Page 1
Control de las direccionales Reemplazo de bombillas (focos) Controles del conductor Control del limpiaparabrisas y lavaparabrisas Ajuste del volante de dirección Ventanas eléctricas Espejos Control de velocidad Toldo corredizo Centro de mensajes 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Interruptor de corte de bomba de combustible Fusibles y relevadores Cambio de las llantas Torsión de las tuercas de seguridad de las ruedas Arranque con cables pasacorriente Remolque con grúa de auxilio 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 3
Ford Motor Company. Ford puede cambiar el contenido sin previo aviso y sin incurrir en ninguna obligación.
Mientras más sepa y entienda de él, mayores serán la seguridad y el placer al manejarlo. Para obtener más información acerca de Ford Motor Company y sus productos, visite los siguientes sitios Web: • En los Estados Unidos: www.ford.com •...
Page 6
ADVERTENCIA: Los asientos de niños o de bebés orientados hacia atrás y montados en el asiento delantero no se deben colocar NUNCA frente a una bolsa de aire del pasajero activa. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 7
Para acceder a esta información, equipos especiales deben estar conectados directamente a los módulos de grabación. Ford Motor Company y Ford of Canada no tienen acceso a la información de la grabadora de datos de eventos sin tener su consentimiento, a menos que se cumpla con una orden judicial o si lo requiere la ley, las autoridades gubernamentales u otras terceras partes que actúen como autoridad...
Page 8
Los equipos de comunicaciones móviles incluyen, pero no se limitan a teléfonos celulares, buscapersonas, dispositivos de correo electrónico portátiles, sistemas de comunicaciones para vehículos, dispositivos telemáticos y radios de dos bandas portátiles. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 9
ADVERTENCIA: Manejar mientras está distraído puede tener como consecuencia la pérdida de control del vehículo, un accidente y lesiones. Ford recomienda encarecidamente que los conductores presten especial cuidado cuando utilicen dispositivos que pudieran quitar su atención del camino. La principal responsabilidad del conductor es utilizar en forma segura el vehículo.
Page 10
Faros de niebla Compartimiento de delanteros fusibles Restablecimiento de la Limpiaparabrisas y bomba de combustible lavaparabrisas Desempañador y Desempañador y descarchador del descarchador de la parabrisas ventana trasera 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 11
Servicio del motor a la Filtro de aire del motor brevedad Filtro de aire del compartimiento de Gato pasajeros Revisar tapón del Advertencia de presión combustible de llanta desinflada 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Muchas luces se encienden cuando arranca el vehículo para asegurarse de que los focos funcionan. Si alguna de las luces permanece encendida después de arrancar el vehículo, consulte la luz de advertencia del sistema correspondiente para obtener información adicional. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 13
Si “CHECK FUEL FILL INLET” (Revisar orificio de llenado de combustible) aparece en el centro de mensajes, para obtener más información, consulte Centro de mensajes en el capítulo Controles del conductor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 14
Cuando se haya detectado una falla en el sistema de seguridad suplementario también sonará una campanilla. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 15
Nivel bajo de combustible: se ilumina cuando el nivel de combustible en el tanque de combustible está en el nivel vacío o casi vacío (consulte Indicador de combustible en este capítulo). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 16
Campanilla de advertencia de faros delanteros encendidos: suena cuando los faros delanteros o las luces de estacionamiento están encendidas, el encendido está en OFF (la llave no está en el encendido) y se abre la puerta del conductor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
(excepto FRENO DE ESTACIONAMIENTO ACCIONADO cuando está estacionado). INDICADORES Indicadores del grupo de instrumentos estándar Indicadores del grupo de instrumentos opcional 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 18
El icono FUEL (combustible) y la flecha indican a qué lado del vehículo está ubicada la puerta de llenado de combustible. Para obtener más información, consulte Llenado del tanque en el capítulo Mantenimiento y especificaciones. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 19
INFO del centro de mensajes hasta que aparezca del modo TRIP A. Presione nuevamente el control para seleccionar la característica TRIP B (Viaje B). Mantenga presionado el botón RESET (Restablecer) para restablecer. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ADVERTENCIA: Manejar mientras está distraído puede tener como consecuencia la pérdida de control del vehículo, un accidente y lesiones. Ford recomienda encarecidamente que los conductores presten especial cuidado cuando utilicen dispositivos que pudieran quitar su atención del camino. La principal responsabilidad del conductor es utilizar en forma segura el vehículo.
Page 21
(0–9). SEEK/TRACK (Buscar/Pista): presione SEEK/TRACK para acceder a la estación de radio potente anterior/siguiente. SCAN (Explorar): presione para obtener una breve muestra de todas las estaciones de radio potentes. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 22
RDS. Presione CAT. En la pantalla aparecerá PRESS UP OR DOWN TO CHANGE RDS CATEGORY (Presione arriba o abajo para cambiar de categoría RDS). Presione para desplazarse a través de todas las 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 23
Saque el CD. Si no retira el disco, el sistema lo volverá a cargar. Para expulsar automáticamente todos los discos cargados: mantenga presionado EJECT. El sistema expulsará todos los discos y le indicará que los saque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 24
Cuando el indicador < / > esté activo, presione TEXT y luego presione SEEK/TRACK para ver el texto anterior / adicional en la visualización. COMPRESSION (Compresión): presione MENU repetidamente hasta que en la visualización aparezca COMPRESSION ON/OFF. Use 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 25
Puede cancelar el ingreso presionando DIRECT. Si ingresa un número de estación no válido, aparecerá INVALID CHANNEL (CANAL NO VÁLIDO) en la visualización y el sistema seguirá reproduciendo la estación actual. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 26
El icono de categoría (CAT) se encenderá en la pantalla cuando se seleccione una categoría específica (no se encenderá durante CATEGORY ALL (Todas las categorías)). Si nunca se ha seleccionado una categoría, aparecerá NO CATEGORY SELECTED (No se seleccionó ninguna categoría). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 27
Presione OK nuevamente y en la visualización aparecerá SONG DELETED (Canción eliminada). Si no desea eliminar la canción indicada actualmente, presione para seleccionar RETURN o CANCEL (Volver o Cancelar). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 28
El ajuste predeterminado es desactivado. SEEK/TRACK para ajustar entre SPEED OFF y los niveles 1–7: aumentar el nivel de 1 (ajuste más bajo) a 7 (ajuste más alto) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ADVERTENCIA: Manejar mientras está distraído puede tener como consecuencia la pérdida de control del vehículo, un accidente y lesiones. Ford recomienda encarecidamente que los conductores presten especial cuidado cuando utilicen dispositivos que pudieran quitar su atención del camino. La principal responsabilidad del conductor es utilizar en forma segura el vehículo.
Page 30
Ajuste el control del volumen a un nivel cómodo para escuchar. 5. Encienda el reproductor de música portátil y ajuste el volumen en la mitad de su nivel. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 31
El cable de extensión del sistema de audio debe ser lo suficientemente largo para permitir que el reproductor de música se guarde en forma segura mientras el vehículo está en movimiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ADVERTENCIA: Manejar mientras está distraído puede tener como consecuencia la pérdida de control del vehículo, un accidente y lesiones. Ford recomienda encarecidamente que los conductores presten especial cuidado cuando utilicen dispositivos que pudieran quitar su atención del camino. La principal responsabilidad del conductor es utilizar en forma segura el vehículo.
Page 33
12 cm (4.75 pulgadas) impresos comercialmente. Debido a incompatibilidad técnica, ciertos discos compactos grabables y regrabables podrían no funcionar correctamente cuando se usan en reproductores de CD Ford. 2009 Escape (204) Owners Guide, 1st Printing...
Page 34
(señaladas con la extensión de archivo .mp3) desde T001 hasta un máximo de T255. Nota: es posible que el número máximo de archivos MP3 reproducibles sea menor según la estructura del CD y el modelo exacto de la radio. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Para obtener más información y una lista completa de los canales de radio satelital SIRIUS, visite www.sirius.com en los Estado Unidos, www.sirius-canada.ca en Canadá, o llame a SIRIUS al 1–888–539–7474. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 36
Ford Motor Company no será responsable de ninguno de dichos cambio en la programación. 2009 Escape (204)
Page 37
(Canal no válido) disponible. estaba disponible ya no lo está. Sintonice otro canal. Si el canal era uno de sus preestablecimientos de memoria, puede seleccionar otro canal para ese botón de preestablecimiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 38
El sistema está funcionando adecuadamente. NO TEXT Información de Información de (Sin texto) categoría no categoría no disponible disponible. en este momento en este canal. El sistema está funcionando adecuadamente. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Para obtener más información, consulte el suplemento de SYNC o la sección SYNC en el suplemento Sistema de navegación (si está equipado). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Cuando el sistema está desactivado, el aire exterior no puede ingresar al vehículo a través de los respiraderos. : distribuye el aire a través de los respiraderos del tablero de instrumentos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 41
(desempañador) y (piso/desempañador). Control de asiento térmico del conductor (si está equipado): presione para activar/desactivar el asiento térmico del conductor. Consulte Asientos térmicos en el capítulo Asientos y sistemas de seguridad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 42
Para ayudar a desempañar la ventana lateral en condiciones de clima frío: 1. Seleccione 2. Seleccione A/C (A/A). 3. Ajuste el control de temperatura para mantener el confort. 4. Ajuste la velocidad del ventilador al máximo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 43
Desempañador trasero: presione para activar o desactivar el desempañador de la ventana trasera. Consulte Desempañador de la ventana trasera más adelante en este capítulo para obtener más información. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 44
Control de asiento térmico del pasajero (si está equipado): presione para activar/desactivar el asiento térmico del pasajero. Consulte Asientos térmicos en el capítulo Asientos y sistemas de seguridad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 45
• Para reducir la niebla del parabrisas en un clima húmedo, seleccione (desempañador) o (piso/desempañador). • Para reducir la acumulación de humedad en el interior del vehículo, no maneje con el sistema apagado ni con (aire recirculado) activado y A/C apagado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 46
Para ayudar a desempañar la ventana lateral en condiciones de clima frío: 1. Seleccione 2. Seleccione A/C (A/A). 3. Ajuste el control de temperatura para mantener el confort. 4. Ajuste la velocidad del ventilador al máximo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
No utilice hojas de afeitar u otros objetos afilados para limpiar el interior de la ventana trasera o para quitar calcomanías. Esto podría dañar las líneas de la rejilla de calefacción, lo que no está cubierto por la garantía. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Si se activan los limpiaparabrisas por un período de tiempo breve, las luces exteriores se encenderán con el control de los faros delanteros en la posición de encendido automático de luces. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 49
Jale el control de los faros delanteros hacia usted para encender los faros de niebla. La luz indicadora de los faros de niebla se encenderá. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 50
(DRL) no se activa con las luces traseras y, por lo general, no proporciona una iluminación adecuada durante estas condiciones. Si no se activan los faros delanteros en estas condiciones, se podría producir un choque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 51
(un trozo de cinta adhesiva puede servir). El centro del faro está marcado con un círculo de 3.0 mm en la mica del faro delantero. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
EN ESTE VEHÍCULO. 8. Cierre el cofre y apague las luces. CONTROL DE LAS DIRECCIONALES • Empújelo hacia abajo para activar la direccional izquierda. • Empújelo hacia arriba para activar la direccional derecha. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 53
Las luces de mapa se encienden cada vez que se abre una puerta. Una vez que se cierra la puerta, las luces permanecerán encendidas por 25 segundos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 54
10 minutos, cuando la llave de encendido esté en la posición OFF/LOCK, cuando una puerta se haya dejado abierta o si los controles de la luz interior están en la posición ON. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 55
Los focos correctos no dañan el conjunto de la luz ni anulan la garantía del conjunto de la luz y proporcionan calidad en el tiempo de consumo del foco. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 56
Revise frecuentemente el funcionamiento de todos los focos. Reemplazo de los focos de los faros delanteros 1. Asegúrese de que el control de los faros delanteros esté en la posición OFF. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 57
1. Asegúrese de que el control de los faros delanteros esté en la posición OFF. 2. Abra el cofre. 3. Llegue detrás del protector para rodillas delantero. 4. Gire el casquillo de la bombilla hacia la izquierda y retírelo del conjunto de la luz. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 58
6. Instale el socket del foco dentro del conjunto de la luz y gírelo hacia la derecha. 7. Con cuidado instale el conjunto de la luz trasera del vehículo y fíjelo con dos tornillos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 59
(ubicado sobre la placa) de la compuerta levadiza. 3. Gire el socket del foco hacia la izquierda y retírelo del conjunto de la luz. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 60
3. Quite el foco del conjunto de la luz jalando el foco y apretando al mismo tiempo los clips de resorte superior e inferior. Instale el nuevo foco en orden inverso. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Cuando los limpiaparabrisas se activan durante el día y el control de los faros delanteros está en la posición de encendido automático de luces, las luces exteriores se encenderán después de un breve retardo y permanecerán encendidas hasta que los limpiadores se apaguen. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 62
3. Empuje hacia arriba la palanca de inclinación de la columna de dirección. Esto bloqueará el volante de la dirección en esa posición. ADVERTENCIA: Nunca ajuste el volante de la dirección cuando el vehículo esté en movimiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 63
Consulte Ajuste de zona de la brújula. La mayoría de las áreas geográficas (zonas) poseen un punto de brújula norte magnético que varía levemente según la dirección norte de los 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 64
