NAME AND FUNCTION OF COMPONENTS
FUNCTIONS OF COMPONENTS
Main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . Start the engine or stall the engine with this switch by means of
Accelerator lever . . . . . . . . . . . . . . . . . . . . . . . Increases and decreases engine speed.
Choke lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . When the lever is pulled, the choke valve closes, and when it is
HST lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . The HST lever changes the discharge of the hydraulic pump in the
AUX. speed change lever . . . . . . . . . . . . . . . Use this lever when shifting speed to high/low levels.
Brake pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . Use to stop the machine.
Differential lock lever . . . . . . . . . . . . . . . . . . Use this lever when slipping one side of the rear wheels.
Light switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . Headlamp is turned on when switch is pulled.
Parking brake lock lever . . . . . . . . . . . . . . . . After stopping the machine, pull the lock lever downward to lock
Blade height adjusting lever . . . . . . . . . . . . . . Adjusts the height of blade (5 steps)
Blade clutch lever . . . . . . . . . . . . . . . . . . . . . . Turns on and off the power of blade.
Grass outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . Secure area around machine before opening. Opening outlet allows
remote control.
When the machine is not used remove and keep the key.
returned, the choke valve opens. Pull the lever when starting the
engine and return it after the engine is started.
(In the case of CM1305, the choke lever is connected with the accel-
erator lever.)
HST and changes the advancing direction and travelling speed in a
stepless way.
When pushing the lever forward from neutral position the machine
starts to move forward. Pulling the lever in reverse makes machine
drive backward. Speed increases as lever is depressed in either direc-
tion.
Speed shift can be used while driving.
When depressing brake pedal HST lever returns to neutral and stops
the machine.
When lever is pushed to "ON", the differential lock is engaged.
When lever is "OFF", the differential lock is released (normal driving
position).
During normal driving always put the lever to "OFF" position.
brake pedal.
When putting this lever to "OFF" position, the cutter brake pulley is
engaged and the brake is applied.
cut grass to be easily removed. Open outlet when changing cutter
blade.
Outlet should be closed during normal use to prevent stones and
other objects from being thrown from machine.
– 10 –
