Menu Overview

The touch screen menu provides access to configuration settings and more device information.
The CONFIG (Configuration) and LOGS menus provide multiple choices through pop-up menus. The
SOURCE XFER menu selection allows you to select the preferred source. The other menu choices pro-
vide information in the display panel. The menu choices are discussed later in this manual.
All programmable functions are preset at the factory to default settings. These settings enable the
unit to be brought up without the need to enter all selectable parameters. The menus allow the set-
tings to be customized.

Figure 50 Menus

Config menu
NOTE
Some menu choices display a keyboard or keypad on the touch screen. Enter data on the
touch screen.
Click OK to save the data that you have entered.
Use the back arrow button (<-) to delete unwanted characters. This button functions like
a backspace key on a keyboard.

Figure 51 Keyboard and keypad displays

System Rating
Event Masks
User Settings
System Settings
Comm Options
System Options
System ID
Backspace
86
STS2 Touch Screen Display
Logs
Event Log
History Log 1
History Log 2
Backspace
