To set the event masks:
1. Access the Event Mask dialog box:
a. Select CONFIG.
b. Select EVENT MASK from the pop-up menu.
The Event Mask dialog box is displayed. See Figure 53.
2. Select the mask settings for each fault and alarm.
a. Select YES to enable the setting,
– or –
b. Select NO to disable the setting.
3. Select SAVE to keep the settings.

Figure 53 Event mask dialog box

User Settings
The User Settings choice allows you to adjust the user-accessible switch settings. Access is limited to
qualified personnel via system security.
To access the User Settings dialog box:
1. Select CONFIG.
2. Select USER SETTINGS from the pop-up menu.
The User Settings dialog box is displayed. See Figure 54. The top six buttons access a series of sec-
ondary dialog boxes to configure the various settings.
89
STS2 Touch Screen Display
