Page 1: Table Of Contents
Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems How to get going AM/FM stereo with CD AM/FM stereo with in-dash six CD Auxiliary input jack (Line in) USB port Rear seat controls Satellite radio information Family entertainment system Navigation system SYNC...
Page 2 Table of Contents Locks and Security Keys Locks Anti-theft system Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac...
Page 4: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 Introduction PERCHLORATE MATERIAL Certain components of this vehicle such as airbag modules, seat belt pretensioners, and button cell batteries may contain Perchlorate Material – Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate. BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in.
Page 7 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 8 Introduction and/or other details about the vehicle or crash to assist 911 operators to provide the most appropriate emergency services. If you do not want to disclose this information, do not activate the feature. See your SYNC supplement for more information. Using your vehicle with a snowplow Do not use this vehicle for snowplowing.
Page 9 Introduction WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 13 Instrument Cluster WARNING: Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Powertrain malfunction/reduced power (RTT) (if equipped): Displays when the engine has defaulted to a “limp-home”...
Page 14 Instrument Cluster Airbag readiness: If this light fails to illuminate when the ignition is turned to on, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will sound when there is a malfunction in the indicator light. Safety belt: Reminds you to fasten your safety belt.
Page 15 Instrument Cluster Low tire pressure warning (if equipped): Illuminates when your tire pressure is low. If the light remains on at start up or while driving, the tire pressure should be checked. Refer to Inflating your tires in the Tires, Wheels and Loading chapter.
Page 16 Instrument Cluster Four wheel drive low (RTT) (if equipped): Displays when four-wheel drive low is engaged. If the light fails to display when the ignition is turned on, or remains on, have the system serviced immediately by your authorized dealer. Four wheel drive (RTT) (if equipped): Displays when four-wheel drive is engaged.
Page 17: Gauges
Instrument Cluster Turn signal chime: Sounds when the turn signal lever has been activated to signal a turn and not turned off after the vehicle is driven more than 1.5 miles (2.4 km). Message center activation chime: Sounds when some warning messages appear in the message center display for the first time.
Page 18 Instrument Cluster WARNING: Never remove the coolant reservoir cap while the engine is running or hot. Odometer: Registers the total miles (kilometers) of the vehicle. • With standard message center • With optional message center Refer to Message center in the Driver Controls chapter on how to switch the display from Metric to English.
Page 19 Instrument Cluster Battery voltage gauge: Indicates the battery voltage when the ignition is in the on position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked by your authorized dealer as soon as possible.
Page 20: Entertainment Systems
Quick start — How to get going WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 21 Entertainment Systems Listening to satellite radio (if equipped) 1. If the audio system is turned off, press VOL-PUSH to turn the radio on. Turn VOL-PUSH to adjust the volume. Note: The system may take a few moments to turn on. 2.
Page 22 Entertainment Systems For a single CD system, if a disc is not already loaded, insert only one, label side up into the CD slot. LOADING CD and READING DISC will appear in the display. The first track on the disc will begin playing. For an in-dash six CD system, if a disc is not already loaded, press LOAD.
Page 23 Entertainment Systems While in folder mode, press FOLDER to access the next folder on MP3 discs, if available. Press SHUFFLE to engage shuffle mode. SHUFFLE ON will appear in the display. If you wish to engage shuffle mode right away, press SEEK to begin random play. Otherwise, random play will begin when the current track is finished playing.
Page 24: Am/Fm Stereo With Cd
(if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 25 Entertainment Systems In satellite radio mode (if equipped), press to scroll through the SIRIUS channels. Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. (Phone): Press to access SYNC phone features if your vehicle is equipped with SYNC .
Page 26 Entertainment Systems The song will appear in the display for confirmation. Press OK again and the display will read SONG DELETED. If you do not want to delete the currently listed song, press to select either RETURN or CANCEL. Note: If there are no songs presently saved, the display will read NO SONGS.
Page 27 Entertainment Systems To activate, press MENU repeatedly until RBDS (ON/OFF) appears in the display. Use SEEK to toggle RBDS ON/OFF. (When RBDS is OFF, you will not be able to search for RBDS equipped stations or view the station name or type.) To search for specific RBDS music categories: When the desired category appears in the display, press to find the desired type,...
Page 28 Entertainment Systems Track/Folder mode: Available only on MP3 discs in CD mode. In Track mode, pressing SEEK, SEEK will scroll through all tracks on the disc In Folder mode, pressing SEEK, SEEK will scroll only through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if...
Page 29 Entertainment Systems press SEEK, SEEK to seek to the previous/next channel in the selected category. Press and hold SEEK, SEEK to fast seek through the previous /next channels. In TEXT MODE, press SEEK, SEEK to view the previous/additional display text. Satellite radio is available only with a valid SIRIUS radio subscription.
Page 30 Entertainment Systems 10. FF (Fast forward): In CD mode, press FF to manually advance in a track. In DVD mode (if equipped), press and hold to advance through the current chapter. 11. REW (Rewind): In CD mode, press REW to manually reverse in a track.
Page 31 Entertainment Systems In satellite radio mode (if equipped), press and release to enter TEXT MODE and display the current song title. While in TEXT MODE, press again to scroll through the current song title, artist, channel category and the SIRIUS long channel name. Press and hold to hear a brief sampling of the next channels.
Page 32: Am/Fm Stereo With In-Dash Six Cd
(if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 33 Entertainment Systems In satellite radio mode (if equipped), press to scroll through the SIRIUS channels. Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. (Phone): Press to access SYNC phone features if your vehicle is equipped.
Page 34 Entertainment Systems and the display will read SONG DELETED. If you do not want to delete the currently listed song, press to select either RETURN or CANCEL. Note: If there are no songs presently saved, the display will read NO SONGS.
Page 35 Entertainment Systems To search for specific RBDS music categories: When the desired category appears in the display, press to find the desired type, then press and release SEEK, SEEK or press and hold SCAN to begin the search. To view the station name or type: With RBDS ON, press TEXT/SCAN to toggle between displaying the station type (COUNTRY, ROCK, etc.) or the station name (WYCD, WXYZ, etc.).
Page 36 Entertainment Systems In Folder mode, pressing SEEK will scroll only through tracks within the selected folder. Press FOLDER, FOLDER to access the previous/next folder (if available). COMPRESS (Compression): Available only in CD/MP3 mode. Press MENU until COMPRESS ON/OFF appears in the display. SEEK, SEEK to toggle ON/OFF.
Page 37 Entertainment Systems In TEXT MODE, press SEEK, SEEK to view the previous/additional display text. Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. OK(Play/Pause): This control is operational in CD and DVD mode (if equipped).
Page 38 Entertainment Systems 11. REW (Rewind): In radio mode, press REW to manually reverse in a track. In DVD mode (if equipped), press to reverse within the current chapter. 12. Memory presets: To set a station, select the desired frequency band, AM, FM1 or FM2. Tune to the desired station.
Page 39 Entertainment Systems 14. AM/FM: Press to select AM/FM1/FM2 frequency band. 15. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. Note: If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 40: Auxiliary Input Jack (Line In)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 41 Entertainment Systems 2. Ensure that the battery in your portable music player is new or fully charged and that the device is turned off. 3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable to the AIJ in your vehicle.
Page 42: Usb Port
USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 43 Entertainment Systems 1. MEDIA: Push repeatedly to cycle through available playing medias such as AM, FM1, FM2, CD, SAT1, SAT2, SAT3 (satellite radio if equipped), DVD (if equipped) and *SYNC (if equipped). If in Dual Play mode, SHARED illuminates in the radio display when the front and rear modes are set to the same media.
Page 44 Entertainment Systems Parental control Press the memory preset controls 3 and 5 simultaneously on the front audio controls to disable the rear seat controls. They will remain disabled until the front seat passengers “enable” them again by simultaneously pressing the 3 and 5 preset controls.
Page 45 Entertainment Systems Using headphones/Dual Play mode WARNING: Do not leave children unattended in the vehicle and do not let children operate the system while unsupervised. If wired headphones or auxiliary systems are used, children may become entangled in the cords and seriously injure themselves. Plug a 3.5 mm headphone (not included) into the jack.
Page 46 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
Page 47 Entertainment Systems CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels.
Page 48: Satellite Radio Information
Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
Page 49 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 50 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. This than two seconds to message should produce audio for the disappear shortly. selected channel. SAT FAULT Internal module or If this message does not system failure present. clear within a short period of time, or with an ignition key cycle,...
Page 51: Family Entertainment System
FAMILY ENTERTAINMENT DVD SYSTEM (IF EQUIPPED) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 52 Entertainment Systems Quick start Your Family Entertainment System includes a DVD system, two sets of wireless infrared (IR) headphones and a wireless infrared (IR) remote control. To play a DVD in the DVD system: The DVD system can play DVD-Video, DVD-R, DVD-R/W discs as well as audio CDs and video CDs.
Page 53 Entertainment Systems To play a CD in the DVD system: The DVD system can play audio CDs, CD-R and CD-R/W, CD-ROM and video CDs. To ensure proper disc operation, check the disc for finger prints and scratches. Clean the disc with a soft cloth, wiping from the center to the edge.
Page 54 Entertainment Systems 3. The disc will begin to play and the ‘MP3 Audio Disc’ screen will display and allow you to access the COMPRESSION, SHUFFLE, SCAN and FOLDER MODE features. Note (navigation-based radio systems only): When a disc is inserted, the FES switches to dual-play mode–rear speakers turn off, and headphones turn on.
Page 55 Entertainment Systems from the auxiliary source, the screen will remain black. If the video source is set to DVD-AUX, the display will automatically turn on if a video signal is detected. To listen to audio over the headphones— Dual play mode (Navigation-based radio systems only): You may listen to channels A and B over wired or wireless headphones.
Page 56 Entertainment Systems 1. Press the headphone/ speaker button on the DVD player or press the 2 and 4 memory presets on the radio at the same time. A green light will illuminate next to either the A or B Headphone Control Button to indicate which channel is active (able to be controlled).
