Page 1: Quick Start Guide
Quick Start Guide XBee-PRO PKG-U™ USB RF Modem Introduction Range Test Setup Range Test Completion Create long range wireless data links in minutes! MaxStream www.maxstream.net © 2006 MaxStream, Inc. All rights reserved. MD0028 [2006.04.25]... -
Page 2: Range Test Setup
Install X-CTU Software Double-click "setup_X-CTU.exe" file and follow prompts of the installation screens. This file is located on the MaxStream CD and under the 'Software' section of the following web page: www.maxstream.net/helpdesk/download.php The X-CTU Software interface is divided into the four following tabs: •... -
Page 3: Hardware Setup
Range Test Setup (continued) Hardware Setup The XBee-PRO USB RF Modem will be referred to as the “BASE”. The XBee-PRO RS-232 RF Modem will be referred to as the “REMOTE”. 1. After installing the X-CTU Software and USB drivers [opposite page], connect the BASE RF modem (XBee-PRO USB) to the PC using a standard USB cable. - Page 4 Determine the range capabilities of the XBee-PRO RF Modems Range Test 1. Launch the X-CTU Software: (Start --> Programs --> MaxStream --> X-CTU) Under the “PC Settings” tab [Figure 3], select the PC serial com port from the list that will be used to connect to the BASE RF modem.
