CS4070 SCANNER
PRODUCT REFERENCE
GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS4070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Symbol CS4070

Summary of Contents for Symbol CS4070

  • Page 1 CS4070 SCANNER PRODUCT REFERENCE GUIDE...
  • Page 3 CS4070 SCANNER PRODUCT REFERENCE GUIDE MN000762A01 Revision A August 2014...
  • Page 4 CS4070 Scanner Product Reference Guide No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems. The material in this manual is subject to change without notice.

  • Page 5: Revision History

    Revision History Changes to the original manual are listed below: Change Date Description -01 Rev A 8/2014 Initial release...
  • Page 6 CS4070 Scanner Product Reference Guide...

  • Page 7: Table Of Contents

    Batch Connection ........................1-5 Bluetooth Connection: Development Options ................1-5 Pairing ............................1-6 Unpairing ..........................1-7 Deleting the CS4070 from the Device List ................1-7 Configuring the Scanner ........................ 1-8 123Scan2 ..........................1-8 Parameter Bar Codes and Config.ini ..................1-8 Updating Scanner Firmware ....................
  • Page 8 CS4070 Scanner Product Reference Guide Chapter 2: Scanning Introduction ............................ 2-1 Scanning ............................2-1 Deleting Bar Codes ........................2-2 Transmitting Bar Code Data to Host ....................2-2 Transferring Data from a Batch Scanner ................. 2-2 Transferring Data from a Bluetooth Scanner ................2-2 User Interface Definitions ......................
  • Page 9 Table of Contents Send Versions ..........................3-25 Firmware Version ........................3-25 Scan Engine Version ....................... 3-25 Dongle Version ........................3-25 Chapter 4: Symbologies Introduction ............................ 4-1 Scanning Sequence Examples ...................... 4-1 Errors While Scanning ........................4-2 Symbology Default Parameters ..................... 4-2 Enable/Disable All Code Types .....................
  • Page 10 CS4070 Scanner Product Reference Guide Code 39 Check Digit Verification ..................... 4-34 Transmit Code 39 Check Digit ....................4-34 Code 39 Full ASCII Conversion ....................4-35 Code 39 Security Level ......................4-36 Code 93 ............................4-37 Enable/Disable Code 93 ......................4-37 Set Lengths for Code 93 ......................
  • Page 11 Table of Contents Composite ............................4-67 Composite CC-C ........................4-67 Composite CC-A/B ........................4-67 Composite TLC-39 ........................4-68 UPC Composite Mode ......................4-68 GS1-128 Emulation Mode for UCC/EAN Composite Codes ............ 4-69 Postal Codes ..........................4-70 US Postnet ..........................4-70 US Planet ..........................
  • Page 12 Appendix A: Standard Default Parameters Appendix B: Accessories Overview ............................B-1 Accessories Summary ........................B-2 Single-Slot CS4070 Charging Cradle with Spare Battery Charger ..........B-3 Battery Charging Indications ....................B-4 Bluetooth Connectivity ......................B-4 Eight-Slot CS4070 Charging Cradle ....................B-5 Battery Charging Indications ....................
  • Page 13 Table of Contents Appendix E: Sample Bar Codes UPC-A ............................E-1 UPC-E ............................E-1 UPC-E1 ............................E-2 EAN-13 ............................E-2 EAN-8 ............................E-2 Code 39 ............................E-2 Trioptic Code 39 ..........................E-3 Code 93 ............................E-3 Code 11 ............................E-3 Codabar ............................
  • Page 14 CS4070 Scanner Product Reference Guide...

  • Page 15: About This Guide

    ABOUT THIS GUIDE Introduction The CS4070 Scanner Product Reference Guide provides general instructions for setting up, operating, maintaining, and troubleshooting the scanner. Configurations The CS4070 scanner is available in the following configurations: • CS4070SR - Standard range, cordless Bluetooth •...

  • Page 16: Chapter Descriptions

    • Appendix B, Accessories provides information on CS4070 accessories, which provide a variety of product support capabilities. • Appendix C, Bluetooth Connection Examples provides pairing examples for several host devices.

  • Page 17: Notational Conventions

    Feature/Option Indicates Default NOTE This symbol indicates something of special interest or importance to the reader. Failure to read the note will not result in physical harm to the reader, equipment or data. This symbol indicates that if this information is ignored, the possiblity of data or material damage may CAUTION occur.

  • Page 18: Service Information

    • Software type and version number Symbol Technologies responds to calls by e-mail, telephone or fax within the time limits set forth in service agreements. If your problem cannot be solved by Symbol Technologies support, you may need to return your equipment for servicing and will be given specific directions.

  • Page 19: Chapter 1 Getting Started

    CHAPTER 1 GETTING STARTED Introduction The CS4070 Scanner captures and stores bar codes for a variety of uses, and transmits bar code data to a host via USB connection or Bluetooth. Bluetooth Key / LED Micro USB Port Battery Level Key...

  • Page 20: Unpacking The Scanner

    Lithium-ion battery • Micro USB cable • Quick Start Guide. Inspect the equipment. If any equipment is missing or damaged, contact Symbol Technologies support. See page xvi for contact information. Inserting and Removing the Battery Inserting the Battery Before using the scanner, insert the lithium-ion battery provided with the device.

  • Page 21: Removing The Battery

    Getting Started 1 - 3 Removing the Battery To remove the battery, pull the release latch upward with one finger, and use a finger from your other hand to pull back on the indent in the bottom of the battery housing. The battery rotates about the bottom edge and the latch end of the battery pops up, enabling you to lift it out from the sides.

  • Page 22: Charging Batteries

    1 - 4 CS4070 Scanner Product Reference Guide Charging Batteries Before using the CS4070 for the first time, charge the battery using the micro USB cable or a cradle until the green charge status LED lights. See Table 2-1 on page 2-3 for charge status indications.

  • Page 23: Connecting To The Host Computer

    Connecting to the Host Computer Batch Connection The micro USB cable enables communication between the CS4070 and a PC, and charges the battery in the CS4070. NOTE To enter batch scanning mode, the scanner cannot be paired to a Bluetooth host.

  • Page 24: Pairing

    NOTE Bluetooth pairing suspends temporarily while charging via a USB cable. Disconnecting the cable re-establishes Bluetooth pairing. NOTE When pairing with an iPad, press the delete key (- ) on the CS4070 to toggle the virtual keyboard on and off.

  • Page 25: Unpairing

    Unpair on page 3-8. This allows the scanner to pair to a different host device. NOTE To enter batch scanning mode, the scanner cannot be paired to a Bluetooth host (applies to CS4070 model only). Deleting the CS4070 from the Device List...

  • Page 26: Configuring The Scanner

    To configure the scanner via 123Scan2, use this utility to generate a 2D bar code with the desired configuration options. Scan the bar code to configure the scanner with these options. Note that the CS4070 does not support 1D configuration bar codes. See Chapter 5, 123Scan2.

  • Page 27: Editing The Configuration File

    Editing the Configuration File Use a text editor such as Notepad to set configuration values in the editable text file in the Config.ini folder on the CS4070. Table 1-1 lists the programmable contents of the file. \Parameters NOTE If you make errors while editing the Config.ini file, the file LOG.TXT is created in the \Parameters folder.
  • Page 28 1 - 10 CS4070 Scanner Product Reference Guide Config.ini File Content (Continued) Table 1-1 Name Description Values Default CountryKeyboardType Country keyboard code North_American North_American Windows_Belgian_ French Windows_French Windows_German Windows_Canadian Windows_Spanish Windows_Italian Windows_Swedish Windows_UK Windows_Japan Windows_Brazil DateFormat Date format 0= MM/DD/YY...
  • Page 29 Getting Started 1 - 11 Config.ini File Content (Continued) Table 1-1 Name Description Values Default ScanParam Any scanner parameter. Multiple entries are Variable allowed. Sent after reset or whenever scanner is powered. For example: ScanParam=0xf0,0x00,0x01 ScanParam=0xee,0x01 ScanParam=0x38,0x00 Separator Separator character Byte ',’...
  • Page 30 1 - 12 CS4070 Scanner Product Reference Guide...

  • Page 31: Chapter 2: Scanning

    CHAPTER 2 SCANNING Introduction This chapter provides instructions for how to scan bar codes and send the data to a host. Beeper and LED definitions are also included. Scanning Chapter 1, Getting Started to install and program the scanner. To scan: Aim the scanner at the bar code.

  • Page 32: Deleting Bar Codes

    2 - 2 CS4070 Scanner Product Reference Guide NOTE Hold down the + button for 10 seconds to toggle the beeper functionality on and off. Deleting Bar Codes In batch mode, to delete a bar code aim the scanner at the bar code and press the delete ( - ) button.