Para lograr una calibración óptima, apague todos los accesorios eléctricos (calefactor, aire acondicionado, limpiadores, etc.) y asegúrese que todas las puertas del vehículo estén cerradas. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 65
5. Charolas pequeñas para guardar e interruptor de control de luz ambiente (si está equipado). ADVERTENCIA: Use sólo vasos livianos en el portavasos. Los objetos duros pueden producirle daños en un choque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 66
Un segundo tomacorriente auxiliar se ubica en el lado trasero de la consola central. No utilice el tomacorriente para hacer funcionar el encendedor (si está equipado). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ADVERTENCIA: Al cerrar las ventanas eléctricas, debe verificar que estén libres de obstrucciones y asegurarse de que los niños y/o mascotas no estén cerca de las aberturas de la ventana. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 68
(si está equipado) y el sistema de audio se pueden usar en un lapso de hasta diez minutos después de que el interruptor de encendido se ha girado a la posición OFF o hasta que se abra alguna de las puertas delanteras. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
No limpie el alojamiento ni los vidrios de ningún espejo con abrasivos, combustibles u otros productos de limpieza fuertes a base de petróleo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 70
Esto puede dañar el vidrio y los espejos. No limpie el alojamiento ni los vidrios de ningún espejo con abrasivos, combustibles u otros productos de limpieza fuertes a base de petróleo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Si la velocidad del vehículo desciende más de 16 km/h (10 mph) por debajo de la velocidad establecida al manejar cuesta arriba, el control de velocidad se desactivará. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 72
1.6 km/h (1 mph). • Use el pedal del acelerador para conseguir la velocidad deseada. Cuando el vehículo alcance dicha velocidad, presione y suelte el control SET +. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 73
• Presione el control OFF. • Apague el encendido. Nota: cuando desactive el control de velocidad o el encendido, se borra la memoria de velocidad establecida en el control de velocidad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 74
En modo de CD: • Presione para escuchar la siguiente pista del disco. En modo Radio satelital (si está equipado): • Presione para avanzar a través de los canales preestablecidos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 75
Mantenga presionado para finalizar una llamada o salir del modo de teléfono. Presione para desplazarse por diversos menús y selecciones. Presione OK para confirmar su selección. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ADVERTENCIA: Al cerrar el toldo corredizo, debe verificar que esté libre de obstrucciones y asegurarse de que los niños y/o mascotas no estén cerca de la abertura del toldo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 77
(si está equipado) se pueden usar en un lapso hasta de 10 minutos después de que el interruptor de encendido se ha girado a la posición OFF (Apagado) o hasta que se abra una de las puertas delanteras. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
(DTE) • Ahorro promedio de combustible (AFE) • Ahorro instantáneo de combustible • En blanco (odómetro desactivado) Odómetro y odómetro de viaje Consulte Indicadores en el capítulo Grupo de instrumentos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 79
2. Registre el ahorro de combustible en carretera para referencia futura. Es importante presionar el control RESET luego de programar el control de velocidad, para obtener lecturas exactas del ahorro de combustible en carretera. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 80
Configuración) y si se ha seleccionado un idioma distinto a inglés, aparecerá “PRESS RESET FOR ENGLISH” (Presione restablecer para volver a inglés) para volver a inglés. Presione el control RESET para volver a inglés. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 81
útil de aceite menor, presione y suelte el control RESET para reducir el valor de inicio. Cada vez que presione el control RESET se reduce el valor en un 10 por ciento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 82
Desbloqueo automático Esta característica desbloquea automáticamente todas las puertas del vehículo cuando se abre la puerta del conductor dentro de 10 minutos luego de apagar el encendido. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 83
• No volverán a aparecer hasta que se haya completado un ciclo de OFF-ON (Encendido-Apagado). Esto funciona como un recordatorio que estas condiciones de advertencia aún permanecen en el vehículo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 84
PUERTA TRASERA DERECHA ABIERTA aparece cuando la puerta trasera derecha no está completamente cerrada. FRENO ESTAC ACTIVADO aparece cuando el freno de estacionamiento manual está accionado, el motor está funcionando y el 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 85
10% y 0%, aparece el mensaje XX% OIL LIFE CHANGE SOON. CAMBIO ACEITE REQUERIDO aparece cuando la vida útil restante del aceite alcanza 0%; aparecerá el mensaje OIL CHANGE REQUIRED. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 86
CARACTERÍSTICAS DEL ÁREA DE CARGA Cubierta de carga (si está equipado) Si su vehículo cuenta con una cubierta de carga, puede usarla para cubrir elementos en el área de carga. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 87
Se puede aplicar seguro con el teclado o mediante una combinación para usar la función de almacenamiento con seguro en el contenedor de almacenamiento grande del usuario. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 88
No use las manijas de la puerta del vehículo como anillos de amarre. Use los anillos de sujeción (en los controles de accionamiento con el pulgar) para asegurar la carga. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 89
1. Suelte el control de accionamiento con el pulgar de ambos extremos de la barra transversal (ambas barras transversales son ajustables). 2. Deslice la barra transversal hacia el extremo del riel. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 90
4. Apriete el control de accionamiento con el pulgar de ambos extremos de la barra transversal. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Se recomienda que mantenga la etiqueta en un lugar seguro para referencia futura, como por ejemplo, en el interior de la tapa de este Manual del propietario. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
IKT en el borde externo cerca del control Asimismo, al girar el IKT a la posición OFF (Apagado) en el cilindro de cerradura del encendido, puede utilizarse el borde inferior del IKT adyacente al control 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 93
• efectuando el siguiente procedimiento del control de seguros eléctrico de las puertas o • efectuando el procedimiento de teclado de entrada sin llave o • efectuando el procedimiento del centro de mensajes (si está disponible). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 94
2. Cierre todas las puertas, la compuerta levadiza y la ventana de la compuerta levadiza. 3. Ingrese el código de entrada de cinco dígitos. 4. Mantenga presionado 3 • 4. Mientras mantiene presionado 3 • 4, presione 7 • 8. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 95
• o mediante el uso del centro de mensajes del grupo de instrumentos. Consulte Centro de mensajes en el capítulo Controles del conductor. Nota: la característica de desbloqueo automático se puede activar o desactivar en forma independiente de la función de autobloqueo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 96
El usuario debe escuchar un sonido de claxon que indica que el sistema se ha desactivado o un sonido seguido de un bocinazo que indica que el sistema se ha activado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 97
(1) Este dispositivo no debiera causar interferencia dañina y (2) Este dispositivo debe aceptar cualquier interferencia recibida, incluso interferencia que podría causar un funcionamiento no deseado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 98
Desbloqueo de las puertas de dos pasos 1. Presione y suéltelo para abrir la puerta del conductor. Nota: las luces interiores se encenderá si el control de la luz superior se encuentra en la posición DOOR. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 99
El claxon sonará y destellarán las luces direccionales. Se recomienda usar este método para ubicar el vehículo, en lugar de utilizar la alarma de emergencia. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 100
5. Presione para volver a colocar la tapa de la batería en la llave. Nota: el reemplazo de la batería no provocará que se desprograme el IKT de su vehículo. El IKT debe funcionar normalmente después de haber reemplazado la batería. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 101
Con el sistema del Transmisor integrado de cabezal de entrada, se iluminarán los siguientes elementos cuando se presiona el control (de desbloqueo) en el transmisor: • Faros delanteros • Luces de estacionamiento • Luces traseras 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 102
El claxon sonará una vez y luego otra vez (un sonido corto y luego uno largo) para indicar que la característica de iluminación del perímetro se ha activado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 103
2. En un lapso de cinco segundos, presione 1 • 2 en el teclado. 3. Ingrese su código personal de 5 dígitos. Cada número se debe ingresar en un lapso de cinco segundos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 104
Para quitar el seguro de todas las puertas y compuerta levadiza, presione el control 3 • 4 dentro de cinco segundos, luego de haber ingresado el código de 5 dígitos definido de fábrica o su código personal. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Nota: El sistema antirrobo pasivo SecuriLock™ no es compatible con los sistemas de arranque remoto no originales que no son Ford. El uso de estos sistemas puede provocar problemas en el arranque del vehículo y una pérdida de la protección de seguridad.
Page 106
Es posible programar un máximo de ocho llaves codificadas para su vehículo; sólo cuatro de estas llaves pueden ser IKT con funcionalidad de entrada a control remoto. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 107
2. Gire el encendido desde la posición 1 (OFF) a la posición 3 (ON). Mantenga el encendido en la posición 3 (ON) durante al menos tres segundos, pero no por más de 10. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 108
Para programar una o más llaves nuevas no programadas, espere 20 segundos y repita este procedimiento desde el Paso 1. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• espuma tapizada que absorbe energía y una estructura (1), • dos vástagos de acero (2), • un botón de ajuste/apertura de manga de guía (3), • y un botón de cierre/extracción (4). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 110
Para los ocupantes extremadamente altos, ajuste el apoyacabezas en su posición más alta. ADVERTENCIA: El apoyacabezas ajustable es un dispositivo de seguridad. Cuando sea posible, debe instalarse y ajustarse correctamente cuando el asiento está ocupado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 111
éste esté pareja con la parte superior de su cabeza y lo más cerca posible de la nuca. Para los ocupantes extremadamente altos, ajuste el apoyacabezas en su posición más alta. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 112
ADVERTENCIA: Siempre maneje y viaje con su respaldo vertical y con el cinturón pélvico ajustado cruzando por encima de la parte baja de las caderas. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 113
El control está ubicado en el costado exterior del cojín del asiento. Presione para levantar o bajar la parte delantera del cojín del asiento. Presione para levantar o bajar la parte trasera del cojín del asiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 114
• Presione el botón ubicado en el tablero de instrumentos para activarlos. • Presione nuevamente para desactivarlo. Los asientos térmicos se activarán cuando el encendido se encuentre en la posición ON y el motor esté funcionando. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 115
Presione el control para bajar o quitar el apoyacabezas. Plegado de los asientos traseros 1. Levante el apoyacabezas del asiento trasero y sáquelo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 116
3. Jale el control de desenganche del asiento. Nota: asegúrese de que no haya objetos en el piso antes de plegar el respaldo del asiento. 4. Incline el asiento hacia adelante. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 117
Nota: cuando jala la palanca de liberación del respaldo, baje lentamente el respaldo a la posición plana. 6. Gire el respaldo del asiento hacia abajo, a la posición de piso de carga. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 118
Un asiento sin seguro puede ser peligroso en caso de un frenado repentino o choque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 119
2. Jale el cojín hacia el costado exterior del vehículo. Para instalar el cojín trasero 1. Empuje el cojín hacia el costado interior del vehículo. 2. Asegúrese de que las bisagras queden bloqueadas en su lugar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 121
ésta comienza a inflarse. Para algunos ocupantes, como los niños en asientos 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 122
Sensores de uso del cinturón de seguridad delantero Los sensores de uso del cinturón de seguridad delantero pueden detectar si están abrochados los cinturones de seguridad del conductor y del 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 123
• Se escuchará una serie de cinco pitidos. El patrón de tono se repite de manera periódica hasta que se reparan el problema y la luz de advertencia. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 124
ADVERTENCIA: En un choque con volcadura, la probabilidad de muerte es mucho mayor para una persona que no lleva cinturón de seguridad, que para una que sí lo lleva. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 125
Asegúrese de ajustar firmemente la lengüeta en la hebilla. 2. Para desabrocharlo, presione el botón de apertura y quite la lengüeta de la hebilla. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 126
Los niños de hasta 12 años deben ir correctamente sujetos en el asiento trasero siempre que sea posible. Consulte Sistemas de seguridad para niños o Asientos de seguridad para niños más adelante en este capítulo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 127
Además, todos los cinturones de seguridad deben revisarse para comprobar que funcionan correctamente. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 128
Un pretensor de cinturón de seguridad es un dispositivo que aprieta las correas de los cinturones pélvicos y de hombros de tal manera que queden más ajustados al cuerpo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 129
La luz de advertencia del cinturón de seguridad se enciende en el grupo de instrumentos y suena una campanilla para recordar a los ocupantes que se abrochen el cinturón de seguridad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 130
Belt-Minder . El conductor y el pasajero delantero reciben las mismas advertencias. Si finalizan las advertencias (cuya duración es aproximadamente 5 minutos) para un ocupante (conductor o pasajero delantero), el otro ocupante aún puede activar esta característica. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 131
5 minutos o hasta que se abrochen los cuando ha transcurrido más de cinturones de seguridad. 1 a 2 minutos desde que el interruptor de encendido se giró a la posición ON... 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 132
40 km (25 millas) de casa. “Los cinturones son Los cinturones de seguridad de su incómodos” Ford están diseñados para aumentar la comodidad. Si se siente incómodo, pruebe las diferentes posiciones del anclaje superior del cinturón y respaldo del asiento, que debe estar lo más vertical posible;...