Page 57 Entertainment Systems To adjust display brightness: To decrease/increase the brightness level on the display screen, press the brightness control on the DVD system. A display will appear at the bottom of the screen indicating the brightness level. The brightness display will only appear when the menu is not displayed.
Page 58 Entertainment Systems (Stop/Eject): Press once to stop and press a second time to eject a disc from the DVD system. (Reverse): Press and release for the previous chapter or track. Press and hold to reverse search a DVD, Video CD, or FES CD in DVD/CD mode. (Fast forward): Press and release for the next chapter or track.
Page 59 Entertainment Systems 10. Volume: When in single play mode, press to increase ( ) or decrease ( ) the volume over all speakers. When in Dual Play, press to increase ( ) or decrease ( the volume for the wired headphones. (Wireless headphone volume is controlled with the rotary dial on the right ear piece.) (Headphones/Speakers): Press once for Dual Play (Headphone mode- the rear speakers are muted) and press again for...
Page 60 Entertainment Systems 16. Cursor /Brightness controls: Use the cursor controls to make various selections when in any menu. When not in a menu, and in DVD mode, press to adjust the brightness. A display bar will appear at the bottom of the screen indicating the brightness levels.
Page 61 Entertainment Systems 4. RETURN: Press to return to the previous menu screen. 5. ANGLE (DVD dependent): Press to select the angle to view the scene. 6. Channel A/B: Press to select either A or B headphones and then use the MEDIA control to select the desired playing media for the headphones.
Page 62 Entertainment Systems 18. Fast reverse/Previous: When a DVD is playing, press and hold for a quick reverse within the DVD. Press and release for the previous chapter. Press PLAY to resume normal playback speed and volume. In CD/MP3 mode, press to access the previous track. 19.
Page 63 Entertainment Systems Remove the screw and unlatch the battery cover to access the batteries. The remote control unit uses two AAA batteries which are supplied with the unit. Headphones Wireless headphones WARNING: The driver should never use the headphones while driving the vehicle.
Page 64 Entertainment Systems To install the batteries, remove the screw at the bottom of the cover. Then, lightly press down on top and slide the cover off. When replacing the batteries, use two new batteries (alkaline recommended) and install them with the correct orientation as indicated in the battery housing.
Page 65 Entertainment Systems To operate the headphones: • Press POWER on the ear piece to turn on the headphones. A red indicator light will illuminate indicating the headphones are ON. Press POWER again to turn the headphones off. • Adjust the headphones to comfortably fit your head using the headband adjustment.
Page 66 Entertainment Systems Wired headphones WARNING: Do not leave children unattended in the vehicle and do not let children operate the system while unsupervised. If wired headphones or auxiliary systems are used, children may become entangled in the cords and seriously injure themselves. WARNING: The driver should never use the headphones while driving the vehicle.
Page 67 Entertainment Systems Single Play: Single play consists of all occupants in the vehicle listening to the same playing media over the front and rear speakers. When the DVD system is on, and the same source is playing through the front and rear speakers, SINGLE PLAY will appear in the front radio display.
Page 68 Entertainment Systems Press the Headphone Control button A to change the audio source for Channel A. Press MEDIA to change the audio source for Channel A. This information will display on the DVD system screen. Press the Headphone Control button B to change the audio source for Channel B.
Page 69 (Headphone only mode) When the Family Entertainment System (FES) detects that the original radio supplied by Ford Motor Company has been removed from the vehicle, the Family Entertainment System will work in a state referred to as “Headphone Only Mode”.
Page 70 Entertainment Systems Menu mode Press MENU once on the DVD system to access the DVD disc menu if available. Press MENU twice to access the DVD set-up menu and the following features: 1. ZOOM 2. ANGLE 3. ASPECT RATIO 4. LANGUAGE 5.
Page 71 Entertainment Systems You can select from: WIDE, LETTER BOX or PAN SCAN. Once you have made your selection, press ENTER to confirm. The LCD screen display will immediately change to your selection after the system resumes playback of the DVD. The system default is WIDE (16:9).
Page 72 Entertainment Systems Once you have made your selection, press ENTER to confirm. This is disc dependent. Audio CDs To play audio CDs on your DVD system: 1. Ensure that the vehicle is on or the ignition is in accessory mode. 2.
Page 73 Entertainment Systems 4. The folder, track and elapsed time will appear in the status bar. The screen will list the Artist, Title, Album and File Name. COMP (Compression): Compression brings soft and loud CD/MP3 passages together for a more consistent listening level when in CD mode.
Page 74 (DVD), DVD-R and R/W discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD and DVD players. Irregular shaped CDs or DVDs, CDs or DVDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the FES DVD system.
Page 75 Entertainment Systems 4. Use the DVD bezel controls to: Press to play or pause a DVD. Press to stop or eject a DVD. Press and release to go to the previous chapter. Press and hold for a fast reverse search. Press and release to go to the next chapter.
Page 76 Entertainment Systems 2. Press the right cursor button. The DVD will advance one frame. Each press of the right cursor button will advance the DVD video by one frame. Headphone/auxiliary jacks There are wired headphones (not included) and auxiliary jacks on the left and right side of your DVD system.
Page 77 Entertainment Systems Audio displays Your DVD system interacts closely with the front audio system. Status messages will appear in the radio display showing the DVD status. Some possible radio display messages: • SINGLE PLAY or DUAL PLAY • DVD LOAD •...
Page 78 Entertainment Systems When the DVD system is ON, you can then press the memory preset controls 2 and 4 simultaneously to toggle between Single Play and Dual Play. In Single Play mode, all speakers listen to the same media. In Dual Play mode, rear seat passengers can use the infrared wireless, or wired (not included) headphones to listen to a different playing media than the front seat passengers.
Page 79 Safety information WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 80 Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln-Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 81 Entertainment Systems Temperature extremes When the vehicle is parked under direct sunlight or in an extremely cold place for a long period of time, wait until the cabin temperature of the vehicle is at normal temperature before operating the system. Humidity and moisture condensation Moisture in the air will condense in the DVD player under extremely humid conditions or when moving from a cold place to a warm one.
Page 82: Navigation System
(headphone only mode) When the Family Entertainment System (FES) detects that the original radio supplied by Ford Motor Company has been removed from the vehicle, the FES will work in a state referred to as “Headphone Only Mode.” This mode allows the FES to operate as a standalone system, without interface to the radio.
Page 83: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control.
Page 84 Climate Controls 6. Fan speed adjustment: Controls the volume of air circulated in the vehicle. Manual heating and air conditioning system with rear passenger compartment climate control (if equipped) 1. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 85 Climate Controls REAR Rear temperature control: Press to enable the auxiliary system and to set the desired rear cabin airflow temperature with the front control. The rear cabin airflow temperature will match the driver airflow temperature setting when only the center rear temperature light ( REAR ) is illuminated.
Page 86: Dual Automatic Temperature Control
Climate Controls the MAX A/C position, turn off the rear A/C unit, reduce blower fan speed from the highest setting and put the vehicle’s transmission into the P (Park) position to continue to receive cool air from your A/C system. •...
Page 87 Climate Controls 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control. The rear cabin airflow temperature will match the driver airflow temperature setting when only the center rear temperature bar is illuminated. The rear cabin airflow temperature will be warmer or cooler than the driver airflow temperature setting when more than one rear temperature bar is illuminated.
Page 88 Climate Controls : Distributes air through the instrument panel vents and the floor vents. : Distributes air through the instrument panel vents. 12. Manual override controls: Allows you to manually select where airflow is distributed. To return to full automatic control, press AUTO. 13.
Page 89 Climate Controls Dual automatic temperature control with heated and cooled seats and rear passenger compartment climate control (if equipped) Defrost: Distributes outside air through the windshield defroster vents and demister vents. Can be used to clear thin ice or fog from the windshield.
Page 90 Climate Controls 5. R Rear fan speed control: Press to enable the auxiliary system or to adjust the rear fan speed from the front control. Press to manually increase or decrease the fan speed. When the rear fan button is pressed, the display will show only the rear cabin settings.
Page 91 Climate Controls 12. F Front fan speed control: Press to manually increase or decrease the fan speed. To return to full automatic control, press AUTO. 13. OFF: Outside air is shut out and the climate system is turned off. 14. Driver temperature control: Press to increase or decrease the temperature on the driver side of the cabin.
Page 92 Climate Controls • To improve the A/C cool down, drive with the windows slightly open for 2-3 minutes after start up or until the vehicle has been “aired out”. • During extreme high ambient temperatures when idling stationary for extended periods of time in gear, it is recommended to run the A/C with recirculation mode selected, turn off the rear A/C unit, reduce blower fan speed from the highest setting and put the vehicle’s...
Page 93: Rear Window Defroster
Climate Controls AUXILIARY CLIMATE CONTROL (IF EQUIPPED) 1. Fan speed: Turn to select the desired fan speed. 2. Temperature/mode selection: The distribution of air from the overhead and floor registers is based on the temperature selected. Turn to select for comfort. To use the rear climate controls, ensure that REAR is pressed on the main climate control face.
Page 94: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position turn on the headlamps. Rotate back to to turn the headlamps off. Autolamp control The autolamp system provides light sensitive automatic on/off control of the exterior lights normally controlled by the headlamp control.
Page 95 Lights Fog lamp control (if equipped) The headlamp control also operates the fog lamps. The fog lamps can be turned on when the headlamp control is in the positions and the high beams are not turned on. Pull the headlamp control towards you to turn the fog lamps on.
Page 96 Lights WARNING: Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 97 Lights 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away. • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground • (3) 25 feet (7.6 meters) •...
Page 98: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Front row map lamps (if equipped) To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: •...
