Dismounting the temperature sensor

Procedure
Note
Follow this procedure to dismount the temperature sensor:
Step Action
1. Dismount the water tank.
2. Dismount the water tank lid.
Use a screw driver to hold the
3.
temperature sensor (1), then
disconnect the 2 flat plugs (to
keep the insulation from
breaking).
NB. The collar of the
temperature sensor has to be
pushed into the water tank, so
the collar is situated behind
the edge of the water tank.
4. Press the temperature sensor out of the water tank by turning it from
the inside.
Note: Check the sensor bushing for tears and brittleness, replace it if
necessary.
Always replace silicone gaskets.
If the temperature sensor is not properly electrically connected the heating
element will not be switched off as long as the machine is switched on
(boiling over).
Illustration
1
12
