- Page 1 MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Audio Embedder User manual V1.0 www.gefei-tech.com [Gefei Tech.Co.,Ltd]...
-
Page 2: Table Of Contents
Table of Content I. Description ...............................1 II. Features ................................1 III. Interface Description ..........................2 3.1 Overview ...............................2 3.2 Right panel ............................2 3.3 Left panel ..............................3 3.4 Front panel ............................3 Ⅳ Installation Guide ............................5 IV. Technical specification ...........................7 V. Contact ................................9... - Page 3 Copyright Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 4: Description
MMIO EMB-HDSDI-2AES Description MMIO EMB-HDSDI-2AES is a kind of embedder based on Mini-Box chassis. It can embed two AES digital audio signal into a single serial digital signal, and output one serial digital signals with embedded audio. It supports SD-SDI, 1.5 Gbps HD-SDI and 3.0 Gbps HD-SDI for inputs and outputs. -
Page 5: Interface Description
MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder III. Interface Description 3.1 Overview 3.2 Right panel LOOP SDI IN ： 12V 1A DC IN ： Power indicator, when the power works normally, the indicator shows green. ： Input signal indicator, when the input signal is correct, the indicator shows green. -
Page 6: Left Panel
MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder SD-SDI, HD-SDI, and 3G-SDI. SD: 525i 60, 625i 50 HD: 720p 50Hz/59.94Hz/60Hz 1080i 50Hz/59.94Hz/60Hz 1080p 23.97Hz/24Hz/25Hz/29.97Hz/30Hz 1080p 50 Hz/59.94Hz/60 Hz ：BNC interface, it support loop function with power on. LOOP 3.3 Left panel... - Page 7 MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder DIP Switch Silence Select embedded audio channel AUTO Note: Power switch UP=OFF DOWN=ON When two AES digital audio signals are embedded to eight certain channels of HD/SD-SDI signal, the other eight audio channels will have no audio any more. For instance, when embedding two AES digital audio to G1, and then G2 will have no audio any more.
-
Page 8: Ⅳ Installation Guide
MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder Ⅳ Installation Guide The unit is equipped with mini mounting bracket. And there are several screw holes on the bottom of unit for installing the mini bracket. Please see the pictures below. - Page 9 MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder Use these two screw holes to fix bracket to case. Use screw hole to fix unit to rack or back of monitor. 6 / 9...
-
Page 10: Technical Specification
MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder IV. Technical specification Digital video input: Input interface: 1*HD/SD-SDI, BNC connection 75Ω Impedance: Format: SD: 525i 60, 625i 50 HD: 720p 50Hz/59.94Hz/60Hz 1080i 50Hz/59.94Hz/60Hz 1080p 23.97Hz/24Hz/25Hz/29.97Hz/30Hz 1080p 50 Hz/59.94Hz/60 Hz SMPTE-259M-C；270Mb/s SMPTE-292M；1.485Gps... - Page 11 MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder Rise time/Fall time: ≤270PS（20%-80%）(HD) 750~1500PS（20%-80%）(SD) Jitter: <0.2UI (100 kHz) Status indicator: Input signal status indicator Power indicator (Indicate by shining or extinguishing of the green LED) Power consumption: Power: 12VDC 1A...
-
Page 12: Contact
MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder V. Contact Technical support Tel: 010-58858188 Fax: 010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd. Haidian District Beijing 100085 To find more information, please visit www.gefei-tech.com...