Page 99: Bulb Replacement
Lights Second row map lamps (if equipped) The second row map lamps are located in the headliner above the second row seats. The second row map lamp lights when: • any door is opened, • the instrument panel dimmer switch is rotated up until the courtesy lamps come on, and •...
Page 100 Lights condensation occurs, a thin film of mist can form on the interior of the lens. The thin mist eventually clears and exits through the vents during normal operation. Clearing time may take as long as 48 hours under dry weather conditions.
Page 101 To replace all instrument panel lights - see your authorized dealer * To obtain replacement approach lamp assembly bulbs, see your authorized dealer and reference Ford part no. 2L1Z–13B374–BB for the passenger side mirror and 2L1Z–13B375–BB for the driver side mirror.
Page 102 Lights 5. Disconnect the electrical connector. 6. Remove the bulb by turning it counterclockwise and then pulling it straight out. WARNING: Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass.
Page 103 Lights 5. Rotate the bulb socket counterclockwise and remove from the lamp assembly. 6. Carefully pull the bulb out of the socket and push in the new bulb. 7. Install the bulb socket into the lamp assembly and rotate clockwise. 8.
Page 104 Lights Replacing the high-mount brakelamp To change the high-mount brakelamp bulbs: 1. Remove the two screws holding the lamp assembly in place. 2. Pull the lamp assembly straight out. 3. Disconnect the wire harness. 4. Depress the four tabs that hold the light assembly on, one at a time, and pull the black bulb carrier away from the lamp.
Page 105 Lights Replacing license plate lamp bulb The license plate bulbs are located in the license plate housing assembly on the liftgate. To change the license plate bulbs: 1. Make sure the headlamp switch is in the off position. 2. Remove the license lamp screw from the assembly.
Page 106: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
Page 107: Steering Wheel Adjustment
Driver Controls Windshield wiper rainlamp feature (if equipped with Autolamp) When the windshield wipers are turned on during daylight, and the headlamp control is in the autolamp position, the exterior lamps will turn on after a brief delay and will remain on until the wipers are turned off. Rear window wiper/washer controls For rear wiper operation, rotate the rear window wiper and washer...
Page 108 Driver Controls ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamp. Slide on rod feature (if equipped) Rotate the visor towards the side window and extend it rearward for additional sunlight coverage. Note: To stow the visor back into the headliner, visor must be retracted before moving it back towards the windshield.
Page 109 Driver Controls Conversation mirror (if equipped) On double bin overhead consoles, the conversation mirror allows the driver to view the rear seating area. WARNING: Do not use the conversation mirror to view rearward traffic, do not allow rear passengers to distract you from the driving task, and make sure the rear view mirror has a clear view of rearward traffic.
Page 110 Driver Controls CENTER CONSOLE (IF EQUIPPED) Your vehicle may be equipped with a variety of console features. These include: 1. Cupholders 2. Utility compartment, coin holder slots, tissue box holder, audio input jack and USB port (if equipped) 3. Power point, rear audio controls (if equipped) and rear heated seat controls (if equipped) 4.
Page 111 Driver Controls To have full capacity usage of your power point, the engine is required to be running to avoid unintentional discharge of the battery. To prevent the battery from being discharged: • do not use the power point longer than necessary when the engine is not running, •...
Page 112: Power Windows
Driver Controls Not equipped with rear climate control Cigar/Cigarette lighter (if equipped) Do not plug optional electrical accessories into the cigarette lighter socket. Do not hold the lighter in with your hand while it is heating, this will damage the lighter element and socket. The lighter will be released from its heating position when it is ready to be used.
Page 113 Driver Controls Press and pull the window switches to open and close windows. • Push down (to the first detent) and hold the switch to open. • Pull up (to the first detent) and hold the switch to close. Rear Window Buffeting: When one or both of the rear windows are open, the vehicle may demonstrate a wind throb or buffeting noise;...
Page 114 Driver Controls Bounce-Back (Driver’s window only) When an obstacle has been detected in the window opening as the window is moving upward, the window will automatically reverse direction and move down. This is known as “bounce-back”. If the ignition is turned off (without accessory delay being active) during bounce-back, the window will move down until the bounce-back position is reached.
Page 115 Driver Controls Automatic dimming interior rear view mirror Your vehicle is equipped with an interior rear view mirror which has an auto-dimming function. The electronic day/night mirror will change from the normal (high reflective) state to the non-glare (darkened) state when bright lights (glare) reach the mirror.
Page 116: Mirrors
Driver Controls EXTERIOR MIRRORS Power side view mirrors The ignition can be in any position to adjust the power side view mirrors. To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.
Page 117 Driver Controls Note: 10 or more switch activations within one minute, or repeated folding/unfolding of the mirrors while holding the switch rearward during full travel, may cause the system to disable the fold/unfold function to protect motors from overheating. Should this occur, wait approximately three minutes with the vehicle running and up to 10 minutes with the vehicle off, for the system to reset and for function to return to normal.
Page 118 Driver Controls Signal indicator mirrors (if equipped) When the turn signal is activated, the lower portion of the mirror housing will blink. POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED) The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position.
Page 119 Driver Controls Automatic power deploy: • The running boards will extend down and out when the doors are opened. Automatic power stow: • The running boards will return to the stowed position when the doors are closed. There will be a two second delay before the running boards move in to the stowed position.
Page 120: Speed Control
Driver Controls Note: Do not use the running boards, front and rear hinge assemblies, running board motors, or the running board under body mounts to lift the vehicle when jacking. Please utilize proper jacking points. Refer to Changing the tires in the Roadside Emergencies chapter. WARNING: In extreme climates, excessive ice buildup may occur, causing the running boards not to deploy.
Page 121 Driver Controls 3. Press the SET + control and release it. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. Note: • Vehicle speed may vary momentarily when driving up and down a steep hill.
Page 122 Driver Controls Increasing speed while using speed control There are two ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control. You can also use the SET + control to operate the Tap-Up function.
Page 123 Driver Controls • Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some radio control features. Audio control features Press MEDIA to select: •...
Page 124 Driver Controls In DVD mode (if equipped): • Refer to the Family entertainment DVD system in the Entertainment Systems chapter. In any mode: • Press VOL + or − to adjust volume. Navigation system hands free control features (if equipped) Press and hold VOICE briefly until the voice icon appears on the...
Page 125: Moon Roof
Driver Controls For further information on the SYNC system, refer to the SYNC supplement. Navigation system/SYNC hands free control features (if equipped) Press VOICE briefly until the voice icon appears on the Navigation display to use the voice command feature. Press to activate phone mode or answer a phone call.
Page 126 Driver Controls Bounce-back: When an obstacle has been detected in the moon roof opening as the moon roof is closing, the moon roof will automatically open and stop at a prescribed position. Bounce-back override: To override bounce-back function, pull and hold the SLIDE switch within two seconds of a bounce-back event.
Page 127 Driver Controls Retain the original transmitter for use in other vehicles as well as for future programming procedures (i.e. new HomeLink equipped vehicle purchase). It is also suggested that upon the sale of the vehicle, the programmed Homelink buttons be erased for security purposes, refer to Programming in this section.
Page 128 Driver Controls 5. Firmly press and release the “learn” or “smart” button. (The name and color of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate Step 6. 6. Return to the vehicle and firmly press, hold for two seconds and release the programmed HomeLink button.
Page 129 Driver Controls Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
Page 130: Message Center
Driver Controls STANDARD MESSAGE CENTER (IF EQUIPPED) With the ignition in the on position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator chime.
Page 131 Driver Controls Distance to empty (DTE) Selecting this function from the INFO MENU estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition off when refueling to allow this feature to correctly detect the added fuel. The DTE function will display LOW FUEL LEVEL and sound a tone for one second when you have approximately 50 miles (80 km) to empty.
Page 132 Driver Controls Outside air temperature (OAT) The outside air temperature is shown together with the compass heading in the bottom row of the message center display. Compass display (if equipped) The compass heading is displayed as one of N, NE, E, SE, S, SW, W and NW in the message center display.
Page 133 Driver Controls 5. Press and hold the RESET stem for approximately two seconds to enter the compass zone adjustment mode. 6. Press and release the RESET stem until the desired zone number appears. 7. Release the RESET stem and allow the setup timer to expire to exit the procedure.
Page 134 Driver Controls Setup menu This menu allows the user, via the RESET stem located in the instrument cluster, to interface and control the information displayed in the message center for following selectable features: • System Check • Oil life • Units (English/Metric) •...
Page 135 Driver Controls Pressing the RESET stem cycles the message center through each of the systems being monitored. If the RESET stem is not pressed, the display will automatically scroll through each of the systems being monitored: 1. OIL LIFE 2. CHARGING SYSTEM 3.
Page 136 Driver Controls 3. Press the RESET stem for the next SETUP MENU item or wait for more than four seconds to return to the INFO MENU (“HOLD RESET FOR SETUP MENU” will appear). Autolamp This feature keeps your headlights on for up to three minutes after the ignition is switched off.
Page 137 Driver Controls 1. To disable/enable the autounlock feature, select this function from the SETUP MENU. 2. Press and hold the RESET stem for two seconds to turn the autounlock ON or OFF. 3. Press the RESET stem for the next SETUP MENU item or wait for more than four seconds to return to the INFO MENU (HOLD RESET FOR SETUP MENU will appear).
Page 138 Driver Controls • They will not reappear until an ignition off-on cycle has been completed. • They reappear if the condition clears then reoccurs within the same ignition on-off cycle. This acts as a reminder that these warning conditions still exist within the vehicle.
Page 139 Driver Controls CHECK CHARGING SYSTEM — Displayed when the electrical system is not maintaining proper voltage when the engine is running. If you are operating electrical accessories when the engine is idling at a low speed, turn off as many of the electrical loads as soon as possible. If the warning stays on or comes on when the engine is operating at normal speeds, have the electrical system checked as soon as possible.
