Dismounting the drip tray sensor

Procedure

Water stop valve (if used)

Maintenance
Follow this procedure to dismount the drip tray sensor:
Step Action
1. Open the door, turn off the machine (main switch), unplug the power
supply plug.
2. Remove the waste bucket (1).
3. Remove the waste tray (2).
Loosen the screws (3).
4.
5. Remove the wires (4) and remove the drip tray sensor (5) by gently
pulling upwards.
3
1
The filter sieve of the water stop valve must be rinsed under running water
after 50,000 dispensings (more often when the water is hard). Replace it,
if necessary.
8
4
5
2