  • Page 33: User Interface Definitions

    Scanning 2 - 3 When the radio loses connection, the Bluetooth LED stops its slow, consistent blinking and the beeper emits a short high low beep. The Bluetooth LED blinks at a faster rate for a period of time while the device attempts to reestablish pairing with the host, and when it returns within range the device repairs.
  • Page 34 2 - 4 CS4070 Scanner Product Reference Guide LED Indications (Continued) Table 2-1 Function Performed User Action LED Feedback Other Toggle data protection on or off Press & hold both None (when enabled) scan (+) and delete (-) buttons for 6 seconds...

  • Page 35: Beeper Indications

    Scanning 2 - 5 Beeper Indications Beeper Indications Table 2-2 Function Performed Beeper Feedback Other Successful bar code scan Short high tone Imager off Successful bar code deletion Short medium tone Imager off Unsuccessful deletion - item doesn't Long short short Imager off exist (when in batch mode) Successful clear all...
  • Page 36 2 - 6 CS4070 Scanner Product Reference Guide...

  • Page 37: Chapter 3 User Preferences

    CHAPTER 3 USER PREFERENCES Introduction This chapter describes each user preference feature and provides the programming bar codes for selecting these features for the scanner. The scanner ships with the settings shown in the User Preferences Default Table on page 3-2 (also see Appendix A, Standard Default Parameters for all host device and miscellaneous scanner defaults).

  • Page 38: User Preferences Default Parameters

    3 - 2 CS4070 Scanner Product Reference Guide User Preferences Default Parameters Table 3-1 lists the defaults for user preference parameters. To change any option, scan the appropriate bar code(s) provided in this chapter. NOTE See Appendix A, Standard Default Parameters for all default parameters.
  • Page 39 User Preferences 3 - 3 User Preferences Default Table (Continued) Table 3-1 Page Parameter Parameter Number Factory Default Number PDF Prioritization Timeout 200 ms 3-20 Data Options Transmit Code ID Character None 3-21 Prefix Value 99, 105 7013 <CR><LF> 3-22 Suffix 1 Value 98, 104 7013 <CR><LF>...

  • Page 40: Reset Factory Defaults

    3 - 4 CS4070 Scanner Product Reference Guide Reset Factory Defaults To reset the scanner to factory defaults, scan the following bar code. This rebuilds the configuration file from program memory. Reset Factory Defaults...

  • Page 41: Set Date And Time

    User Preferences 3 - 5 Set Date and Time NOTE You must scan the configuration bar codes to set the time and date stamp on the scanner. The time and date can not be set or edited in the config.ini file. This setting persists for three months if the scanner is not used.
  • Page 42 3 - 6 CS4070 Scanner Product Reference Guide Numeric Bar Codes for Date and Time Settings Enter...

  • Page 43: Bluetooth Options

    User Preferences 3 - 7 Bluetooth Options Master/Slave Set Up The scanner can be set up as a master or slave. When the scanner is set up as a slave, it is discoverable and connectable to other devices. When the scanner is set up as a master, the Bluetooth address of the remote device to which a connection is requested is required.

  • Page 44: Bluetooth Unpair

    Bluetooth SSI Profile • - allows the scanner to connect to a serial port on iOS devices such as iPad and Bluetooth MFi SPP iPhone. • - allows bi-directional (command and control) communication between the CS4070 Bluetooth MFi SSI and iOS devices.

  • Page 45: Clear Data

    User Preferences 3 - 9 Bluetooth Profile (continued) *Bluetooth HID Profile Bluetooth SPP Bluetooth SSI Profile Bluetooth MFi_SPP Bluetooth MFi_SSI Clear Data Scan the following bar code to clear all batch bar code data on the scanner. This deletes the BarcodeFile.txt from the scanner.

  • Page 46: Auto-Reconnect

    3 - 10 CS4070 Scanner Product Reference Guide Auto-reconnect When auto-reconnect is enabled, the scanner automatically tries to reconnect to a remote device when a disconnection occurs that is due to the radio losing communication. This can happen if the scanner goes out of range with the remote device, or if the remote device powers down.

  • Page 47: Connection Interval

    User Preferences 3 - 11 Connection Interval Select the time period that the scanner attempts to connect or auto-reconnect to another device. *30 Seconds 1 Minute 5 Minutes HID Security Parameter # 911 Scan one of the following bar codes to set HID security as follows: •...

  • Page 48: Radio Output Power

    Radio Output Power The CS4070 uses a Class 1 Bluetooth radio with a transmission range of up to 100m. To place the radio in a Class 2 operating mode to restrict the transmission range to 10m and reduce the effect of the radio on neighboring wireless systems, scan the Bluetooth Class 2 bar code.

  • Page 49: User Preference Settings

    User Preferences 3 - 13 User Preference Settings Parameter Bar Code Scanning Parameter # 236 To disable the decoding of parameter bar codes, including the Set Defaults parameter bar codes, scan the Disable Parameter Scanning bar code below. To enable decoding of parameter bar codes, scan Enable Parameter Scanning.

  • Page 50: Beeper Volume

    3 - 14 CS4070 Scanner Product Reference Guide Beeper Volume Parameter # 140 To select a decode beep volume, scan the appropriate bar code. Low Volume Medium Volume High Volume...

  • Page 51: Beeper Tone

    User Preferences 3 - 15 Beeper Tone Parameter # 145 To select a decode beep frequency (tone), scan the appropriate bar code. Low Frequency Medium Frequency High Frequency Mute Beeper Scan the bar code to mute the beeper. Mute Beeper Mute Beeper Do Not Mute Beeper...

  • Page 52: Decode Pager Motor (Cs4070Hc Only)

    3 - 16 CS4070 Scanner Product Reference Guide Decode Pager Motor (CS4070HC only) Parameter # 613 The scanner includes a pager motor which, when enabled, vibrates the scanner for a period of time when a successful decode occurs. Scan a bar code below to enable or disable the pager motor. If enabled, scan the appropriate bar code to set...
  • Page 53 User Preferences 3 - 17 Decode Pager Motor Duration (continued) 250 msec (25) 300 msec (30) 400 msec (40) 500 msec (50) 600 msec (60) 750 msec (75)

  • Page 54: Picklist Mode

    3 - 18 CS4070 Scanner Product Reference Guide Picklist Mode Parameter # 402 Picklist mode enables the scanner to decode only bar codes aligned under the center of the aiming pattern. Select one of the following picklist modes: • Disabled Always - Picklist mode is always disabled.

  • Page 55: Mirrored Image

    User Preferences 3 - 19 Mirrored Image Parameter # 624 Enable this to scan images in reverse, or mirrored, as if seen through a mirror. This mode is useful in applications requiring scanning through a mirror and using symbologies that do not decode in reverse. Enabling this mode when using snapshot, video, or video viewfinder mode transmits images as mirrored images.

  • Page 56: Pdf Prioritization

    (e.g., on a US driver's license), and if successful reports this only. If it does not decode (can not find) a PDF417 symbol, it reports the 1D symbol after the timeout. The 1D symbol must be in the device’s field of view for the scanner to report it.

  • Page 57: Data Options

    In addition to any single character prefix already selected, the Code ID character is inserted between the prefix and the decoded symbol. Select no Code ID character, a Symbol Code ID character, or an AIM Code ID character. For Code ID Characters, see Appendix D, Programming Reference.

  • Page 58: Prefix/Suffix Values

    3 - 22 CS4070 Scanner Product Reference Guide Prefix/Suffix Values Key Category Parameter # P = 99, S1 = 98, S2 = 100 Decimal Value Parameter # P = 105, S1 = 104, S2 = 106 You can append a prefix and/or one or two suffixes to scan data for use in data editing. To set a value for a prefix or suffix, scan a four-digit number (i.e., four bar codes from...

  • Page 59: Scan Data Transmission Format

    User Preferences 3 - 23 Scan Data Transmission Format Parameter # 235 To change the scan data format, scan one of the following eight bar codes corresponding to the desired format. NOTE If using this parameter do not use ADF rules to set the prefix/suffix To set values for the prefix and/or suffix, see Prefix/Suffix Values on page 3-22.

  • Page 60: Transmit "No Read" Message

    NR when a successful decode does not occur before trigger release or during the timeout period. Disable this to send nothing to the host if a symbol does not decode. NOTE If you enable Transmit No Read, and also enable Symbol Code ID Character or AIM Code ID Character Transmit Code ID Character on page 3-21, the scanner appends the code ID for Code 39 to the NR message.