Page 140 Driver Controls XXX MILES TO E FUEL LEVEL LOW — Displayed as an early reminder of a low fuel condition. WASHER FLUID LEVEL LOW — Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Windshield washer fluid in the Maintenance and Specifications chapter.
Page 141 Driver Controls • Average Fuel Economy (AFE) • Instantaneous Fuel Economy • Trip Elapsed Drive Time • Blank Screen Odometer/Trip odometer Refer to Gauges in the Instrument Cluster chapter. Outside air temperature (if equipped) Press and hold the INFO button for two seconds to display the outside temperature.
Page 142 Driver Controls Average fuel economy (AFE) Select this function from the INFO menu to display your average fuel economy in miles/gallon or liters/100 km. If you calculate your average fuel economy by dividing 100 miles traveled by gallons of fuel used (kilometers traveled by liters used), your figure may be different than displayed for the following reasons: •...
Page 143 Driver Controls 2. Press and release RESET to pause the timer. 3. Press and hold RESET for two seconds in order to reset the timer. Blank screen Press the RESET once to turn the message center display off. Setup menu Press this control for the following displays: •...
Page 144 Driver Controls The sequence of the system check report and how it appears in the message center is as follows: 1. OIL LIFE 2. CHARGING SYSTEM 3. WASHER FLUID LEVEL 4. DOOR STATUS 5. LIFTGATE/GLASS 6. BRAKE FLUID LEVEL 7. AIR SUSPENSION SYSTEM (if equipped) 8.
Page 145 Driver Controls Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed. 2. Press the RESET control to change from English to Metric. Autolamp delay This feature keeps your headlights on for up to three minutes after the ignition is switched off.
Page 146 Driver Controls Autolock This feature automatically locks all vehicle doors when the vehicle is shifted into any gear, putting the vehicle in motion. 1. To disable/enable the autolock feature, select this function from the SETUP control for the current display mode. 2.
Page 147 Driver Controls Power Liftgate (if equipped) This feature allows users to open/close the rear liftgate at the touch of a button. 1. To disable/enable the power liftgate feature, select this function from the SETUP control for the current display mode. 2.
Page 148 Driver Controls Compass zone/calibration adjustment 1. Determine your magnetic zone by referring to the zone map. 2. Turn ignition to the on position. 3. Start the engine. 4. From Setup menu, select the Update Zone function. 7 8 9 1011 5.
Page 149 Driver Controls 9. Press the RESET control to start the compass calibration function. 10. Slowly drive the vehicle in a circle (less than 3 mph [5 km/h]) until the CIRCLE SLOWLY TO CALIBRATE display changes to CALIBRATION COMPLETED. It will take up to five circles to complete calibration.
Page 150 Driver Controls System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for four seconds.
Page 151 Driver Controls Warning display Status Brake fluid level low Warning can be reset. Will NOT return if reset and warning is Check park brake cleared and set again within Washer fluid level low the same ignition cycle. Will Oil change required return on ignition cycle.
Page 152 Driver Controls PASSENGER DOOR AJAR — Displayed when the passenger door is not completely closed. REAR LEFT DOOR AJAR — Displayed when the rear left door is not completely closed. REAR RIGHT DOOR AJAR — Displayed when the rear right door is not completely closed.
Page 153 Driver Controls WASHER FLUID LEVEL LOW — Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Windshield washer fluid in the Maintenance and Specifications chapter. AIR SUSPENSION OFF (if equipped) — Displayed when the air suspension is off.
Page 154 Driver Controls TO EXIT 4X4 LOW STOP VEHICLE(if equipped) — Displayed when 2WD is selected while the vehicle is operating in 4X4 LOW. For more information, refer to Control Trac four-wheel drive (4x4) operation in the Driving chapter. TO EXIT 4X4 LOW SHIFT TO N(if equipped) — Displayed when 2WD is selected while the vehicle has been stopped in 4X4 LOW.
Page 155 Driver Controls WARNING: Keep keys out of reach of children. Do not allow children to play near an open or moving power liftgate. The liftgate will only operate with the vehicle in P (Park). The chime will beep once if conditions are not correct to start an operation. These conditions include: •...
Page 156 Driver Controls To open the liftgate with outside liftgate control button (manual actuation): 1. To open, unlock the liftgate with the remote entry transmitter or power door unlock control. 2. To open the liftgate, push the control button located in the top of the liftgate pull cup handle.
Page 157 Driver Controls To manually operate the liftgate: 1. Disable the liftgate power function, refer to the Message center in this chapter. 2. Open and close the liftgate as you would a standard liftgate. Note: In case of operation in extreme cold -40°F (-40°C), or on extreme inclines, manual operation of the liftgate is suggested.
Page 158 Driver Controls Liftgate ajar signal If the liftgate or liftgate glass are not fully latched, you will receive a “LIFTGATE or LIFTGLASS AJAR” message on the instrument panel. If you see this message, check both the liftgate glass and liftgate door to ensure they are fully latched.
Page 159 Driver Controls To open the liftgate, push the control button located on the inside of the liftgate handle to unlatch the liftgate, then pull on the handle to access the cargo area. • Do not open the liftgate or liftgate glass in a garage or other enclosed area with a low ceiling.
Page 160 Driver Controls Cargo shelf/divider (if equipped) The cargo shelf/divider is located behind the rear seat of your vehicle. The shelf has two positions: Flat shelf which pivots up and snaps into place or a divider which pivots up and snaps vertically into place. Do not put more than 30 lb.
Page 161 Always ensure that the load is secure before traveling. Ford Motor Company recommends loading the roof rack only when equipped with (optional) crossbars, to avoid unintended damage to the roof panel.
Page 162: Locks And Security
Locks and Security KEYS Your vehicle may be equipped with two Integrated Keyhead Transmitters (IKTs). The key blade functions as a programmed key which starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter. Your IKTs are programmed to your vehicle;...
Page 163 Locks and Security Recommended handling of the Integrated Keyhead Transmitter (IKT) To avoid inadvertently activating the remote entry functions of your vehicle, it is recommended that the Integrated Keyhead Transmitter (IKT) be handled properly when starting and turning off your vehicle. When inserting the IKT into the ignition cylinder, place your thumb on the center thumb rest of the IKT...
Page 164: Locks
Locks and Security POWER DOOR LOCKS Press control to unlock all doors. Press control to lock all doors. Smart locks This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open one of the front doors or the liftgate and you lock the vehicle with the power door lock control (on the driver or passenger door trim panel), all the doors will lock, then all doors will automatically...
Page 165 Locks and Security The autolock feature repeats when: • any door is opened then closed while the ignition is in the on position and the vehicle speed is 9 mph (15 km/h) or lower, and • the vehicle attains a speed greater than 12 mph (20 km/h). Deactivating/activating autolock Your vehicle comes with the autolock feature enabled.
Page 166 Locks and Security Keyless entry keypad procedure 1. Turn the ignition to the off position. 2. Close all doors, the liftgate and liftgate window. 3. Enter 5–digit entry code 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
Page 167 Locks and Security Power door lock switch autounlock enable/disable procedure Before starting, ensure the ignition is in the off position and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, wait a minimum of 30 seconds before beginning again.
Page 168 Locks and Security CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 169 Locks and Security The typical operating range for your IKT is approximately 33 feet (10 meters). A decrease in operating range could be caused by: • weather conditions, • nearby radio towers, • structures around the vehicle, or • other vehicles parked next to your vehicle. The IKT allows you to: •...
Page 170 Locks and Security The inside lights will not turn off if: • they have been turned on using the dimmer control or • any door is open. The battery saver feature will turn off the interior lamps 10 minutes after the ignition is turned to the off position.
Page 171 Locks and Security WARNING: Make sure the power liftgate is closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate open, keep the vents open so outside air comes into the vehicle.
Page 172 Locks and Security 3. Within three seconds press the control on the remote entry transmitter. 4. A tone will be heard when the activation is complete. 5. Repeat this procedure for another remote entry transmitter if desired. Deactivating the memory feature To deactivate this feature: 1.
Page 173 Locks and Security 4. Snap the battery cover back onto the key. Note: Replacement of the battery will not cause the IKT to become deprogrammed from your vehicle. The IKT should operate normally after battery replacement. Replacing lost Integrated Keyhead Transmitters (IKTs) If you would like to have your Integrated Keyhead Transmitters reprogrammed because you lost one, or would like to buy additional IKTs, you can either reprogram them yourself, or take all IKTs to your...
Page 174 Locks and Security The lamps will automatically turn off: • if the ignition switch is turned to the on position, or • the control is pressed, or • after 25 seconds of illumination. Note: On some vehicles, the perimeter lamps illuminated entry feature will not activate in daylight conditions.
Page 175 Locks and Security The lights will turn off if all the doors remain closed and • 25 seconds elapse, or • the key is inserted in the ignition. Battery saver The battery saver will shut off the interior lamps 10 minutes after the ignition has been turned to the off position.
Page 176 Locks and Security • Pressing 1 • 2 assigns driver 1 settings. • Pressing 3 • 4 assigns driver 2 settings. • Pressing 5 • 6, 7 • 8, or 9 • 0 assigns Driver 3 settings. 5. The doors will again lock then unlock to confirm that your personal entry code has been programmed to the module.
Page 177: Anti-Theft System
Note: The SecuriLock™ passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 178 Locks and Security Anti-theft indicator The anti-theft indicator is located in the instrument panel cluster. • When the ignition is in the off position, the indicator will flash once every two seconds to indicate the SecuriLock™ system is functioning as a theft deterrent.
Page 179 Check to make sure the coded key is an approved Ford coded key. If your keys are lost or stolen you will need to do the following: •...
Page 180 Locks and Security • If two previously programmed coded keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed. Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition.
Page 181 Locks and Security To program additional new unprogrammed key(s), wait 20 seconds and then repeat this procedure from Step 1. PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will help protect your vehicle from unauthorized entry. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL Integrated Keyhead Transmitters are brought to the authorized dealer to aid in troubleshooting.