Page 133
Belt-Minder . Esto puede afectar negativamente al funcionamiento del sistema de bolsas de aire del vehículo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 134
Recomendamos que deje el sistema activado por su seguridad y la de otros que puedan utilizar el vehículo. Para reducir el riesgo de lesiones, no active/desactive la función de recordatorio de cinturón mientras maneje. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 135
• Después de recibir la confirmación, el proceso de desactivación o activación está completo. SISTEMA DE SUJECIÓN SUPLEMENTARIO DE BOLSA DE AIRE (SRS) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 136
Para colocarse a una distancia correcta de la bolsa de aire: • Mueva su asiento hacia atrás lo más posible, sin dejar de alcanzar cómodamente los pedales. • Recline levemente el asiento uno o dos grados desde la posición vertical. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 137
Si no se siguen estas instrucciones puede aumentar el riesgo de lesiones en una colisión. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 138
Puede tratarse de fécula de maíz, polvo de talco o compuestos de sodio que pueden irritar la piel y los ojos, pero ninguno de los residuos es tóxico. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 140
El sistema de sensores del pasajero delantero desactivará la bolsa de aire lateral del asiento del pasajero si: • el asiento del pasajero se encuentra vacío y el cinturón de seguridad está desabrochado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 141
Si esto sucede: • Apague el vehículo y pídale a la persona que ponga el respaldo en posición completamente vertical. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 143
• Objetos guardados en el bolsillo del mapa en el respaldo del asiento (si está equipado) • Objetos en el regazo del ocupante • Interferencia de la carga con el asiento 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 144
• El conductor y los pasajeros adultos deben buscar objetos que puedan estar almacenados debajo del asiento del pasajero delantero o alguna carga que interfiera con el asiento. • Retire los obstáculos (si los hay). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 145
En caso de que sea necesario modificar un sistema avanzado de bolsa de aire delantera para acomodar a una persona discapacitada, comuníquese con el Centro de relaciones con el cliente Ford al número de teléfono que aparece en el capítulo Asistencia al cliente de este Manual del propietario.
Page 146
Consulte con un distribuidor autorizado. ADVERTENCIA: Todos los ocupantes del vehículo deben usar siempre los cinturones de seguridad, incluso si se cuenta con un SRS de bolsas de aire. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 147
La bolsa de aire se diseñó para inflarse entre el panel de la puerta y el ocupante, para mejorar la protección proporcionada a los ocupantes en los choques de impacto lateral. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 148
• La luz de disponibilidad no se iluminará inmediatamente después de activar el encendido. • Se escuchará una serie de cinco pitidos. El tono se repite de manera periódica hasta que se reparen el problema o la luz. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 149
SRS de bolsas de aire y el sistema Safety Canopy . ADVERTENCIA: Para reducir el riesgo de lesiones, no obstruya ni coloque objetos en el espacio donde se despliega el sistema Safety Canopy inflable. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 151
C y D y forro del techo) debe ser inspeccionado y reparado por un distribuidor autorizado. Si no se reemplaza Safety Canopy , no funcionará nuevamente, lo cual aumentará el riesgo de lesión en caso de accidente. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 152
Eliminación de bolsas de aire y de vehículos con bolsas de aire (incluidos los pretensores) Consulte con su distribuidor autorizado. Las bolsas de aire DEBEN SER eliminadas por personal calificado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
NHTSA y otras organizaciones de seguridad o corresponden a los requisitos mínimos de la ley. Ford recomienda verificar con un técnico en seguridad de niños pasajeros certificado (CPST) de la NHTSA y con su pediatra para asegurarse de que el asiento para niño sea adecuado para su hijo y sea...
Page 154
• La ley en Estados Unidos y Canadá exige el uso de asientos de seguridad para niños e infantes. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 155
21 kg orientado (48 lbs) hacia atrás Asiento Hasta para niños 21 kg orientado (48 lbs) hacia ade- lante Asiento Sobre para niños 21 kg orientado (48 lbs) hacia ade- lante 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 156
ADVERTENCIA: Siempre asegure un asiento para niños o un asiento auxiliar no ocupado. Estos objetos podrían transformarse en proyectiles en un choque o frenada repentina, lo cual podría aumentar el riesgo de sufrir lesiones graves. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 157
0 y 16 años se aseguren adecuadamente en el sistema de sujeción correcto. Ford recomienda verificar con un técnico en seguridad de niños pasajeros certificado (CPST) de la NHTSA y con su pediatra para asegurarse de que el asiento para niño sea adecuado para su hijo y se...
Si todos los niños no se pueden sentar y asegurar correctamente en el asiento trasero, asegure correctamente al niño más grande en el asiento delantero. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 159
1. Coloque el asiento de seguridad para niños en un asiento con una combinación de cinturón pélvico y de hombros. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 160
Jálela para asegurarse que la lengüeta esté enganchada firmemente. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 161
También ayuda a lograr un ajuste adecuado del asiento del niño al vehículo. En ocasiones, una leve inclinación hacia la hebilla ayudará también a quitar el aflojamiento restante del cinturón. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 162
Si está bien instalado, no debería moverse más de 2.5 cm (una pulgada). 11. Ford recomienda verificar con un técnico en seguridad de niños pasajeros certificado (CPST) de la NHTSA para cerciorarse de que el sistema de seguridad para niños esté correctamente instalado.
Page 163
En caso de accidente, es posible que un anclaje no sea lo suficientemente fuerte como para sostener dos conexiones de asientos para niños y puede romperse, provocando lesiones graves o incluso la muerte. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 164
2,5 cm (una pulgada). Si el asiento de seguridad no está correctamente anclado, el riesgo de que un niño resulte lesionado en un choque aumenta considerablemente. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 165
Realice los siguientes pasos para instalar un asiento de seguridad para niños con los anclajes de correa: 1. Pase la correa de sujeción del asiento de seguridad para niños sobre el respaldo del asiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 166
Si el asiento de seguridad no está correctamente anclado, el riesgo de que un niño resulte lesionado en un choque aumenta considerablemente. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 167
Para que el cinturón pélvico y de hombros se ajuste mejor en los niños que han superado el tamaño de los asientos de seguridad para niños, Ford Motor Company recomienda el uso de un reforzador de colocación de cinturón.
Page 168
• ¿El cinturón pélvico descansa en la parte inferior de las caderas? • ¿El cinturón de hombros está centrado en el hombro y en el pecho? • ¿El niño puede permanecer sentado así durante todo el viaje? 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 170
No introduzca ningún elemento más grueso que éste bajo el asiento auxiliar. Revise las instrucciones del fabricante del asiento auxiliar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 171
Ford Motor Company recomienda reemplazar todos los conjuntos de cinturón de seguridad que se usan en vehículos que han participado en un accidente.
Page 172
ADVERTENCIA: Si no se inspecciona ni se reemplaza el mecanismo de los cinturones de seguridad o sistema de sujeción para niños de acuerdo con las condiciones anteriores, se pueden producir lesiones personales graves en caso de un choque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Estudie el Manual del propietario y todos los suplementos para obtener información específica acerca de las características del equipo, las instrucciones para una conducción segura y las precauciones adicionales para reducir el riesgo de accidentes o de lesiones graves. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 174
AWD pueden acelerar mejor que los de tracción en dos ruedas en situaciones que requieran baja tracción, éstos no frenan más rápido. Siempre maneje a una velocidad segura. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 175
Estas diferencias que hacen que su vehículo sea tan versátil también provocan que se maniobre en forma diferente a otros vehículos comunes de pasajeros. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 176
Departamento de Transportes de Estados Unidos: grados de calidad de llantas: el Departamento de Transportes de Estados Unidos exige que Ford Motor Company le proporcione la siguiente información acerca de los grados de las llantas exactamente como el gobierno la ha redactado.
Page 177
• Etiqueta de la llanta: una etiqueta que muestra los tamaños de llantas del OE (Equipamiento original), la presión de inflado recomendada y el peso máximo que puede transportar el vehículo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 178
Todos los días, antes de manejar, revise sus llantas. Si una parece estar más baja que las otras, use un manómetro para llantas para revisarlas y ajustarlas según sea necesario. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 179
Siempre infle sus llantas según la presión de inflado recomendada por Ford, incluso si ésta es menor a la información de presión de inflado máxima que aparece en la llanta. La presión de inflado de las llantas recomendada por Ford se encuentra en la Etiqueta de certificación del...
Etiqueta de la llanta. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 181
2 mm de desgaste (1/16 de una pulgada). Cuando la banda de rodadura de la llanta se desgasta a la misma altura que estas barras de desgaste , la llanta está gastada por lo que se debe reemplazar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 182
Por ejemplo, 2501 significa la semana 25 del 2001. Los números del medio son códigos de identificación que se usan para seguimiento. Esta información se usa para contactar a los clientes si un defecto en las llantas exige un retiro. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 183
Si esta información no se encontrara en estas etiquetas, entonces deberá consultar con un distribuidor Ford. El uso de cualquier llanta o rueda no recomendada por Ford puede afectar la seguridad y el rendimiento de su vehículo, lo que podría producir un aumento en el riesgo de pérdida de control del vehículo, volcadura, lesión personal y...
Page 184
Los sensores de presión de las llantas montados en las ruedas (que vienen originalmente en su vehículo) no están diseñados para uso en ruedas de refacción. El uso de ruedas o llantas no recomendadas por Ford Motor Company puede afectar el funcionamiento del Sistema de monitoreo de presión de las llantas.
Page 186
• Vehículos con tracción en las ruedas traseras (RWD)/Tracción en las cuatro ruedas (4WD)/ Vehículos con tracción en todas las ruedas (AWD) (llantas delanteras en la parte superior del diagrama) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 187
Nota: si el tamaño de la llanta no comienza con una letra, esto puede significar que fue diseñada por la ETRTO (Organización técnica europea de llantas y rines) o la JATMA (Asociación de fabricantes de llantas de Japón). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 188
Calificación de velocidad: km/h (mph) 130 km/h (81 mph) 140 km/h (87 mph) 159 km/h (99 mph) 171 km/h (106 mph) 180 km/h (112 mph) 190 km/h (118 mph) 200 km/h (124 mph) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 189
Pilar B o en el borde de la puerta del conductor, para conocer la presión correcta de las llantas de su vehículo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 190
Los proveedores de llantas pueden aplicar indicaciones, notas o advertencias adicionales, tales como carga estándar, radial sin cámara, etc. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 191
4. Carga máxima simple kg (lbs) a kPa (psi) en frío: indica la carga máxima y la presión de las llantas cuando la llanta se usa sola; una sola llanta se define así cuando se ponen dos llantas (total) en el eje trasero. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 192
Etiqueta de la llanta que contiene la presión de inflado de ésta, según tamaño y otra información importante. Consulte la descripción de carga útil y gráfico en la sección Carga del vehículo: con y sin remolque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Esta secuencia continuará en los siguientes arranques del vehículo, mientras exista el funcionamiento incorrecto. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 194
Debe tener cuidado cuando cambie las llantas para evitar dañar el sensor. Se recomienda que siempre repare sus llantas en un distribuidor autorizado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 195
Para restaurar toda la funcionalidad del Sistema de monitoreo de presión de las llantas, repare y vuelva a montar la rueda/llanta de carretera dañada en el vehículo. Para obtener información adicional, consulte Cambio de llantas con TPMS en esta sección. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 196
Si las llantas están correctamente incorrecto del infladas y la llanta de refacción no TPMS está en uso y la luz permanece encendida, lleve a revisar el sistema inmediatamente a su distribuidor autorizado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 197
éstas. Una vez que las llantas se inflan según la presión recomendada, deberá manejar unos dos minutos a más de 32 km/h (20 mph) para que la luz se apague. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 198
índice de carga, régimen de velocidad que aquellas proporcionadas originalmente por Ford. El uso de cualquier llanta o rueda no recomendada por Ford puede afectar la seguridad y el rendimiento de su vehículo, lo que podría producir un aumento en el riesgo de pérdida de control del vehículo, volcadura, lesión personal y...
• No los use en caminos secos. • No exceda los 48 km/h (30 mph) con cables para llantas en el vehículo. Para obtener información sobre otros métodos aprobados por Ford Motor Company para el control de la tracción, consulte a su distribuidor autorizado.
