DVR-E - Model: DE200-00DP Contents Overview ..............................5 Product Key Features ........................... 6 Product Application Diagram ........................ 7 System Setup ............................... 8 Position the Unit ..........................8 Selecting Video Format......................... 8 Connecting Devices to the Unit......................8 Rear Panel Connections ........................9 General System Setup ..........................
Page 3
DVR-E - Model: DE200-00DP Caution and Preventive Tips • Take care not to drop the unit or subject the unit to major shocks or jolts. • Do not place this unit on an unstable stand, bracket or mount. • This unit is designed for indoor use only. Do not place the unit near water or in other extremely humid conditions.
Page 4
DVR-E - Model: DE200-00DP Important Information Before proceeding, please read and observe all instructions and warnings in this manual. Retain this manual with the original bill of sale for future reference and, if necessary, warranty service. When unpacking your unit, check for missing or damaged items. If any item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT.
Text Message (Short Message Service; SMS) sent to your mobile phone for alarm notice. • Dome control protocols: DynaColor, Pelco D, Pelco P,AD422 and Fastrax 2. Pre-program the OSD menu using a mouse connected to the USB port • User´s Manual...
DVR-E - Model: DE200-00DP Product Application Diagram Connect the unit with other devices as shown in the system diagram to complete a video surveillance solution. The figure shows also the expandability and flexibility of this digital recording and editing system.
DVR-E - Model: DE200-00DP System Setup The notices and introduction on system installation will be described particularly in this chapter. Please follow the description to operate the unit. In order to prevent the unit from data loss and system damage that caused by a sudden power...
DVR-E - Model: DE200-00DP Connecting Short-term Device If you plan to install any short-term devices to the DVR-E and use them as part of the unit system, such as USB CD-RW, USB Hard Disk Drive, etc. Make sure connecting those devices only during the unit is powered up.
Page 10
DVR-E - Model: DE200-00DP Camera Looping Plenty of BNC connectors are positioned on the real panel for looping out the video input. LAN Connector (RJ-45) The DVR-E is capable of networking. The LAN port opens the door of DVR-E to Ethernet where by the Internet.
Page 11
DVR-E - Model: DE200-00DP VGA Out A VGA output connector is offered for connecting to a VGA main monitor. The source of image of VGA and BNC main monitor are the same. RS-232C The unit provides a RS-232C communication port for sending and receiving signals.
DVR-E - Model: DE200-00DP General System Setup The DVR-E allows user to access some general operations through the front panel easily. The following subsections introduce the general operations of the unit. Front Panel Introcuction The unit’s front panel controls enable user to control the unit and preset the programmable functions.
DVR-E - Model: DE200-00DP Funcional Keys The DVR-E functional keys on the front panel for normal operation are described as follows. Dome Mode Menu Zoom/Enter Channels Call Play/Stop Freeze Search Direction Buttons Shuttle Jog CALL • In Live mode, press to enter call monitor control mode.
Page 14
DVR-E - Model: DE200-00DP • Press to cancel or exit from certain mode or OSD menu without changing the settings made previously. • This key allows you to enable the key lock function. If the password protection has been enabled, press ESC for two seconds to lock up the function of certain keys on the front panel, including PLAY, MENU, SEARCH, CALL and DOME.
Page 15
DVR-E - Model: DE200-00DP PLAY/ STOP Press this key to switch between live image and playback video. NOTE: The video of latest 5 ~ 10 minutes cannot be played back, because the video is still saved in the buffer. FREEZE •...
Page 16
DVR-E - Model: DE200-00DP JOG / SHUTLLE The jog/shuttle knob, shown as below figure, is a combination of a shuttle ring with an embedded jog disk, which is used to provide wide latitude in playback control. Note that the jog/shuttle knob is active only when the DVR-E unit has been in Playback mode.
DVR-E - Model: DE200-00DP Install HDD to The Unit There is a cartridge positioned on the front panel, and it allows user to install a swappable HDD. There will be two possible situations when you install a HDD into your DVR-E.
DVR-E - Model: DE200-00DP Setup Sequence This section introduce you how to view in sequence mode with both Main Monitor and Call Monitor, if connected. Sequence function can avoid manually backtracking and give more flexibility while surveillance. Sequence with Main Monitor Automatic sequence function can be used in any view mode.
DVR-E - Model: DE200-00DP • Press CHANNEL key to display the associated camera on call monitor. • Alternatively, press SEQ repeatedly to display the sequence of cameras previously programmed in Call Monitor Schedule menu. • Press ESC to return the front panel to Main monitor control mode.
DVR-E - Model: DE200-00DP Searching by Event “Event List” allows you to search wanted video by event. The Event List is displayed as below figure: Follow these steps to search event video through Event List: • Press SEARCH to enter the Search menu.
DVR-E - Model: DE200-00DP ezBurn Introdution Built with the ezBurn technology, ezBurn function provides users the easier way to export desired video with CD-RW built in or to an external device connected, such as an USB ThumbDrive ® TWO keys (SEARCH and CALL) and THREE touches are all you need for completing the export.
DVR-E - Model: DE200-00DP Audio & Video Edit The Audio &Video edit menu enables the administrator to export recorded video with digital signature to a USB ThumbDrive , a CD-RW or to DVD+RW drive. Administrator's password is ® required to edit audio and video.
Page 23
DVR-E - Model: DE200-00DP Select Export Edit File to Device The available external devices for exporting video will be listed by name and free size in Select Device menu. The Select Device menu displays as follows. The DVR-E only supports EXT3 file system. If you connect an external HDD to the unit, ensure the format of HDD is EXT3.
DVR-E - Model: DE200-00DP Type of Edit Data Exported The item is used to select exporting video type. The options are <Normal> (export normal video only), <Event> (export event video only) and <Both> (export both normal and event video). NOTE: If you want to export event video only, then please set the “From” and “To” items at the same date and time.
DVR-E - Model: DE200-00DP 5.3 Dome Control The DVR-E allows user to control a dome camera by the front panel. In Live mode, user can press CHANNEL key to display the desired dome camera in full view. To enter Dome Control mode, press the DOME key and press channel key 2 to display the hint screen;...
DVR-E - Model: DE200-00DP Dome Controlling Key The function keys used in Dome Control are described as follows. Set/Go Toggle Hint Iris Focus Zoom Enter/ Preset Screen Open Near Auto Iris Focus Zoom Pan/Tilt Close Set / Go Preset This key is used to enter the Dome Preset menu to set up certain position as a preset and go to the predetermined preset positions for viewing.
DVR-E - Model: DE200-00DP Iris Close Use to close the Iris on the dome camera. Focus Far Use to focus the selected dome camera far. Zoom Out Use to zoom the dome camera out. This function is for user to choose the viewing area, more or less of it.
Page 28
DVR-E - Model: DE200-00DP • Press 1 to access the Set/Go Preset function. The Dome Preset menu is displayed. Dome Preset Index Set Preset Go Preset • Use UP / DOWN keys to select the desired preset number from the menu.
DVR-E - Model: DE200-00DP Edit The Audio and Video Recorder-Editor model DE200-00DP allows the user to edit the audio and the image of a video. For to do of the audio edition, the user should execute the connections showed in the figure in the Appendix A – Audio Edit Connection.
DVR-E - Model: DE200-00DP Appendix A: Audio and Ed Audio and Edit Connection The image above shows the conection The image above shows the conections that can use to audio edit in the t in the DE200-00DP. Channel Channel L, R or Both...