Page 182 Locks and Security Each door, the hood, and the liftgate is armed individually, and if any are open, they must be closed before the open entry point (door, hood, or liftgate) can enter the 20 second countdown. The turn signal lamps will flash once when all doors, the hood and the liftgate are closed indicating the vehicle is locked and entering the 20 second countdown.
Page 183: Seating And Safety Restraints
Seating and Safety Restraints SEATING Adjustable head restraints Your vehicle is equipped with front row outboard head restraints that are vertically adjustable. WARNING: To minimize the risk of neck injury in the event of a crash, the driver and passenger occupants should not sit in and/or operate the vehicle, until the head restraint is placed in its proper position.
Page 184 Seating and Safety Restraints 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint. Properly adjust the head restraint so that the top of the head restraint is even with the top of your head and positioned as close as possible to the back of your head.
Page 185 Seating and Safety Restraints 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint. To reinstall the adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars.
Page 186 Seating and Safety Restraints Lift handle to move seat forward or backward. Manual seat recliner (if equipped) WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
Page 187 Seating and Safety Restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support (if equipped) The lumbar support control is located on the outboard side of the seat. Turn the lumbar support control clockwise for more support.
Page 188 Seating and Safety Restraints Using the power lumbar support (if equipped) The power lumbar control is located on the outboard side of the seat. Press the forward side of the control for additional support. Press the rear side of the control to reduce support.
Page 189 Seating and Safety Restraints Move the switch in the direction of the arrows to raise or lower the rear portion of the seat cushion. Press the switch in the direction of the arrows to move the seat forward, backward, up or down. Press the control to recline the seatback forward or rearward.
Page 190 Seating and Safety Restraints Memory seat/power mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, outside rearview mirrors and adjustable pedals to two programmable positions. The memory seat control is located on the outboard side of the seat cushion. •...
Page 191 Seating and Safety Restraints Heated seats WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 192 Seating and Safety Restraints Climate controlled seats air filter replacement (if equipped) The climate controlled seat system includes air filters that must be replaced periodically. Refer to the scheduled maintenance information for more information. • There is a filter located under each front seat.
Page 193 Seating and Safety Restraints To install a filter: • First, position the filter in its housing making sure that the far forward end is all the way up in the housing. Then push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
Page 194 Seating and Safety Restraints 2. Locate handle on the side of the seat cushion by the door. 3. Pull up on the handle and push the seatback forward toward the front of the vehicle. To return the seat to the upright position: 1.
Page 195 Seating and Safety Restraints Placing the 2nd row outboard 40% seats in cargo mode WARNING: Use caution when folding the seatback to the flat back position as the system will move forward when you lift the release handle. The 2nd row seats can be placed in a kneel down load floor position to allow more cargo space.
Page 196 Seating and Safety Restraints Returning to the upright position from full lowered load floor position The seatback cannot be returned to the upright position until the seat is returned from the kneel down position. To return the seat to the upright position: 1.
Page 197 Seating and Safety Restraints To return the seat to a seating position: 1. Push the seat down and latch to the floor with a moderate amount of effort and speed. 2. Make sure the seat is latched to the floor. 3.
Page 198 Seating and Safety Restraints Exiting the 3rd row 1. Pull the strap located at the bottom outboard of the seat back to release the seat from the floor, and rotate the seat up towards the front seat. 2. Follow the directions above to return the seat from the E-Z entry and to the upright position.
Page 199 Seating and Safety Restraints WARNING: To prevent possible damage to the seat or safety belts, ensure that the safety belts are not buckled when moving the seat to the load floor position. 2. With the latch released the seatback can be lowered into the load floor position.
Page 200 Seating and Safety Restraints Adjusting the 2nd row center 20% seat (if equipped) Lift the handle to move the seat forward or backward. Note: This seat can be moved forward to keep a child in a child restraint close to the front seat occupants. The seat should be moved to the full rearward position when it is occupied by older children or adults.
Page 201 Seating and Safety Restraints The rear seat heat controls are located on the rear of the center console. To operate the heated seats: • Push the indicated side of the control for maximum heat. • Push again to deactivate. • Push the indicated side of the control for minimum heat.
Page 202 Seating and Safety Restraints Folding down the 3rd row seats to the load floor WARNING: To prevent possible damage to the seat or safety belts, ensure that the safety belts are not buckled when moving the seat to the load floor position. Before folding the third row seats, fold the head restraints down by pulling on the strap located at the...
Page 203 Seating and Safety Restraints Third row power folding seat (if equipped) Note: Be sure that the head restraints are folded down before powering the 3rd row seat down. The control buttons are located on the right-hand rear quarter trim panel (accessible from the liftgate area).
Page 204: Safety Restraints
Seating and Safety Restraints opening any door, pressing the unlock button on the key fob, pressing any keyless entry keypad button, or turning the ignition key. SAFETY RESTRAINTS Personal Safety System The Personal Safety System provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries.
Page 205 Seating and Safety Restraints Driver and passenger dual-stage airbag supplemental restraints The dual-stage airbags offer the capability to tailor the level of airbag inflation energy. A lower, less forceful energy level is provided for more common, moderate-severity impacts. A higher energy level is used for the most severe impacts.
Page 206 Seating and Safety Restraints Determining if the Personal Safety System is operational The Personal Safety System uses a warning light in the instrument cluster or a back-up tone to indicate the condition of the system. Refer to the Warning lights and chimes section in the Instrument Cluster chapter.
Page 207 Seating and Safety Restraints WARNING: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 208 Seating and Safety Restraints • Front and rear seats 2. To unfasten, push the release button and remove the tongue from the buckle. • Front and rear seats The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. The front outboard passenger and rear seat safety belts have three types of locking modes described as follows: Vehicle sensitive mode...
Page 209 Seating and Safety Restraints Automatic locking mode In this mode, the shoulder belt is pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to use the automatic locking mode •...
Page 210 Seating and Safety Restraints WARNING: After any vehicle collision, the combination lap and shoulder belt system at all passenger seating positions must be checked by an authorized dealer to verify that the “automatic locking retractor” feature for child seats is still functioning properly, in addition to other checks for proper safety belt system function.
Page 211 Seating and Safety Restraints Safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and right front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, squeeze the side release buttons with your thumb and finger and slide the height adjuster down.
Page 212 Seating and Safety Restraints To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide. (The portion of the belt between the latch tongue and the D-ring, not the portion where the belt exits from the quarter trim panel.) 2.
Page 213 Seating and Safety Restraints Conditions of operation If... Then... The driver safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the on warning chime sounds 4-8 seconds. position...
Page 214 Seating and Safety Restraints If... Then... The driver’s safety belt is The Belt-Minder feature is activated - not buckled approximately the safety belt warning light illuminates five seconds after the safety and the warning chime sounds for six belt warning light has seconds every 30 seconds, repeating for turned off...
Page 215 Seating and Safety Restraints Reasons given... Consider... “I was in a hurry” Prime time for an accident. Belt-Minder reminds us to take a few seconds to buckle up. “Safety belts don’t work” Safety belts, when used properly, reduce risk of death to front seat occupants by 45% in cars, and by 60% in light trucks.
Page 216 Seating and Safety Restraints Deactivating/activating the Belt-Minder feature (if equipped) Read Steps 1 - 4 thoroughly before proceeding with the deactivation/activation programming procedure. The driver Belt-Minder feature can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that: •...
Page 217: Airbags
Seating and Safety Restraints seconds with the light off, then followed by the safety belt warning light flashing four times per second for three seconds again. AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries.
Page 218 Seating and Safety Restraints WARNING: The National Highway Traffic Safety Administration (NHTSA) recommends a minimum distance of at least 10 inches (25 cm) between an occupant’s chest and the driver airbag module. WARNING: Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries.
Page 219 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 220 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 221 Seating and Safety Restraints • one or more impact and safing sensors and diagnostic monitor (RCM), • a readiness light and tone • the electrical wiring which connects the components. The RCM (restraints control module) monitors its own internal circuits and the supplemental airbag electrical system wiring (including the impact sensors, the system wiring, the airbag system readiness light, the airbag back up power and the airbag ignitors).
Page 222 Seating and Safety Restraints WARNING: Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. Contact your authorized dealer as soon as possible. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
Page 223 Seating and Safety Restraints The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration.
Page 224 Seating and Safety Restraints WARNING: Do not attempt to service, repair, or modify the Safety Canopy system, its fuses, the A, B, C or D pillar trim, or the headliner on a vehicle containing a Safety Canopy . See your authorized dealer.
Page 225 Seating and Safety Restraints • Two crash sensors mounted in the front doors (one on each side of the vehicle). • Two crash sensors located at the C pillar behind the rear doors (one on each side of the vehicle). •...
Page 226 Seating and Safety Restraints WARNING: If the Safety Canopy system has deployed, the Safety Canopy will not function again unless replaced. The Safety Canopy system (including the A, B, C, and D pillar trim and headliner) must be inspected and serviced by an authorized dealer.
Page 227: Child Restraints
Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 228 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended re- Child size, height, weight, or age straint type Infants Children weighing 40 lb (18 kg) or less Use a child safety or tod- (generally age four or younger) seat (sometimes dlers called an infant car-...
Page 229 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated be- low by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt Child anchors anchors LATCH only straint Weight and top only) (lower...
Page 230 Seating and Safety Restraints WARNING: Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by the vehicle manufacturer.
Page 231 Highway Traffic Safety Administration (NHTSA) provides education and training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 232 Seating and Safety Restraints When installing a child safety seat: • Review and follow the information presented in the Airbag supplemental restraint system (SRS) section in this chapter. • Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle.
Page 233 Seating and Safety Restraints • Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to help prevent accidental unbuckling. • Place vehicle seat back in upright position. •...
Page 234 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 235 There should be no more than 1 inch (2.5 cm) of movement for proper installation. 11. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) to make certain the child restraint is properly installed.
