Replacing the fluorescent tube (IN)

Replacement The procedure for replacing the fluorescent tube is as follows:
Step Action
1. Open the door, turn off the machine (main switch), unplug the power
supply plug and close the water cock.
2. Loosen screw on the inside of
the door.
3. Remove the lid.
4. Remove the advertising panel
by pushing it upwards.
5. Take hold of fluorescent tube and turn it 90° until poles are free in
grooves and remove it.
6. Mount new fluorescent tube.
7. Relocate parts in reverse order.
Illustration
