Summary of Contents for AJA V2Digital

  • Page 1 Mini-Converter V2Digital Installation & Operation Guide Version 1.0 Published: November 4, 2013 InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 2: Table Of Contents

    USB Control and Setup—Using AJA MiniConfig ........
  • Page 3: Notices

    Copyright Copyright © 2013 AJA Video, Inc. All rights reserved. All information in this manual is subject to change without notice. No part of the document may be reproduced or transmitted in any form, or by any means, electronic or mechanical, including photocopying or recording, without the express written permission of AJA Inc.
  • Page 4: Chapter 1: Introduction

    V2Digital accepts YPbPr (SMPTE/EBU-N10), Betacam, or RGB component inputs (HD only) or NTSC/PAL or Y/C (S-Video) composite inputs (SD only). Configuration can be set by on unit DIP switches or remotely via AJA MiniConfig software control over USB.
  • Page 5: Block Diagram

    + 5VDC Power Input User Controls The V2Digital converter has two user interfaces: • DIP switch settings • MiniConfig via USB The DIP switch 1 setting determines which configuration parameters the converter will use. When Off the unit is set to Local, DIP switches 2-4 will be active. When On the unit is set to Remote and will use the MiniConfig settings.
  • Page 6: External Dip Switches

    External DIP The V2Digital has a 4-switch DIP accessible through a cut-out in the bottom of the unit. Switches For specific DIP switch setting information, see “DIP Switch Settings” on page MiniConfig Control MiniConfig is an AJA application used for configuring and updating the firmware of several AJA products.
  • Page 7: Chapter 2: Operation

    V2 Digital unit. For other applications, you can configure the unit using its DIP switch settings, or by using MiniConfig and a PC or Mac via USB. When configured for “component” V2DIGITAL will auto detect between various component standards.
  • Page 8: Dip Switch Settings Summary

    Note: X = don't care USB Control and Setup—Using AJA MiniConfig The V2Digital can usually be used right out of the box for most applications since it is designed to recognize inputs and perform standard actions automatically by default. However you can also manually configure the V2Digital using a supplied software application for PCs and Macs called “MiniConfig.
  • Page 9: Installing Miniconfig On A Pc

    If you do, press Cancel—this alert can be ignored. Figure 4. Mac Network Message (ignore) PC Startup: To run MiniConfig on a PC, find the AJA MiniConfig in the program list and locate the AJA MiniConfig application. Figure 5. PC MiniConfig Startup V2Digital v1.0...
  • Page 10: Operating Miniconfig

    Open menu item. A Revert to Factory Settings menu item similarly allows you to change the settings back to AJA’s factory defaults. An Edit menu allows you to cut and paste values to/from fields, just as in other applications.
  • Page 11: Tabbed Screens

    Mini-Converter type. Click on any of the tab buttons and the screen below will change to match. Each of these screens are described on the following pages. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 12: Input Tab Screen

    Input Tab Screen Click on the Input tab to view and make changes to the V2Digital Input settings. Figure 7. MiniConfig, Input Tab Screen Format: Selects the input video format. Only applies if in SD mode. Choose from the following: •...
  • Page 13: Update Tab Screen

    This indicator bar shows the progress of software being installed. Software Update 1. Check the AJA website for new MiniConfig software for your Mini-Converter. If new Procedure software is found, download it and uncompress the file archive (zip). Here is the URL to use when checking: http://www.aja.com/support/converters/converters-mini-rackmount.php...
  • Page 14: Info Tab Screen

    This is the factory set model name of the Mini-Converter. Assembly: This is the factory assembly number. Serial Number: This is the factory set unique serial number of your unit. If you ever call AJA Support for service, you may be asked for this number. V2Digital v1.0 www.aja.com...
  • Page 15: Miniconfig Settings Summary

    Component RGB 1080i/psf * Component YPbPr SMPTE/EBU-N10 YPbPr (SMPTE) Component RGB * = all supported frame rates Note: X = don't care V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 16: Appendix A: Safety And Compliance

    Bprescrites dans le Règlement sur le brouillage radioélectrique du ministère des Communications du Canada. Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 17: European Union And European Free Trade Association (Efta)

    Attention! Ceci est un produit de Classe B. Dans un environnement domestique, ce produit risque de créer des interférences radioélectriques, il appartiendra alors à l?utilisateur de prendre les mesures spécifiques appropriées. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 18: Korea Kcc Compliance Statement

    Install and use the equipment according to the instruction manual. Translated Warning and Caution Messages The following caution statements, warning conventions, and warning messages apply to this product and manual. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 19: Before Operation Please Read These Instructions

    Aviso! Não obstrua nenhuma das aberturas de ventilação. Instale de acordo com as instruções do fabricante. Avviso! Non ostruire le aperture di ventilazione. Installare in conformità con le istruzioni del fornitore. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 20 Avviso! Non installare vicino a fonti di calore come termosifoni, diffusori di aria calda, stufe o altri apparecchi (amplificatori compresi) che emettono calore. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 21 Se la spina fornita non si inserisce nella presa di corrente, contattare un elettricista per la sostituzione della presa obsoleta. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 22 Avviso! Proteggere il cavo di alimentazione in modo che nessuno ci cammini sopra e che non venga schiacciato soprattutto in corrispondenza delle spine e del punto in cui esce dal dispositivo. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 23 è stato rovesciato o qualche oggetto è caduto nel dispositivo, il dispositivo è stato esposto a pioggia o umidità, non funziona correttamente o è caduto. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 24 Warning! Do not open the chassis. There are no user-serviceable parts inside. Opening the chassis will void the warranty unless performed by an AJA service center or licensed facility. Avertissement! Ne pas ouvrir le châssis. Aucun élément à l’intérieur du châssis ne peut être réparé...
  • Page 25 Advertência! Remova os cabos CA de alimentação brick da rede elétrica ao mover a unidade. Avvertenza! Scollegare il cavo dell’alimentatore quando si sposta l’unità. V2Digital v1.0 www.aja.com InterTest, Inc • 303 Route 94 • Columbia, NJ 07832 • 908-496-8008 • sales@intertest.com • www.intertest.com...
  • Page 26: Warranty Information

    AJA Video, with shipping charges prepaid. AJA Video shall pay for the return of the product to the Customer if the shipment is to a location within the country in which the AJA Video service center is located.