  • Page 61: Send Versions

    User Preferences 3 - 25 Send Versions Firmware Version Scan the following bar code to send the firmware version to the host. Firmware Version Scan Engine Version Scan the following bar code to send the scan engine version to the host. Scan Engine Version Dongle Version Scan the following bar code to send the dongle version to the host.
  • Page 62 3 - 26 CS4070 Scanner Product Reference Guide...

  • Page 63: Chapter 4 Symbologies

    CHAPTER 4 SYMBOLOGIES Introduction This chapter describes symbology features and provides the programming bar codes for selecting these features for the scanner. Before programming, follow the instructions in Chapter 1, Getting Started. The scanner ships with the settings in Table 4-1 on page 4-2 (also see Appendix A, Standard Default Parameters...

  • Page 64: Errors While Scanning

    4 - 2 CS4070 Scanner Product Reference Guide Errors While Scanning Unless otherwise specified, to correct an error during a scanning sequence, re-scan the correct parameter. Symbology Default Parameters Table 4-1 lists the defaults for all symbologies parameters. To change any option, scan the appropriate bar code(s) in this chapter.

  • Page 65: Trioptic Code 39

    Symbologies 4 - 3 Symbology Parameter Defaults (Continued) Table 4-1 Parameter Page Parameter Default Number Number Convert UPC-E to A Disable 4-21 Convert UPC-E1 to A Disable 4-21 EAN-8/JAN-8 Extend Disable 4-22 Bookland ISBN Format ISBN-10 4-22 UCC Coupon Extended Code Disable 4-23 Coupon Report...

  • Page 66: Codabar

    4 - 4 CS4070 Scanner Product Reference Guide Symbology Parameter Defaults (Continued) Table 4-1 Parameter Page Parameter Default Number Number Code 11 Code 11 Disable 4-39 Set Lengths for Code 11 28, 29 4 to 55 4-39 Code 11 Check Digit Verification...
  • Page 67 Symbologies 4 - 5 Symbology Parameter Defaults (Continued) Table 4-1 Parameter Page Parameter Default Number Number Matrix 2 of 5 Matrix 2 of 5 Disable 4-59 Matrix 2 of 5 Lengths 619, 620 4 to 55 4-59 Matrix 2 of 5 Check Digit Disable 4-61 Transmit Matrix 2 of 5 Check Digit...

  • Page 68: Data Matrix

    4 - 6 CS4070 Scanner Product Reference Guide Symbology Parameter Defaults (Continued) Table 4-1 Parameter Page Parameter Default Number Number USPS 4CB/One Code/Intelligent Mail Disable 4-75 UPU FICS Postal Disable 4-76 2D Symbologies PDF417 Enable 4-77 MicroPDF417 Disable 4-77 Code 128 Emulation...

  • Page 69: Enable/Disable All Code Types

    Symbologies 4 - 7 Enable/Disable All Code Types To disable all symbologies, scan Disable All Code Types below. This is useful when enabling only a few code types. Scan Enable All Code Types turn on (enable) all code types. This is useful when you want to read all codes, or when you want to disable only a few code types.

  • Page 70: Upc/Ean

    4 - 8 CS4070 Scanner Product Reference Guide UPC/EAN Enable/Disable UPC-A Parameter # 1 To enable or disable UPC-A, scan the appropriate bar code below Enable UPC-A Disable UPC-A Enable/Disable UPC-E Parameter # 2 To enable or disable UPC-E, scan the appropriate bar code below...

  • Page 71: Enable/Disable Upc-E1

    Symbologies 4 - 9 Enable/Disable UPC-E1 Parameter # 12 UPC-E1 is disabled by default. To enable or disable UPC-E1, scan the appropriate bar code below. NOTE UPC-E1 is not a UCC (Uniform Code Council) approved symbology. Enable UPC-E1 Disable UPC-E1 Enable/Disable EAN-8/JAN-8 Parameter # 4 To enable or disable EAN-8/JAN-8, scan the appropriate bar code below...

  • Page 72: Enable/Disable Ean-13/Jan-13

    4 - 10 CS4070 Scanner Product Reference Guide Enable/Disable EAN-13/JAN-13 Parameter # 3 To enable or disable EAN-13/JAN-13, scan the appropriate bar code below Enable EAN-13/JAN-13 Disable EAN-13/JAN-13 Enable/Disable Bookland EAN Parameter # 83 To enable or disable Bookland EAN, scan the appropriate bar code below.

  • Page 73: Decode Upc/Ean/Jan Supplementals

    If you select one of the following Supplemental Mode options, the scanner immediately transmits EAN-13 bar codes starting with that prefix that have supplemental characters. If the symbol does not have a supplemental, the scanner must decode the bar code the number of times set via...
  • Page 74 4 - 12 CS4070 Scanner Product Reference Guide Decode UPC/EAN/JAN Supplementals (continued) Decode UPC/EAN/JAN Only With Supplementals Ignore Supplementals Autodiscriminate UPC/EAN/JAN Supplementals Enable 378/379 Supplemental Mode Enable 978/979 Supplemental Mode Enable 977 Supplemental Mode...
  • Page 75 Symbologies 4 - 13 Decode UPC/EAN/JAN Supplementals (continued) Enable 414/419/434/439 Supplemental Mode Enable 491 Supplemental Mode Enable Smart Supplemental Mode Supplemental User-Programmable Type 1 Supplemental User-Programmable Type 1 and 2 (10) Smart Supplemental Plus User-Programmable 1 (11) Smart Supplemental Plus User-Programmable 1 and 2 (12)

  • Page 76: User-Programmable Supplementals

    If you selected Autodiscriminate UPC/EAN/JAN Supplementals, this option adjusts the number of times to decode a symbol without supplementals before transmission. The range is from two to thirty times. Five or above is recommended when decoding a mix of UPC/EAN/JAN symbols with and without supplementals. The default is 10.

  • Page 77: Upc/Ean/Jan Supplemental Aim Id Format

    Symbologies 4 - 15 UPC/EAN/JAN Supplemental AIM ID Format Parameter # 672 Select an output format when reporting UPC/EAN/JAN bar codes with Supplementals with Transmit Code ID Character on page 3-21 set to AIM Code ID Character • - transmit UPC/EAN with supplementals with separate AIM IDs but one transmission, i.e.: Separate ]E<0 or 4><data>]E<1 or 2>[supplemental data] •...

  • Page 78: Transmit Upc-A Check Digit

    Parameter # 40 The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-A check digit. It is always verified to guarantee the integrity of the data.

  • Page 79: Transmit Upc-E1 Check Digit

    Parameter # 42 The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-E1 check digit. It is always verified to guarantee the integrity of the data.

  • Page 80: Upc-A Preamble

    UPC-A Preamble Parameter # 34 Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-A preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.

  • Page 81: Upc-E Preamble

    UPC-E Preamble Parameter # 35 Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.

  • Page 82: Upc-E1 Preamble

    UPC-E1 Preamble Parameter # 36 Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E1 preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble. Select the appropriate option to match the host system.

  • Page 83: Convert Upc-E To Upc-A

    Symbologies 4 - 21 Convert UPC-E to UPC-A Parameter # 37 Enable this to convert UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, the data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit).

  • Page 84: Ean-8/Jan-8 Extend

    4 - 22 CS4070 Scanner Product Reference Guide EAN-8/JAN-8 Extend Parameter # 39 Enable this parameter to add five leading zeros to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Disable this to transmit EAN-8 symbols as is.

  • Page 85: Ucc Coupon Extended Code

    Symbologies 4 - 23 UCC Coupon Extended Code Parameter # 85 Enable this parameter to decode UPC-A bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’, and UPC-A/GS1-128 Coupon Codes. UPCA, EAN-13, and GS1-128 must be enabled to scan all types of Coupon Codes.

  • Page 86: Coupon Report

    4 - 24 CS4070 Scanner Product Reference Guide Coupon Report Parameter # 730 Select an option to determine which type of coupon format to support. • Select Old Coupon Format to support UPC-A/GS1-128 and EAN-13/GS1-128. • Select New Coupon Format as an interim format to support UPC-A/GS1-DataBar and EAN-13/GS1-DataBar.

  • Page 87: Code 128

    Cancel on page F-3. • Length Within Range - Select this option to decode a Code 128 symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode Code 128 symbols containing between 4 and 12 characters, first scan Code 128 - Length Within Range.

  • Page 88: Set Lengths For Code 128

    4 - 26 CS4070 Scanner Product Reference Guide Set Lengths for Code 128 (continued) Code 128 - One Discrete Length Code 128 - Two Discrete Lengths Code 128 - Length Within Range Code 128 - Any Length...

