Parts List - Icom IC-M23 Service Manual

SECTION 6.
[MAIN UNIT]
REF PARTS
NO. NO.
IC1 1130011671 S.IC MB15E03SLPFV1-G-ER-6E1
IC50 1110006490 S.IC LMV321IDCKR
IC170 1110007320 S.IC NJM2591V-TE1-#ZZZB
IC190 1190001350 S.IC M62364FP 600D
IC200 1110006470 S.IC LMV324IPWR
IC220 1180003690 S.REG NJU7772F03-TE1-#ZZZB
IC260 1130011770 S.IC CD4066BPWR
IC340 1130015560 S.IC S-24C64CI-T8T1U3
IC341 1110007790 S.IC NJU7704F03A-TE1-#ZZZB
IC360 1140015840 S.IC UPD780318GC-513-9EB-A
(FX3340A)
IC362 1110007610 S.IC TPA0211DGNR
IC365 1110006740 S.IC LMV358IPWR
IC601 1190002270 S.IC NJW4100V-TE1-#ZZZB
IC602 1180003470 S.REG NJM2835DL1-05-TE1-#ZZZB
Q3 1560000811 S.FET 2SK1069-4-TL-E
Q20 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q21 1530004011 S.TRA KTC3770U-C-RTK/P
Q22 1530004011 S.TRA KTC3770U-C-RTK/P
Q23 1530002381 S.TRA 2SC4215-Y(TE85LF)
Q24 1530002381 S.TRA 2SC4215-Y(TE85LF)
Q25 1530002381 S.TRA 2SC4215-Y(TE85LF)
Q50 1530004011 S.TRA KTC3770U-C-RTK/P
Q53 1560001550 S.FET RD01MUS2-T113
Q54 1560001700 S.FET RD07MUS2B-T112
Q55 1560001700 S.FET RD07MUS2B-T112
Q90 1580000751 S.FET 3SK294(TE85LF)
Q150 1580000731 S.FET 3SK293(TE85LF)
Q151 1530003890 S.TRA KTC3880S Y-RTK/P
Q221 1510001151 S.TRA L2SA1576AST1G <SLVJ>
Q222 1510001151 S.TRA L2SA1576AST1G <SLVJ>
Q224 1590003800 S.TRA KTC811U-GR-RTK/P
Q225 1520000840 S.TRA KTA1664Y-RTF/P
Q230 1550000090 S.FET RSQ035P03TR
Q231 1590003800 S.TRA KTC811U-GR-RTK/P
Q240 1590004230 S.TRA LMUN5213DW1T1G <SLVJ>
Q250 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q350 1590004100 S.TRA LDTC144TET1G <SLVJ>
Q351 1590004050 S.TRA LDTA144EET1G <SLVJ>
Q353 1550000090 S.FET RSQ035P03TR
Q354 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q357 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q362 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q363 1550000090 S.FET RSQ035P03TR
Q364 1550000170 S.FET 2SJ347(TE85LF)
Q365 1590004050 S.TRA LDTA144EET1G <SLVJ>
Q366 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q602 1520000840 S.TRA KTA1664Y-RTF/P
Q603 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q606 1550000090 S.FET RSQ035P03TR
Q608 1550000170 S.FET 2SJ347(TE85LF)
Q609 1590004100 S.TRA LDTC144TET1G <SLVJ>
D1 1750000771 S.VAR HVC376BTRF-E
D3 1750001810 S.DIO L1SS400T1G <SLVJ>
D20 1790001261 S.DIO MA2S077G0L
D21 1790001261 S.DIO MA2S077G0L
D22 1750001780 S.VAR HVB350BYPTL-E
D50 1750001910 S.DIO HVD144AKRF-E
D51 1750001910 S.DIO HVD144AKRF-E
D52 1750000581 S.DIO 1SV307(TPH3F)
D90 1750001910 S.DIO HVD144AKRF-E
D91 1790001670 S.DIO RB706F-40T106
D92 1750001190 S.VAR KDV214E RTK/P
D93 1750001190 S.VAR KDV214E RTK/P
D130 1750001190 S.VAR KDV214E RTK/P
D131 1750001190 S.VAR KDV214E RTK/P
