  • Page 1 Symbol LS4208 Quick Reference Guide...

  • Page 2: Warranty

    Motorola products. MOTOROLA, the Stylized M Logo and Symbol and the Symbol logo are registered trademarks of Motorola, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.

  • Page 3: Inserting And Removing The Interface Cable

    Quick Reference Guide Introduction The Symbol LS4208 scanner combines excellent scanning performance and advanced ergonomics to provide the best value in a lightweight laser scanner. Whether used as a hand-held scanner or in hands-free mode in a stand, the scanner ensures comfort and ease of use for extended periods of time.

  • Page 4: Beeper Definitions

    Standard Use Low/medium/high beep Power up. Short high beep A bar code symbol was decoded (if decode beeper is enabled). 4 long low beeps A transmission error was detected in a scanned symbol. The data is ignored. This occurs if a unit is not properly configured.

  • Page 5: Led Definitions

    Quick Reference Guide Beeper Sequence Indication Hi/lo/hi/lo beep Successful program exit with change in the parameter setting. Low/hi/low/hi beep Out of host parameter storage space. Scan Set Defaults on page Code 39 Buffering Hi/lo beep New Code 39 data was entered into the buffer. 3 Beeps - long high beep Code 39 buffer is full.

  • Page 6: Troubleshooting

    Refer to the Symbol LS4208 Product code type. Reference Guide, p/n 72E-69413-xx, for more information. Bar code symbol is Check the symbol to ensure it is not defaced. unreadable. Try scanning test symbols of the same bar code type. Distance between...

  • Page 7: Programming Bar Codes

    Quick Reference Guide Programming Bar Codes Following are some frequently used programming bar codes. For additional host types, refer to the Symbol LS4208 Product NOTE Reference Guide, p/n 72E-69413-xx, available on the LS4208 CD, or on the Symbol website: http://www.motorola.com/enterprisemobility/manuals.

  • Page 8: Keyboard Wedge Host Type

    See page 10 to select the IBM hand-held host type. Refer to the Symbol LS4208 Product Reference Guide, p/n 72E-69413-xx, for additional USB host types. If a Keyboard Wedge, RS-232, Wand Emulation, Scanner Emulation, or IBM 46XX is used, the appropriate host type must be scanned.

  • Page 9: Rs-232 Host Types

    Quick Reference Guide Country Keyboard Types (Country Codes) SPANISH Windows ITALIAN Windows SWEDISH Windows UK ENGLISH Windows JAPANESE Windows PORTUGUESE-BRAZILIAN Windows RS-232 Host Types STANDARD RS-232 ICL RS-232...
  • Page 10 Symbol LS4208 RS-232 Host Types NIXDORF RS-232 MODE A NIXDORF RS-232 MODE B FUJITSU RS-232 OPOS/JPOS USB Host Types HID KEYBOARD EMULATION IBM HAND-HELD USB IBM 46XX Host Types PORT 5B PORT 9B...
  • Page 11 To append a carriage return/line feed to all transmitted data, scan the following bar codes in the order shown. To cancel this operation, the SET DEFAULTS bar code on page 7, or refer to the Symbol LS4208 Product Reference Guide. SCAN OPTIONS <DATA><SUFFIX>...

  • Page 12: Ergonomic Recommendations

    Regulatory Information Symbol Technologies, Inc. the Enterprise Mobility business of Motorola, Inc. (“Motorola”). All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment.

  • Page 13: Marking And European Economic Area (Eea)

    Marking and European Economic Area (EEA) Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC. Declaration of Conformities may be obtained from http://www.motorola.com/enterprisemobility/doc/.

  • Page 14: Laser Devices

    Symbol LS4208 ENGLISH HEBREW CLASS 1 CLASS 1 LASER PRODUCT CLASS 2 LASER LIGHT DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT DANISH / DANSK ITALIAN / ITALIANO KLASSE 1 KLASSE 1 LASERPRODUKT CLASSE 1 PRODOTTO AL LASER DI CLASSE 1...

  • Page 15: Waste Electrical And Electronic Equipment (Weee)

    Quick Reference Guide Waste Electrical and Electronic Equipment (WEEE) English: For EU Customers: All products at the end of their life must be returned to Motorola for recycling. For information on how to return product, please go to: http://www.motorola.com/recycling/weee. Bulgarish: За клиенти от ЕС: След края на полезния им живот всички продукти трябва да се връщат на Motorola за...

  • Page 16: Service Information

    1-800-927-9626 http://www.motorola.com/enterprisemobility MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their registered owners. © Motorola, Inc. 2008...
