DELTA DORE TYBOX 811 W RF User Manual

TYBOX 811 W RF
Wireless programmable thermostat
for heating control
User guide
Delta Dore hereby declares that the equipment complies
with the essential requirements and other relevant provisions
of the R&TTE Directive 1999/5/EC.
The EC declaration of conformity for this equipment is available,
on request, from:
"Technical info" department
DELTA DORE - Bonnemain - 35270 Combourg (France)
Email: info.techniques@deltadore.com
Because of changes in standards and equipment, the characteristics given in the
text and the illustrations in this document are not binding unless confirmed.
• Carefully read these instructions before
using this product.
• Do not attempt to repair the unit
yourself; an after-sales service is available.
9. Time setting
2
1
3
0
1
4
0
5
1. Presentation
This thermostat lets you put your heating system in
Comfort or Economy mode.
Position of
selector dial
Shutdown mode
Absence mode
Timer mode
Automatic mode
Continuous mode
3. Override
In automatic mode, the override function allows
you to switch from Comfort to Economy mode (or vice
versa) until the next programmed change.
Example: It is 15:30 and you would like to switch
to Comfort mode before the set time (17:00).
0h 6h 8h 15h30 17h
Current day programming
Press the override
button.
Override
in progress
To cancel the current
At 5pm, the programme will
override, press the button
once more.
6. Absence mode
This mode protects your home from
frost if you are absent for
several days.
Turn the dial to .
Sets the number of days (1 to 365).
For example, leaving on 1 March,
returning on 16 March: indicate
15 days of absence.
Automatic operation will resume at
midnight between 15 and 16 March.
Confirmation
Temperature setting
(5 °C to 15 °C)
Confirms and
begins
countdown
To change the current mode,
press the OK button again.
To cancel the current mode, turn
the dial.
10. Programming
Turn the selector dial to PROG.
7 The default programme is a Comfort period from
06:00 to 23.00.
1. Create your programme
The programme begins on day 1 at midnight.
Press the or buttons to create your
various Economy or Comfort periods.
23
Day
1st time slot
59
2. Confirm and copy the programme
Hold down the OK button for 3 seconds to confirm
and copy the programme you created to the next day.
OR
3. Confirm the programme
Press the OK button to confirm and go to program-
ming for the next day.
On the receiver:
- the green LED indicates that the product is
switched on,
- the red LED indicates the output status:
light on = ON, light off = OFF.
Change
mode
buttons
Selector
dial
Time setting
Programming
Temperature
setting
adjustment
4. Timer mode
This mode is used to choose a temperature
setting for a given amount of time.
Turn the dial to
23h 0h
To change the mode in
progress, press the OK button
again.
To cancel the timer mode in
progress, turn the selector dial.
return to the normal
schedule.
7. Shutdown mode
This mode shuts down your
heating system.
Turn the selector dial to
Room
temperature
Return to
AUTO mode
at the end of
the countdown
Example: Comfort from 6.00am to 8.00am and 5.00pm to 11.00pm
0h 6h
Sets a Comfort
period
Press up to 06:00
Sets an
Economy period
Press up to 08:00
Press up to 17:00
2. Automatic Mode
Turn the dial to AUTO.
Your thermostat will function according to the pro-
gramming.
Current day
Current day
programming
NOTE: depending on the configuration during
installation, your unit will continuously
display the temperature setting or the
room temperature.
To change these settings,
refer to the "Installation instructions" or contact our
customer service department or your installer.
5. Continuous mode
This mode is used to choose a temperature
setting that remains constant.
Turn the dial to
.
Sets the duration from 15 minutes to
72 hours (in increments of 15 min-
utes)
Temperature
Confirmation
Setting the temperature
(5 °C to 30 °C)
Confirmation
Return to
To exit the mode, turn the dial.
AUTO mode
at the end of
the countdown
8. Temperature setting
Turn the dial to
.
Configuration
menu access
button
(press and hold
for 5 seconds)
To exit the mode, turn the dial.
Depending on the system configuration (menu 1-08),
"conf" may be displayed for the
This temperature setting cannot be modified.
If this is the case, the Comfort temperature
setting can be adjusted on your heat emitter
(thermostatically controlled valve).
Check your programme
8h 17h 23h 0h
Press the
Comfort and Economy periods you have created.
Time for
selected
Programme
Press up to 23:00
Press OK to check the next day.
Exit programming mode
Turn the dial to another mode.
Press up to 00:00
NOTE: The programme can be weekly or daily
depending on the configuration during
installation. Likewise, this programming may be
done in increments of one hour, 30 minutes,
or 15 minutes.
To change these settings, refer to the "Installation
instructions" or contact our customer service
Copy and
department or your installer.
confirm or confirm
Current mode
Time
Override
Heating
Room
demand
temperature
Information
button
Display in automatic mode
.
Temperature
setting
selection
(5 °C to 30 °C).
setting
Confirmation
Temperature
setting
modification
.
Comfort temperature setting
(5 °C to 30 °C in increments
of 0.5 °C)
Confirmation
proceed to Economy
temperature setting
Economy temperature setting
(5 °C to 30 °C)
Confirmation
setting.
button repeatedly to check the
the
slot
Checking
the various
profile
or
periods
