Dismounting the cup platform

Procedure Follow this procedure to dismount the cup platform:
Step Action
1. Open the cabinet door, turn off machine (main switch), unplug the
power supply plug and close the water cock.
2. Remove the O-ring (1).
3. Pull the arm for cup platform
down (2).
4. Remove 2 screws (3).
Remove the complete cup
5.
platform.
Illustration
3
7
1
2