  • Page 89: Enable/Disable Gs1-128 (Formerly Ucc/Ean-128)

    Symbologies 4 - 27 Enable/Disable GS1-128 (formerly UCC/EAN-128) Parameter # 14 To enable or disable GS1-128, scan the appropriate bar code below. Enable GS1-128 Disable GS1-128 Enable/Disable ISBT 128 Parameter # 84 ISBT 128 is a variant of Code 128 used in the blood bank industry. Scan a bar code below to enable or disable ISBT 128.

  • Page 90: Isbt Concatenation

    • If you select Autodiscriminate ISBT Concatenation, the scanner decodes and concatenates pairs of ISBT codes immediately. If only a single ISBT symbol is present, the scanner must decode the symbol the number of times set via ISBT Concatenation Redundancy on page 4-29 before transmitting its data to confirm that there is no additional ISBT symbol.

  • Page 91: Check Isbt Table

    If you set ISBT Concatenation to Autodiscriminate, use this parameter to set the number of times the scanner must decode an ISBT symbol before determining that there is no additional symbol. Scan the bar code below, then scan two numeric bar codes in...

  • Page 92: Code 128 Security Level

    4 - 30 CS4070 Scanner Product Reference Guide Code 128 Security Level Parameter # 751 Code 128 bar codes are vulnerable to misdecodes, particularly when Code 128 Lengths is set to Any Length. The scanner offers four levels of decode security for Code 128 bar codes. There is an inverse relationship between security and scanner aggressiveness.

  • Page 93: Code 39

    Symbologies 4 - 31 Code 39 Enable/Disable Code 39 Parameter # 0 To enable or disable Code 39, scan the appropriate bar code below. Enable Code 39 Disable Code 39 Enable/Disable Trioptic Code 39 Parameter # 13 Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges. Trioptic Code 39 symbols always contain six characters.

  • Page 94: Convert Code 39 To Code 32

    4 - 32 CS4070 Scanner Product Reference Guide Convert Code 39 to Code 32 Parameter # 86 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32.

  • Page 95: Set Lengths For Code 39

    Discrete Lengths, then scan 0, 2, 1, and then 4. To correct an error or change the selection, scan Cancel on page F-3. • Length Within Range - Select this option to decode a Code 39 symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode Code 39 symbols containing between 4 and 12 characters, first scan Code 39 - Length Within Range.

  • Page 96: Code 39 Check Digit Verification

    4 - 34 CS4070 Scanner Product Reference Guide Code 39 Check Digit Verification Parameter # 48 Enable this feature to check the integrity of all Code 39 symbols to verify that the data complies with specified check digit algorithm. Only Code 39 symbols which include a modulo 43 check digit are decoded. Enable this feature if the Code 39 symbols contain a Modulo 43 check digit.

  • Page 97: Code 39 Full Ascii Conversion

    Symbologies 4 - 35 Code 39 Full ASCII Conversion Parameter # 17 Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set. To enable or disable Code 39 Full ASCII, scan the appropriate bar code below. Enable Code 39 Full ASCII Disable Code 39 Full ASCII NOTE You cannot enable Trioptic Code 39 and Code 39 Full ASCII simultaneously.

  • Page 98: Code 39 Security Level

    4 - 36 CS4070 Scanner Product Reference Guide Code 39 Security Level Parameter # 750 The scanner offers four levels of decode security for Code 39 bar codes. There is an inverse relationship between security and scanner aggressiveness. Increasing the level of security can reduce scanning aggressiveness, so select only the level of security necessary.

  • Page 99: Code 93

    Cancel on page F-3. • Length Within Range - Select this option to decode a Code 93 symbol with a specific length range. Select lengths using the numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode Code 93 symbols containing between 4 and 12 characters, first scan Code 93 - Length Within Range.

  • Page 100: Set Lengths For Code 93

    4 - 38 CS4070 Scanner Product Reference Guide Set Lengths for Code 93 (continued) Code 93 - One Discrete Length Code 93 - Two Discrete Lengths Code 93 - Length Within Range Code 93 - Any Length...

  • Page 101: Code 11

    Cancel on page F-3. • Length Within Range - Select this option to decode a Code 11 symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode Code 11 symbols containing between 4 and 12 characters, first scan Code 11 - Length Within Range.
  • Page 102 4 - 40 CS4070 Scanner Product Reference Guide Set Lengths for Code 11 (continued) Code 11 - One Discrete Length Code 11 - Two Discrete Lengths Code 11 - Length Within Range Code 11 - Any Length...

  • Page 103: Code 11 Check Digit Verification

    Symbologies 4 - 41 Code 11 Check Digit Verification Parameter # 52 This feature allows the scanner to check the integrity of all Code 11 symbols to verify that the data complies with the specified check digit algorithm. This selects the check digit mechanism for the decoded Code 11 bar code.

  • Page 104: Transmit Code 11 Check Digits

    4 - 42 CS4070 Scanner Product Reference Guide Transmit Code 11 Check Digits Parameter # 47 This feature selects whether or not to transmit the Code 11 check digit(s). Transmit Code 11 Check Digit(s) (Enable) Do Not Transmit Code 11 Check Digit(s) (Disable)

  • Page 105: Interleaved 2 Of 5 (Itf)

    Cancel on page F-3. • Length Within Range - Select this option to decode an I 2 of 5 symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode I 2 of 5 symbols containing between 4 and 12 characters, first scan I 2 of 5 - Length Within Range.

  • Page 106: Set Lengths For Interleaved 2 Of 5

    4 - 44 CS4070 Scanner Product Reference Guide Set Lengths for Interleaved 2 of 5 (continued) I 2 of 5 - One Discrete Length I 2 of 5 - Two Discrete Lengths I 2 of 5 - Length Within Range...

  • Page 107: I 2 Of 5 Check Digit Verification

    Symbologies 4 - 45 I 2 of 5 Check Digit Verification Parameter # 49 Enable this feature to check the integrity of all I 2 of 5 symbols to verify the data complies with either the specified Uniform Symbology Specification (USS), or the Optical Product Code Council (OPCC) check digit algorithm.

  • Page 108: Transmit I 2 Of 5 Check Digit

    4 - 46 CS4070 Scanner Product Reference Guide Transmit I 2 of 5 Check Digit Parameter # 44 Scan the appropriate bar code below to transmit I 2 of 5 data with or without the check digit. Transmit I 2 of 5 Check Digit (Enable)

  • Page 109: I 2 Of 5 Security Level

    Symbologies 4 - 47 I 2 of 5 Security Level Parameter # 1121 Interleaved 2 of 5 bar codes are vulnerable to misdecodes, particularly when I 2 of 5 Lengths is set to Any Length. The scanner offers four levels of decode security for Interleaved 2 of 5 bar codes. There is an inverse relationship between security and scanner aggressiveness.

  • Page 110: Discrete 2 Of 5 (Dtf)

    Cancel on page F-3. • Length Within Range - Select this option to decode a D 2 of 5 symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode D 2 of 5 symbols containing between 4 and 12 characters, first scan D 2 of 5 - Length Within Range.

  • Page 111: Set Lengths For Discrete 2 Of 5

    Symbologies 4 - 49 Set Lengths for Discrete 2 of 5 (continued) D 2 of 5 - One Discrete Length D 2 of 5 - Two Discrete Lengths D 2 of 5 - Length Within Range D 2 of 5 - Any Length...

  • Page 112: Codabar (Nw - 7)

    Cancel on page F-3. • Length Within Range - Select this option to decode a Codabar symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode Codabar symbols containing between 4 and 12 characters, first scan Codabar - Length Within Range.
  • Page 113 Symbologies 4 - 51 Set Lengths for Codabar (continued) Codabar - One Discrete Length Codabar - Two Discrete Lengths Codabar - Length Within Range Codabar - Any Length...

  • Page 114: Clsi Editing

    Enable this parameter to strip the start and stop characters and insert a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Enable this feature if the host system requires this data format. NOTE Symbol length does not include start and stop characters.

  • Page 115: Codabar Upper Or Lower Case Start/Stop Characters Detection

    Symbologies 4 - 53 Codabar Upper or Lower Case Start/Stop Characters Detection Parameter # 855 Select whether to detect upper case or lower case Codabar start/stop characters. Lower Case Upper Case...

  • Page 116: Msi

    Cancel on page F-3. • Length Within Range - Select this option to decode a MSI symbol with a specific length range. Select lengths using numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode MSI symbols containing between 4 and 12 characters, first scan MSI - Length Within Range. Then scan 0, 4, 1, and 2 (enter a leading zero for single digit numbers).
  • Page 117 Symbologies 4 - 55 Set Lengths for MSI (continued) NOTE Due to the construction of the MSI symbology, it is possible for a scan line covering only a portion of the code to transmit as a complete scan, yielding less data than is encoded in the bar code. To prevent this, select specific lengths (MSI - One Discrete Length, Two Discrete Lengths) for MSI applications.

