Wittenborg FB 5100 Service Manual page 57

List of items
Note
FB
Parts
1. Colour panel
2. Coin insert
Coin return motor
3.
4. Card reader
Cover, top with adhesive tape
5.
6. Outer housing for FB canister
7. Cover
8. Trim bracket
9. Door lock
Cup sensor
10.
11. Cover for inspection hole
12. Protective cover, dispensing area
13. Inner housing, dispensing area
14. Pot platform
Pot platform guide
15.
16. Door cover
Cup platform
17.
18. Coin chute
19. Cash box
20. Door switch
21. Coin mechanism
Reinforcement panel, SPC print board
22.
23. SPC print board
Display
24.
25. Selection panel, operating unit
If installed with a payment system, the machine is installed with either the
coin mechanism (and other coin components) or the card reader.