Page 236 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 237 Seating and Safety Restraints Follow the instructions on attaching child safety seats with tether straps. Refer to Attaching child safety seats with tether straps later in this chapter. Attach LATCH lower attachments of the child seat only to the anchors shown.
Page 238 Seating and Safety Restraints Some of the rear seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as described below. In the third row center seating position, the tether anchor is a loop at the bottom of the seatback.
Page 239 Seating and Safety Restraints • Second row outboard seating positions • Second row center seating position (if equipped) 3. Grasp the tether strap and position it to the seat frame. 4. Rotate the tether strap, and clip the tether strap to the anchor on the seat frame.
Page 240 Seating and Safety Restraints 5. Rotate the tether strap clip. 6. Tighten the child safety seat tether strap according to the manufacturer’s instructions. Third row center seating position 1. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seatback.
Page 241 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. 2009 Expedition (exd)
Page 242 Seating and Safety Restraints Booster seats position a child so that vehicle lap/shoulder safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably at the edge of the cushion, while minimizing slouching.
Page 243 Seating and Safety Restraints Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back. Always use booster seats in conjunction with the vehicle lap/shoulder belt. • Backless booster seats If your backless booster seat has a removable shield, remove the shield.
Page 244 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 245 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 246: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 247 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter. Information on transfer case maintenance can be found in the Maintenance and Specifications chapter.
Page 248: Tire Information
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 249 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
Page 250: Tire Inflation
Tires, Wheels and Loading Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
Page 251 Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 252 Tires, Wheels and Loading of 1 psi (7 kPa) in inflation pressure. Check your tire pressures frequently and adjust them to the proper pressure which can be found on the Safety Compliance Certification Label or Tire Label. To check the pressure in your tire(s): 1.
Page 253 Tires, Wheels and Loading TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check for holes or cuts that may permit air leakage from the tire and make necessary repairs.
Page 254 Tires, Wheels and Loading WARNING: Age Tires degrade over time depending on many factors such as weather, storage conditions, and conditions of use (load, speed, inflation pressure, etc.) the tires experience throughout their lives. In general, tires should be replaced after six years regardless of tread wear.
Page 255 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 256 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System.
Page 257 Tires, Wheels and Loading Tire and wheel alignment A bad jolt from hitting a curb or pothole can cause the front end of your vehicle to become misaligned or cause damage to your tires. If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment.
Page 258 Tires, Wheels and Loading Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels.
Page 259 Tires, Wheels and Loading 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 6.
Page 260 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 261 Tires, Wheels and Loading 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 262 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 263: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 264 Tires, Wheels and Loading following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: The Tire Pressure Monitoring System is NOT a substitute for manually checking tire pressure.
Page 265 Tires, Wheels and Loading When your temporary spare tire is installed When one of your road tires needs to be replaced with the temporary spare, the TPMS system will continue to identify an issue to remind you that the damaged road wheel/tire needs to be repaired and put back on your vehicle.
Page 266 Tires, Wheels and Loading Low Tire Possible Customer Action Required Pressure cause Warning Light Flashing Spare tire Your temporary spare tire is in use. Repair the Warning in use damaged road wheel and re-mount it on the Light vehicle to restore system functionality. For a description of how the system functions under these conditions, refer to When your tempo- rary spare tire is installed in this section.
Page 267: Vehicle Loading
Follow these guidelines when using snow tires and chains: • Use only cable type chains or chains offered by Ford as an accessory or equivalent. Other conventional link type chains may contact and cause damage to the vehicle’s wheel house and/or body.
Page 268 Tires, Wheels and Loading capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance. Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Tire Label or Safety Compliance Certification Label: Base Curb Weight –...
Page 269 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 270 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 271 Tires, Wheels and Loading WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer.
Page 272 Tires, Wheels and Loading WARNING: Do not use replacement tires with lower load carrying capacities than the original tires because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the original tires do not increase the GVWR and GAWR limitations.
Page 273: Trailer Towing
Tires, Wheels and Loading • A final example for your vehicle with 1,400 lb. (635 kg) of cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years.
Page 274 Tires, Wheels and Loading Follow these guidelines to ensure safe towing procedure: • Stay within your vehicle’s load limits. If exceeded, cargo should be removed from the trailer and/or the vehicle until all weights are within specified limits. • Thoroughly prepare your vehicle for towing. Refer to Preparing to tow in this chapter.
Page 275 Tires, Wheels and Loading Trailer weight Rear axle Maximum GCWR - Engine range (0 - ratio lb. (kg) maximum) lb. (kg) 5.4L with standard 11800 (5352) 0–6000 (0–2721) trailer tow package 5.4L with optional 15000 (6804) 0–9200 (0–4172) trailer tow package 5.4L with standard...
Page 276 Tires, Wheels and Loading Trailer weight Rear axle Maximum GCWR - Engine range (0 - ratio lb. (kg) maximum) lb. (kg) Expedition EL (U.S. Only) Expedition Max (Canada Only) 4x2 5.4L with standard 12100 (5488) 0–6000 (0–2721) trailer tow package 5.4L with optional 15000 (6804)
Page 277 Tires, Wheels and Loading Integrated hitch rating The standard integrated hitch has two ratings depending on mode of operation: • Weight carrying - requires a draw bar and hitch ball. The draw bar supports all the vertical tongue load of the trailer. •...
Page 278 Tires, Wheels and Loading Weight distributing hitch When hooking up a trailer using a load equalizing hitch, always use the following procedure: 1. Park the unloaded vehicle on a level surface. With the ignition in the ON position and all doors closed, allow the vehicle to stand (without passengers) for several minutes so that it can level.
Page 279 Tires, Wheels and Loading The braking system of the tow vehicle is rated for operation at the GVWR not GCWR. Trailer lamps Trailer lamps are required on most towed vehicles. Make sure all running lights, brake lights, turn signals and hazard lights are working. Contact your authorized dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps.
Page 280 Tires, Wheels and Loading Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 281: Recreational Towing
Tires, Wheels and Loading Exceeding these limits may allow water to enter vehicle components: • causing internal damage to the components. • affecting driveability, emissions and reliability. Replace the rear axle lubricant any time the axle has been submerged in water.
Page 282: Driving
Driving STARTING Positions of the ignition 1. Off— locks the steering wheel, automatic transmission gearshift lever and allows key removal. 2. Accessory— allows the electrical accessories such as the radio to operate while the engine is not running. 3. On— all electrical circuits operational.
Page 283 Driving WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine.
Page 284 Driving 4. Make sure the parking brake is set. 5. Turn the key to 3 (on) without turning the key to 4 (start). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
Page 285 Driving 3. After idling for a few seconds, release the parking brake, apply the brake, shift into gear and drive. Note: If the engine does not start on the first try, turn the key to the off position, wait 10 seconds and try Step 2 again. If the engine still fails to start, press the accelerator to the floor and try Step 2 again, keeping the accelerator on the floor until the engine begins to accelerate above cranking speeds;...
Page 286 Driving Guarding against exhaust fumes Carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes.
Page 287 Driving WARNING: To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. Prior to using the engine block heater, follow these recommendations for proper and safe operation: • For your safety, use an outdoor extension cord that is product certified by Underwriter’s Laboratory (UL) or Canadian Standards Association (CSA).
Page 288: Brakes
Driving How to use the engine block heater Ensure the receptacle terminals are clean and dry prior to use. To clean them, use a dry cloth. Depending on the type of factory installed equipment, your engine block heater system may consume anywhere between 400 watts or 1000 watts of power per hour.
Page 289 Driving Anti-lock brake system (ABS) On ABS-equipped vehicles, a noise from the hydraulic pump motor and pulsation in the pedal may be observed during ABS braking events. Pedal pulsation coupled with noise while braking under panic conditions or on loose gravel, bumps, wet or snowy roads is normal and indicates proper functioning of the vehicle’s anti-lock brake system.
Page 290 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned on) until the parking brake is released.
Page 291: Advancetrac
Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. ADVANCETRAC WITH ROLL STABILITY CONTROL™ (RSC ) STABILITY ENHANCEMENT SYSTEM (IF EQUIPPED) WARNING: Vehicle modifications involving braking system, aftermarket roof racks, suspension, steering system, tire construction and/or wheel/tire size may change the handling characteristics of the vehicle and may adversely affect the performance...
Page 292 Driving WARNING: If a failure has been detected within the AdvanceTrac with RSC system, the sliding car icon will illuminate steadily. Verify that the AdvanceTrac with RSC system is not manually disabled (push the AdvanceTrac with RSC “Off “ button located on the center of the instrument panel). If the sliding car icon still illuminates steadily, have the system service by an authorized dealer immediately.
Page 293 Driving When AdvanceTrac with RSC performs a normal system self-check, some drivers may notice a slight movement of the brake, and/or a rumble, grunting, or grinding noise after startup and when driving off. When an event occurs that activates AdvanceTrac with RSC you may experience the following: •...
Page 294 Driving Electronic Stability Control (ESC) Electronic Stability Control (ESC) may enhance your vehicle’s directional stability during adverse maneuvers, for example when cornering severely or avoiding objects in the roadway. ESC operates by applying brakes to one or more of the wheels individually and, if necessary, reducing engine power if the system detects that the vehicle is about to skid or slide laterally.
Page 295 Driving The Roll Stability Control system may be deactivated in certain situations. See the Switching Off AdvanceTrac with RSC section following. Switching Off AdvanceTrac with RSC If the vehicle is stuck in snow, mud or sand, and seems to lose engine power, switching off certain features of the AdvanceTrac with RSC system may be beneficial because the wheels are allowed to spin.
Page 296 Driving STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to decrease the driver’s effort in steering the vehicle. To help prevent damage to the power steering pump: • Never hold the steering wheel to the extreme right or the extreme left for more than a few seconds when the engine is running.
