3) PRODUCT DESCRIPTION

Panel Illustration

V1.1 8/12

netzerotools.com

1) 5-4/5 digits 500000

counts LCD display

2) Push-buttons for special

functions & features

3) Selector to turn the Power

On or Off and Select a

function

4) Input Jack for 10A (+)

(20A for 30sec) current, and

for T2 (-) function

5) Input Jack (+) for all

functions EXCEPT current



(

A, mA, A) and T2

functions

6) Common (Ground

reference) Input Jack (-) for

all functions EXCEPT T2

function

7) Input Jack (+) for

milli-amp, micro-amp, and

T2 (+) functions

MM560A-MM570A-EU-EN
