this: Use these two screw holes to fix bracket to case. Use screw hole to fix unit to rack or back of monitor. © Gefei Tech. Co., Ltd...
-
Page 9: Technical Specifications
MMIO VDA analog video distribution User manual 5. Technical Specifications: Input Analog video input: Input interface: CVBS, BNC connection Impedance: 75Ω System: PAL/NTSC Output Analog video output: Output interface: CVBS, BNC connection Impedance: 75Ω Signal amplitude: 1Vpp Peak level: 0.7V Horizontal sync. -
Page 10: Contact Us
Technical support Tel:010-58858188 Fax:010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd. Haidian District Beijing 100085 To Find More information , please visit www.gefei-tech.com © Gefei Tech. Co., Ltd 7 / 7...