Page 297: Air Suspension
Driving AIR SUSPENSION SYSTEM (IF EQUIPPED) The air suspension system is designed to improve ride, handling and general vehicle performance during: • Certain road conditions • Steering maneuvers • Braking • Acceleration This system keeps the rear of your vehicle at a constant level by automatically adding air or releasing air from the springs.
Page 298: Transmission Operation
Driving WARNING: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Utility vehicles and trucks have larger tires and increased ground clearance, giving the vehicle a higher center of gravity than a passenger car.
Page 299 Driving 3. Remove the access plug on top of the steering column. 4. Using a flat-head screwdriver or similar tool, move the brake-shift interlock actuator spindle toward the left, apply the brake and shift the transmission into N (Neutral). 5. Start the vehicle. 6.
Page 300 Driving the off position, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly. Refer to Fuses and relays in the Roadside Emergencies chapter. If the fuse is not blown, perform the following procedure: 1.
Page 301 Driving engine while decelerating. This fuel economy benefit may be perceived as a light to medium braking sensation when removing your foot from the accelerator pedal. This vehicle is equipped with an Adaptive Transmission Shift Strategy. The Adaptive Transmission Shift Strategy offers the optimal transmission operation and shift quality.
Page 302 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Overdrive) with Tow/Haul Off The normal driving position for the best fuel economy. Transmission operates in gears one through six.
Page 303 Driving transmission is in the D (Overdrive) position; this engine braking will slow the vehicle and assist the driver in controlling the vehicle when descending a grade. Depending on driving conditions and load conditions, the transmission may downshift, slow the vehicle and control the vehicle speed when descending a hill, without the accelerator pedal being pressed.
Page 304: Reverse Sensing System
Driving If your vehicle gets stuck in mud or snow If your vehicle gets stuck in mud or snow, it may be rocked out by shifting between forward and reverse gears, stopping between shifts in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 305 Driving The system will assist the driver in detecting certain objects while the vehicle moves in reverse at speeds less than 6 mph (10 km/h). The system is not effective at speeds greater than 6 mph (10 km/h) and may not detect certain angular or moving objects.
Page 306 Driving Audible Warnings Distance to Object Warning Speed above 2.5 mph (4 km/h) up to 1.6 feet (.5 meters) Solid 1.6 feet (.5 meters) to 3.1 feet (1 meter) Fast beep 3.1 feet (1 meter) to 5.7 feet (1.8 meters) Medium/fast beep 5.7 feet (1.8 meters) to 9 feet Medium beep (2.8 meters)
Page 307: Reverse Camera
Driving REARVIEW CAMERA SYSTEM (IF EQUIPPED) The camera system located on the liftgate provides a video image, which appears in the rearview mirror or on the navigation screen (if equipped), of the area behind the vehicle. It adds assistance to the driver while reversing or reverse parking the vehicle.
Page 308 Driving Note: The default setting for the camera delay is off. Push the “Settings” button found on the navigation screen (if equipped) to set the camera delay feature to on or off. When towing, the camera system will only see what is being towed behind the vehicle;...
Page 309 Driving Servicing • If the image comes on while the vehicle is not in R (Reverse), have the system inspected by your authorized dealer. • If the image is not clear, then check if there is anything covering the lens such as dirt, mud, ice, snow, etc. If the image is still not clear after cleaning, have your system inspected by your authorized dealer.
Page 310 Driving Positions of the Control Trac system The Control Trac system functions in four modes: • 2H (2WD) delivers power to the rear wheels only. This is appropriate for normal on-road driving on dry pavement and provides best fuel economy. •...
Page 311 Driving WARNING: Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions. Avoid sharp turns or abrupt maneuvers in these vehicles.
Page 312 Driving AdvanceTrac with Roll Stability Control (RSC) Stability Enhancement System in this chapter) while operating in 2H, 4A or 4H while driving in deep sand, very deep snow or more strenuous off-road maneuvers. This will disable the engine management feature, allowing the vehicle to maintain full power and enhanced momentum through the obstacle.
Page 313 Driving • It often may be less risky to strike small objects, such as highway reflectors, with minor damage to your vehicle rather than attempt a sudden return to the pavement which could cause the vehicle to slide sideways out of control or roll over. Remember, your safety and the safety of others should be your primary concern.
Page 314 Driving Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency. Excessive steering will result in less vehicle control, not more.
Page 315 Driving Normal characteristics On some four–wheel drive models, the initial shift from two-wheel drive to four–wheel drive while the vehicle is moving can cause some momentary clunk and ratcheting sounds. This is the front drivetrain coming up to speed and engaging the front wheels, and is not cause for concern.
Page 316 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 317 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
Page 318 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 319: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 320: Hazard Flasher Control
Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.
Page 321: Fuel Pump Shut-Off Switch
Roadside Emergencies FUEL FUEL PUMP SHUT-OFF SWITCH RESET The fuel pump shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt. After a collision, if the engine cranks but does not start, the fuel pump shut-off switch may have been activated.
Page 322: Fuses And Relays
Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
Page 323 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located under the right-hand side of the instrument panel. To remove the trim panel for access to the fuse box, pull the panel toward you and swing it out away from the side and remove it.
Page 324 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Protected Circuits Location Rating Smart window #1 Driver side memory module FES, Audio rear seat controls, SDARS, SYNC Smart window #2 Keypad illumination, 3rd row seat enable, Brake Shift Interlock (BSI), SPDJB Turn signals Low beam headlamps (left)
Page 325 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Ignition switch Radio Instrument panel cluster Not used (Spare) Not used (Spare) Restraints control module Not used (Spare) Not used (Spare) Rear park assist, 4x4, rear video camera PATS transceiver Climate control Subwoofer/Amp (Audiophile radio) Radio Navigation system amplifier...
Page 326 Roadside Emergencies WARNING: To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and Specifications chapter. The high-current fuses are coded as follows: Fuse/Relay Fuse Amp...
Page 327 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 40A** Run/Start relay 30A ** Starter relay — Not used — Not used — Not used — Not used 30A** Trailer brake 60A** Rear air suspension relay feed 20A** 4x4 module 30A** Trailer tow battery charge 30A**...
Page 328 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 10A* TCM/PCM keep alive power — Not used 15A* Brake on/off switch 20A* Fuel pump relay 25A* Trailer tow stop turn relay feed — Not used — Not used 30A** Rear air suspension module —...
Page 329: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 20A** Auxiliary power point 20A** Auxiliary power point — Not used 30A** Driver power seat/DSM 20A* PCM – voltage power 1 20A* PCM – voltage power 2 15A* Voltage power 4, Ignition coils —...
Page 330 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 331 Roadside Emergencies • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability 3. Full-size dissimilar spare without label on wheel When driving with the full-size dissimilar spare tire/wheel, do not: •...
Page 332 Roadside Emergencies Stopping and securing the vehicle 1. Park on a level surface, activate the hazard flashers and set the parking brake. 2. Place the gearshift in P (Park) and turn the engine off. Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations: Item...
Page 333 Roadside Emergencies Removing the spare tire 1. Remove the jack handle and winch extension from the tray and assemble them. 2. Open the spare tire winch access plug in the bottom of the compartment for the jack and tools tray. 3.
Page 334 Roadside Emergencies WARNING: Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack and changing the wheel.
Page 335 Roadside Emergencies 5. Position the jack according to the jack locator arrows found on the frame and turn the jack handle and extension tool assembly clockwise. Note: Use the frame rail as the jacking location point, NOT the control arm. 6.
Page 336 Roadside Emergencies WARNING: Turn off the running boards (if equipped) before jacking or placing any object under the vehicle. Never place your hand between the extended running board and the vehicle. A moving running board may cause injury. • Never use the front or rear differential as a jacking point.
Page 337 Roadside Emergencies 13. Turn on the air suspension system (if equipped). Refer to Message center in the Driver Controls chapter for instructions on turning the air suspension system on. Stowing the spare tire 1. Lay the tire on the ground, near the rear of the vehicle, with the valve stem side facing up.
Page 338: Wheel Lug Nut Torque
M14 x 2.0 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 339: Jump Starting
Roadside Emergencies RUNNING OUT OF FUEL If you have run out of fuel and need to refill the vehicle with a portable fuel container, see Running out of fuel in the Maintenance and Specifications chapter for proper fuel filling method using a portable fuel container and the included fuel filler funnel.
Page 340 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the automatic transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 341 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 342 Roadside Emergencies 4. Make the final connection of the negative (-) cable to the jump starting stud located in the engine compartment, near the washer fluid bottle. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Note: Do not attach the negative (-) cable to fuel lines, engine rocker covers, the intake manifold or electrical components as grounding points.
Page 343 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 344 Roadside Emergencies Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the jump starting stud. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery.
Page 345 Roadside Emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 346: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Also, wrecker towing the vehicle by the frame-mounted tow hooks is not recommended or advised.
Page 347 Roadside Emergencies Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. Emergency towing In case of a roadside emergency with a disabled vehicle (without access...
Page 348: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 349 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 350 Dearborn, MI 48126 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step 2009 Expedition (exd) Owners Guide, 2nd Printing...
Page 351 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 352 United States and Canada, provided by a network of more than 4,600 participating authorized dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this...
Page 353 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 354: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 355: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 356 Cleaning • After polishing chrome bumpers, apply a coating of Motorcraft Premium Liquid Wax (ZC-53-A), available from your authorized dealer, or an equivalent quality product to help protect from environmental effects. WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
Page 357 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 358 Cleaning WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, water repellent coatings, tree sap, or other organic contamination;...
Page 359 Cleaning • Be certain to wash or wipe your hands clean if you have been in contact with certain products such as insect repellent and suntan lotion in order to avoid possible damage to the interior painted surfaces. • Do not use household or glass cleaners as these may damage the finish of the instrument panel, interior trim and cluster lens.