D350 1750001180 S.DIO KDS122 RTK/P
D353 1750002170 S.DIO DB2S31400L
D355 1750001810 S.DIO L1SS400T1G <SLVJ>
D356 1750001810 S.DIO L1SS400T1G <SLVJ>
D357 1790001860 S.VAR EZJZ0V80010
D358 1750001850 S.DIO LDAN222T1G <SLVJ>
D359 1750002110 S.DIO LRB551V-30T1G <SLVJ>
D360 1750002110 S.DIO LRB551V-30T1G <SLVJ>
D601 1750002110 S.DIO LRB551V-30T1G <SLVJ>
D603 1750002110 S.DIO LRB551V-30T1G <SLVJ>
D604 1730002870 S.ZEN LM3Z3V0T1G <SLVJ>
D609 1750001810 S.DIO L1SS400T1G <SLVJ>
D610 1750002110 S.DIO LRB551V-30T1G <SLVJ>
D612 1750001810 S.DIO L1SS400T1G <SLVJ>
FI150 2030000350 MON 21R15AB (FL-368)
FI151 2030000481 MON 21R15AB (FL-399A)
FI170 2020002410 CER LTM450FW <JJE>
X1 6050011740 S.XTA CR-766 TSS-6035B 21.250 MHz
X170 6070000310 S.DIS JTBM450CX70 <JJE>
X360 6050013200 S.XTA CR-911(HC49U/SM 4.9152 MHz
<SKD>
L1 6200009141 S.COI NLV25T-6R8J

PARTS LIST

DESCRIPTION M.
LOCATION
B 41.85/11.6
T
B
B
B
B
T
B
B
B
B
B
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
T
B
B
B
B
B
T
T
T
T
B
T
T 100.0/36.3
T
T
B
T
T
B
B
B
B
B
B
B
B
B
B 101.0/12.0
B
B
B 103.1/25.8
B 100.8/25.8
B
B
B
B
B
B
T
T
T
T
T
B
B
T
T
B
B
B
B
B 46.05/27.6
[MAIN UNIT]
H/V REF PARTS
NO. NO.
L20 6200011021 S.COI
96.7/19.9 L21 6200002861 S.COI
56.7/36.9 L22 6200009910 S.COI
39.0/25.3 L23 6200011031 S.COI
37.7/38.1 L24 6200011031 S.COI
15.9/38.9 L25 6200011031 S.COI
52.7/34.0 L26 6200007001 S.COI
25.0/7.3 L50 6200011031 S.COI
13.6/13.6 L51 6200011021 S.COI
L53 6200006981 S.COI
19.6/26.8 L55 6200012680 S.COI
76.0/32.8 L56 6200012390 S.COI
56.1/29.9 L57 6200012680 S.COI
88.4/34.8 L58 6200003711 S.COI
95.5/36.7 L80 6200012470 S.COI
L81 6200012770 S.COI
L82 6200012780 S.COI
33.3/5.1 L90 6200012470 S.COI
53.5/14.5 L92 6200007750 S.COI
61.2/15.0 L93 6200007750 S.COI
62.5/11.4 L96 6200007750 S.COI
58.3/20.2 L97 6200007750 S.COI
64.1/21.5 L98 6200003680 S.COI
52.5/22.0 L99 6200011001 S.COI
72.4/19.0 L100 6200010991 S.COI
72.5/13.3 L101 6200010991 S.COI
82.6/9.1 L102 6200007901 S.COI
82.6/17.6 L103 6200007901 S.COI
96.2/24.1 L104 6200012680 S.COI
88.1/25.6 L105 6200012390 S.COI
56.2/40.6 L106 6200012680 S.COI
61.7/27.2 L107 6200012470 S.COI
64.3/27.0 L108 6200012470 S.COI
67.1/27.9
72.9/28.2
72.5/31.7 R1 7510001661 S.THR NTCG16 4LH 473JT
71.5/27.4 R2 7030012480 S.RES ERJ2RKF 1003X (100K)
20.5/37.1 R3 7030005050 S.RES ERJ2GEJ 103 X (10K)
88.3/41.6 R4 7030005240 S.RES ERJ2GEJ 473 X (47K)
6.5/15.7 R5 7030007280 S.RES ERJ2GEJ 331 X (330)
99.2/20.0 R6 7030005240 S.RES ERJ2GEJ 473 X (47K)
63.8/35.2 R7 7030005000 S.RES ERJ2GEJ 471 X (470)
67.6/35.1 R8 7030008370 S.RES ERJ2GEJ 561 X (560)
91.3/19.8 R10 7030008370 S.RES ERJ2GEJ 561 X (560)
64.4/8.5 R11 7030005000 S.RES ERJ2GEJ 471 X (470)