Page 200
útil máxima de su vehículo, no agregue más carga, incluso si hay espacio disponible. La sobrecarga o carga inadecuada del vehículo puede contribuir a que usted pierda el control o a que ocurra una volcadura. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 201
Al remolcar, el peso de la lengüeta de remolque o el peso del pivote de la dirección también es parte del peso de la carga. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 202
Etiqueta de certificación del cumplimiento de las normas de seguridad, ubicada en el Pilar B o en el borde de la puerta del conductor. El GVW nunca debe exceder el GVWR. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 203
Peso en la lanza o peso en el pasador maestro de la quinta rueda: Se refiere a la cantidad de peso que un remolque aplica sobre el enganche del remolque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 204
5. Determine el peso combinado de equipaje y carga que llevará el vehículo. Ese peso no puede exceder, sin correr peligro, la capacidad de carga de equipaje y la carga disponible calculadas en el Paso 4. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 205
Peso bruto vehicular del eje delantero o trasero, especificado para su vehículo en la Etiqueta de certificación del cumplimiento de las normas de seguridad que se encuentra en la puerta del conductor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 206
• No arrastre un remolque hasta que el vehículo haya recorrido por lo menos 1,600 km (1,000 millas). • Consulte las instrucciones incluidas con los accesorios de remolque para obtener las especificaciones adecuadas de instalación y ajuste. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 207
Ciertos Estados requieren frenos eléctricos de remolque para remolques sobre el peso específico. El sistema eléctrico del vehículo Escape no permite que se instalen frenos de remolque eléctricos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 209
Consulte con su distribuidor autorizado o la agencia de arrendamiento de remolques para obtener las instrucciones y los equipos adecuados para conectar las luces del remolque. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 210
• Deje una mayor distancia para detenerse con un remolque enganchado. • El peso de la lengüeta del remolque debe representar entre un 10% y un 15% del peso del remolque cargado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
(por ejemplo, detrás de una casa rodante o camión). En caso de emergencia en el camino con un vehículo descompuesto consulte, Remolque con grúa de auxilio en el capítulo Emergencias en el camino. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 212
105 km/h (65 mph) en vehículos con transmisión automática. • Arranque el motor y déjelo funcionar durante 5 minutos al comienzo de cada día y en cada parada de combustible. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ADVERTENCIA: No estacione, ponga en ralentí o maneje su vehículo en pasto seco u otras superficies secas. El sistema de emisión de gases calienta el compartimiento del motor y el sistema de escape, lo que puede iniciar un incendio. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 214
Asientos y sistemas de seguridad. 2. Asegúrese de que los faros delanteros y los accesorios del vehículo estén apagados. Si arranca un vehículo con transmisión automática: • Asegúrese que esté puesto el freno de estacionamiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 215
• Asegúrese que esté puesto el freno de estacionamiento. • Pise el pedal del embrague hasta el suelo. 3. Gire la llave a 3 (ON) sin girarla a 4 (START). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 216
ADVERTENCIA: Si huele gases de escape dentro de su vehículo, haga que su distribuidor lo inspeccione de inmediato. No conduzca si huele gases de escape. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 217
• No utilice varios cables de extensión. Por el contrario, use un cable de extensión de largo suficiente para unir el cable del calefactor de bloque del motor con el tomacorriente, sin que sea necesario estirarlo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 218
Asegúrese de que el sistema esté desconectado y adecuadamente guardado antes de conducir el vehículo. Cuando no lo use, asegúrese de que la tapa protectora selle las puntas del enchufe del cable del calefactor de bloque del motor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ABS y aumentará la distancia de frenado de su vehículo. El ABS se activará inmediatamente, permitiéndole conservar el control de la dirección durante frenados bruscos y en superficies resbalosas. Sin embargo, el ABS no disminuye la distancia de frenado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 220
ADVERTENCIA: Si suelta completamente el freno de estacionamiento, pero la luz de advertencia de frenos permanece iluminada, es posible que los frenos no estén funcionando correctamente. Consulte con su distribuidor autorizado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 221
AdvanceTrac con RSC . Reducir la eficacia del sistema AdvanceTrac con RSC puede derivar en un mayor riesgo de perder el control del vehículo, una volcadura, lesiones personales o la muerte. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 222
Todas las características del sistema (TCS, ESC y RSC ) están activas y monitorean el vehículo desde el arranque. Sin embargo, el sistema sólo interviene si la situación de manejo lo requiere. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 223
El Control de tracción está más activo a baja velocidad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 224
• Entrar en un camino pavimentado desde un camino de grava o viceversa • Virar en curvas cuando se arrastra un remolque muy cargado (consulte Arrastre de remolque en el capítulo Llantas, ruedas y carga). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 225
AdvanceTrac con RSC desactivado se apagará el icono En R (Reversa), ABS y las características de control de tracción del motor y de frenado continuarán funcionando; sin embargo, ESC y RSC están desactivados. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 226
Consulte la sección Arrastre de remolque en el capítulo Llantas, ruedas y carga del manual del propietario para obtener más información sobre cómo arrastrar un remolque con su vehículo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 227
ADVERTENCIA: Al desactivar el control de oscilación de remolque aumenta el riesgo de pérdida de control del vehículo, de sufrir lesiones graves o incluso la muerte. Ford no recomienda desactivar esta función, excepto en situaciones donde la reducción de velocidad pueda ser perjudicial (por ejemplo, al subir un cerro), cuando el conductor tenga gran experiencia en arrastre de remolques y pueda controlar la oscilación del remolque y mantener un...
Page 228
Si sobrecarga o carga de manera inadecuada el vehículo, puede deteriorar la capacidad de manejo y contribuir a la pérdida del control del vehículo o causar una volcadura. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
P (Estacionamiento) y quede en la posición N (Neutro). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 230
Con el tiempo, el proceso de aprendizaje de adaptación actualizará por completo el funcionamiento de la transmisión. Adicionalmente, cuando se desconecta la batería o cuando se instala una nueva, la estrategia se debe volver a aprender. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 231
R (Reversa) Con la palanca de cambio de velocidades en R (Reversa), el vehículo se mueve hacia atrás. Siempre detenga completamente el vehículo antes de cambiar hacia y desde R (Reversa). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 232
• La sobremarcha se desactiva. • La transmisión funciona en las marchas uno a cinco. • Se enciende la luz de cancelación de sobremarcha y asistencia en pendientes en el grupo de instrumentos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 233
No balancee el vehículo por más de un minuto, de lo contrario, es posible que se dañen la transmisión y las llantas o bien, se sobrecaliente el motor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 234
Si no presiona totalmente el pedal del embrague hasta el piso, el cambio hará más esfuerzo, los componentes de la transmisión se gastarán prematuramente o se dañará la transmisión. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 235
Suelte el pedal del clutch durante un momento, luego vuelva a presionarlo y cambie nuevamente a R (Reversa). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 236
Es posible que el sistema no detecte objetos más pequeños, especialmente aquellos que estén cerca del suelo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 237
Cuando el sistema está desactivado, se enciende una luz indicadora en el control. Si se enciende cuando el RSS no está desactivado, la luz indicadora puede señalar una falla del sistema. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 238
Las diferencias que hacen que su vehículo sea tan versátil también hacen que se maneje en forma diferente a otros vehículos comunes de pasajeros. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 239
Recuerde, su seguridad y la de otros debe ser su principal preocupación. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 240
Consulte con su distribuidor autorizado. ADVERTENCIA: No gire las ruedas a más de 56 km/h (35 mph). Las llantas pueden fallar y lesionar a un pasajero o a un observador. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 241
Recuerde, usted puede ser capaz de salir en reversa por donde entró si procede con cuidado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 242
áreas salvajes de nuestra nación. Ford Motor Company se une al Servicio Forestal de EE.UU. (U.S. Forest Service) y a la Oficina de Administración de Tierras (Bureau of Land Management) instándolo a ayudar a preservar los bosques de la nación y otros terrenos públicos y...
Page 243
Si lo hace, las ruedas delanteras no podrán girar y, si no lo hacen, usted no podrá maniobrar. Las ruedas delanteras tienen que girar 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 244
Los sistemas de suspensión y dirección de su vehículo se han diseñado y probado para proporcionar un rendimiento predecible, ya sea cargado o vacío, así como también una capacidad durable de transporte de carga. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 245
Toda modificación al vehículo que levante el centro de gravedad puede hacer que el vehículo tenga más probabilidades de volcarse como resultado de una pérdida de control. Ford Motor Company recomienda tener precaución con cualquier vehículo equipado con una carga o dispositivo alto (tales como parrillas de escalera o cubiertas de caja de pickup).
Obtener asistencia en el camino Para brindarle una ayuda total en caso de que tenga un problema con el vehículo, Ford Motor Company ofrece un programa gratuito de asistencia en el camino. Este programa es independiente de la Garantía limitada de vehículos nuevos.
Page 247
En Canadá, la tarjeta se encuentra en el Manual de información del propietario, dentro de la guantera. Los clientes propietarios de vehículos Ford, Mercury y Lincoln en los EE.UU. que necesiten asistencia en el camino, llamen al 1-800-241-3673.
Este dispositivo impide que la bomba eléctrica de combustible siga enviando combustible al motor cuando su vehículo ha participado en un choque. Después de un accidente, si el motor gira pero no arranca, puede que se haya activado este interruptor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Nota: Siempre reemplace un fusible por otro que tenga el amperaje especificado. El uso de un fusible con un amperaje mayor puede causar un grave daño al cableado y podría provocar un incendio. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 250
Verde Verde jado 50 A — — Rojo Rojo Rojo 60 A — — Azul Amarillo Amarillo 70 A — — Canela — Marrón 80 A — — Natural Negro Negro 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 251
Quite la tapa del tablero para tener acceso a la cubierta de fusibles. Presione las lengüetas en la parte superior e inferior de la cubierta de fusibles para quitarla. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 252
20 A Alimentaciones de todos los seguros eléctricos, apertura de compuerta levadiza, apertura de ventana de compuerta levadiza 20 A Asiento térmico 25 A Limpiador trasero 15 A Enlace de datos 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 253
Transceptor PATS (sistema pasivo antirrobo) 10 A Control de aire acondicionado y calefacción 20 A Bocina de graves auxiliar/Amp (radio Audiophile) 20 A Radio, Amplificador de radio (sólo navegación) 20 A Tomacorriente delantero 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 254
Esta caja contiene fusibles de alta potencia que protegen a los sistemas eléctricos principales del vehículo contra sobrecargas. ADVERTENCIA: Siempre desconecte la batería antes de trabajar con fusibles de alta potencia. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 255
Desempañador trasero 20 A** Tomacorriente trasero (consola central) — No se usa 10 A* Mantenimiento de energía del Módulo de control del tren motriz (PCM), relevador de PCM, Ventilación del cánister 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 256
Bomba de combustible 15 A* Inyectores de combustible — No se usa — No se usa 15 A* Bobinas de encendido 10 A* Luz indicadora de funcionamiento incorrecto no mil de PCM 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 257
— Diodo del PCM — Diodo de arranque 10 A* Relevador de marcha/arranque, luces de reversa, desempañador trasero — No se usa — No se usa *Mini fusible **Fusible de cartucho 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 258
Sistema de control de la presión de las llantas (TPMS) en el capítulo Llantas, ruedas y carga. Si se daña, el sensor del monitor de presión de las llantas no volverá a funcionar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 259
Ford originalmente. Si la llanta o rueda de refacción distinta está dañada, en lugar de repararla, debe reemplazarla.
Page 260
• maneje vehículos con carga en una parrilla para carga Maneje con cuidado cuando use una llanta o rueda de refacción distinta de tamaño completo y busque servicio lo antes posible. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 261
Quite la llave de tuercas del gato para quitar la llanta de refacción de debajo del vehículo. Quite la llave de tuercas del gato para quitar la llanta de refacción de debajo del vehículo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 262
(1). 5. Use la llave de tuercas para sacar la tuerca de seguridad de la correa de la llanta de refacción. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 263
Saque el vehículo del camino para evitar el peligro de ser golpeado al manejar el gato o al cambiar la rueda. 1. Bloquee la rueda diagonalmente opuesta. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 264
Antes de colocar el gato debajo del vehículo, OBSERVE las ubicaciones del gato: • Delantero Vista desde la parte trasera de la llanta delantera. Coloque el gato directamente debajo del perno que sobresale. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 265
25 mm (1 pulgada) del suelo. Asegúrese de colocar el gato lejos del borde trasero del balancín para evitar dañar el alerón de la llanta trasera (en la imagen). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 266
Consulte Especificaciones de torsión de las tuercas de seguridad de las ruedas más adelante en este capítulo para ver la especificación adecuada para la torsión de las tuercas de seguridad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 267
4. Deslice parcialmente la rueda bajo el vehículo e instale el retén a través del centro de la rueda. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
N•m M12 x 1.5 * Las especificaciones de torsión son para las roscas de pernos y tuercas sin suciedad ni óxido. Sólo utilice los sujetadores de repuesto que recomienda Ford. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 269
Fuel™ . Esto podría dañar el sistema de combustible y su sello y hacer que el combustible caiga al suelo en lugar de llenar el tanque, todo lo cual podría ocasionar graves lesiones personales. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
5. Encienda el ventilador del calefactor en ambos vehículos para evitar daños causados por descargas de voltaje. Apague todos los demás accesorios. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 271
Nota: En las ilustraciones, los pernos destacados con un rayo se usan para designar la batería auxiliar. 2. Conecte el otro extremo del cable positivo (+) al terminal positivo (+) de la batería auxiliar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 272
Arranque con cables pasacorriente 1. Encienda el motor del vehículo auxiliar y haga funcionar el motor aumentando la velocidad en forma moderada. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 273
Nota: En las ilustraciones, los pernos destacados con un rayo se usan para designar la batería auxiliar. 2. Retire el cable pasacorriente de la conexión negativa (-) de la batería del vehículo auxiliar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 274
Después de encender el vehículo descompuesto y de retirar los cables pasacorriente, déjelo funcionar en ralentí durante varios minutos, de modo que la computadora del motor pueda reaprender sus condiciones de ralentí. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Se recomienda remolcar su vehículo con un elevador y plataformas rodantes o equipos de plataforma plana. No remolque con una eslinga. Ford Motor Company no ha aprobado el procedimiento de remolque con eslingas. En vehículos FWD, si se remolcan desde la parte delantera, asegúrese de usar el equipo elevador correcto para levantar las ruedas delanteras.
