2.2.1
Handling Considerations
The static switch is bolted to a wooden shipping pallet to allow handling by forklift equipment or a
pallet jack.
Easily Moved — The unit is furnished with integral castors that allow the unit to be rolled into place
after it has reached its location and is removed from the pallet.
WARNING
!
Exercise extreme care when handling static switch cabinets to avoid equipment damage or
injury to personnel.
The cabinet can be safely tilted 15 degrees in any direction by forklift.
If moving the unit up a ramp on its casters or a pallet jack, ensure that the incline does not
exceed fifteen (15) degrees.
Locate the center of gravity symbols
the cabinet.
Check the unit size and weight — Refer to the cabinet drawings furnished with the unit for size
and weight. Typical cabinet dimensions are shown in Figures 5 through 7. Typical unit weights are:
100-250 amp
400-600 amp
800-1000 amp
Plan the route — Review the route over which the unit will be transported to its installation loca-
tion to ensure that all passages are large enough to accommodate the unit and support the weight.
Check for any non-negotiable corners or offsets in hallways. Before moving the unit to the intended
location, review 3.0 - Location Considerations.
2.2.2
Unit Preparation
The unit can be removed from the pallet before it is moved to its location.
Complete the following steps to properly remove the STS2 from the shipping pallet:
1. Set the pallet in a level area with enough room to maneuver and remove the unit.
2. Remove the bolts holding the unit to the shipping pallet (located in the base of the unit).
3. Remove the shipping blocks from under the frame of the unit.
4. Use a forklift to raise the unit off the pallet and onto the floor. Ensure that the forklift is clear of
the unit's casters and leveling feet. Lift the unit from the rear.
5. Conduct an internal inspection of the unit. See the list below of inspection items.
2.3
Internal Inspections
After the STS2 has been unpacked, conduct an internal inspection:
1. Verify that all items have been received.
2. If spare parts were ordered, verify their arrival.
3. After the Static Transfer Switch has been removed from the pallet, open the door and remove
cabinet panels to check for shipping damage to internal components.
4. Check for loose connections or unsecured components in the cabinet(s).
5. Check for any unsafe condition that may be a potential safety hazard.
After the STS2 has been inspected and no problems are found, the unit can be moved to its installa-
tion location. If using a forklift, remember to lift the unit from the rear.
780 lbs. (354 kg)
1200 lbs. (544 kg)
2500 lbs. (1134 kg).
and determine the unit's weight before handling
5
Unpacking and Inspections