96.6/36.1 R12 7030005050 S.RES ERJ2GEJ 103 X (10K)
R13 7030005050 S.RES ERJ2GEJ 103 X (10K)
76.1/15.3 R20 7030004980 S.RES ERJ2GEJ 101 X (100)
65.6/24.6 R22 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
86.4/35.1 R23 7030004990 S.RES ERJ2GEJ 221 X (220)
81.5/36.7 R24 7030005090 S.RES ERJ2GEJ 104 X (100K)
60.4/35.2 R25 7030005090 S.RES ERJ2GEJ 104 X (100K)
4.9/23.5 R26 7030005290 S.RES ERJ2GEJ 682 X (6.8K)
4.6/28.5 R27 7030005210 S.RES ERJ2GEJ 822 X (8.2K)
R28 7030004980 S.RES ERJ2GEJ 101 X (100)
R30 7030005070 S.RES ERJ2GEJ 683 X (68K)
34.0/16.8 R31 7030004990 S.RES ERJ2GEJ 221 X (220)
30.8/10.1 R32 7030007270 S.RES ERJ2GEJ 151 X (150)
51.5/12.8 R33 7030007350 S.RES ERJ2GEJ 393 X (39K)
54.5/16.2 R34 7030008280 S.RES ERJ2GEJ 271 X (270)
61.9/7.6 R35 7030007350 S.RES ERJ2GEJ 393 X (39K)
70.0/23.6 R36 7030005710 S.RES ERJ2GEJ 121 X (120)
81.0/24.0 R47 7030008410 S.RES ERJ2GEJ 392 X (3.9K)
R50 7030005120 S.RES ERJ2GEJ 102 X (1K)
99.1/18.1 R52 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
97.7/10.3 R53 7030004980 S.RES ERJ2GEJ 101 X (100)
R54 7030005530 S.RES ERJ2GEJ 100 X (10)
R55 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
92.3/26.0 R56 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
90.1/25.8 R57 7030005590 S.RES ERJ2GEJ 680 X (68)
7.2/18.3 R65 7030005100 S.RES ERJ2GEJ 154 X (150K)
99.9/20.2 R66 7030005070 S.RES ERJ2GEJ 683 X (68K)
27.5/9.9 R67 7030005310 S.RES ERJ2GEJ 124 X (120K)
75.1/28.4 R68 7030004980 S.RES ERJ2GEJ 101 X (100)
65.6/39.9 R69 7030005050 S.RES ERJ2GEJ 103 X (10K)
67.6/32.7 R70 7030005100 S.RES ERJ2GEJ 154 X (150K)
97.2/32.7 R71 7030004980 S.RES ERJ2GEJ 101 X (100)
99.9/34.3 R73 7030005050 S.RES ERJ2GEJ 103 X (10K)
99.9/38.2 R74 7030005720 S.RES ERJ2GEJ 563 X (56K)
86.0/31.1 R75 7030004980 S.RES ERJ2GEJ 101 X (100)
7.7/23.9 R76 7030000260 S.RES MCR10EZHJ 100 (101)
59.8/32.2 R80 7030005080 S.RES ERJ2GEJ 823 X (82K)
78.8/27.3 R81 7030005090 S.RES ERJ2GEJ 104 X (100K)
6.4/28.6 R91 7030005110 S.RES ERJ2GEJ 224 X (220K)
R93 7030005050 S.RES ERJ2GEJ 103 X (10K)
R94 7030005110 S.RES ERJ2GEJ 224 X (220K)
R95 7030005310 S.RES ERJ2GEJ 124 X (120K)
R96 7030005700 S.RES ERJ2GEJ 274 X (270K)
R97 7030004990 S.RES ERJ2GEJ 221 X (220)
R103 7030005050 S.RES ERJ2GEJ 103 X (10K)
R104 7030005090 S.RES ERJ2GEJ 104 X (100K)
34.4/11.5 R105 7030005110 S.RES ERJ2GEJ 224 X (220K)
46.7/42.5 R107 7030005110 S.RES ERJ2GEJ 224 X (220K)
R109 7030005530 S.RES ERJ2GEJ 100 X (10)
18.9/10.0 R110 7030008400 S.RES ERJ2GEJ 182 X (1.8K)
R111 7030005090 S.RES ERJ2GEJ 104 X (100K)
R113 7030005530 S.RES ERJ2GEJ 100 X (10)
R115 7030006610 S.RES ERJ2GEJ 394 X (390K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 1
DESCRIPTION M.