Page 276
4WD o el vehículo. Ford Motor Company elabora un manual de remolque para todos los operadores autorizados de camiones de remolque. Haga que el operador de la grúa de remolque consulte este manual para que vea los...
Fuera de la ciudad Si estuviera lejos de su casa cuando necesite hacer una reparación, comuníquese con el Centro de relaciones con el cliente de Ford o utilice los recursos en línea indicados a continuación para encontrar el distribuidor más cercano a usted.
Page 278
2. Si sus preguntas o preocupaciones quedan sin resolver, contáctese con el Gerente de ventas o el Gerente de relaciones comerciales. 3. Si requiere asistencia o aclaración con respecto a las políticas o procedimientos de Ford Motor Company, comuníquese con Ford Customer Relationship Center. 2009 Escape (204)
Page 279
En algunos estados, debe notificar directamente a Ford (por escrito) antes de proceder con soluciones, de acuerdo con las leyes de garantía de su estado. En algunos estados también se le permitirá a Ford intentar una reparación final. En Estados Unidos, una disputa de garantía se debe enviar a BBB AUTO LINE antes de tomar acciones bajo la ley Magnuson–Moss Warranty Act,...
Page 280
Usted no está obligado por esta decisión, pero debería optar por aceptar la decisión de BBB AUTO LINE, Ford debe cumplir con la decisión tomada de igual manera. Los conflictos enviados al programa BBB AUTO LINE normalmente se deciden dentro de cuarenta días a contar de la...
Page 281
(SÓLO CANADÁ) Para vehículos entregados a distribuidores autorizados canadienses. En aquellos casos en que considere que los esfuerzos realizados por Ford of Canada y por el distribuidor autorizado para resolver un problema del servicio del vehículo relacionado con la fabricación han sido insatisfactorios, Ford of Canada participa en un programa de mediación y...
Page 282
Extensión de Servicio Ford o visite el sitio Web de ESP de Ford en: www.ford-esp.com. CÓMO CONSEGUIR ASISTENCIA FUERA DE EE.UU. Y CANADÁ...
Page 283
Si se encuentra en otro país, comuníquese con el distribuidor autorizado más cercano. Si los empleados del distribuidor autorizado no pueden ayudarlo, ellos pueden llevarlo a la oficina afiliada de Ford más cercana. Si usted compra su vehículo en Norteamérica y luego lo lleva fuera de los Estados Unidos o Canadá, registre el número de identificación del...
Administración nacional de seguridad de tránsito en carreteras (NHTSA) además de notificar a Ford Motor Company. Si la NHTSA recibe quejas similares, puede abrir una investigación y si encuentra que existe un defecto de seguridad en un grupo de vehículos, puede solicitar una campaña de devolución y reparación.
• Después de pulir las defensas cromadas, aplique Motorcraft Premium Liquid Wax (ZC-53-A), disponible en los distribuidores autorizados, o bien un producto de calidad equivalente como protección contra los efectos ambientales. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 286
• Para eliminar la grasa o el alquitrán, use Motorcraft Bug and Tar Remover (ZC-42), disponible en su distribuidor autorizado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 287
• Cubra las áreas destacadas para evitar daños causados por el agua al limpiar el motor. • Nunca lave ni enjuague el motor mientras esté funcionando; el agua en el motor en marcha puede provocar daños internos. I4 DE 2.5L 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 288
• El parabrisas, las ventanas traseras y las ventanas laterales se pueden limpiar con un limpiador no abrasivo, como por ejemplo, Motorcraft Ultra Clear Spray Glass Cleaner (ZC-23), disponible con su distribuidor autorizado. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 289
• No use limpiadores caseros o limpiavidrios, puesto que éstos podrían dañar el acabado del tablero de instrumentos, tapizado interior y mica del grupo de instrumentos. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 290
• No use productos de limpieza caseros o limpiadores de vidrio que puedan decolorar y manchar la tela y afectar las capacidades de retardo de llama que poseen los materiales del asiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 291
PARTE INFERIOR DE LA CARROCERÍA Lave frecuentemente toda la parte inferior del vehículo. Mantenga los orificios de drenaje de la carrocería y de las puertas libres de suciedad. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 292
PRODUCTOS PARA EL CUIDADO DE LOS VEHÍCULOS FORD Y LINCOLN MERCURY Su distribuidor autorizado Ford o Lincoln Mercury dispone de muchos productos de calidad para limpiar su vehículo y proteger sus acabados. Estos productos de calidad han sido diseñados específicamente para satisfacer sus necesidades automovilísticas;...
1. Ponga el freno de estacionamiento, presione el embrague y coloque la palanca de cambio de velocidades en 1 (Primera). 2. Apague el motor y quite la llave. 3. Bloquee las ruedas. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 294
2. En la parte delantera del vehículo, levante la manija del seguro auxiliar ubicada en la parte central, entre el cofre y la rejilla. 3. Abra el cofre y asegúrelo con la varilla de soporte. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
6. Caja de distribución de la corriente 7. Batería 8. Válvula de descarga de líquido refrigerante del motor 9. Varilla indicadora del nivel de aceite del motor 10. Depósito del líquido lavaparabrisas 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 296
6. Batería 7. Válvula de descarga de líquido refrigerante 8. Varilla indicadora del nivel de aceite del motor 9. Tapón de llenado del aceite del motor 10. Depósito del líquido lavaparabrisas 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 297
Use sólo un líquido lavaparabrisas que cumpla con las especificaciones de Ford. No use ningún líquido lavaparabrisas especial como líquido lavaparabrisas repelente al agua o líquido para eliminar insectos. Pueden causar chirrido, castañeteo, rayas y manchas. Consulte la sección Especificaciones de productos de mantenimiento y capacidades en este capítulo.
Page 298
Cambio de la hoja del limpiador trasero El brazo del limpiador trasero está diseñado sin una posición de servicio. Esto disminuye el riesgo de dañar la hoja en un lavado automático de automóviles. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
(Estacionamiento) (transmisiones automáticas) o en 1 (Primera) (transmisiones manuales). 4. Abra el cofre. Protéjase del calor del motor. 5. Ubique y extraiga cuidadosamente la varilla indicadora del nivel de aceite del motor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 300
• Si el nivel del aceit está por debajo del orificio inferior o la línea inferior, debe agregarse aceite de motor para elevar el nivel dentro del rango operativo normal. • Motor I4 de 2.5L 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 301
Para evitar posibles pérdidas de aceite, NO haga funcionar el vehículo sin la varilla indicadora de nivel o el tapón de llenado de aceite del motor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 302
Cambie el filtro y el aceite del motor de acuerdo con el programa adecuado señalado en la información de mantenimiento programado. Los filtros de aceite Ford y de refacción Motorcraft están diseñados para proporcionar una mayor protección al motor y una vida útil más prolongada.
ácido fluya a través de los tapones de ventilación y provoque lesiones personales o daños al vehículo o a la batería. Levante la batería con un portabaterías o con las manos apoyadas en esquinas opuestas. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 304
Como resultado, la transmisión puede cambiar firmemente. Esta operación se considera normal y el funcionamiento de la transmisión se actualizará completamente a su percepción de cambio óptima. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Protección contra el congelamiento hasta -36° C (-34° F) • Protección contra la ebullición hasta 129° C (265° F). • Protección contra óxido y otras formas de corrosión. • Función correcta de los indicadores calibrados. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 306
El vapor y los líquidos candentes, liberados de un sistema de enfriamiento caliente, pueden producirle quemaduras graves. También puede sufrir quemaduras si derrama líquido refrigerante en las piezas calientes del motor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 307
Motorcraft Specialty Orange Engine Coolant, que cumple con la especificación WSS-M97B44-D o DEX-COOL de Ford, con el líquido refrigerante que viene de fábrica. La mezcla de Motorcraft Specialty Orange Engine Coolant o cualquier producto de larga vida de color naranja, como DEX-COOL , con su líquido refrigerante de fábrica, puede hacer que se degrade la...
Page 308
50/50 (protección hasta –36° C [–34° F]), drene un poco de líquido refrigerante y ajuste la concentración. Es posible que se tengan que efectuar varios drenajes y adiciones para obtener una concentración de líquido refrigerante 50/50. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 309
éste. Líquido refrigerante del motor reciclado Ford Motor Company NO recomienda el uso de un líquido refrigerante reciclado del motor en vehículos originalmente provistos de Motorcraft Premium Gold Engine Coolant, dado que aún no se encuentra disponible un proceso de reciclaje aprobado por Ford.
Page 310
Si alcanza una condición de temperatura excesiva preestablecida, el motor cambia automáticamente al funcionamiento alterno de cilindros. Cada cilindro desactivado actúa como una bomba de aire y enfría el motor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 311
FILTRO DE COMBUSTIBLE Si vehículo cuenta con un filtro de combustible de por vida que está integrado al tanque de combustible. No es necesario realizar mantenimiento periódico ni reemplazarlo. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 312
Si se ingiere combustible, llame a un médico cuanto antes, incluso si no se presentan síntomas aparentes inmediatamente. Los efectos tóxicos del combustible pueden no hacerse visibles durante horas. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 313
ADVERTENCIA: El flujo de combustible a través de una boquilla de la bomba de combustible puede producir electricidad estática, lo que podría provocar un incendio si el combustible se bombea hacia un contenedor de combustible no conectado a tierra. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 314
Cuando llene el tanque de combustible de su vehículo: 1. Apague el motor. 2. Abra la puerta de llenado de combustible. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 315
Seguir conduciendo con la luz o el mensaje que indican revisar el orificio de llenado de combustible encendidos puede hacer que la luz Service Engine Soon (Servicio del motor a la brevedad) se encienda también. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 316
(R+M)/2 de 87. No se recomienda el uso de (R+M)/2 METHOD gasolinas etiquetadas como Normales en áreas de gran altitud que se venden con clasificaciones de octanaje inferior a 87. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 317
Aire más limpio Ford respalda el uso de gasolinas “con una combustión más limpia” reformuladas para mejorar la calidad del aire, según las recomendaciones de la sección Cómo escoger el combustible adecuado.
Page 318
Cuando llene el tanque de combustible del vehículo con un contenedor portátil de combustible, use el embudo que se incluye. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 319
No recomendamos medir el ahorro de combustible durante los primeros 1,600 km (1,000 millas) de manejo (período de asentamiento del motor). Obtendrá una medida más precisa después de 3,000 a 5,000 km (2,000 a 3,000 millas). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 320
Sus resultados serán más precisos si su método de llenado es constante. Cálculo para ahorrar combustible 1. Llene completamente el tanque y registre la lectura inicial del odómetro (en kilómetros o millas). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 321
• Baje la velocidad gradualmente. • Al manejar a velocidades razonables (viajar a 88 km/h [55 mph]), se usa un 15% menos de combustible que cuando se viaja a 105 km/h (65 mph). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 322
• El uso de combustible mezclado con alcohol puede reducir el ahorro de combustible. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 323
útil y el rendimiento de su vehículo y de su sistema de emisión de gases. Si se usan refacciones que no sean Ford, Motorcraft o autorizadas por Ford para los reemplazos de mantenimiento o para el servicio de componentes que afecten el control de emisión de gases, dichas refacciones que no son Ford deben ser equivalentes a las refacciones Ford Motor Company originales en cuanto a rendimiento y durabilidad.
Page 324
El sistema OBD-II además ayuda a su distribuidor autorizado a prestar la asistencia adecuada a su vehículo. Cuando el indicador Servicio del motor a la 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 325
OBD-II determina que algunos de los sistemas de control de emisiones no se han supervisado adecuadamente. En este caso, el vehículo se considera no listo para la prueba de I/M. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 326
Si el vehículo aún no está listo para la prueba de I/M, deberá repetirse el ciclo de conducción anterior. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 327
3. Con el freno de estacionamiento puesto y el pie en el pedal del freno, arranque el motor y mueva la palanca de cambio de velocidades por todas las velocidades. Dé tiempo suficiente para que cada cambio se engrane. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 328
Una condición de llenado excesivo de líquido de la transmisión puede provocar problemas de cambios y/o de acoplamiento o posibles daños. Los niveles altos de líquido pueden ser producto del sobrecalentamiento. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 329
6. El nivel del líquido debe estar en la parte inferior de la abertura. 7. Agregue líquido suficiente a través de la abertura de llenado, de modo que el nivel del líquido esté en la parte inferior de la abertura. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Mantenimiento y especificaciones 8. Instale y apriete el tapón de llenado con firmeza. Use sólo un líquido que cumpla con las especificaciones de Ford. Consulte la sección Especificaciones de productos de mantenimiento y capacidades en este capítulo. FILTRO DE AIRE Consulte la información de mantenimiento programado para conocer...
