[MAIN UNIT]
REF PARTS
NO. NO.
DS240 5040003060 S.LED SML-512WWT86
DS241 5040003060 S.LED SML-512WWT86
DS242 5040003510 S.LED LNJ426W83RA
DS243 5040003510 S.LED LNJ426W83RA
DS244 5040003510 S.LED LNJ426W83RA
DS245 5040003510 S.LED LNJ426W83RA
DS246 5030003400 LCD TAK-35920 FX3340<ITAK>
DS247 5040003560 LED RT3-234HRH16T-BNS <ROD>
DS248 5040003001 S.LED SML-A12UT T86J
MC250 7700002710 MIC EM6027P-46C33-G <HOR>
S250 2260001900 SWI SW-149 (SKHLLD)
EP2 6910014690 S.BEA MPZ1608S221A-T
EP3 6910014690 S.BEA MPZ1608S221A-T
EP8 6910021240 S.BEA MMZ1005A152ET
EP10 6910014690 S.BEA MPZ1608S221A-T
EP11 6910018460 S.BEA MMZ1005Y102C-T
EP360 8930082550 LCD SRCN-3340-SP-N-W (SHJ)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
B
B
B
B
T 105.4/42.0
S.=Surface mount
H/V
53.1/3.8
61.1/3.8
17.2/32.2
28.1/32.2
17.2/18.5
28.1/18.5
2.9/25.3
71.4/7.9
88.1/12.7
61.1/17.0
83.0/22.2
6 - 4
