Dismounting the freshbrew/instant water tank

Introduction
Procedure
The water tank only has to be dismounted, if it is going to be replaced by
a new one. All other parts than the water tank can be replaced, while the
water tank remains inside the machine.
Follow this procedure to dismount the water tank:
Step Action
1. Open the cabinet door, turn off machine (main switch), unplug the power
supply plug and close the water cock.
2. Drain water from the water tank.
3. Dismount the FB brewer unit (FB) or dismount left instant ingredient unit
(IN)
4. Dismount water tank cover.
5. Remove valves with hoses
and electrical connections (1).
6. Remove water inlet (2).
Remove the overflow hose (3).
7.
Illustration
2
1
3
9