PCV. Reemplace la válvula PCV con una que cumpla con los materiales y especificaciones de diseño Ford para su vehículo, tales como refacciones de Motorcraft o equivalentes. La garantía al usuario se puede anular por cualquier daño al sistema de emisión de gases si no se usa una válvula PCV.
Page 332
Mantenimiento y especificaciones Reemplace las bujías por otras que cumplan con los materiales y especificaciones de diseño Ford para su vehículo, tales como refacciones de Motorcraft o equivalentes. La garantía al usuario se puede anular por cualquier daño al motor si no se usan tales bujías.
Page 333
Mantenimiento y especificaciones 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 334
Mantenimiento y especificaciones 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 335
Mantenimiento y especificaciones 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 336
Mantenimiento y especificaciones 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Separación de los 1.25–1.35mm 1.15–1.25mm (0.045–0.049 electrodos de las (0.049–0.053 pulg) pulg) bujías Relación de 9.7:1 10.3:1 compresión Enrutado de las correas de la transmisión del motor • Motor I4 de 2.5L 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 338
(pilar B) junto al borde de salida de la puerta del conductor o en el borde de la puerta del conductor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 339
3. Línea, serie y tipo de carrocería del vehículo 4. Tipo de motor 5. Dígito de verificación 6. Año de modelo 7. Planta de ensamblaje 8. Número de secuencia de producción 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 340
Etiqueta de certificación del cumplimiento de las normas de seguridad. El siguiente cuadro le indica qué transmisión representa cada código. Descripción Código Manual de 5 velocidades Automática de seis velocidades 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
ACCESORIOS LEGÍTIMOS DE FORD PARA SU VEHÍCULO Existe una amplia variedad de accesorios Ford legítimos disponibles para su vehículo a través de su distribuidor local Ford o Ford de Canadá. Estos accesorios de calidad han sido diseñados específicamente para satisfacer las necesidades para su vehículo; están diseñados especialmente para complementar el estilo y apariencia aerodinámica de...
Page 342
• La incorporación de accesorios o componentes eléctricos o electrónicos al vehículo por parte del distribuidor autorizado o del propietario puede afectar el rendimiento y la durabilidad de la batería. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
.......283 para utilizar el Programa de AM/FM .........20 mediacio ´ n y arbitraje .....281 Anticongelante (vea Lı ´ quido Plan Gane de Ford ....282 refrigerante del motor) ....305 Asistencia en el camino ...246 Apoyacabezas ......115 Aviso especial Arranque con cables ....270 transformacio ´...
Page 344
Control de velocidad) ....71 Clutch Control de velocidad ....71 funcionamiento al manejar ..234 Controles lı ´ quido ........327 asiento ele ´ ctrico .....112 velocidades de cambio recomendadas ......235 columna de direccio ´ n ....74 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 346
(vea Luces) .........12 capacidades de llenado ...309, 333 especificaciones ......333 Luces diurnas automa ´ ticas (consulte Luces) ......50 revisio ´ n y llenado ....305 Llantas .......176–177 Luces intermitentes de emergencia ........248 alineamiento ......185 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 347
´ n de vehı ´ culo ........228 seguridad .........130 Sensor de Clasificacio ´ n de Prueba de Peso .........121 inspeccio ´ n/mantenimiento (I/M) ...........325 Retardo de accesorios ....68 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 348
´ n del tablero e cierre y apertura de interior ........51 puertas ........104 limpieza ........289 programacio ´ n del co ´ digo de entrada ........103 Tablero de instrumentos teclado ........103 grupo .........12 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 349
........74 automa ´ tica .......231 inclinacio ´ n .........62 Transmisio ´ n manual ....234 Volante de la dirección de capacidades de lı ´ quido ...333 inclinación ........62 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 350
Dual automatic temperature control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Moon roof Message center 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 354
Drive your new vehicle at least 1,000 miles (1,600 km) before towing a trailer. For more detailed information about towing a trailer, refer to Trailer towing in the Tires, Wheels and Loading chapter. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 355
In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 356
• where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 357
Your vehicle is not equipped with a snowplowing package. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs.
Page 358
Owner’s Guide is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for Export. Refer to this Owner’s Guide for all other required information and warnings. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 359
Brake Fluid - Parking Aid System Non-Petroleum Based Stability Control System Speed Control Master Lighting Switch Hazard Warning Flasher Fog Lamps-Front Fuse Compartment Fuel Pump Reset Windshield Wash/Wipe Windshield Rear Window Defrost/Demist Defrost/Demist 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 360
Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Service Engine Soon Engine Air Filter Passenger Compartment Jack Air Filter Low Tire Pressure Check Fuel Cap Warning 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Many lights will illuminate when you start your vehicle to make sure the bulbs work. If any light remains on after starting the vehicle, refer to the respective system warning light for additional information. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 362
Easy Fuel “no cap” fuel system in the Maintenance and Specification chapter. If “CHECK FUEL FILL INLET” is displayed in the message center, refer to Message center in the Driver Controls chapter for more information. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 363
A Belt-Minder chime will also sound to remind you to fasten your safety belt. Refer to the Seating and Safety Restraints chapter to activate/deactivate the Belt-Minder chime feature. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 364
(refer to Fuel gauge in this chapter). Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 365
Message center activation chime (if equipped): Sounds when a warning message (except PARKING BRAKE ENGAGED while parked) appears in the message center display for the first time. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Instrument Cluster GAUGES Standard instrument cluster gauges Optional instrument cluster gauges Speedometer: Indicates the current vehicle speed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 367
Refer to Filling the tank in the Maintenance and Specifications chapter for more information. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 368
Press and release the message center INFO button until TRIP A mode appears in the display. Press the control again to select the TRIP B feature. Press and hold the RESET button to reset. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 370
10 in AM, 10 in FM1 and FM2. Saving presets automatically (Autoset)– Autoset allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 371
LOAD CD #, load the desired disc, label side up. If you do not choose a slot within five seconds, the system will choose for you. Once loaded, the first track will begin to play. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 372
In CD mode– Press DIRECT. The display will read DIRECT TRACK MODE SELECT TRACK. Enter the desired track number using the memory preset buttons (0–9). The system will then begin playing that track. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 373
SIRIUS: Press to access satellite radio mode, if equipped. Press repeatedly to cycle through SAT1, SAT2 and SAT3 modes. TUNE/OK: Turn the knob to go to the next / previous available SIRIUS satellite station. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 374
NO CATEGORY SELECTED will display. Note: Separate categories can be set for SAT1, SAT2 or SAT3. Refer to Satellite radio menu for further information on selecting a satellite radio category. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 375
The display will read ARE YOU SURE ? Press OK to confirm deletion of all saved songs and the display will read ALL DELETED. Note: If there are no songs presently saved, the display will read NO SONGS. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 376
ALL SEATS (Occupancy mode, if equipped): Press SOUND repeatedly to reach the Occupancy mode setting. Press SEEK/TRACK to select and optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 378
6. Press AUX on the vehicle radio repeatedly until LINE, LINE IN or SYNC LINE IN appears in the display. You should hear audio from your portable music player although it may be low. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 380
• Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 381
CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
Page 382
.mp3 file extension) and all folders containing MP3 files, from F001 (folder) T001 (track) to F253 T255. • Creating discs with only one level of folders will help with navigation through the disc files. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Antenna obstructions: For optimal reception performance, keep the antenna clear of snow and ice build-up and keep luggage and other material as far away from the antenna as possible. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 384
Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 385
The system is working properly. NO TEXT Song title Song title information not information not available at this time on available. this channel. The system is working properly. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Your vehicle may be equipped with SYNC, a hands-free communications and entertainment system with special phone and media features. For more information, please refer to the SYNC supplement or to the SYNC section in the Navigation system supplement (if equipped). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
: Distributes air through the instrument panel vents, demister vents, floor vents and rear seat floor vents (if equipped). : Distributes air through the demister vents, floor vents and rear seat floor vents (if equipped). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 388
• Do not put objects under the front seats that will interfere with the airflow to the back seats. • Remove any snow, ice or leaves from the air intake area at the base of the windshield. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 389
5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
: Distributes air through the windshield defroster vents, demister vents, floor vents and rear seat floor vents. The system will automatically provide outside air to reduce window fogging. Press AUTO to return to full automatic control. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 391
Press the MAX A/C button again for normal A/C operation. 13. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in MAX A/C, (defrost) and (floor/defrost). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 392
2. Do not override A/C or (recirculated air). 3. Set the temperature to 60°F (16°C). • Manual operation: 1. Select MAX A/C. 2. Select 3. Select (recirculated air) to provide colder airflow. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
If the windshield wipers are turned on for a brief period of time, the exterior lamps will turn on with the headlamp control in the autolamp position. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 395
Pull the headlamp control towards you to turn the fog lamps on. The fog lamp indicator light will illuminate. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 396
(DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 397
3.0 mm circle on the headlamp lens. 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. Cover the left-hand headlamp with an opaque cloth. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Push up to activate the right turn signal. INTERIOR LAMPS Dome lamps and map lamps The front dome lamp is located overhead between the driver and passenger seats. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 399
ON position. • the control is in the DOOR position and any door is open. When the control is in the OFF position, it will not illuminate when you open the doors. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Examples of unacceptable moisture (usually caused by a lamp water leak) are: • Water puddle inside the lamp • Large water droplets, drip marks or streaks present on the interior of the lens 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 401
To replace all instrument panel lights - see your authorized dealer Replacing the interior bulbs Check the operation of all bulbs frequently. Replacing exterior bulbs Check the operation of all the bulbs frequently. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 402
1. Make sure the headlamp control is in the off position. 2. Open the hood. 3. Reach over the front bolster. 4. Rotate the bulb socket counterclockwise and remove from the lamp assembly. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 403
5. Pull bulb straight out of socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly and rotate clockwise. 7. Carefully install the tail lamp assembly on the vehicle and secure with two screws. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 404
2. Depress the lever and carefully pry the license plate lamp assembly (located above the license plate) from the liftgate. 3. Rotate the bulb socket counterclockwise and remove from lamp assembly. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 405
3. Remove the bulb from the lamp assembly by pulling out on the bulb while squeezing on the upper and lower snap clips at the same time. Install the new bulb in reverse order. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
When the windshield wipers are turned on during daylight, and the headlamp control is in the autolamp position, the exterior lamps will turn on after a brief delay and will remain on until the wipers are turned off. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 407
3. Push the steering column tilt lever up. This will lock the steering wheel in position. WARNING: Never adjust the steering wheel when the vehicle is moving. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 408
This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error. Refer to Compass calibration adjustment. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 409
Perform compass calibration in an open area free from steel structures and high voltage lines. For optimum calibration, turn off all electrical accessories (heater/air conditioning, wipers, etc.) and make sure all vehicle doors are shut. 1. Start the vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 410
4. Rear cupholders 5. Small storage trays and (if equipped) an ambient light control switch. WARNING: Use only soft cups in the cupholders. Hard objects can injure you in a collision. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 411
Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
POWER WINDOWS (IF EQUIPPED) WARNING: Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure themselves. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 413
With accessory delay, the window switches, moon roof (if equipped) and audio system may be used for up to 10 minutes after the ignition switch is turned to the off position or until either front door is opened. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. EXTERIOR MIRRORS Power side view mirrors WARNING: Do not adjust the mirror while the vehicle is in motion. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal. WARNING: Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 416
Disengaging the speed control will not erase previous set speed. Note: When you use the clutch pedal to disengage the speed control, the engine speed may briefly increase, this is normal. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 417
• Press and release the SET- control to operate the Tap-Down function. Each tap will decrease the set speed by 1 mph (1.6 km/h). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 418
These controls allow you to operate some audio control features. Radio control features Press MEDIA to select: • AM, FM1, FM2, or CD • SAT1, SAT2 or SAT3 (Satellite Radio mode if equipped). • LINE IN (Auxiliary input jack) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 419
Press to complete a voice command. For further information on the navigation system, refer to the Navigation System supplement. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
You can move the glass panel of the moon roof back to open or tilt up (from the closed position) to ventilate the vehicle. WARNING: Do not let children play with the moon roof or leave children unattended in the vehicle. They may seriously hurt themselves. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 421
• To close the moon roof from the vent position, press and hold the rear portion of the control until the glass panel stops moving. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Odometer/Trip Odometer • Distance to Empty (DTE) • Average Fuel Economy (AFE) • Instantaneous Fuel Economy • Blank (odometer off) Odometer/Trip odometer Refer to Gauges in the Instrument Cluster chapter. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 423
Instantaneous fuel economy Select this function from the INFO menu to display your instantaneous fuel economy. This will display your fuel economy as a bar graph ranging from poor economy to excellent economy. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 424
OK message or a warning message for three seconds. Pressing the RESET control cycles the message center through each of the systems being monitored. The sequence of the system check report is as follows: 1. Oil life 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 425
2. Press the RESET control to change from English to Metric. Autolamp delay This feature keeps your headlights on for up to three minutes after the ignition is switched off. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 426
Selectable languages are English, Spanish, or French. 3. Press and hold the RESET control for two seconds to set the language choice. Compass zone/Compass calibration Refer to Electronic compass in the this chapter. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 427
Oil life change soon Oil change required DRIVER DOOR AJAR — Displayed when the driver’s door is not completely closed. PASSENGER DOOR AJAR — Displayed when the passenger side door is not completely closed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 428
10% or less. When oil life left is between 10% and 0%, the XX% OIL LIFE CHANGE SOON message will be displayed. OIL CHANGE REQUIRED — Displayed when the oil life left reaches 0%, the OIL CHANGE REQUIRED message will be displayed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 429
CARGO AREA FEATURES Cargo shade (if equipped) If your vehicle has a cargo shade, you can use it to cover items in the cargo area of your vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 430
A pad lock or combination lock can be applied to use the lockable storage feature on the large customer storage bin. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 431
1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the desired location. 3. Tighten the thumbwheel at both ends of the cross-bar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 432
3. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar. 4. Slide the cross-bar assembly off the end of the rail. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 433
3. Slide the cross-bar assemblies over the end cap tongue and into the side rails. 4. Tighten thumbwheel at both ends of the cross-bar. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
It is recommended that you maintain the label in a safe place for future reference, such as the inside front cover of this Owner’s Guide. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 435
Likewise, when rotating the IKT to the off position in the ignition lock cylinder, the bottom edge of the IKT adjacent to the control can be utilized. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Through your authorized dealer, or • Performing the power door lock control procedure, or • Performing the keyless entry keypad (if equipped) procedure, or • Performing the message center (if equipped) procedure. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 437
6. Release the 3 • 4. The user should receive a horn chirp to indicate the system has been disabled or a chirp followed by a honk to indicate the system has been enabled. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 438
You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 439
With the key in any ignition position, the driver’s door will automatically unlock if it is locked using the power lock control on the driver’s door panel while the driver’s door is open. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 440
(10 meters). A decrease in operating range could be caused by: • weather conditions, • nearby radio towers, • structures around the vehicle, or • other vehicles parked next to your vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 441