ELJRF 82NJFB B
NLV25T-4R7J B
C6342A-88NG-A B
ELJRF R10JFB B
ELJRF R10JFB B
ELJRF R10JFB B
ELJRE 82NGFA B
ELJRF R10JFB B
ELJRF 82NJFB B
ELJRE R10GFA B
0.30-1.3-5TL 20N <COMO> B
0.30-0.92-3TR 5.8N <COMO> B
0.30-1.3-5TL 20N <COMO> B
NLV25T-2R7J B
0.30-1.7-7TL 45.3N <COMO> B
0.26-1.1-7TR 24N <COMO> B
0.30-1.4-6TL 27.2N <COMO> B
0.30-1.7-7TL 45.3N <COMO> B
LQW2BHN56NJ03L B
LQW2BHN56NJ03L B
LQW2BHN56NJ03L B
LQW2BHN56NJ03L B
LQH31MNR82M03L B
ELJRF 56NJFB B
ELJRF 47NJFB B
ELJRF 47NJFB B
ELJRF 22NJFB B
ELJRF 22NJFB B
0.30-1.3-5TL 20N <COMO> B
0.30-0.92-3TR 5.8N <COMO> B
0.30-1.3-5TL 20N <COMO> B
0.30-1.7-7TL 45.3N <COMO> B
0.30-1.7-7TL 45.3N <COMO> B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
B
B
B
B
B
B
B
B
T
T
T
T
T
T
B
T
T
B
B
B
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
S.=Surface mount
H/V
LOCATION
51.0/20.0
51.5/9.2
57.0/9.7
60.3/19.6
62.9/19.8
54.3/20.4
83.7/24.5
73.8/20.3
74.3/16.7
71.4/9.2
87.6/9.6
87.1/6.5
89.7/6.0
98.6/14.4
98.6/5.9
102.3/8.6
106.1/9.0
101.8/16.4
102.3/21.7
99.7/22.5
94.0/26.6
91.4/23.0
84.6/28.6
73.7/9.2
77.5/12.8
77.5/13.7
78.7/10.0
78.7/16.4
87.6/20.2
87.0/17.2
89.8/17.1
93.1/9.5
94.9/13.3
37.3/16.8
33.8/18.8
37.6/18.2
36.7/15.7
37.5/8.5
49.5/13.4
50.0/12.1
40.7/6.4
38.7/6.0
31.5/6.0
35.2/5.6
31.5/4.2
51.0/18.4
41.6/6.4
52.7/12.6
53.1/18.2
52.7/16.5
63.1/16.2
63.5/13.2
61.9/13.2
58.7/18.4
60.8/18.4
62.4/18.6
62.3/21.5
55.8/18.8
55.3/20.4
61.6/25.0
45.6/19.4
71.0/24.8
71.0/23.1
71.9/23.6
72.3/21.7
72.3/20.8
70.1/18.3
70.1/19.3
94.3/21.3
93.8/20.1
96.2/17.8
95.5/16.3
74.5/15.2
71.8/15.2
72.9/16.3
77.5/11.3
77.5/9.5
78.7/8.3
95.7/17.9
107.3/7.0
99.1/16.2
101.9/27.9
99.5/27.9
101.0/27.9
97.5/26.1
98.0/23.5
95.8/25.9
98.4/26.1
93.8/22.1
92.2/28.1
91.2/28.1
87.7/29.4
85.4/26.8
89.9/22.1
98.6/27.9
86.3/25.2