  • Page 118: Msi Check Digits

    4 - 56 CS4070 Scanner Product Reference Guide MSI Check Digits Parameter # 50 With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits bar code to enable verification of the second check digit.
  • Page 119 Symbologies 4 - 57 MSI Check Digit Algorithm Parameter # 51 Two algorithms are possible for the verification of the second MSI check digit. Select the bar code below corresponding to the algorithm used to encode the check digit. MOD 10/MOD 11 MOD 10/MOD 10...

  • Page 120: Chinese 2 Of 5

    4 - 58 CS4070 Scanner Product Reference Guide Chinese 2 of 5 Enable/Disable Chinese 2 of 5 Parameter # 408 To enable or disable Chinese 2 of 5, scan the appropriate bar code below. Enable Chinese 2 of 5 Disable Chinese 2 of 5...

  • Page 121: Matrix 2 Of 5

    Cancel on page F-3. • Length Within Range - Select this option to decode a Matrix 2 of 5 symbol with a specific length range. Select lengths using the numeric bar codes in Appendix F, Numeric Bar Codes. For example, to decode Matrix 2 of 5 symbols containing between 4 and 12 characters, first scan Matrix 2 of 5 - Length Within Range.

  • Page 122: Set Lengths For Matrix 2 Of 5

    4 - 60 CS4070 Scanner Product Reference Guide Set Lengths for Matrix 2 of 5 (continued) Matrix 2 of 5 - One Discrete Length Matrix 2 of 5 - Two Discrete Lengths Matrix 2 of 5 - Length Within Range...

  • Page 123: Matrix 2 Of 5 Check Digit

    Parameter # 622 The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the Matrix 2 of 5 check digit.

  • Page 124: Korean 3 Of 5

    4 - 62 CS4070 Scanner Product Reference Guide Korean 3 of 5 Enable/Disable Korean 3 of 5 Parameter # 581 To enable or disable Korean 3 of 5, scan the appropriate bar code below. NOTE The length for Korean 3 of 5 is fixed at 6.

  • Page 125: Inverse 1D

    Symbologies 4 - 63 Inverse 1D Parameter # 586 This parameter sets the 1D inverse scanner setting. Options are: • - the scanner decodes regular 1D bar codes only. Regular Only • - the scanner decodes inverse 1D bar codes only. Inverse Only •...

  • Page 126: Gs1 Databar

    4 - 64 CS4070 Scanner Product Reference Guide GS1 DataBar The variants of GS1 DataBar are DataBar-14, DataBar Expanded, and DataBar Limited. The limited and expanded versions have stacked variants. Scan the appropriate bar codes to enable or disable each variant of GS1 DataBar.

  • Page 127: Gs1 Databar Expanded

    This parameter only applies to GS1 DataBar-14 and GS1 DataBar Limited symbols not decoded as part of a Composite symbol. Enable this to strip the leading '010' from DataBar-14 and DataBar Limited symbols encoding a single zero as the first digit, and report the bar code as EAN-13.

  • Page 128: Gs1 Databar Limited Security Level

    4 - 66 CS4070 Scanner Product Reference Guide GS1 DataBar Limited Security Level Parameter # 728 The scanner offers four levels of decode security for GS1 DataBar Limited bar codes. There is an inverse relationship between security and scanner aggressiveness. Increasing the level of security may result in reduced aggressiveness in scanning, so choose only that level of security necessary.

  • Page 129: Composite

    Symbologies 4 - 67 Composite Composite CC-C Parameter # 341 Scan a bar code below to enable or disable Composite bar codes of type CC-C. Enable CC-C Disable CC-C Composite CC-A/B Parameter # 342 Scan a bar code below to enable or disable Composite bar codes of type CC-A/B. Enable CC-A/B Disable CC-A/B...

  • Page 130: Composite Tlc-39

    UPC Composite Mode Parameter # 344 Select an option for linking UPC symbols with a 2D symbol during transmission as if they were one symbol: • Select UPC Never Linked to transmit UPC bar codes regardless of whether a 2D symbol is detected.

  • Page 131: Gs1-128 Emulation Mode For Ucc/Ean Composite Codes

    Symbologies 4 - 69 GS1-128 Emulation Mode for UCC/EAN Composite Codes Parameter # 427 Select whether to enable or disable this mode. Enable GS1-128 Emulation Mode for UCC/EAN Composite Codes Disable GS1-128 Emulation Mode for UCC/EAN Composite Codes...

  • Page 132: Postal Codes

    4 - 70 CS4070 Scanner Product Reference Guide Postal Codes US Postnet Parameter # 89 To enable or disable US Postnet, scan the appropriate bar code below. Enable US Postnet Disable US Postnet US Planet Parameter # 90 To enable or disable US Planet, scan the appropriate bar code below.

  • Page 133: Transmit Us Postal Check Digit

    Symbologies 4 - 71 Transmit US Postal Check Digit Parameter # 95 Select whether to transmit US Postal data, which includes both US Postnet and US Planet, with or without the check digit. Transmit US Postal Check Digit Do Not Transmit US Postal Check Digit UK Postal Parameter # 91 To enable or disable UK Postal, scan the appropriate bar code below.

  • Page 134: Transmit Uk Postal Check Digit

    4 - 72 CS4070 Scanner Product Reference Guide Transmit UK Postal Check Digit Parameter # 96 Select whether to transmit UK Postal data with or without the check digit. Transmit UK Postal Check Digit Do Not Transmit UK Postal Check Digit...

  • Page 135: Australia Post

    Symbologies 4 - 73 Australia Post Parameter # 291 To enable or disable Australia Post, scan the appropriate bar code below. Enable Australia Post Disable Australia Post...

  • Page 136: Australia Post Format

    4 - 74 CS4070 Scanner Product Reference Guide Australia Post Format Parameter # 718 To select one of the following formats for Australia Post, scan the appropriate bar code below: • (or Smart mode) - Attempt to decode the Customer Information Field using the N and C Autodiscriminate Encoding Tables.

  • Page 137: Netherlands Kix Code

    Symbologies 4 - 75 Netherlands KIX Code Parameter # 326 To enable or disable Netherlands KIX Code, scan the appropriate bar code below. Enable Netherlands KIX Code Disable Netherlands KIX Code USPS 4CB/One Code/Intelligent Mail Parameter # 592 To enable or disable USPS 4CB/One Code/Intelligent Mail, scan the appropriate bar code below. Enable USPS 4CB/One Code/Intelligent Mail Disable USPS 4CB/One Code/Intelligent Mail...

  • Page 138: Upu Fics Postal

    4 - 76 CS4070 Scanner Product Reference Guide UPU FICS Postal Parameter # 611 To enable or disable UPU FICS Postal, scan the appropriate bar code below. Enable UPU FICS Postal Disable UPU FICS Postal...

  • Page 139: 2D Symbologies

    Symbologies 4 - 77 2D Symbologies Enable/Disable PDF417 Parameter # 15 To enable or disable PDF417, scan the appropriate bar code below. Enable PDF417 Disable PDF417 Enable/Disable MicroPDF417 Parameter # 227 To enable or disable MicroPDF417, scan the appropriate bar code below. Enable MicroPDF417 Disable MicroPDF417...

  • Page 140: Code 128 Emulation

    4 - 78 CS4070 Scanner Product Reference Guide Code 128 Emulation Parameter # 123 Enable this parameter to transmit data from certain MicroPDF417 symbols as Code 128. AIM Code ID Character (1) on page 3-21 must be selected for this parameter to work.

  • Page 141: Data Matrix

    Symbologies 4 - 79 Data Matrix Parameter # 292 To enable or disable Data Matrix, scan the appropriate bar code below. Enable Data Matrix Disable Data Matrix Data Matrix Inverse Parameter # 588 This parameter sets the Data Matrix inverse scanner setting. Options are: •...

  • Page 142: Decode Mirror Images (Data Matrix Only)

    4 - 80 CS4070 Scanner Product Reference Guide Decode Mirror Images (Data Matrix Only) Parameter # 537 Select an option for decoding mirror image Data Matrix bar codes: • Always - decode only Data Matrix bar codes that are mirror images •...

  • Page 143: Maxicode

    Symbologies 4 - 81 Maxicode Parameter # 294 To enable or disable Maxicode, scan the appropriate bar code below. Enable Maxicode Disable Maxicode QR Code Parameter # 293 To enable or disable QR Code, scan the appropriate bar code below. Enable QR Code Disable QR Code...