The turn signal will flash twice to indicate that the vehicle has switched to one step unlocking. Repeat the procedure to switch back to two step unlocking. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 442
Note: The panic alarm will only operate when the ignition is in the off position. Replacing the battery The Integrated Keyhead Transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 443
To program a new Integrated Keyhead Transmitter yourself, refer to Programming spare keys in the SecuriLock™ passive anti-theft section of this chapter. Note: At least two IKTs are required to perform this procedure yourself. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 444
Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 445
You can also create your own 5–digit personal entry code. When pressing the controls on the keyless entry keypad, press the middle of the controls to ensure a good activation. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 446
To unlock the driver’s door, enter the factory set 5-digit code or your personal code. Each number must be pressed within five seconds of each other. The interior lamps will illuminate. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Note: The SecuriLock™ passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 448
The key codes need to be erased from your vehicle and new coded keys will need to be programmed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 449
3 (on) position for at least three seconds, but no more than 10 seconds. 6. Turn the ignition to the 1 (off) position and remove the second previously programmed coded key from the ignition. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 450
Steps 1 through 8. If failure repeats, bring your vehicle to your authorized dealer to have the new key(s) programmed. To program additional new unprogrammed key(s), wait 20 seconds and then repeat this procedure from Step 1. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
: • a trimmed energy absorbing foam and structure (1), • two steel stems (2), • a guide sleeve adjust/release button (3), • and a guide sleeve unlock/remove button (4). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 452
For occupants of extremely tall stature, adjust the head restraint to its full up position. WARNING: The adjustable head restraint is a safety device. Whenever possible it should be installed and properly adjusted when the seat is occupied. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 453
For occupants of extremely tall stature, adjust the head restraint to its full up position. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 454
WARNING: Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 455
The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 456
• Push the button located on the instrument panel to activate. • Push again to deactivate. The heated seats will activate when the ignition is in the on position and the engine is running. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 457
Push control to lower or remove head restraint. Folding down rear seats 1. Raise the rear seat head restraint and remove. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 458
2. Place the head restraint under the front seat for storage. 3. Pull the seat release control. Note: Make sure the floor is clear of all objects before folding the seat. 4. Flip seat forward. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 459
This is common for both 60% and 40% seatbacks. Note: When the seatback release lever is pulled, slowly lower seatback to the flat position. 6. Rotate seatback down into load floor position. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 460
An unlatched seat may become dangerous in the event of a sudden stop or collision. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 461
2. Pull the cushion to the outboard side of the vehicle. To install the rear cushion 1. Push the cushion to the inboard side of the vehicle. 2. Make sure that the hinges are locked into place. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
(not rollovers, side impacts or rear impacts) unless the collision causes sufficient longitudinal deceleration. The pretensioners are designed to activate in frontal, and in side collisions and rollovers. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 463
If you must use a forward-facing child seat in the front seat, move the seat all the way back. WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 464
Refer to the Warning light section in the Instrument Cluster chapter. Routine maintenance of the Personal Safety System is not required. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 465
Be sure everyone in your vehicle is in a seat and using a safety belt properly. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 466
(the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 467
12 years old and under should be properly restrained in a rear seating position whenever possible. Refer to Safety restraints for children or Safety seats for children later in this chapter. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 468
In addition, all safety belts should be checked for proper function. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 469
(including retractors, buckles and height adjusters) must be replaced if the vehicle is involved in a collision that results in deployment of front airbags, seat-mounted side airbags and Safety Canopy , and safety belt pretensioners. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 470
The driver’s safety belt is The safety belt warning light and buckled before the ignition indicator chime remain off. switch is turned to the on position... 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 471
6 seconds every (5 km/h) and 1-2 minutes have 30 seconds, repeating for elapsed since the ignition approximately 5 minutes or until the switch has been turned to on... safety belts are buckled. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 472
I’m not going far 3 of 4 fatal crashes occur within 25 miles of home. Belts are Your Ford safety belts are designed to uncomfortable enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 473
When deactivating/activating one seating position, do not buckle the other position as this will terminate the process. Read Steps 1 - 4 thoroughly before proceeding with the deactivation/activation programming procedure. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 474
• After receiving confirmation, the deactivation/activation procedure is complete. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 475
WARNING: The National Highway Traffic Safety Administration (NHTSA) recommends a minimum distance of at least 10 inches (25 cm) between an occupant’s chest and the driver airbag module. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 476
WARNING: Additional equipment may affect the performance of the airbag sensors increasing the risk of injury. Please refer to the Body Builders Layout Book for instructions about the appropriate installation of additional equipment. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 477
Front airbags are designed to inflate in frontal and near-frontal collisions, not rollover, side-impact, or rear-impacts unless the collision causes sufficient longitudinal deceleration. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• Front passenger sensing system. Refer to Front passenger sensing system later in this chapter. • “Passenger airbag off” or “pass airbag off” indicator lamp. Refer to Front passenger sensing system later in this chapter. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 479
• a front passenger takes his/her weight off of the seat for a period of time, The front passenger sensing system will turn off the passenger seat side airbag if: • the seat is empty and safety belt is unbuckled. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 480
• Restart the vehicle and have the person remain in this position for about two minutes. This will allow the system to detect that person and enable the passenger’s frontal airbag. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 481
Even though the passenger airbag is disabled, the pass airbag off lamp may or may not be illuminated according to the table below. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 482
(if equipped). Check the “passenger airbag off” or “pass airbag off” indicator lamp for proper airbag Status. Failure to follow these instructions may interfere with the front passenger seat sensing system. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 483
If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance chapter of this Owner’s Guide.
Page 484
SRS, its fuses or the seat cover on a seat containing an airbag. See an authorized dealer. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 485
The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side airbags are designed 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 486
If any of these things happen, even intermittently, have the SRS serviced at your authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 487
SRS and Safety Canopy system is provided. WARNING: To reduce risk of injury, do not obstruct or place objects in the deployment path of the inflatable Safety Canopy . 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 488
The Safety Canopy system is designed to active when the vehicle sustains lateral deceleration sufficient to cause the RCM to initiate Safety Canopy inflation or when a certain likelihood of a rollover event is detected by the rollover sensor. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 489
• The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 490
Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 491
Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 492
A safety seat that is improperly installed or utilized, is inappropriate for your child’s height, age, or weight or does not properly fit the child may increase the risk of serious injury or death. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 493
Highway Traffic Safety Administration (NHTSA) provides education and training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 494
Children 12 and under should be properly restrained in a rear seating position whenever possible. If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 495
Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 496
Make sure the tongue is latched securely by pulling on it. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 497
There should be no more than one inch (2.5 cm) of movement for proper installation. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 498
Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 499
280 mm (11 inches) center to center. Do not use LATCH lower anchors for the center seating position unless the child seat manufacturer’s instructions permit and specify using anchors spaced at least as far apart as those of this vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 500
The rear seating positions of your vehicle are equipped with built-in tether strap anchors located behind the seats on the roof panel in the cargo area. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 501
2. Locate the correct anchor for the selected seating position. There are three tether anchors located on the headliner at the rear of the vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 502
To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. 2009 Escape (204)
Page 503
• Does the lap belt rest low across the hips? • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 504
• High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 505
For this reason, you should never use a booster seat with a lap belt only. It is generally best to use a booster seat with lap/shoulder belts in the back seat. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 506
Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
A vehicle equipped with AWD or 4WD (when selected) has the ability to use all four wheels to power itself. This increases traction which may enable you to safely drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 508
All other things held equal, a shorter wheelbase may make your vehicle quicker to respond to steering inputs than a vehicle with a longer wheelbase. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 509
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 510
TIRES Tires are designed to give many thousands of miles of service, but they must be maintained in order to get the maximum benefit from them. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 511
INFLATING YOUR TIRES Safe operation of your vehicle requires that your tires are properly inflated. Remember that a tire can lose up to half of its air pressure without appearing flat. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 512
Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 513
6. Visually inspect the tires to make sure there are no nails or other objects embedded that could poke a hole in the tire and cause an air leak. 7. Check the sidewalls to make sure there are no gouges, cuts or bulges. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 514
If damage is observed or suspected have the tire inspected by a tire professional. Tires can be damaged during off-road use, so inspection after off-road use is also recommended. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 515
This information is used to contact customers if a tire defect requires a recall. Tire replacement requirements Your vehicle is equipped with tires designed to provide a safe ride and handling capability. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 516
B-Pillar or edge of the driver’s door. If this information is not found on these labels then you should consult your Ford dealer. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 517
The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System.
Page 518
• Front Wheel Drive (FWD) vehicles (front tires at top of diagram) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 519
This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 520
These speed ratings may need to be adjusted for the difference in conditions. The ratings range from 81 mph (130 km/h) to 186 mph (299 km/h). These ratings are listed in the following chart. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 521
Refer to the Safety Compliance Certification Label, which is located on the B-Pillar or the edge of the driver’s door, for the correct tire pressure for your vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 522
The cold inflation pressure should never be set lower than the recommended pressure on the vehicle label. The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 523
4. Maximum Load Single lb. (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a single; defined as two tires (total) on the rear axle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 524
B-Pillar or the edge of the driver’s door. Refer to the payload description and graphic in the Vehicle loading — with and without a trailer section. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 526
The tire pressure should be checked periodically (at least monthly) using an accurate tire gauge, refer to Inflating your tires in this chapter. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 527
To restore the full functionality of the Tire Pressure Monitoring System, have the damaged road wheel/tire repaired and remounted on your vehicle. For additional information, refer to Changing tires with TPMS in this section. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 528
TPMS If your tires are properly inflated and malfunction your spare tire is not in use and the light remains ON, have the system inspected by your authorized dealer. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 529
Check air pressure in the road tires. If any tire is under-inflated, carefully drive the vehicle to the nearest location where air can be added to the tires. Inflate all the tires to the recommended inflation pressure. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 530
SNOW TIRES AND CABLES WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 531
Tire Label in order to determine the new payload. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 532
Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space available. Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. Example only: 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 533
Note: For trailer towing information refer to Trailer towing found in this chapter or the RV and Trailer Towing Guide provided by your authorized dealer. GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 534
GCW of the towing vehicle plus the trailer exceed the GVWR of the towing vehicle. The GCW must never exceed the GCWR. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 535
150 lb. passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lb. (1400-750 (5 x 150) = 650 lb.). In metric units (635-340 (5 x 68) = 295 kg.) 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 536
Front or the Rear Gross Axle Weight Rating specified for your vehicle on the Safety Compliance Certification Label found on the edge of the driver’s door. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Certification Label. For load specification terms found on the label, refer to Vehicle loading in this chapter. Remember to figure in the tongue load of your loaded vehicle when figuring the total weight. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 538
The Escape is capable of pulling the maximum trailer weight(s) as specified above. Certain states require electric trailer brakes for trailers over a specified weight. The Escape vehicle electrical system is not equipped to accommodate electric trailer brakes. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 539
Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle. See your authorized dealer or a reliable trailer dealer if you require assistance. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 540
• To ensure proper “break-in” of powertrain components during the first 500 miles (800 km) of trailer towing, drive no faster than 70 mph (113 km/h) with no full throttle starts. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 541
When backing down a ramp during boat launching or retrieval: • do not allow the static water level to rise above the bottom edge of the rear bumper. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
65 mph (105 km/h) for automatic transmission vehicles. • Start the engine and allow it to run for five minutes at the beginning of each day and at each fuel stop. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 543
65 mph (105 km/h) for automatic transmission vehicles. • Start the engine and allow it to run for five minutes at the beginning of each day and at each fuel stop. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
WARNING: Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 545
Seating and Safety Restraints chapter. 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: • Make sure the parking brake is set. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 546
• Make sure the parking brake is set. • Push the clutch pedal to the floor. 3. Turn the key to 3 (on) without turning the key to 4 (start). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 547
If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least one inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 548
• Make sure that when in operation, the extension cord plug /engine block heater cord plug connection is free and clear of water in order to prevent possible shock or fire. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Refer to Brake system warning light in the Instrument Cluster chapter for information on the brake BRAKE system warning light. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 550
Even when the ABS is disabled, normal braking is still effective. If your BRAKE warning lamp BRAKE illuminates with the parking brake released, have your brake system serviced immediately by an authorized dealer. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 551
Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 552
If your AdvanceTrac with RSC system activates, SLOW DOWN. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 553
AdvanceTrac with RSC button located on the center stack of the instrument panel. If the “sliding car” icon remains steadily illuminated, have the system serviced by an authorized dealer immediately. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 554
The Engine Traction Control and Brake Traction Control system may be deactivated in certain situations. See the Switching Off AdvanceTrac with RSC section following. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 555
Certain adverse driving maneuvers may activate the Roll Stability Control system, which include: • Emergency lane-change • Taking a turn too fast • Quick maneuvering to avoid an accident, pedestrian or obstacle 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
AdvanceTrac with RSC system to detect and attempt to mitigate trailer sway by applying brake force at individual wheels and, if necessary, by reducing engine power. No driver action is required. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 557
WARNING: Turning off Trailer Sway Control increases the risk of loss of vehicle control, serious injury, or death. Ford does not recommend disabling this feature except in situations where speed reduction may be detrimental (e.g., hill climbing), the driver has significant trailer towing experience, and can control trailer sway and maintain safe operation.
