L200
Owner's Operating and
Maintenance Manual
For Standard Wheelchairs
INTRODUCTION
Standard wheelchairs are the result of extensive engineering research, and rigid quality assurance testing. Every new component
and finished assembled product must satisfy our high standards.
We are dedicated to maximum mobility and independence, and have developed what we believe is the finest line of wheelchairs
available, providing safety as well as comfort and function. This operating manual should help you achieve optimum safety,
performance, and confidence in your wheelchair.
Many activities require the wheelchair user to reach, bend, and transfer in and out of the wheelchair. You should be instructed in
the proper use of your chair before attempting these movements.
It is imperative that the procedures and cautions outlined in this manual be observed for your own safety. You should develop a
routine inspection and maintenance schedule and should periodically review the recommended operating techniques.
Please, read the manual thoroughly BEFORE using your wheelchair, ensure you understand the instructions and refer to it
regularly for maximum safety and performance.
We are pleased that you have chosen our wheelchair and trust it will serve you well.
BUYER'S NAME:
MODEL No.
SERIAL No.
DATE AND WHERE PURCHASED
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L200 and is the answer not in the manual?

Questions and answers

Related Manuals for Merits L200

Summary of Contents for Merits L200

  • Page 1 L200 Owner’s Operating and Maintenance Manual For Standard Wheelchairs INTRODUCTION Standard wheelchairs are the result of extensive engineering research, and rigid quality assurance testing. Every new component and finished assembled product must satisfy our high standards. We are dedicated to maximum mobility and independence, and have developed what we believe is the finest line of wheelchairs available, providing safety as well as comfort and function.

  • Page 2: Wheelchair Parts

    Wheelchair Parts Initial Inspection Checklist General ♦ ◆Wheelchair opens and closes with ease. ♦ ◆Wheelchair rolls straight ( no excessive drag ). Wheel Locks ◆Locks do not interfere with tires when rolling. ◆Locks easily engage.

  • Page 3: Folding & Unfolding The Wheelchair

    Cross braces ◆Pivot bolt secure but loose enough to keep all four wheels on ground when crossing uneven surfaces. Arms ◆Make sure arm lock pin is secured. Wheels ◆No excessive side movement or binding when lifted from ground and spun. Caster ◆Inspect axle for proper tension by spinning caster.
  • Page 4 caster off the ground) and Push downward on seat rail nearest you at seat upholstery until fully open. 2. Set both wheel locks, open the footrest/legrest for clearance, and transfer to chair. TO CLOSE： 1. Swing footrest/legrest in locked position to front of chair. 2.
  • Page 5 Individual wheelchair users are subject to various capabilities and limitations and often develop skills to overcome their disabilities in daily living activities that may differ from those described in this manual. Each individual is encouraged to try what works for him/her in overcoming architectural obstacles that the wheelchair user may encounter. The techniques described in this guide are a stating point for the new wheelchair user and attendant with “safety”...
  • Page 6 curbs METHOD1-The attendant should tilt the chair until the front casters clear the curb. Roll the chair forward and lower the front casters to the sidewalk. Push the chair forward until the rear wheels roll up and over the curb. METHOD2-The attendant should stand on the sidewalk and turn the chair so that the rear wheels are against the curb.

  • Page 7: Transferring To And From Other Seats

    and steadies it as the first attendant places one foot on the next stair and repeats the procedure. 3. The chair should not be lowered until the last stair has been negotiated and it has been rolled away from the stairway. Transferring to and from other seats This activity maybe performed independently provided you have adequate mobility and upper body strength: Remove arm by depressing the flip-lock and lifting the arm off.

  • Page 8: Maintenance And Adjustments

    When reaching, leaning or bending it is important to use the front castors as a tool to maintain stability and balance. Proper positioning is essential for your safety. Reaching, Bending-----FORWARD Position the front caster so that they are extended as for forward as possible and activate wheel locks, DO NOT LEAN FORWARD OF THE ARMRESTS.
  • Page 9 To Adjust Length Adjustments are made to desired length with individual sitting in the wheelchair with feet on footplates. Use a spanner to loosen the bolt at the side of the footrest support hanger. Adjust the footplate up or down as needed to provide maximum support of thighs on the seat upholstery, then re-tighten the bolt.
  • Page 10 Slowly lower the footplate until desired position is reached. Caution! To operate properly and safety your wheelchair must be Do not allow leg rest to suddenly drop. cared for just like any other vehicle. Routine maintenance will extend life and efficiency of Safety Inspection Checklist Initial adjustments should be made to suit your personal body structure and preference.
  • Page 11 Ensure all fasteners are secure 5. Arms Secure but easy to release: adjustment levers engage properly 6. Armrests Inspect for rips in upholstery Base sits flush against arm tube 7. Seat and back upholstery Inspect for rips in upholstery 8. 24” wheels Axle nut and sealed bearings tension correct No excessive side movement or binding when lifted from ground and spun...
  • Page 12 of your wheelchair. Upholstery cleaning Use a commercial NYLON material cleaner or mild soap and water. Caution! Do not use paint remover, liquid brush cleaner or similar solvents on upholstery. Metal Parts Clean all metal parts with auto wax or similar compounds. DO NOT use any abrasive cleaner or material that will scratch the finish.

  • Page 13: Wheel Locks

    Casters The casters are secured to the caster fork by axle nut and bolt. This nut and bolt should be periodically checked to allow a snug, but free spinning wheel. The caster fork swivel allows the wheelchair to turn properly. An adjustment locknut is located under the caster cap.
  • Page 14 run through the mounting bracket and frame. Slide the clamp toward the rear wheel until the wheel brake shoe is embedded approximately 1/8” into the tyre material when the handle is engaged in the lick position. Re-tighten the nut and bolt to secure the mounting bracket in the desired position.