  • Page 144: Qr Inverse

    4 - 82 CS4070 Scanner Product Reference Guide QR Inverse Parameter # 587 This parameter sets the QR inverse scanner setting. Options are: • - the scanner decodes regular QR bar codes only. Regular Only • - the scanner decodes inverse QR bar codes only.

  • Page 145: Aztec

    Symbologies 4 - 83 Aztec Parameter # 574 To enable or disable Aztec, scan the appropriate bar code below. Enable Aztec Disable Aztec Aztec Inverse Parameter # 589 This parameter sets the Aztec inverse scanner setting. Options are: • - the scanner decodes regular Aztec bar codes only. Regular Only •...

  • Page 146: Han Xin

    4 - 84 CS4070 Scanner Product Reference Guide Han Xin Parameter # 1167 To enable or disable Han Xin, scan the appropriate bar code below. Enable Han Xin Disable Han Xin Han Xin Inverse Parameter # 1168 Select a Han Xin inverse scanner setting: •...

  • Page 147: Symbology-Specific Security Levels

    Symbologies 4 - 85 Symbology-Specific Security Levels Redundancy Level Parameter # 78 The scanner offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality. As redundancy levels increase, the scanner’s aggressiveness decreases. Select the redundancy level appropriate for the bar code quality. Redundancy Level 1 The following code types must be successfully read twice before being decoded: Redundancy Level 1 Codes...
  • Page 148 4 - 86 CS4070 Scanner Product Reference Guide Redundancy Level 4 The following code types must be successfully read three times before being decoded: Redundancy Level 4 Codes Table 4-5 Code Type Code Length Redundancy Level 1 Redundancy Level 2...

  • Page 149: Bi-Directional Redundancy

    Symbologies 4 - 87 Bi-directional Redundancy Parameter # 67 This parameter is only valid when a Redundancy Level is enabled. When this parameter is enabled, the scanner must scan a bar code successfully in both directions (forward and reverse) before decoding. Enable Bi-directional Redundancy Disable Bi-directional Redundancy...

  • Page 150: Security Level

    4 - 88 CS4070 Scanner Product Reference Guide Security Level Parameter # 77 The scanner offers four levels of decode security for delta bar codes, which include the Code 128 family, UPC/EAN, and Code 93. Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and scanner aggressiveness, so choose only that level of security necessary for any given application.

  • Page 151: Intercharacter Gap Size

    The Code 39 and Codabar symbologies have an intercharacter gap that is typically quite small. Due to various bar code-printing technologies, this gap can grow larger than the maximum size allowed, preventing the scanner from decoding the symbol. If this problem occurs, scan the Large Intercharacter Gaps parameter to tolerate these out-of-specification bar codes.
  • Page 152 4 - 90 CS4070 Scanner Product Reference Guide...

  • Page 153: Chapter 5 123Scan2

    CHAPTER 5 123SCAN2 Introduction 123Scan² is an easy to use, PC-based software tool that enables rapid customized setup of Symbol Technologies scanners. 123Scan² uses a wizard tool to guide users through a streamlined set up process. Settings are saved in a configuration file that can be distributed via e-mail, electronically downloaded via a USB cable, or used to generate a sheet of scannable programming bar codes.

  • Page 154: 123Scan2 Requirements

    5 - 2 CS4070 Scanner Product Reference Guide 123Scan Requirements • Host computer with Windows XP SP2 or Windows 7 • Scanner • USB cable. For more information on123Scan², go to: http://www.motorolasolutions.com/123Scan For a 1 minute tour of 123Scan², go to: http://www.motorolasolutions.com/scannerhowtovideos...

  • Page 155: Chapter 6 Advanced Data Formatting

    Use ADF to edit scan data to suit requirements. Implement ADF by scanning a related series of bar codes which program the scanner with ADF rules. The scanner stores ADF rules in persistent memory and retains them through a battery replacement. The CS4070 supports all ADF rules except: • LED rules, beeper rules, pause duration •...
  • Page 156 6 - 2 CS4070 Scanner Product Reference Guide...

  • Page 157: Chapter 7 Maintenance And Technical Specifications

    CHAPTER 7 MAINTENANCE AND TECHNICAL SPECIFICATIONS Introduction This chapter provides suggested scanner maintenance, troubleshooting, and technical specifications. Maintenance Cleaning the scan window is the only maintenance required. A dirty window can affect scanning accuracy. • Do not allow any abrasive material to touch the window. •...
  • Page 158 Before contacting support, view the sysinfo.txt file in the \Parameters folder on the CS4070. This indicates the device’s serial number, software version, Bluetooth version, and scan engine version and is useful when troubleshooting the scanner.
  • Page 159 Maintenance and Technical Specifications 7 - 3 Technical Specifications For the latest technical specification information for the CS4070, visit: http://www.motorolasolutions.com/CS4070...
  • Page 160 7 - 4 CS4070 Scanner Product Reference Guide...

  • Page 161: Appendix A Standard Default Parameters

    APPENDIX A STANDARD DEFAULT PARAMETERS Default Table Table A-1 Parameter Number Page Parameter Factory Default (Hex) Number Reset Factory Defaults Set Date Set Time Cancel Date and Time Settings Bluetooth Options Pairing Bar Code Format Bluetooth Unpair Bluetooth Profile Clear Data Auto-reconnect Disable 3-10...
  • Page 162 A - 2 CS4070 Scanner Product Reference Guide Default Table (Continued) Table A-1 Parameter Number Page Parameter Factory Default (Hex) Number Decode Pager Motor Duration 200 msec 3-16 Picklist Mode Disabled Always 3-18 Fuzzy 1D Processing Enable 3-18 Mirrored Image...
  • Page 163 Standard Default Parameters A - 3 Default Table (Continued) Table A-1 Parameter Number Page Parameter Factory Default (Hex) Number UPC/EAN/JAN Supplemental Redundancy 4-14 Decode UPC/EAN/JAN Supplemental AIM ID Combined 4-15 Transmit UPC-A Check Digit Enable 4-16 Transmit UPC-E Check Digit Enable 4-16 Transmit UPC-E1 Check Digit...
  • Page 164 A - 4 CS4070 Scanner Product Reference Guide Default Table (Continued) Table A-1 Parameter Number Page Parameter Factory Default (Hex) Number Code 39 Check Digit Verification Disable 4-34 Transmit Code 39 Check Digit Disable 4-34 Code 39 Full ASCII Conversion...
  • Page 165 Standard Default Parameters A - 5 Default Table (Continued) Table A-1 Parameter Number Page Parameter Factory Default (Hex) Number Set Length(s) for MSI 30, 31 4 to 55 4-54 MSI Check Digits 4-56 Transmit MSI Check Digit Disable 4-56 MSI Check Digit Algorithm Mod 10/Mod 10 4-57 Chinese 2 of 5...
  • Page 166 A - 6 CS4070 Scanner Product Reference Guide Default Table (Continued) Table A-1 Parameter Number Page Parameter Factory Default (Hex) Number UK Postal Disable 4-71 Transmit UK Postal Check Digit Enable 4-72 Japan Postal Disable 4-72 Australia Post Disable 4-73...

  • Page 167: Appendix B Accessories

    APPENDIX B ACCESSORIES Overview CS4070 accessories provide a variety of product support capabilities. Accessories include a micro USB cable, cradles, spare battery charger, wall mounts, and lanyard. See Table B-1 for a full list of accessories and descriptions.

  • Page 168: Accessories Summary

    B - 2 CS4070 Scanner Product Reference Guide Accessories Summary Table B-1lists the accessories available for the CS4070. CS4070 Accessories Table B-1 Accessory Part Number Description Page Cradles and Battery Accessories 1-slot terminal and spare CHS5000-1000CR Single-slot cradle for charging one CS4070...

  • Page 169: Single-Slot Cs4070 Charging Cradle With Spare Battery Charger

    • Charges one spare battery. • NOTE Use only genuine Symbol Technologies batteries (p/n 82-83172-01) with CS4070 devices and charging accessories. Use only an approved power supply 50-14000-147R output rated 12 Vdc and minimum 3.3 A with AC line cord 50-16000-182R. The power supply is certified to EN60950-1 with SELV outputs. Use of an alternative power supply invalidates any approval given to this device and may be dangerous.

  • Page 170: Battery Charging Indications

    Solid Green Spare battery is fully charged Blinking Red Charging error No battery inserted Cradle Power Solid Green Power on Power off Bluetooth Connectivity When a CS4070 is inserted into a charging cradle, it maintains Bluetooth communication over the wireless network.

  • Page 171: Eight-Slot Cs4070 Charging Cradle

    B - 5 Eight-Slot CS4070 Charging Cradle The eight-slot CS4070 charging cradle provides 5.1 VDC power for operating the device and charges the CS4070 battery in the device. NOTE Use only genuine Symbol Technologies batteries (p/n 82-83172-01) with CS4070 devices and charging accessories.