Page 558
Avoid sharp turns, excessive speed or abrupt maneuvers in these vehicles. Failure to drive cautiously could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 559
3. Insert a screwdriver or similar tool straight down into the access hole and press downward while pulling the gearshift lever out of the P (Park) position and into the N (Neutral) position. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 560
Over time, the adaptive learning process will fully update transmission operation. Additionally, whenever the battery is disconnected or a new battery installed, the strategy must be relearned. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 561
LOCK position and remove the key whenever you leave your vehicle. R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 562
(engine) braking and extends lower gear operation on uphill climbs. • Provides additional engine braking through the automatic transmission shift strategy which reacts to vehicle inputs (vehicle acceleration, accelerator pedal, brake pedal and vehicle speed). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 563
MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch Manual transmission vehicles have a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 564
These actions will severely reduce the life of the clutch and could nullify a clutch warranty claim. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 565
If R (Reverse) is not fully engaged, press the clutch pedal down and return the gearshift to the neutral position. Release the clutch pedal for a moment, then press it down and shift to R (Reverse) again. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
WARNING: Certain add-on devices such as large trailer hitches, bike or surfboard racks and any device that may block the normal detection zone of the RSS system may create false beeps. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 567
RSS. If your vehicle sustains damage to the rear bumper/fascia, leaving it misaligned or bent, the sensing zone may be altered causing inaccurate measurement of obstacles or false alarms. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 568
• Drive slower in strong crosswinds which can affect the normal steering characteristics of your vehicle. • Be extremely careful when driving on pavement made slippery by loose sand, water, gravel, snow or ice. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 569
WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 570
When driving over sand, try to keep all four wheels on the most solid area of the trail. Avoid reducing the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 571
Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 572
Rapid pumping of the brake pedal will help you slow the vehicle and still maintain steering control. Since your vehicle has anti-lock brakes, apply the brakes steadily. Do not “pump” the brakes. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 573
Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 574
Once through the water, always dry the brakes by moving your vehicle slowly while applying light pressure on the brake pedal. Wet brakes do not stop the vehicle as quickly as dry brakes. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 576
Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.
Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 578
Remove the panel cover to access the fuse cover. Press the tabs on the top and bottom of the fuse cover to remove. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 579
Low beam headlamps (left) Low beam headlamps (right) Interior lights Backlighting Four wheel drive 7.5A Power mirror switch Not used (spare) FCIM (radio buttons), Satellite radio, Front display module Climate control 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 580
Anti-lock brake system (ABS) Four wheel drive, Electric Power Steering Module (EPAS) , Park aid module PATS transceiver Climate control Subwoofer/Amp (Audiophile radio) Radio, Radio Amplifier (Navigation only) Front power point 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 581
WARNING: Always disconnect the battery before servicing high current fuses. WARNING: To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 582
Powertrain Control Module (PCM) Keep Alive power, PCM relay, Canister vent 15A* Alternator 15A* Liftgate latch 20A* Trailer tow parking lamps 50A** Anti-lock Brake System (ABS) 30A** Front wipers 30A** Starter 40A** Blower motor 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 583
Cooling fan main relay — Cooling fan 2 relay — Reverse lamp relay — Not used — Trailer tow left turn relay — Trailer tow right turn relay — Trailer tow park relay 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 584
TPMS sensor for damage. WARNING: The use of tire sealants may damage your Tire Pressure Monitoring System and should not be used. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 585
Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 586
• Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a full-size dissimilar spare tire/wheel and seek service as soon as possible. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 587
Unbuckle the strap and remove the jack and tools by pulling the right side up first. Remove the tools from the jack in order to remove the spare tire from under the vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 588
3. Slide the retainer through the center of the wheel. If equipped with a tether, perform the following additional steps: 4. Lift the spare tire on end to access tether attachment (1). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 589
(other side and end of the vehicle) to the tire being changed. WARNING: If the vehicle slips off the jack, you or someone else could be seriously injured. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 590
2. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Before placing the jack under the vehicle, NOTE the jack locations: 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 591
View shown from rear of front tire. Position the jack directly below the protruding bolt. • Rear View shown from forward of rear tire. Position the jack directly below the stud on the rear trailing arm. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 592
Reinstall lug nuts until the wheel is snug against the hub. Do not fully tighten the lug nuts until the wheel has been lowered. 6. Lower the wheel by turning the jack handle counterclockwise. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 593
If you are stowing a tire that requires reattaching it to the vehicle with a tether, perform these steps first, then proceed with the steps following. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 594
WHEEL LUG NUT TORQUE SPECIFICATIONS Retighten the lug nuts to the specified torque at 500 miles (800 km) after any wheel disturbance (tire rotation, changing a flat tire, wheel removal, etc.). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 595
M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect from any electrical surges. Turn all other accessories off. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 597
Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 598
5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 599
1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 600
After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
Page 602
Roadside Emergencies Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. If the vehicle is towed by other means or incorrectly, vehicle damage may occur.
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 604
• The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 605
In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 606
THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.
Page 607
(CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 608
Customer Assistance If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your authorized dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform Transport Canada, using their toll-free number: 1–800–333–0510. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
• After polishing chrome bumpers, apply a coating of Motorcraft Premium Liquid Wax (ZC-53-A), available from your authorized dealer, or an equivalent quality product to help protect from environmental effects. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 612
• Do not use hydrofluoric acid-based or high caustic-based wheel cleaners, steel wool, fuels or strong household detergent. • To remove tar and grease, use Motorcraft Bug and Tar Remover (ZC-42), available from your authorized dealer. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 613
• Cover the highlighted areas to prevent water damage when cleaning the engine. • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. 2.5L I4 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 614
To clean these items, follow these tips: • The windshield, rear windows and side windows may be cleaned with a non-abrasive cleaner such as Motorcraft Ultra-Clear Spray Glass Cleaner (ZC-23), available from your authorized dealer. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 615
WARNING: Do not use chemical solvents or strong detergents when cleaning the steering wheel or instrument panel to avoid contamination of the airbag system. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 616
WARNING: On vehicles equipped with seat-mounted airbags, do not use chemical solvents or strong detergents. Such products could contaminate the side-airbag system and affect performance of the side airbag in a collision. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 617
FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
• Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in 1 (First). 2. Turn off the engine and remove the key. 3. Block the wheels. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 620
2. At the front of the vehicle, lift up on the auxiliary latch handle located in the center between the hood and the grille. 3. Lift the hood open and secure it with the prop rod. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 623
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 624
The layer of ice has many sharp edges and can damage the micro edge of the wiper rubber element. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmissions) or 1 (First) (manual transmissions). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level dipstick. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 626
• If the oil level is below the lower hole or the lower line, engine oil must be added to raise the level within the normal operating range. • 2.5L I4 engine 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 627
1/4 of a turn until it is seated. To avoid possible oil loss, DO NOT operate the vehicle with the engine oil level dipstick and/or the engine oil filler cap removed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 628
Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance information. Ford production and Motorcraft replacement oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Lift the battery with a battery carrier or with your hands on opposite corners. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 630
If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
50/50 mixture of coolant and water provides the following: • Freeze protection down to -34°F (-36°C). • Boiling protection up to 265°F (129°C). • Protection against rust and other forms of corrosion. • Proper function of calibrated gauges. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 632
If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. • Add Motorcraft Premium Gold Engine Coolant or equivalent meeting Ford specification WSS-M97B51-A1. Refer to Maintenance product specifications and capacities in this chapter. 2009 Escape (204)
Page 633
Refer to the Cooling section of the Workshop Manual. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, or DEX-COOL brand with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine...
Page 634
Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 635
If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 636
FUEL FILTER Your vehicle is equipped with a lifetime fuel filter that is integrated with the fuel tank. Regular maintenance or replacement is not needed. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 637
• Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 638
Use the following guidelines to avoid electrostatic charge build-up when filling an ungrounded fuel container: • Place approved fuel container on the ground. • DO NOT fill a fuel container while it is in the vehicle (including the cargo area). 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 639
Continuing to drive with the Check Fuel Fill Inlet lamp or Check Fuel Fill Inlet message on may cause the Service Engine Soon lamp to turn on as well. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 640
Do not be concerned if your engine sometimes knocks lightly. However, if it knocks heavily under most driving conditions while you are using fuel with the recommended octane rating, see your authorized dealer to prevent any engine damage. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 641
Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 642
Do not use aftermarket funnels; they will not work with the Easy Fuel™ system and can damage it. The included funnel has been specially designed to work safely with your vehicle. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 643
• Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 644
65 mph [105 km/h]). • Revving the engine before turning it off may reduce fuel economy. • Using the air conditioner or defroster may reduce fuel economy. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 645
• Close windows for high speed driving. EPA fuel economy estimates Every new vehicle should have a window sticker containing EPA fuel economy estimates. Contact your authorized dealer if the window sticker 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 646
If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 647
OBD-II may not have symptoms that are apparent, continued driving with the Service engine soon indicator on can result in increased emissions, lower fuel economy, reduced engine and transmission smoothness, and lead to more costly repairs. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 648
If the vehicle is still not ready for I/M testing, the above driving cycle will have to be repeated. BRAKE/CLUTCH FLUID Brake and clutch systems are supplied from the same reservoir. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 649
6. Install the dipstick making sure it is fully seated in the filler tube. 7. Remove the dipstick and inspect the fluid level. The fluid should be in the crosshatch zone for normal operating temperature. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 650
If an overfill occurs, excess fluid should be removed by an authorized dealer. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
7. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 8. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Maintenance product specifications and capacities section in this chapter. AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element.
Page 652
Note: Failure to use the correct air filter element may result in severe engine damage. The customer warranty may be void for any damage to the engine if the correct air filter element is not used. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 653
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 654
Maintenance and Specifications 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 655
Maintenance and Specifications 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 656
Maintenance and Specifications 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Ignition system Coil on plug Coil on plug 0.049–0.053 inch 0.045–0.049 inch Spark plug gap (1.25–1.35mm) (1.15–1.25mm) Compression 9.7:1 10.3:1 ratio Engine drivebelt routing • 2.5L I4 Engine • 3.0L V6 Engine 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 658
Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 659
TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code Five-speed manual Six-speed automatic 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 661
• Electrical or electronic accessories or components that are added to the vehicle by the authorized dealer or the owner may adversely affect battery performance and durability. 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Child safety seats ......145 overdrive .........212 attaching with tether straps ..151 fluid, refill capacities ....305 in front seat ......146 fluid, specification ....305 in rear seat ......146 LATCH ........149 Auxiliary input jack (Line in) ..28 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 663
....280 Ford Extended Service lubrication specifications ..305 Plan ..........258 refill capacities ......305 Getting assistance outside the service points ....272–273 U.S. and Canada .....259 starting after a collision ..228 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Page 664
..294 Inspection/maintenance (I/M) octane rating ....291, 308 testing ........299 quality ........292 Instrument panel running out of fuel ..246, 292 safety information relating to cleaning ........266 cluster ........12 automotive fuels .....288 2009 Escape (204) Owners Guide, 1st Printing USA (fus)
Need help?
Do you have a question about the 2009 Escape and is the answer not in the manual?
Questions and answers