Page 360 Cleaning WARNING: Do not use cleaning solvents, bleach or dye on the vehicle’s safety belts, as these actions may weaken the belt webbing. WARNING: On vehicles equipped with seat-mounted airbags, do not use chemical solvents or strong detergents. Such products could contaminate the side-airbag system and affect performance of the side airbag in a collision.
Page 361 Cleaning LEATHER SEATS FOR THE KING RANCH EXPEDITION ONLY (IF EQUIPPED) Your vehicle is equipped with seating covered in premium, top-grain leather which is extremely durable, but still requires special care and maintenance in order to ensure longevity and comfort. Regular cleaning and conditioning will maintain the appearance of the leather.
Page 362 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 363 Cleaning Motorcraft Detail Wash (ZC-3-A) Motorcraft Dusting Cloth (ZC-24) Motorcraft Engine Shampoo and Degreaser (U.S. only) (ZC-20) Motorcraft Engine Shampoo (Canada only) (CXC-66-A) Motorcraft Multi-Purpose Cleaner (Canada only) (CXC-101) Motorcraft Premium Glass Cleaner (Canada only) (CXC-100) Motorcraft Premium Liquid Wax (ZC-53-A) Motorcraft Premium Windshield Washer Concentrate (U.S.
Page 364: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Customer Information Guide to find out which parts and services are covered.
Page 365 Maintenance and Specifications Working with the engine on 1. Set the parking brake and shift to P (Park). 2. Block the wheels. WARNING: To reduce the risk of vehicle damage and/or personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 366: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 5.4L V8 1. Windshield washer fluid reservoir 2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Power distribution box 8.
Page 367 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 368 Maintenance and Specifications CHANGING THE WIPER BLADES It is recommended that wiper blades are renewed before winter. To replace the wiper blades: 1. Fold back the wiper arm and position the wiper blade at right angles to the wiper arm. 2.
Page 369: Engine Oil
Maintenance and Specifications 4. To attach the new wiper to the wiper arm, align the cross pin and keyway (denoted with the arrows) and firmly press the wiper blade into the wiper arm until an audible snap is heard. ENGINE OIL Checking the engine oil Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil.
Page 370 Maintenance and Specifications • If the oil level is below this mark, engine oil must be added to raise the level within the normal operating range. • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. •...
Page 371 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance information. Ford production and Motorcraft replacement oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 372: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
Page 373 Maintenance and Specifications WARNING: Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.
Page 374: Engine Coolant
Maintenance and Specifications • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned. If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected.
Page 375 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 376 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, or DEX-COOL brand with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine...
Page 377 Maintenance and Specifications WARNING: To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Add the proper mixture of coolant and water to the cooling system by following these steps: 1.
Page 378 Maintenance and Specifications Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids.
Page 379 Maintenance and Specifications Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection. What you should know about fail-safe cooling If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred.
Page 380: Fuel Information
Maintenance and Specifications 3. If this is not possible, wait a short period for the engine to cool. 4. Check the coolant level and replenish if low. WARNING: Never remove the coolant reservoir cap while the engine is running or hot. 5.
Page 381 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuels such as gasoline and ethanol are highly toxic and if swallowed can cause death or permanent injury.
Page 382 Maintenance and Specifications Pure ethanol is the alcohol which is the intoxicating agent in liquor, beer and wine. It is distilled from the fermentation of plants such as field corn and sugar cane. When ethanol is produced for use in motor fuels, a small amount of gasoline is added to make it unfit for beverage use.
Page 383 Maintenance and Specifications Refueling WARNING: Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 384 Maintenance and Specifications Note: A fuel spillage concern may occur if overfilling the fuel tank. Do not overfill the tank to the point that the fuel is able to bypass the fuel filler nozzle. The overfilled fuel may run down the drain located below and in front of the fuel filler door.
Page 385 Maintenance and Specifications Choosing the right fuel Use only UNLEADED FUEL and FUEL ETHANOL (Ed75–Ed85). The use of leaded fuel is prohibited by law and could damage your vehicle. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based additives.
Page 386 3,000 miles (4,800 km). See scheduled maintenance information for more information. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 387 Maintenance and Specifications • The service engine soon indicator may come on. For more information on the service engine soon indicator, refer to Warning lights and chimes in the Instrument Cluster chapter. Refilling with a portable fuel container With the Easy Fuel™ “no cap” fuel system, use the following directions when filling from a portable fuel container: WARNING: Do not insert the nozzle of portable fuel containers or aftermarket funnels into the Easy Fuel™...
Page 388 Maintenance and Specifications ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy.
Page 389 Maintenance and Specifications Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers). 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
Page 390 Maintenance and Specifications • You may want to turn off the speed control in hilly terrain if unnecessary shifting between the top gears occurs. Unnecessary shifting of this type could result in reduced fuel economy. • Warming up a vehicle on cold mornings is not required and may reduce fuel economy.
Page 391 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 392 Maintenance and Specifications WARNING: Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 393 Maintenance and Specifications detected by the OBD-II may not have symptoms that are apparent, continued driving with the service engine soon indicator on can result in increased emissions, lower fuel economy, reduced engine and transmission smoothness, and lead to more costly repairs. Readiness for Inspection/Maintenance (I/M) testing Some state/provincial and local governments may have Inspection/Maintenance (I/M) programs to inspect the emission control...
Page 394 Maintenance and Specifications POWER STEERING FLUID Check the power steering fluid. Refer to scheduled maintenance information. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 395: Air Filter(S)
Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid The automatic transmission does not have a transmission fluid dipstick. Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, (i.e., if the transmission slips or shifts slowly) or if you notice some sign of fluid leakage.
Page 396 Maintenance and Specifications 2. Unlock the locking clip on the connector (connector shown from below for clarity), then squeeze and pull the connector off of the air outlet tube. 3. Clean the area around the air tube to air cover connection to prevent debris from entering the system and then loosen the bolt on the air tube clamp so the clamp is...
Page 397 Maintenance and Specifications 6. Remove the air filter element from the air filter housing. 7. Install a new air filter element. 8. Replace the air filter housing cover and secure the clamps. Be careful not to crimp the filter element edges between the air filter housing and cover and ensure that the tabs on the edge are properly aligned into the slots.
Page 398: Part Numbers
Long wheel base only Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 399: Maintenance Product Specifications And Capacities
Maintenance and Specifications 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 400 Maintenance and Specifications 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 401 Maintenance and Specifications 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 402 Maintenance and Specifications 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 403: Engine Data
Maintenance and Specifications ENGINE DATA Engine 5.4L V8 engine Cubic inches Fuel 87 octane or (E-85) Firing order 1-3-7-2-6-5-4-8 Ignition system Coil on plug Spark plug gap 0.039–0.043 inch (1.05 +/– 0.05mm) Compression ratio 9.85:1 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 404 Maintenance and Specifications Engine drivebelt routing IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
Page 405 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: 1.
Page 406 Maintenance and Specifications TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code Six-speed automatic (6R80 ) 2009 Expedition (exd) Owners Guide, 2nd Printing USA (fus)
Page 407: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 408 Accessories Peace of mind Mobile-Ease™ hands-free communication system Remote start Vehicle security systems Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 409: Index
Index Axle lubricant specifications ..399 refill capacities ......399 ABS (see Brakes) .....289 Accessory delay ......114 AdvanceTrac ......291 Battery ........372 Air cleaner filter ....395, 398 acid, treating emergencies ..372 Air suspension ......297 jumping a disabled battery ..339 description ......297 maintenance-free ....372 Airbag supplemental replacement, specifications ...398 restraint system ..217, 221, 223...
Page 410 Cruise control coolant ........374 (see Speed control) ....120 fail-safe cooling .......379 Customer Assistance ....319 idle speed control ....372 Ford Extended lubrication specifications ..399 Service Plan ......352 refill capacities ......399 Getting assistance outside the service points ......366 U.S. and Canada .....352 starting after a collision ..321...
Page 411 Index checking and adding ....369 fuel pump shut-off switch ..321 dipstick ........369 improving fuel economy ..388 filter, specifications ..371, 398 octane rating ...385, 403–404 recommendations ....371 quality ......385–386 refill capacities ......399 running out of fuel ..339, 386 specifications ......399 safety information relating to automotive fuels .....380 Event data recording ....7 Fuel - flex fuel vehicle...
Page 412 Index headlamps .........94 headlamps, flash to pass ..95 instrument panel, dimming ..96 Ignition .......282, 403–404 interior lamps ....98, 101 Illuminated visor mirror ...108 replacing bulbs ....101, 104 Infant seats LATCH anchors ......235 (see Safety seats) .....231 Liftgate ......154, 158, 170 Inspection/maintenance (I/M) Lights, warning and indicator ..12 testing ........393...
Page 413 Index Remote entry system ..168–169 illuminated entry ....173–174 locking/unlocking Octane rating ......385 doors ........169–170 Oil (see Engine oil) ....369 opening the trunk ....170 panic alarm ......171 replacement/additional transmitters ......173 Parking brake ......290 replacing the batteries ...172 Parts (see Motorcraft parts) ..398 Reverse camera ......307 Pedals (see Power adjustable Reverse sensing system ...304...
Page 414 Index cleaning ........361 climate control ......192 Tilt steering wheel ....107 Tire Pressure Monitoring heated ........200 System (TPMS) memory seat ....171, 190 Driving ........315 Tires, Wheels and Loading ..263 SecuriCode keyless entry Warning Displays ..12, 137, 150 system ........175 Tires ......248–249, 329 alignment ........257 SecuriLock passive anti-theft care ..........253...
Page 415 Index Water, Driving through .....318 Windows Vehicle Identification Number power ........112 (VIN) ..........405 rear wiper/washer ....107 Vehicle loading ......267 Windshield washer fluid and Ventilating your vehicle ...286 wipers ........106 checking and adding fluid ..367 liftgate reservoir .....367 replacing wiper blades ...368 Warning lights (see Lights) ..12 Wrecker towing ......346 Washer fluid ......367...