  • Page 172: Battery Charging Indications

    CS4070 Scanner Product Reference Guide Battery Charging Indications The eight-slot cradle charges up to eight CS4070 devices simultaneously. The LEDs on each CS4070 indicate the charging status of the battery in the device. See Table 2-1 on page 2-3 for status indications.

  • Page 173: Eight-Slot Spare Battery Charger

    Eight-Slot Spare Battery Charger This section describes how to use the eight-slot spare battery charger to charge up to eight spare batteries. NOTE Use only genuine Symbol Technologies batteries (p/n 82-83172-01) with CS4070 devices and charging accessories. Use only an approved power supply KT-14000-148R output rated 12 Vdc and minimum 3.3 A with AC line cord 23844-00-00.

  • Page 174: Battery Charging Indications

    B - 8 CS4070 Scanner Product Reference Guide Insert the spare battery into a spare battery charging well and gently press down on the battery to ensure proper contact. Spare Batteries Spare Battery Charging LED(s) Cradle Power LED Spare Battery Installation...

  • Page 175: Wall Mount Brackets

    B - 9 Wall Mount Brackets Two optional wall mount brackets are available for mounting a CS4070 battery charger and/or a spare battery charger to a wall. The KT-102376-01R wall mount bracket is used to mount one SAC5000-8000CR (eight-slot) battery •...
  • Page 176 B - 10 CS4070 Scanner Product Reference Guide Mounting Instructions NOTE Connect an approved power supply to the cradle prior to attaching the cradle to the wall mount bracket. Eight-Slot Spare Battery Charger on page B-7 for power supply information.

  • Page 177: Kt-102375-01R Bracket

    Figure B-8 KT-102375-01R Bracket The KT-102375-01R bracket mounts one CHS5000-8000CR (eight-slot) CS4070 charger, or two SAC5000-8000CR (eight-slot) spare battery chargers to a wall. Use the wall mount brackets as a template to mark the locations of the four mounting screws.
  • Page 178 Eight-Slot CS4070 Charging Cradle on page B-5 for power supply information. When mounting one eight-slot CS4070 battery charger (CHS5000-8000CR), slide the four bracket mounting tabs into the receptacles on the bottom of the charger as shown in Figure B-9. Ensure the screw holes in the bracket flanges align with the screw holes in the cradle.
  • Page 179 Accessories B - 13 Screw the bracket to the cradle(s). CHS5000-8000CR: Screw the two supplied .5” Phillips screws into the two bracket flanges and tighten until the cradle is securely attached to the bracket (as shown in drawing A, Figure B-11).

  • Page 180: Bluetooth To Usb Hid Dongle

    B - 14 CS4070 Scanner Product Reference Guide Bluetooth to USB HID Dongle The Bluetooth to USB HID dongle pairs the scanner with an HID host simply by scanning the bar code on the dongle. The dongle is available for the CS4070HC only, and has the following features: USB bus powered •...

  • Page 181: Pairing To A Usb Hid Device

    Connect the RJ45 cable to the dongle RJ45 port, and the other end of the cable to a USB port on the HID device. Connecting Dongle to HID Device Figure B-14 Using the CS4070, scan the bar code on the dongle to pair the scanner with the HID device.

  • Page 182: Lanyard With Clip

    B - 16 CS4070 Scanner Product Reference Guide Lanyard with Clip For ease of use, attach the CS4070 to the lanyard with clip in order to wear the device around the neck as shown in Figure B-15. Wearing Lanyard Figure B-15...

  • Page 183: Appendix C Bluetooth Connection Examples

    EXAMPLES Overview Pairing the CS4070 with a host device typically requires holding the Bluetooth button to place the scanner in discoverable mode, then entering a pairing PIN. To enter the PIN on the CS4070, use the PIN Entry Bar Codes on page C-9.

  • Page 184: Ipad Pairing Example

    Bluetooth Devices Figure C-1 Select the CS4070 from the list. In HID mode, the CS4070 doesn't have to scan a PIN code to authenticate pairing. The scanner beeps to indicate it has paired with the iPad, and the iPad displays Connected next to the CS4070 device name.

  • Page 185: Android Pairing Example

    Samsung Available Devices List Figure C-3 Select the CS4070 from the list. A window prompts for a PIN generated by the Samsung Galaxy Tab 2. Samsung Pairing Request Window Figure C-4...

  • Page 186: Accessing The Android Phone Keyboard

    C - 4 CS4070 Scanner Product Reference Guide With the CS4070, scan the PIN using the PIN Entry Bar Codes on page C-9 and scan Enter. The scanner beeps to indicate it has paired with the Samsung Galaxy Tab 2, and the Samsung Galaxy Tab 2 displays below the CS4070 device name.

  • Page 187: Windows 7 Pairing Example

    Add a device Devices serial number. Device List Figure C-6 Select the CS4070 from the list. A window prompts for a PIN generated by the HP NB (WIN7 OS). PIN Prompt Figure C-7...
  • Page 188 PIN Entry Bar Codes on page C-9 and scan Enter. The scanner beeps to indicate it has paired with the HP NB (WIN7 OS), and the HP NB displays a success window. CS4070 Connected Figure C-8 Ensure the CS4070 device icon displays in devices list.

  • Page 189: Windows 8 Pairing Example

    Settings icon. Tap Change PC Settings to invoke the PC settings list, and tap PC and devices. Tap Bluetooth. If Bluetooth is not enabled, swipe to enable it. The CS4070 appears in the Devices list, indicated by its model name.
  • Page 190 C - 8 CS4070 Scanner Product Reference Guide With the CS4070, scan the PIN using the PIN Entry Bar Codes on page C-9 and scan Enter. The scanner beeps to indicate it has paired with the Lenovo ThinkPad Tablet, and the Lenovo ThinkPad Tablet displays Connected below the CS4070 device name.

  • Page 191: Pin Entry Bar Codes

    Bluetooth Connection Examples C - 9 PIN Entry Bar Codes Use the following bar codes for PIN entry for Bluetooth connection.
  • Page 192 C - 10 CS4070 Scanner Product Reference Guide PIN Entry Bar Codes (continued) Enter Cancel...

  • Page 193: Appendix D Programming Reference

    APPENDIX D PROGRAMMING REFERENCE Code Type IDs Bar Code Type Identifiers Table D-1 SDL Code Type ID Bar Code Type Code 39 Codabar Code 128 Discrete (Standard) 2 of 5 IATA Interleaved 2 of 5 Code 93 UPC-A UPC-E0 EAN-8 EAN-13 Code 11 Code 49...
  • Page 194 D - 2 CS4070 Scanner Product Reference Guide Bar Code Type Identifiers (Continued) Table D-1 SDL Code Type ID Bar Code Type Code 16K Code 39 Full ASCII UPC-D Code 39 Trioptic Bookland Coupon Code NW-7 ISBT-128 Micro PDF DataMatrix...
  • Page 195 Programming Reference D - 3 Bar Code Type Identifiers (Continued) Table D-1 SDL Code Type ID Bar Code Type UPU 4State ISSN Scanlet CueCode Matrix 2 of 5 UPC-A + 2 Supplemental UPC-E0 + 2 Supplemental EAN-8 + 2 Supplemental EAN-13 + 2 Supplemental UPC-E1 + 2 Supplemental CCA EAN-128...

  • Page 196: Code Type Ids

    D - 4 CS4070 Scanner Product Reference Guide Bar Code Type Identifiers (Continued) Table D-1 SDL Code Type ID Bar Code Type UPC-A + 5 supplemental UPC-E0 + 5 supplemental EAN-8 + 5 supplemental EAN-13 + 5 supplemental UPC-E1 + 5 Supplemental...
  • Page 197 Programming Reference D - 5 Symbol Code Characters (Continued) Table D-2 Code Character Code Type Korean 3 of 5 ISSN EAN, PDF417, Macro PDF417, Micro PDF417 Aztec, Aztec Rune Data Matrix QR Code, MicroQR Maxicode US Postnet US Planet Japan Postal...

