- Page 1 Merits P310 series Service Manual Nov.1.2006 V1...
-
Page 2: Table Of Contents
Index 1. Introduction ................1 2. Service guide ................1 2.1. How to replace or repair the seat assembly ..........1 2.1.1. To replace the seat body ................... 1 2.1.2. To replace the seat base plate assembly ............2 2.1.3. To replace the seat post assembly ..............2 2.1.4. -
Page 3: Introduction
1. Introduction The purpose of this manual is to provide dealers and/or distributors with the product information and instructions that are required for servicing the P310 powerchair. 2. Service guide The P310 powerchair consists of three main parts: n Seat assembly n Body assembly n Electrical system (Please refer to P3 /P7series Shark or VR2 service manual) -
Page 4: To Replace The Seat Base Plate Assembly
2.1.2. To replace the seat base plate assembly ◆ When should you replace the seat base plate assembly? ◇ If the seat base plate is deformation. ◇ If the seat base plate out of shape due to an accident. ◆ How to replace the seat base plate assembly? ◇... -
Page 5: To Replace The Left/Right Armrest
a. To replace the upper seat post: Use two wrenches to loosen the nut (3.09) and screw (3.07) to remove the upper seat post if it is worn out or deformed. b. To replace the lower seat post: Repeat step of a. then hold the screw (3.03) and loosen the nut (3.05) to remove the lower seat post if it is worn out or deformed. - Page 6 Use hex tools to loosen bolt (3.28) under armrest to disassemble armrest from armrest support plate. If the armrest is broken, then replace it. Note: The arm tube protective shrouds (3.34 and 3.35) are option parts for powerchair.
-
Page 7: How To Replace Or Repair The Body Assembly
2.2. How to replace or repair the body assembly The Body Assembly includes shroud, footplate assembly, anti-tipper wheel assembly, caster wheel assembly, driver wheel assembly and the frame assembly. 2.2.1. To replace the shroud ◆ When should you replace the shroud? ◇... -
Page 8: To Replace The Anti-Tipper Wheel Assembly
Replace the footplate assembly if it is worn out or deformed. Hold the screw (8.07) and loosen the nut (8.08) and then replace the footplate assembly. Hole the screw (8.03) and loosen the nut (8.10) then remove the footplate. If the footplate is worn out, then replace it. 2.2.3. -
Page 9: To Replace The Caster Wheel Assembly
2.2.4. To replace the caster wheel assembly ◆ When should you replace the caster wheel assembly? ◇ If the caster wheel assembly is worn out. ◇ If the caster wheel assembly is out of shape due to an accident. ◆ How to replace the caster wheel assembly? ◇... -
Page 10: To Replace The Driver Wheel Assembly
b. If the PU tire is worn out, then replace it. PU form (two piece of rims) solid tire (one piece of rim) 2.2.5. To replace the driver wheel assembly ◆ When should you replace the driver wheel assembly? ◇ If the driver wheel assembly is worn out. ◇... -
Page 11: To Replace The Frame Assembly
Replace the driver wheel by the following steps if it is worn out or deformed. a. Follow preceding step above. b. If the PU tire is worn out, replace it by loosening screw (5.33) and replace it. 2.2.6. To replace the frame assembly ◆... - Page 12 ◇ If your powerchair can not avoid knocked or bumped cause the frame deform. ◇ If the frame is out of shape due to an accident. ◆ How to replace the frame? ◇ Please proceeding steps as follows if it has to replace. The frame assembly is composed of the cross beam and the frame.