  • Page 198: Aim Code Identifiers

    D - 6 CS4070 Scanner Product Reference Guide AIM Code Identifiers Each AIM Code Identifier contains the three-character string ]cm where: = Flag Character (ASCII 93) c = Code Character (see Table D-3) m = Modifier Character (see Table D-4)
  • Page 199 No option specified at this time. Always transmit 0. Example: A Trioptic bar code 412356 is transmitted as ]X0412356 Code 128 Standard data packet, no Function code 1 in first symbol position. Function code 1 in first symbol character position. Function code 1 in second symbol character position.
  • Page 200 Data packet containing the data following an escape mechanism character. The data packet supports the ECI protocol. GS1-128 emulation Note: UPC portion of composite is transmitted using UPC rules. Data packet is a GS1-128 symbol (i.e., data is preceded with ]JC1).
  • Page 201 ECI escape sequences cannot be transmitted. The bar code contains a GS1-128 symbol, and the first codeword is 903-907, 912, 914, 915. The bar code contains a GS1-128 symbol, and the first codeword is in the range 908-909.
  • Page 202 Model 1 symbol. Model 2 / MicroQR symbol, ECI protocol not implemented. Model 2 symbol, ECI protocol implemented. Model 2 symbol, ECI protocol not implemented, FNC1 implied in first position. Model 2 symbol, ECI protocol implemented, FNC1 implied in first position.

  • Page 203: Gs1-128 (Formerly Ucc/Ean-128

    GS1-128 is a convention for printing data fields with standard Code 128 bar code symbols. GS1-128 symbols are distinguished by a leading FNC 1 character as the first or second character in the symbol. Other FNC 1 characters are used to delineate fields.

  • Page 204: Setting Prefixes And Suffixes

    D - 12 CS4070 Scanner Product Reference Guide Setting Prefixes and Suffixes To append a prefix and suffixes to the decode data: Set the Scan Data Transmission Format (parameter 0xE2) to the desired option. Enter the required value(s) for Prefix (0x69), Suffix1 (0x68) or Suffix2 (0x6A) using the hex values for the...
  • Page 205 Programming Reference D - 13 Character Equivalents (Continued) Table D-6 Full ASCII Code 39 Scan Value Hex Value Keystroke Encode Char. 1025 CTRL Y 1026 CTRL Z 1027 CTRL [ 1028 CTRL \ 1029 CTRL ] 1030 CTRL 6 1031 CTRL - 1032 Space...
  • Page 206 D - 14 CS4070 Scanner Product Reference Guide Character Equivalents (Continued) Table D-6 Full ASCII Code 39 Scan Value Hex Value Keystroke Encode Char. 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067 1068 1069...
  • Page 207 Programming Reference D - 15 Character Equivalents (Continued) Table D-6 Full ASCII Code 39 Scan Value Hex Value Keystroke Encode Char. 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 ‘ 1097 1098 1099 1100 1101 1102 1103 1104 1105 1106 1107...
  • Page 208 D - 16 CS4070 Scanner Product Reference Guide Character Equivalents (Continued) Table D-6 Full ASCII Code 39 Scan Value Hex Value Keystroke Encode Char. 1118 1119 1120 1121 1122 1123 1124 1125 1126 1127 Undefined Values from 1128 through 1255 may also be set.

  • Page 209: Appendix E Sample Bar Codes

    APPENDIX E SAMPLE BAR CODES UPC-A 12345 67890 UPC-E 123456...

  • Page 210: Upc-E1

    E - 2 CS4070 Scanner Product Reference Guide UPC-E1 NOTE To enable this symbology in order to scan the sample, see Enable/Disable UPC-E1 on page 4-9. 123456 EAN-13 3 456789 012340 EAN-8 1234 5670 Code 39 123ABC...

  • Page 211: Trioptic Code 39

    Sample Bar Codes E - 3 Trioptic Code 39 NOTE To enable this symbology in order to scan the sample, see Enable/Disable Trioptic Code 39 on page 4-31. 456123 Code 93 NOTE To enable this symbology in order to scan the sample, see Enable/Disable Code 93 on page 4-37.

  • Page 212: Codabar

    E - 4 CS4070 Scanner Product Reference Guide Codabar NOTE To enable this symbology in order to scan the sample, see Enable/Disable Codabar on page 4-50. A1234567890A NOTE To enable this symbology in order to scan the sample, see Enable/Disable MSI on page 4-54.

  • Page 213: Gs1 Databar-14

    Sample Bar Codes E - 5 GS1 DataBar-14 NOTE DataBar-14 must be enabled to read the bar code below (see GS1 DataBar on page 12-72). 7612341562341 PDF417 Data Matrix Maxicode...

  • Page 214: Qr Code

    E - 6 CS4070 Scanner Product Reference Guide QR Code Han Xin US Postnet UK Postal...

  • Page 215: Appendix F: Numeric Bar Codes

    APPENDIX F NUMERIC BAR CODES Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s).
  • Page 216 F - 2 CS4070 Scanner Product Reference Guide Numeric Bar Codes (continued)

  • Page 217: Cancel

    Numeric Bar Codes F - 3 Cancel To correct an error or change a selection, scan the bar code below. Cancel...
  • Page 218 F - 4 CS4070 Scanner Product Reference Guide...

  • Page 219: Appendix G Ascii Character Sets

    APPENDIX G ASCII CHARACTER SETS ASCII Value Table Table G-1 Full ASCII Code 39 ASCII Value Keystroke Encode Char 1000 CTRL 2 1001 CTRL A 1002 CTRL B 1003 CTRL C 1004 CTRL D 1005 CTRL E 1006 CTRL F 1007 CTRL G 1008...
  • Page 220 G - 2 CS4070 Scanner Product Reference Guide ASCII Value Table (Continued) Table G-1 Full ASCII Code 39 ASCII Value Keystroke Encode Char 1016 CTRL P 1017 CTRL Q 1018 CTRL R 1019 CTRL S 1020 CTRL T 1021 CTRL U...
  • Page 221 ASCII Character Sets G - 3 ASCII Value Table (Continued) Table G-1 Full ASCII Code 39 ASCII Value Keystroke Encode Char 1045 1046 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 >...
  • Page 222 G - 4 CS4070 Scanner Product Reference Guide ASCII Value Table (Continued) Table G-1 Full ASCII Code 39 ASCII Value Keystroke Encode Char 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090...
  • Page 223 ASCII Character Sets G - 5 ASCII Value Table (Continued) Table G-1 Full ASCII Code 39 ASCII Value Keystroke Encode Char 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124...
  • Page 224 G - 6 CS4070 Scanner Product Reference Guide ALT Key Standard Default Tables Table G-2 ALT Keys Keystroke 2064 ALT 2 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E 2070 ALT F 2071...
  • Page 225 ASCII Character Sets G - 7 USB GUI Key Character Set Table G-3 GUI Key Keystroke 3000 Right Control Key 3048 GUI 0 3049 GUI 1 3050 GUI 2 3051 GUI 3 3052 GUI 4 3053 GUI 5 3054 GUI 6 3055 GUI 7 3056...
  • Page 226 G - 8 CS4070 Scanner Product Reference Guide USB GUI Key Character Set (Continued) Table G-3 GUI Key Keystroke 3082 GUI R 3083 GUI S 3084 GUI T 3085 GUI U 3086 GUI V 3087 GUI W 3088 GUI X...
  • Page 227 ASCII Character Sets G - 9 PF Key Standard Default Table Table G-4 PF Keys Keystroke 4001 PF 1 4002 PF 2 4003 PF 3 4004 PF 4 4005 PF 5 4006 PF 6 4007 PF 7 4008 PF 8 4009 PF 9 4010...
  • Page 228 G - 10 CS4070 Scanner Product Reference Guide F key Standard Default Table Table G-5 F Keys Keystroke 5001 5002 5003 5004 5005 5006 5007 5008 5009 5010 F 10 5011 F 11 5012 F 12 5013 F 13 5014...
  • Page 229 ASCII Character Sets G - 11 Numeric Key Standard Default Table Table G-6 Numeric Keypad Keystroke 6042 6043 6044 Undefined 6045 6046 6047 6048 6049 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock...
  • Page 230 G - 12 CS4070 Scanner Product Reference Guide Extended Keypad Standard Default Table Table G-7 Extended Keypad Keystroke 7001 Break 7002 Delete 7003 Pg Up 7004 7005 Pg Dn 7006 Pause 7007 Scroll Lock 7008 Backspace 7009 7010 Print Screen...
  • Page 231 INDEX Numerics 123Scan2 ....... . . 5-1 bar codes 2D bar codes Australia post .
  • Page 232 Index - 2 CS4070 Scanner Product Reference Guide composite CC-C ......4-67 mute beeper ......3-15 composite TLC-39 .
  • Page 233 SPP profile ......3-8 Symbol ....... . D-4 SSI profile .
  • Page 234 Index - 4 CS4070 Scanner Product Reference Guide cradles eight-slot ....... B-5 maintenance .
  • Page 235 ........xvi Symbol Technologies support ....xvi symbology default parameters .
  • Page 236 Index - 6 CS4070 Scanner Product Reference Guide...
